2AFCUHNY500R3Bluetooth Remote Control

Remote controller specification: Power: DC3V 2 AAA batteries) Temperature setting range: 67‐105°F or 19‐41 °C Time setting range: 1‐12H Default parameter: temperature 74Ｆ，8Ｈ Press button will illume the backlight, and it will light for 5S, if no operation in 60S, will go to sleep mode automatically, LCD screen no display to save energy. When install the battery, the LCD screen shows 74F and illume the backlight, and light for 3 seconds, then go to sleep mode. Wake up the remote controller by press any button, will check the battery’s voltage in each awakening.  If battery voltage <2.5V，show Lo, then go to sleep mode.  If battery voltage >2.5V, no repair at the first time, show “‐” “‐ ‐” “‐ ‐ ‐” “‐”“‐ ‐” “‐ ‐ ‐”“‐” Display the three horizontal lines animation repeatedly, and search the unit, when find out the unit to be matched, display “YES” until press or , confirm the pairing, display “YES”, and then show temperature after 2 seconds. If battery voltage >2.5V, automatically search unit, display the temperature set at the last time, when find the unit paired will connect it automatically, and synchronous setting information to the unit, display the unit’s setting temperature. If the battery voltage >2.5,<2.7V, display same with >2.5V condition, but will show ”Lo” for 0.5 second in each 3 seconds,( reminder the consumer to change battery, but the current battery could be used for a certain time.) Button explaination: 1.Press , could trigger between ON and OFF, the sleep curve will be re‐counted after ON, if need to send the setting information on remote controller, still need press . 2.Press : Flash, and display the original setting time( default 8 hours)  Adjust the timer via press “”“” in 5 second, display the new setting.  Unless press , the new setting will not be saved in unit, only save in remote controller, if not press any other button, it will show temperature automatically after 5S.  Press , display new set time, show temperature after 3 seconds.  If no operation in 5S on the timing screen, then will change to temperature automatically. 3.Press , trigger between °F/°C . 4.Press :  temperature/time “+”, the increment is 1°F or 1°C or 1H. When the temperature or time is the max value, then in vain.  Press and not release, the value will progressive increase. 5.Press  temperature/time“‐”, the increment is 1°F or 1°C or 1H. When the temperature or time is the minimum value, then in vain.  Press and not release, the value will progressive decrease. 6.Press , send the setting in remote controller to unit.  When unit on standby status, press ENTER, only save setting, keep on OFF statue, if turn on the unit, still need press .  If the unit is running, the unit will run at the new setting. No need to press at this situation( for the system is running). The temperature will increase or decrease the difference exactly, if the temperature reach to 66 °F, consumer change to 69°F, then the difference is 1°F, the unit will try to low the setting temperature to 65°F( difference is 1°F), the temperature will go back to 69°F in 20 minutes before shut off. The time will be added up, mean re‐timing, for example, if set timing is 8 hours, then run for more 8 hours. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐‐ Reorient or relocate the receiving antenna. ‐‐ Increase the separation between the equipment and receiver. ‐‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐‐ Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be use d in portable exposure condition without restriction.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Eagle Electric (Shenzhen) Co., LTD 2015-07-31 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We,Eagle Electric (Shenzhen) Co., LTD hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Bluetooth Remote Control Model Number: HNY500R3 FCC ID: 2AFCUHNY500R3 Sincerely, Rongjie Wen /Engineering manager E-mail: [email protected] Phone: 0755-27642811-228 Fax: 0755-27642931 Address NO.4, Industry Area, Shiyan Town Baoan District Shenzhen China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Eagle Electric (Shenzhen) Co., LTD 2015-07-31 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AFCUHNY500R3 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Rongjie Wen /Engineering manager E-mail: [email protected] Phone: 0755-27642811-228 Fax: 0755-27642931 Address NO.4, Industry Area, Shiyan Town Baoan District Shenzhen China

FCC ID: Model:HNY500 Made in China/Fabriqués en Chine This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Label Location Proposed Label Location on EUT

Module Antenna

FCC ID: 2AFCUHNY500R3 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculated. Maximum measured transmitter power: Transmit Frequency (GHz) Mode Measured Power (dBm) Tune-up power (dBm) Max tune-up power(dBm) Result calculation 1-g SAR 2.402 GFSK -3.71 -4.5±1 -3.5 0.1385 3.00 2.441 GFSK -4.65 -4.5±1 -3.5 0.1395 3.00 2.480 GFSK -5.34 -4.5±1 -3.5 0.1407 3.00 Conclusion: For the max result 0.1407≤ 3.0 for 1-g SAR extremity SAR, No SAR is required. Sincerely, Signature Company Name: SHENZHEN EMTEK CO., LTD. Address: Bldg 69, Majialong Industry Zone, NanshanDistrict, Shenzhen, China. David Lee/ Manager

TRF No.: FCC 15.247 Page 1 of 40 Report No.: ES150713153E Ver.1.0 Access to the World FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT For Bluetooth Remote Control MODEL No.: HNY500R3 FCC ID: 2AFCUHNY500R3 Trademark: Healthometer NuYu REPORT NO.: ES150713153E ISSUE DATE: July 31, 2015 Prepared for Eagle Electric (Shenzhen) Co., LTD NO.4, Industry Area, Shiyan Town, Baoan District, Shenzhen, China Prepared by SHENZHEN EMTEK CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.: FCC 15.247 Page 2 of 40 Report No.: ES150713153E Ver.1.0 Access to the World Table of Contents 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION .................................................................................................................... 4 3 SUMMARY OF TEST RESULT ........................................................................................................................... 6 4 TEST METHODOLOGY ...................................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................................... 7 4.2 MEASUREMENT EQUIPMENT USED ..................................................................................................... 7 4.3 DESCRIPTION OF TEST MODES ............................................................................................................. 8 5 FACILITIES AND ACCREDITATIONS ............................................................................................................. 9 5.1 FACILITIES ................................................................................................................................................. 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS .............................................................................. 9 6 TEST SYSTEM UNCERTAINTY ...................................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST ......................................................................................................... 11 7.1 RADIO FREQUENCY TEST SETUP 1 ..................................................................................................... 11 7.2 RADIO FREQUENCY TEST SETUP 2 ..................................................................................................... 11 7.3 CONDUCTED EMISSION TEST SETUP ................................................................................................. 12 7.4 SUPPORT EQUIPMENT ........................................................................................................................... 12 8 TEST REQUIREMENTS .................................................................................................................................... 13 8.1 DTS (6DB) BANDWIDTH ........................................................................................................................ 13 8.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER ............................................................................ 16 8.3 MAXIMUM POWER SPECTRAL DENSITY .......................................................................................... 19 8.4 UNWANTED EMISSIONS IN NON-RESTRICTED FREQUENCY BANDS ......................................... 22 8.5 RADIATED SPURIOUS EMISSION ......................................................................................................... 27 8.6 CONDUCTED EMISSION TEST .............................................................................................................. 39 8.7 ANTENNA APPLICATION ....................................................................................................................... 40 TRF No.: FCC 15.247 Page 3 of 40 Report No.: ES150713153E Ver.1.0 Access to the World 1 TEST RESULT CERTIFICATION Applicant: Eagle Electric (Shenzhen) Co., LTD Manufacturer: Eagle Electric (Shenzhen) Co., LTD EUT Description: Bluetooth Remote Control Model Number: HNY500R3 File Number: ES150713153E Date of Test: June 30, 2015 to July 31, 2015 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J:2014 FCC 47 CFR Part 15, Subpart C:2014 PASS The above equipment was tested by SHENZHEN EMTEK CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report Date of Test : June 30, 2015 to July 31, 2015 Prepared by : Jie Yang/Editor Reviewer : Jack Li /Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF No.: FCC 15.247 Page 4 of 40 Report No.: ES150713153E Ver.1.0 Access to the World 2 EUT TECHNICAL DESCRIPTION Characteristics Description Device Type: Portable device Data Rate: 1Mbps Modulation: GFSK Bluetooth Version: Bluetooth 4.0 for BLE Operating Frequency Range(s): 2402MHz ~ 2480MHz; Number of Channels: 40 Channels Transmit Power Max: -3.71dBm Antenna Type: PCB antenna Antenna Gain: 1dBi ; Power supply: DC supply: DC 3V from AAA battery Adapter supply: Note: for more details, please refer to the User’s manual of the EUT. TRF No.: FCC 15.247 Page 5 of 40 Report No.: ES150713153E Ver.1.0 Access to the World Modified Information Version. Summary Date of Rev. Report No. Ver.1.0 Original Report 2015-07-31 ES150713153E TRF No.: FCC 15.247 Page 6 of 40 Report No.: ES150713153E Ver.1.0 Access to the World 3 SUMMARY OF TEST RESULT FCC Pa…

Text truncated - open the document above for the full version.

Radiated Emission Test
