VP5001I Guía de referencia rápida Índice Características del equipo ........................................ 3 Antes de empezar .................................................... 5 Encendido/Apagado del teléfono ...........................5 Para encender el teléfono ..................................5 Para apagar el teléfono ......................................5 Desbloqueo de la pantalla ......................................5 Bloqueo de la pantalla ............................................7 Utilizando la pantalla táctil .....................................7 Barra de estado ......................................................8 Orientación de la pantalla.....................................10 Teclas y funciones .................................................10 Aplicaciones (Apps) y herramientas (Widgets) .....10 Conexión a Internet mediante una WLAN .............. 12 Conexión a Internet mediante banda ancha móvil . 13 Por su seguridad .................................................... 14 Características del equipo ① Conexión para auriculares MiniJack de 3,5 mm ② Cámara frontal ③ Auricular ④ Micro USB 2.0 HS ⑤ Botón de volumen ⑥ Botón de encendido ⑦ Cámara trasera ⑧ Altavoz  Instalación de la tarjeta SIM y tarjeta SD  Instalación de la batería  Fijación de la tapa trasera Antes de empezar  Encendido/Apagado del teléfono Para encender el teléfono 1. Pulse y mantenga presionado el botón de encendido momentáneamente. 2. Deslizando su dedo, desbloquee la pantalla. Para apagar el teléfono 1. Pulse y mantenga presionado el botón de encendido y seleccione la opción Apagar. 2. Seleccione OK y el teléfono se apagará después de algunos segundos.  Desbloqueo de la pantalla Cuando encienda su teléfono encontrará que su teléfono está bloqueado por defecto. Para desbloquear la pantalla: 1. Presione el botón de encendido para que la pantalla muestre la imagen. 2. Para desbloquear la pantalla, arrastre el anillo con un candado en su interior, hasta el borde del círculo (derecha). De estar bloqueado con un patrón de dibujo, dibuje el patrón ya establecido. De estar bloqueado con un PIN o clave secreta, introduzca el que corresponda.  Bloqueo de la pantalla Para bloquear la pantalla, presione el botón de encendido. También podrá configurar el teléfono para que se bloquee automáticamente después de un período de inactividad determinado. Seleccionar → Configuración (o Ajustes) → Pantalla → Suspender esta opción le permitirá configurar el tiempo de suspensión después de 15 o 30 segundos, 1, 2, 5, 10 o 30 minutos.  Utilizando la pantalla táctil Excepto el encendido/apagado y volumen, todas las funciones del teléfono se llevan a cabo mediante la pantalla táctil. Por lo tanto, es fundamental saber cómo se utiliza dicha pantalla táctil. Los siguientes movimientos con los dedos le permitirán entender con facilidad cómo se utiliza la pantalla táctil.  Seleccionar: para ejecutar, ingresar a un menú u opción de cualquier aplicación o herramienta que aparezca en la pantalla, selecciónelo con su dedo.  Doble Clic: con su dedo, seleccione el ítem dos veces.  Arrastrar: con su dedo, seleccione y mantenga presionado el ítem deseado y desplácelo sin dejar de hacer contacto con la pantalla.  Cambiar de pantallas: con su dedo, seleccione cualquier espacio abierto en la pantalla y deslizando su dedo vertical u horizontalmente podrá pasar de una pantalla a otra.  Pellizcar: para ampliar una pantalla coloque dos dedos sobre la pantalla y sepárelos; para disminuir una pantalla coloque dos dedos sobre la pantalla y únalos. Esta función también se puede utilizar en páginas electrónicas y varios tipos de archivos.  Pulsar y seleccionar: seleccione un ítem que aparezca en la lista de opciones disponibles.  Pulsar y mantener: durante unos segundos, seleccione cualquier ítem hasta que aparezca un listado de opciones. Precaución:  No utilice objetos afilados que puedan rallar la pantalla.  No permita que la pantalla haga contacto o limpie la misma con productos químicos ya que dichos productos pueden dañar la pantalla.  Para evitar daños a la pantalla del equipo, evite sentarse sobre el teléfono.  Barra de estado La barra de estado se encuentra en el borde superior de la pantalla la cual muestra notificaciones de diversas aplicaciones, la hora y el estado en que se encuentran varias opciones, tales como la carga de la batería, la señal WLAN, la señal del equipo y otros más. 1. Los iconos del panel de notificación le brinda información acerca de correo electrónico, mensajes y de otras funciones. Para visualizar esta información deslice la barra superior hacia abajo y seleccione el icono deseado que a su vez le permitirá visualizar la información. 2. La barra de estado muestra el estado en qué se encuentra el teléfono y sus dispositivos, tales como la batería, su carga, alarmas, Bluetooth así como otras funciones. Al deslizar esta barra hacia abajo se tendrá acceso a más opciones de ajustes y configuración.  Orientación de la pantalla Para obtener una visualización óptima de la pantalla, la orientación de la misma cambiará automáticamente dependiendo de la forma en que se sostenga el teléfono. NOTA: para activar o desactivar la auto-rotación, deslice el panel de estado y seleccione el icono de auto-rotación.  Teclas y funciones 1. Tecla “Volver”  Para volver a la pantalla previa o salir de una aplicación, seleccione la tecla “Volver”.  Para cerrar el teclado virtual también puede presionar la tecla “Volver”. 2. Tecla “Inicio”  Para regresar a la pantalla principal seleccione la tecla “Inicio”.  Para abrir la opción de búsqueda en Google, presione y mantenga la tecla “Inicio”. 3. Tecla “Menú”  Esta opción se utiliza para abrir aplicaciones usadas recientemente.  Aplicaciones (Apps) y herramientas (Widgets)  Aplicaciones: consisten en programas que permiten llevar a cabo funciones específicas. El teléfono cuenta una variedad de aplicaciones precargadas y otras aplicaciones se pueden descargar mediant…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Bluebank Communication Technology Co.Ltd. 2015-08-07 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ____ Bluebank Communication Technology Co.Ltd..__ _hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： Smartphone Trade Name： VULCAN Model Name： VP5001I Serial Model： N/A FCC ID： 2AFK7-VP5001I Sincerely, Signature Client’s name / title :han ting / Director of Operations Contact information / address : No. 13-2, Jiang Ying Road, Nan An District, Chongqing, P.R. China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Bluebank Communication Technology Co.Ltd. 2015-08-07 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AFK7-VP5001I We hereby request confidential treatment of information accompanying this application as outlined below: - . Block Diagram - Schematics - Operational Description - - BOM - - tune up procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Client’s name / title :han ting / Director of Operations Contact information / address : No. 13-2, Jiang Ying Road, Nan An District, Chongqing, P.R. China

Bluebank Communication Technology Co.Ltd. WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for FCC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID: 2AFK7-VP5001I Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Signature Client’s name / title :han ting / Director of Operations Contact information / address : No. 13‐2, Jiang Ying Road, Nan An District, Chongqing, P.R. China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

FCC ID LABELING AND LOCATION FCC ID Label Smartphone Model NO.: VP5001I VULCAN Input Rating: DC 5V/ 1000mA FCC ID: 2AFK7-VP5001I Bluebank Communication Technology Co.Ltd. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10

FCC RADIO TEST REPORT FCC ID: 2AFK7-VP5001I Product： Smartphone Trade Name： VULCAN Model Name： VP5001I Serial Model： N/A Report No.： NTEK-2015NT07202309F4 Prepared for Bluebank Communication Technology Co.Ltd. No. 13-2, Jiang Ying Road, Nan An District, Chongqing, P.R. China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 51 Report No.: NTEK-2015NT07202309F4 TEST RESULT CERTIFICATION Applicant’s name ........ Bluebank Communication Technology Co.Ltd. Address ......................... No. 13-2, Jiang Ying Road, Nan An District, Chongqing, P.R. China Manufacture's Name ... Bluebank Communication Technology Co.Ltd. Address ......................... No. 13-2, Jiang Ying Road, Nan An District, Chongqing, P.R. China Product description Product name ..................Smartphone Model and/or type reference ..................... VP5001I Serial Model .................... N/A Standards .................... FCC Part15.247 01 Oct. 2014 Test procedure ................ ANSI C63.10-2013 and KDB 558074: June 5, 2014 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ..................................... . Date (s) of performance of tests ....... . 15 Jun. 2015 ~03 Jul. 2015 Date of Issue .................................... . 03 Aug. 2015 Test Result ........................................ . Pass Testing Engineer : (Eileen Liu) Technical Manager : (Brown Lu) Authorized Signatory : (Sam Chen) Page 3 of 51 Report No.: NTEK-2015NT07202309F4 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 19 3.2.1 RADIATED EMISSION LIMITS 19 3.2.2 TEST PROCEDURE 20 3.2.3 DEVIATION FROM TEST STANDARD 20 3.2.4 TEST SETUP 21 3.2.5 EUT OPERATING CONDITIONS 22 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 23 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 24 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 26 4 . POWER SPECTRAL DENSITY TEST 27 4.1 APPLIED PROCEDURES / LIMIT 27 4.1.1 TEST PROCEDURE 27 4.1.2 DEVIATION FROM STANDARD 27 4.1.3 TEST SETUP 27 4.1.4 EUT OPERATION CONDITIONS 27 4.1.5 TEST RESULTS 28 5 . BANDWIDTH TEST 34 5.1 APPLIED PROCEDURES / LIMIT 34 5.1.1 TEST PROCEDURE 34 Page 4 of 51 Report No.: NTEK-2015NT07202309F4 Table of Contents Page TEST SETUP 34 5.1.2 EUT OPERATION CONDITIONS 34 5.1.3 TEST RESULTS 35 6 . PEAK OUTPUT POWER TEST 41 6.1 APPLIED PROCEDURES / LIMIT 41 6.1.1 TEST PROCEDURE 41 6.1.2 DEVIATION FROM STANDARD 41 6.1.3 TEST SETUP 41 6.1.4 EUT OPERATION CONDITIONS 41 6.1.5 TEST RESULTS 42 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 43 7.1 DEVIATION FROM STANDARD 43 7.2 TEST SETUP 43 7.3 EUT OPERATION CONDITIONS 43 7.4 TEST RESULTS 44 8 . ANTENNA REQUIREMENT 49 8.1 STANDARD REQUIREMENT 49 8.2 EUT ANTENNA 49 9 . EUT TEST PHOTO 50 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 51 Report No.: NTEK-2015NT07202309F4 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 51 Report No.: NTEK-2015NT07202309F4 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 51 Report No.: NTEK-2015NT07202309F4 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Smartphone Trade Name VULCAN Model Name VP5001I Serial Model N/A Model Difference N/A Product Description Operation Frequency: 802.11b/g/n(20MHz): 2412~2462MHz Modulation Type: IEEE 802.11b : DSSS (CCK, QPSK, DBPSK) IEEE 802.11g/n (HT20) : OFDM (64QAM, 16QAM, QPSK, BPSK) Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz):150/144.44/130/117/ 115.56/104/86.67/78/52/6.5Mbps Number Of Channel 802.11b/g/n20MHz:11CH Antenna Designation: Please see Note 3. Antenna Gain (dBi) 1.0 dbi Channel List Please refer to the Note 2. Ratings DC 3.7V Adapter Mode: WTA0501000USA1 Input: 100-240V~, 50/60Hz, 0.3A Output: 5.0V , 1000mA Battery DC 3.7V,2000mAh Connecting I/O Port(s) Please refer to the User'…
