2AFJZ-HOM07197436 RAPiD Keypad Vault

1. Power supply mode Powered by 2 AA batteries After installing the battery, the backlight lights up in red, and the red light in the box lights up at the same time. If there is no operation within 10 seconds, the two lights will be off at the same time. After the light is off, all operations (including entering the password and changing the password/RFID) are suspended, and need to be restarted after activation. After the light is off, pressing any button will light up the backlight and the red light in the cabinet again. 2. set password Step 1: Use the emergency key to open the box Step 2: Press the reset button once, the backlight flashes red once (0.5 seconds), the buzzer beeps once (0.5 seconds), and the internal lighting red light flashes (until the registration status is exited). (Red light for non-low voltage, yellow light for low voltage) Step 3: Enter the password (4-6 digits) within 6 seconds and press the reset button once: If the password is matched correctly, the backlight is turned off twice (0.5 seconds each time, 0.5 seconds interval), and 2 beeps (0.5 seconds each time, 0.5 seconds interval), the password setting is successful. (Red light for non-low voltage, yellow light for low voltage) If the password exceeds 6 digits or is less than 4 digits, 3 buzzers (0.05 seconds each time, 0.05 seconds interval) will beep quickly, and the password setting fails, restart from step 2. It enters sleep without any action within 6 seconds. Note: Registering a new password will overwrite the old password. 3. Set up RFID Step 1: Use the emergency key to open the box Step 2: Press the reset button once, the backlight flashes red once (0.5 seconds), and the buzzer beeps once (0.5 seconds); the internal lighting red light flashes (until the registration status is exited). (Red light for non-low voltage, yellow light for low voltage) Step 3: Register an RFID within 6 seconds: The backlight is turned off twice (0.5 seconds each time, 0.5 seconds interval), 2 buzzers (0.5 seconds each time, 0.5 seconds interval), RFID registration is successful. (Red light for non-low voltage, yellow light for low voltage) 3 beeps (0.05 seconds each time, 0.05 seconds interval), RFID registration fails (including configured and configured full), restart from step 2. It enters sleep without any action within 6 seconds. Note: Each device can store 5 groups of RFID. After the 5 groups have been stored, the 5 groups of RFID that have been registered before need to be cleared. three. Reset RFID Clear RFID operation: press the reset button for 3 seconds (without any feedback in the first second), the backlight will be red for 6 seconds, and the internal lighting will flash red (until the registration status is exited) (red light for non-low voltage, yellow light for low voltage) ). Within this time range, press the reset button once again, and the backlight will turn off 3 times (lights off for 0.25 seconds each time, with an interval of 0.25 seconds). Beep once for 2 seconds. (Red light for non-low voltage, yellow light for low voltage) 4. Password out of the box Press any button, the backlight will light up in red. (The first number of keystrokes is counted as the first password) (Red light for non-low voltage, yellow light for low voltage) Enter the password correctly, the backlight is off once, the duration is 0.5 seconds, the buzzer beeps once, the duration is 0.5 seconds, and the door is opened. (Red light for non-low voltage, yellow light for low voltage) If the password is entered incorrectly, 3 beeps (0.05 seconds each time, 0.05 seconds interval). The password is entered incorrectly for 5 consecutive times, the backlight flashes red for 2 minutes (on 0.5 seconds each time, 0.5 seconds interval), beeps for 2 minutes (0.5 seconds each time, 0.5 seconds interval), and the keys are locked for 2 minutes. The alarm can be cancelled by removing the battery. After the password is entered, no matter whether it is correct or incorrect, any keystroke will be invalid within 1.5 seconds. 5. RFID unpacking Put the RFID card into the detection area The RFID reading is correct, the backlight is turned off once for 0.5 seconds (red light for non-low voltage, yellow light for low voltage), and the box door is opened. RFID reading error, 3 beeps (each 0.05 seconds, interval 0.05 seconds). 6. Low voltage alarm Press any button or read the RFID. If the actual voltage is detected to be too low, the backlight will turn on yellow (instead of the red light), prompting the consumer to replace the battery. 4.8V lights up yellow, 4.5V stops working. 7. Mute function Press and hold the number 1 button for 3 seconds, the lights around the button will turn off once, count for 1 second, and enter the silent mode, and there will be no buzzer for any subsequent operations. Long press the number 1 button for 3 seconds, the lights around the button will turn off once, count for 1 second, beep once, count for 1 second, and exit the silent mode. In the registered state, the mute function is invalid. (Red light for non-low voltage, yellow light for low voltage) FCC Warning Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the…

Text truncated - open the document above for the full version.

< Hornady Manufacturing Company > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Date: Dec. 01, 2021 Subject; Request for Long Term Confidentiality FCC ID: 2AFJZ-HOM071 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Matthew Mack Title: Manager

Hornady Manufacturing Company Letter of Authorization Company: Hornady Manufacturing Company Address: 3625 Old Potash Hwy, Grand Island, Nebraska, United States Product Name: 97436 RAPiD Keypad Vault Trade Mark: Hornady Model Name: 97436 FCC Identifier: 2AFJZ-HOM071 We authorize MiCOM LabsInc, 575 Boulder Court, Pleasanton, California94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM LabsInc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Matthew Mack Date: Dec. 01, 2021 Title: Manager Signature of applicant:

Model: 97436 Model: 97436 Model: 97436 Model: 97436

FCC ID LABEL: Label Location: FCC ID: 2AFJZ-HOM071 Product Name: 97436 RAPiD Keypad Vault Model Name: 97436 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Long: 3cm Width: 2cm

Model: 97436 Model: 97436 Model: 97436 Model: 97436 Model: 97436 Model: 97436 Model: 97436 Model: 97436 Coil Antenna

Page 1 of 20 Report No.: UNIA21102519ER-63 FCC RADIO TEST REPORT FCC ID: 2AFJZ-HOM071 Sample： 97436 RAPiD Keypad Vault Trade Name： Hornady Main Model： 97436 Additional Model： N/A Report No.： UNIA21102519ER-63 Prepared for Hornady Manufacturing Company 3625 Old Potash Hwy, Grand Island, Nebraska, United States Prepared by Shenzhen United Testing Technology Co., Ltd. 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China Page 2 of 20 Report No.: UNIA21102519ER-63 TEST RESULT CERTIFICATION Applicant .............................. : Hornady Manufacturing Company Address ................................. : 3625 Old Potash Hwy, Grand Island, Nebraska, United States Manufacturer ........................ : shenzhenZaifengda TecHnology co Ltd Address ................................. : Fu Di Gang 2nd Industrial estate 2-1, PingDi Street, LongGang District, Shenzhen, China Product description Product ....................................... : 97436 RAPiD Keypad Vault Trade Name ........................... : Hornady Model Name .......................... : 97436 Test Methods ........................ : FCC Rules and Regulations Part 15 Subpart C Section 15.209 ANSI C63.10: 2013 This device described above has been tested by Shenzhen United Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of UNI, this document may be altered or revised by Shenzhen United Testing Technology Co., Ltd., personnel only, and shall be noted in the revision of the document. Remark: This test report replaces the test report No. UNIA21102519ER-61 and the test report No. UNIA21102519ER-61 is invalid. Date of Test ........................................... : Date (s) of performance of tests ............. : Oct. 25, 2021 ~ Nov. 15, 2021 Date of Issue .......................................... : Dec. 01, 2021 Test Result.............................................. : Pass Prepared by: Kahn yang/Editor Reviewer: Sky dong/Supervisor Approved & Authorized Signer: Liuze/Manager Page 3 of 20 Report No.: UNIA21102519ER-63 Table of Contents Page 1 TEST SUMMARY 4 2 GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 CARRIER FREQUENCY OF CHANNELS 7 2.3 TEST MODE 7 2.4 TEST SETUP 7 2.5 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL 8 2.6 MEASUREMENT INSTRUMENTS LIST 9 3 CONDUCTED EMISSION 10 3.1 TEST LIMIT 10 3.2 TEST SETUP 10 3.3 TEST PROCEDURE 11 3.4 TEST RESULT 11 4 RADIATED EMISSION 12 4.1 TEST LIMIT 12 4.2 TEST SETUP 14 4.3 TEST PROCEDURE 15 4.4 TEST RESULT 15 5 ANTENNA REQUIREMENT 18 6 PHOTO OF TEST 19 6.1 RADIATED EMISSION 19 6.2 CONDUCTED EMISSION 20 Page 4 of 20 Report No.: UNIA21102519ER-63 1 TEST SUMMARY 1.1 TEST PROCEDURES AND RESULTS ITEM STANGARD RESULT CONDUCTED EMISSION FCC Part 15.207 N/A RADIATED EMISSION FCC Part 15.209 COMPLIANT ANTENNA REQUIREMENT FCC Part 15.203 COMPLIANT 1.2 TEST FACILITY Test Firm : Shenzhen United Testing Technology Co., Ltd. Address : 2F, Annex Bldg, Jiahuangyuan Tech Park, #365 Baotian 1 Rd, Tiegang Community, Xixiang Str, Bao'an District, Shenzhen, China The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19.The testing quality system of our laboratory meets with ISO/IEC-17025 requirements. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: A2LA Certificate Number: 4747.01 The EMC Laboratory has been accredited by A2LA, and in compliance with ISO/IEC 17025:2017 General Requirements for testing Laboratories. FCC Registration Number: 674885 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. IC Registration Number: 21947 The EMC Laboratory has been registered and fully described in a report filed with the (IC) Industry Canada. Page 5 of 20 Report No.: UNIA21102519ER-63 1.3 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. A. Conducted Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9KHz ~ 150KHz 2.96 150KHz ~ 30MHz 2.44 B. Radiated Measurement: Test Site Method Measurement Frequency Range U, (dB) NOTE UNI ANSI 9KHz ~ 30MHz 2.50 30MHz ~ 1000MHz 4.80 1000MHz ~ 6000MHz 4.13 Page 6 of 20 Report No.: UNIA21102519ER-63 2 GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product: 97436 RAPiD Keypad Vault Trade Name: Hornady Main Model: 97436 Additional Model: N/A Model Difference: N/A FCC ID: 2AFJZ-HOM071 Operation Frequency: 125KHz Number of Channels: 1CH Modulation Type: ASK Antenna Type: Coil Antenna Antenna Gain: 0dBi Battery: AA Battery*2 Adapter: N/A Power Source: DC 3V from battery Page 7 of 20 Report No.: UNIA21102519ER-63 2.2 CARRIER FREQUENCY OF CHANNELS Channel List Channel Frequency (KHz) Channel Frequency (KHz) Channel Frequency (KHz) Channel Frequency (KHz) 01 125 2.3 TEST MODE The EUT was programmed to be in transmitting mode. Channel List Test Channel Test Frequency (KHz) 01 125 2.4 TEST SETUP Operation of EUT during Radiation testing: EUT Page 8 of 20 Report No.: UNIA21102519ER-63 2.5 DESCRIPTION TEST PERIPHERAL AND EUT PERIPHERAL The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Item Equipment Mfr/Brand Model/Type No. Note E-1 97436 RAPiD Keypad Vault Hornady 97436 EUT Item Shielded Type Ferrite Core Length Note Note: 1. The support equipment was authorized by Declaration of Confirma…

Text truncated - open the document above for the full version.

Model: 97436 Radiated Emission test Model: 97436 Conducted Emission test N/A
