2AFHPSK-M4AUKEY

- 01 -- 02 -- 03 -- 04 -- 05 - Package Content ● 1x Aukey SK-M4 Bluetooth Speaker ● 1 x USB Charging Cable ● 1 x 3.5mm Audio Cable ● 1 x Camping Snap Hook ● 1 x User Manual Specification Bluetooth Version Supported Bluetooth Profile Product Weight Product Dimension Play Time Charging Time Operation Range Speaker Output Power AUX Power Input Battery Type V2.1+EDR A2DP 6.6 oz / 187g 4.3x 3.74 x 2.2in / 11 x9.5x 5.5cm (L x B x H) 6 hrs 3 hrs Up to 10m / 33ft 3W 3.5mm Audio-in Jack DC 5V Built-in Lithium Battery (700mAh) Product Overview Charging The speaker is partially charged at the factory. Please make sure that you fully charge it before using it for the first time. To charge the unit, simply connect the speaker to any active USB port or adapter using the USB charging cable. The speaker can be fully charged in around 3 hours. When fully charged, the LED indicator turns off. * If the battery is running low, there will be a voice prompt and the red LED will be flashing , then the speaker turns off automatically, please recharge the battery according to the instructions above. Now that your device is charged, it is ready to go! Bluetooth Pairing (for mobile phones, tablets, laptops) 1. Bring the SK-M4 Bluetooth speaker to within 3ft (1m) of your Bluetooth device. 2. Press and hold the multi-function button for 3 seconds then you will hear a crisp sound. The speaker will automatically go into pairing mode and the white LED should be flashing slowly. 3. Activate the Bluetooth function on your device and search for the speaker. 4. Once the speaker has been located by your Bluetooth device you should see "Aukey SK-M4", simply select the device name to connect. If your device is asking for a PIN or pass code, please enter "0000". 5. When devices are successfully paired, you will hear a short beep and the solid white LED light will stay on. On some devices, you might have to select “Use as Audio Device (stereo)” or similar on the device’s Bluetooth menu. Note: 1. If pairing is not completed within 2 minutes, please turn off the speaker and try again. 2. When turning on the Bluetooth function of the device last connected, the speaker will automatically connect to it. 3. If using with computer, please make sure you have downloaded the latest Bluetooth driver for your operating system. 4. Maximum operating range for the SK-M4 speaker is 33ft (10m). If you move out of range, the speaker will lose connection. You will need to move back to within range and reconnect to your Bluetooth audio device. Playing Audio via Auxiliary (AUX) Turn on the SK-M4 Bluetooth speaker and connect it with your PC or notebook via the 3.5mm audio jack by using the 3.5mm audio cable attached. Note: 1. The Bluetooth connection on your speaker will be disconnected when there is an audio cable attached to Aux-in as Aux-in mode has higher priority. 2. When playing audio through Aux, you can adjust the volume from the speaker, but adjust the previous/next track from your device only. 3. For some computers, you may need to visit the audio control panel to manually set the speaker as the default audio device. Functions Introduction Turning the speaker on / off Press and Hold the multi-function button for 3 seconds to turn the speaker on or off. Adjust the Volume Press and hold the volume +/- button to increase or decrease the volume. Music Control Short Press the +/- button to move to previous/next track. Press the multi-function button once to pause, and press it again to resume. Answering a call Press the multi-function button once to answer a call, or answer directly from your phone. Ending a call During a call, press the multi-function button once will end the call. You can also end the call directly from your phone. Rejecting an incoming call When a call is incoming, hold and press the multi-function button for 3 seconds will reject the incoming call. Remote taking Photos Download the APP: Aukey Play from Aukey official Website: www.aukey.com and install it on your phone, then you can take photos by double pressing the multi-function button from the speaker. Note: The APP can only work with Android Smartphones. LED Indicator Instruction Status of the speaker Pairing mode Connected to a Bluetooth device Connected to a Aux-in device Low Battery Charging Fully charged LED Indicator The white LED flashes slowly Solid white LED The white LED flashes slowly The red LED flashes Solid red LED The red LED goes off FAQ and Trouble Shooting Q: Why isn’t my speaker pairing with my iPad/iPhone? A: Please make sure that your SK-M4 speaker is powered on and in pairing mode (white light flashes slowly). Also, check to see that the Bluetooth function of your iPad/iPhone is turned on. Q: Why can't my speaker play audio via Aux? A: Please try connecting and disconnecting the 3.5mm audio cable a few times. Make sure the speaker is turned on. Sometimes, computer system may not recognize the device at first. For some computers, you may need to visit the audio control panel to manually set the speaker as the default audio device. Q: Can I use the speaker while it is charging? A: Yes, definitely! But in order to ensure the long-term performance of the battery, we recommend that you try to avoid using the speaker while charging. Q: The music sometimes cuts off while playing. A: The operation range of the speaker may be influenced by obstructions, such as walls, pillars, etc. To ensure a stable connection, we recommend avoiding such obstructions whenever possible and/or shortening the distance during use. Q: I turn on the speaker, but I cannot see any LED lights coming on? A: Please make sure that the unit is charged. If it is fully charged and still nothing happens or if you are not able to charge the unit, please contact our customer support for warranty cover. Care and Maintenance 1. Keep the speaker away from heat and humidity. 2. Do not put the product under direct sunlight or hot areas. High temperatures will shorten lifespan of the speaker, bat…

Text truncated - open the document above for the full version.

Shenzhen Aukey E Business Co., Ltd. Date: 2015-09-22 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2AFHPSK-M4 To Whom It May Concern: This letter is to ascertain that Shenzhen Aukey E Business Co., Ltd.__ Product AUKEY has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, (signture) Lina Shen Manager Tel: 86-755 33622851 Fax: 86-755-33622854 E-mail: [email protected]

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Shenzhen Aukey E Business Co., Ltd. 2015-09-22 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ____ Shenzhen Aukey E Business Co., Ltd.___ __hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product description: AUKEY model name: SK-M4 FCC ID: 2AFHPSK-M4 Sincerely, (signture) Lina Shen Manager Tel: 86-755 33622851 Fax: 86-755-33622854 E-mail: [email protected] Room 102 Bld P09, Huanan International Printing Paper Packing Logistics Zone, No.1 Huanan Rd, Pinghu Town, Longgang District, Shenzhen City, Guangdong Province 518000, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Shenzhen Aukey E Business Co., Ltd. 2015-09-22 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AFHPSK-M4 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Operational Description - Schematics The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, (signture) Lina Shen Manager Tel: 86-755 33622851 Fax: 86-755-33622854 E-mail: [email protected]

Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1506121F-1 FCC ID: 2AFHPSK-M4 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1506121F-1 FCC ID: 2AFHPSK-M4 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1506121F-1 FCC ID: 2AFHPSK-M4

Model: SK-M4 INPUT: DC 5V 700mA FCC ID: 2AFHPSK-M4 www.aukey.com Made in China Model: SK-M4 INPUT: DC 5V 700mA FCC ID: 2AFHPSK-M4 www.aukey.com Made in China

Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1506121F-1 FCC ID: 2AFHPSK-M4 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1506121F-1 FCC ID: 2AFHPSK-M4 Dongguan Nore Testing Center Co., Ltd. BT Chip BT Antenna Report No.: NTC1506121F-1 FCC ID: 2AFHPSK-M4

Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1506121F-2 FCC ID: 2AFHPSK-M4 RF EXPOSURE EVALUATION EUT Specification EUT AUKEY Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others(Bluetooth: 2.402GHz ~ 2.480GHz) Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 2.67dBm(1.85mW) Antenna gain 0dBi (declared by manufacturer) Evaluation applied MPE Evaluation SAR Evaluation Standard Requirement Portable Device According to §15.247(i) and §1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See KDB 447498 D01 General RF Exposure Guidance v05, section 4.3.1. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, 16 where ·f(GHz) is the RF channel transmit frequency in GHz ·Power and distance are rounded to the nearest mW and mm before calculation17 ·The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1506121F-2 FCC ID: 2AFHPSK-M4 Measurement Result Channel Channel Frequency (MHz) Max Output power (dBm) ToleranceMax Tune-UP power (mW) Calcul ation Value (Note 1) Threshold Value GFSK Low 2402.00 2.66 ±0.2 1.93 0.60 3.0 Middle 2441.00 2.39 ±0.2 1.82 0.57 3.0 High 2480.00 2.29 ±0.2 1.77 0.56 3.0 π/4-DQPSK Low 2402.00 2.67 ±0.2 1.94 0.60 3.0 Middle 2441.00 2.54 ±0.2 1.88 0.59 3.0 High 2480.00 2.32 ±0.2 1.79 0.56 3.0 8DPSK Low 2402.00 2.67 ±0.2 1.94 0.60 3.0 Middle 2441.00 2.40 ±0.2 1.82 0.57 3.0 High 2480.00 2.29 ±0.2 1.77 0.56 3.0 Note 1: Calculation Value =[(max. power of channel, mW)/(min. test separation distance, mm)] ·[√f(GHz)]. Fox example: 1.93/5*√2.402=0.60 ≤ 3.0 According to KDB447498 D01 v05, threshold at which no SAR required is ≤3.0 for 1-g SAR, separation distance is 5mm, and no simultaneous SAR measurement is required.

Dongguan Nore Testing Center Co., Ltd. Conducted Emission Report No.: NTC1506121F-1 FCC ID: 2AFHPSK-M4 Dongguan Nore Testing Center Co., Ltd. Radiated Emission Report No.: NTC1506121F-1 FCC ID: 2AFHPSK-M4
