2AFKNGTS12WOneTap SmartLock Noiseless Wireless Car Charger for Galaxy Z Fold

3MN085530 US and Canada Customers Only Distributed by Spigen, Inc. in Irvine, CA 92618, USA Manufacturer : Spigen Korea Co., Ltd. IC Statement This digital apparatus complies with CAN ICES-003(B)/NMB-003(B) This device complies with Industry Canada license ICES-003. Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. Cet appareil numérique est conforme à la norme CAN ICES-003(B)/NMB-003(B) Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. IC Radiation Exposure Statement CAN RSS-216 / CNR-216 This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. CAN RSS-216 / CNR-216 Cet équipement est conforme aux limites d'exposition aux radiations IC CNR-102 établies pour un environnement non contrôlé. Cet émetteur ne doit pas être situé ou fonctionner conjointement avec une autre antenne ou un autre émetteur. Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. (4) Consult the dealer or an experienced radio / TV technician for help. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The following importer is the responsible party (for FCC matters only). Spigen Inc. 9975 Toledo Way #100, Irvine, CA 92618 USA E-mail : [email protected] Note / Hinweis / Précautions / Atención / Attenzione / Notlar / 유의사항 EN • B Class Equipment (Equipment for home use) * This product is mainly for home use with radio wave acceptability registration; therefore, it can be used in all areas. DE • Das Gerät der Klasse B ( Rundfunk- und Kommunikationsmaterial für den Hausgebrauch) * Dieses Produkt, das ein elektromagnetisches verträgliches Haushaltsgerät der Klasse B ist, passt meistens zum Haushalt und kann in allen Orten benutzt werden. FR • Equipement classe B (appareils domestiques de radio et de communication) * Ce produit est un équipement adapté aux ondes électromagnétiques domestiques (classe B), destiné à un usage domestique et peut être utilisé dans toutes les zones. ES • Dispositivo de Clase B (Aparato de la Comunicación de servicios públicos de radiodifusión) * Este producto es un dispositivo doméstico (Clase B) con la compatibilidad electromagnética. Se puede usarlo en todos los locales con el propósito del uso doméstico. IT • la macchina livello B(il materiale di corrispondenza radiodifontata da casa) * questo prodotto è adatto una macchina cimòmetro da casa(livello B) principalmente si prende a scopo di usare da casa ed si può tutta la zona. TR • B Sınıfı Ekipman (Ev kullanımı için ekipman) * Bu ürün esas olarak radyo dalgası kabul kaydı ile evde kullanım içindir; bu nedenle her alanda kullanılabilir. KR • B급 기기(가정용 방송통신기자재) * 이 제품은 가정용(B급)전자파적합기기로서 주로 가정에서 사용하는 것을 목적으로 하며, 모든 지역에서 사용할 수 있습니다. Caution / Vorsichtsmaßnahmen / Remarque / Precaución / Attenzione / Önlem / 주의 EN • Vent Clip can only be installed on air event blades less than 4.5mm (0.18in) thick. • When installing Vent Clip, only 7.5mm (0.3in) apart from vehicle vent blade can be installed. DE • Der Vent Clip kann nur an Lüftungslamellen mit einer Dicke von weniger als 4,5 mm installiert werden. • Bei der Installation des Entlüftungsclips kann nur ein Abstand von 7,5 mm zum Fahrzeugentlüftungsblatt eingehalten werden. FR • Le Vent Clip ne peut être installé que sur des lames d'aération d'une épaisseur inférieure à 4,5 mm. • Lors de l'installation du Vent Clip, la distance entre la lame d'évent du véhicule et le clip ne peut être que de 7,5 mm. ES • El clip de ventilación solo se puede instalar e…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 1 of 8 External Photos for FYCR2204000053AT FCC ID: 2AFKNGTS12W Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 2 of 8 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 3 of 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 4 of 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 5 of 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 6 of 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 7 of 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 8 of 8

Tolerance 公差 100 100 产品配色与工艺说明图 Product Model 产品型号 Part Number 物料编号 Material 材质 Remark 备注 Original Designer 原设计师 Verifing 审核 Date 日期 Color 颜色 Membrane 表面工艺 Dimension 尺寸 Scale 比例 Job No. 图档编码 Revision 版本号 Change Description 版本变更描述 Brand 品牌 Product Type 产品类 Description 描述 Product Colour,Material & Finishing Specfications FA14 SA01 80gPET不干胶贴纸+黑底+冷灰7C 贴纸 1:1 1.0 2022-6-29

发件人：[email protected] 收件人：Liao, Christy (Shenzhen) 主题：[EXTERNAL] Response to Inquiry to FCC (Tracking Number 782994) 日期：2022 年 6 月 28 日 20:54:56 *** WARNING: this message is from an EXTERNAL SENDER. Please be cautious, particularly with links and attachments. *** Inquiry on 06/28/2022 : Inquiry: Dear Sir Spigen Korea Co., Ltd. (grantee code: 2AFKN) will apply FCC ID for 2AFKNGTS12W. Due to the size, appearance, shape and shell material of the product, Considering that there is not enough space on the back of the product to print the part 15.19 a(3) statement, they hope to add this information in the manual to replace. Please refer the label and manual to check. Could you accept it? Looking forward to receiving your reply, thanks. FCC response on 06/28/2022 Hello, Yes, we will accept your proposal to place the 15.19 statement in the manual. Attachment Details: Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry.

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 1 of 8 Internal Photos for FYCR2204000053AT FCC ID: 2AFKNGTS12W Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 2 of 8 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 3 of 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 4 of 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 5 of 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 6 of 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 7 of 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 8 of 8

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005302 Page: 1 of 13 Kidd Yang EMC Laboratory Manager Human Exposure Report Application No.: FYCR2204000053AT Applicant: Spigen Korea Co., Ltd. Address of Applicant: Spigen HQ-A, 446, Bongeunsa-ro, Gangnam-gu, Seoul, 06153, South Korea Manufacturer: Spigen Korea Co., Ltd. Address of Manufacturer: Spigen HQ-A, 446, Bongeunsa-ro, Gangnam-gu, Seoul, 06153, South Korea Factory: Spigen Korea Co., Ltd. Address of Factory: Spigen HQ-A, 446, Bongeunsa-ro, Gangnam-gu, Seoul, 06153, South Korea Equipment Under Test (EUT): EUT Name: OneTap SmartLock Noiseless Wireless Car Charger for Galaxy Z Fold Model No.: GTS12W Trade Mark: FCC ID : 2AFKNGTS12W Standards: 47 CFR PART 1, Subpart I, Section 1.1310 47 CFR PART 2, Subpart J, Section 2.1093 Date of Receipt: 2022-04-06 Date of Test: 2022-04-09 to 2022-06-02 Date of Issue: 2022-07-04 Test Result : Pass* Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005302 Page: 2 of 13 Revision Record Version Chapter Date Modifier Remark 01 2022-06-06 Original 02 2022-07-04 Update the Equipments Used during Test Authorized for issue by: Tree Zhan/Project Engineer Winkey Wang/Reviewer Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005302 Page: 3 of 13 1 Contents 1 CONTENTS .............................................................................................................................................................. 3 2 GENERAL INFORMATION ................................................................................................................................... 4 2.1 DETAILS OF E.U.T. ................................................................................................................................................. 4 2.2 DESCRIPTION OF SUPPORT UNITS ........................................................................................................................... 4 2.3 TEST LOCATION ...................................................................................................................................................... 5 2.4 TEST FACILITY ....................................................................................................................................................... 5 2.5 DEVIATION FROM STANDARDS ............................................................................................................................... 5 2.6 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................... 5 3 EQUIPMENTS USED DURING TEST .................................................................................................................. 6 4 TEST RESULTS ...................................................................................................................................................... 7 4.1 RF EXPOSURE TEST ................................................................................................................................................ 7 4.1.1 E.U.T. Operation ........................................................................................................................................ 7 5 PHOTOGRAPHS- RF EXPOSURE SETUP PHOTOS .................................................................................... 13 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005302 Page: 4 of 13 2 General Information 2.1 Details of E.U.T. Power supply: Powered by car charger with Model:GTS12W Input:DC12-24V Output:DC5V,3A; DC9V,2A;DC12V,1.5A Cable(s): Type-C cable: 145cm unshielded Output Power: 5W/7.5W/10W/15W Antenna Type: Loop Antenna Modulation Type: Load Modulation Operating frequency: 110.4KHz-136.6KHz Remark: This device has been tested DC12V, DC24V and the worst status of full load and the device has been tested with load at 5W(Nexus mobile phone), 7.5W(Apple mobile phone) and 10W(E-Loading), 15W(SAMSUNG mobile phone), the worst case DC24V,15W is reported only. 2.2 Description of Support Units Description Manufacturer Model No. Serial No. Mobile Phone Nexus MRA58K REF. No.SEA16P00 iPhone 8 Apple A1863 REF. No.SEA16J00 Mobile Phone SAMSUNG SM-G9810 REF. No.SEA16K00 Mobile Phone SAMSUNG SM-G9500 REF. No.SEA16J00 E-loading SGS N/A REF. No.SEA42A00 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005302 Page: 5 of 13 2.3 Test Location All tests were performed at: Compliance Certification Services（Kunshan）Inc. Shenzhen branch. Fuyong lab. Xinlong TechnoPark,Fengtang Road, Fuyong Subdistrict, Bao’an, Shenzhen, China Tel: +86 755 8866 3988 Fax: +86 755 2671 0594 No tests were sub-contracted. 2.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 6606.01) Compliance Certification Services（Kunshan）Inc. Shenzhen branch is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 6606.01. • FCC –Designation Number: CN1322 Compliance Certification Services（Kunshan）Inc. Shenzhen branch has been recognized as an accredited testing laboratory. Designation Number: CN1322. Test Firm Registration Number: 718073 • Innovation, Science and Economic Development Canada Compliance Certification Services（Kunshan）Inc. Shenzhen branch has been recognized by ISED as an accredited testing laboratory. CAB identifier: CN0129. IC#: 28189. 2.5 Deviation from Standards None. 2.6 Abnormalities from Standard Conditions None. Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005302 Page: 6 of 13 3 Equipments Used during Test Item Test Equipment Manufacturer Model No. Inventory No. Cal. Due date 1 3m Fully-Anechoic Chamber AUDIX N/A SEM001-02 2024-12-23 2 Electric and Magnetic Field Probe - Analyzer(3kHz-30MHz) Narda EHP-200AC SEM022-20 2023-0…

Text truncated - open the document above for the full version.

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005301 Page: 1 of 23 Kidd Yang EMC Laboratory Manager TEST REPORT Application No.: FYCR2204000053AT Applicant: Spigen Korea Co., Ltd. Address of Applicant: Spigen HQ-A, 446, Bongeunsa-ro, Gangnam-gu, Seoul, 06153, South Korea Manufacturer: Spigen Korea Co., Ltd. Address of Manufacturer: Spigen HQ-A, 446, Bongeunsa-ro, Gangnam-gu, Seoul, 06153, South Korea Factory: Spigen Korea Co., Ltd. Address of Factory: Spigen HQ-A, 446, Bongeunsa-ro, Gangnam-gu, Seoul, 06153, South Korea Equipment Under Test (EUT): EUT Name: OneTap SmartLock Noiseless Wireless Car Charger for Galaxy Z Fold Model No.: GTS12W Trade Mark: FCC ID : 2AFKNGTS12W Standard(s) : 47 CFR Part 15, Subpart C Date of Receipt: 2022-04-06 Date of Test: 2022-04-09 to 2022-06-02 Date of Issue: 2022-06-06 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005301 Page: 2 of 23 Revision Record Version Chapter Date Modifier Remark 01 2022-06-06 Original Authorized for issue by: Tree Zhan/Project Engineer Winkey Wang/Reviewer Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005301 Page: 3 of 23 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Radiated Emissions (30MHz-1GHz) 47 CFR Part 15, Subpart C ANSI C63.10 (2013) Section 6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Emissions (9kHz-30MHz) ANSI C63.10 (2013) Section 6.4 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass 20dB Bandwidth ANSI C63.10 (2013) Section 6.9.2 47 CFR Part 15, Subpart C 15.215 Pass Restricted Bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 Pass Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220400005301 Page: 4 of 23 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 TEST SUMMARY ....................................................................................................................................... 3 3 CONTENTS ................................................................................................................................................ 4 4 GENERAL INFORMATION ........................................................................................................................ 5 4.1 DETAILS OF E.U.T. ............................................................................................................................... 5 4.2 DESCRIPTION OF SUPPORT UNITS ......................................................................................................... 5 4.3 TEST LOCATION .................................................................................................................................... 5 4.4 TEST FACILITY ...................................................................................................................................... 6 4.5 DEVIATION FROM STANDARDS ............................................................................................................... 6 4.6 ABNORMALITIES FROM STANDARD CONDITIONS ..................................................................................... 6 5 EQUIPMENT LIST ...................................................................................................................................... 7 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................... 10 6.1 ANTENNA REQUIREMENT .................................................................................................................... 10 6.1.1 Test Requirement: ....................................................................................................................... 10 6.1.2 Conclusion ................................................................................................................................... 10 7 RADIO SPECTRUM MATTER TEST RESULTS ..................................................................................... 11 7.1 RADIATED EMISSIONS (30MHZ-1GHZ) ................................................................................................ 11 7.1.1 E.U.T. Operation .......................................................................................................................... 11 7.1.2 Test Mode Description ................................................................................................................. 11 7.1.3 Test Setup Diagram ..................................................................................................................... 12 7.1.4 Measurement Procedure and Data............................................................................................. 12 7.2 RADIATED EMISSIONS (9KHZ-30MHZ) ................................................................................................. 15 7.2.1 E.U.T. Operation .......................................................................................................................... 15 7.2.2 Test Mode Description ................................................................................................................. 16 7.2.3 Test Setup Diagram ..................................................................................................................... 16 7.2.4 Measurement Procedure and Data............................................................................................. 16 7.3 20DB BANDWIDTH ...................................................................................................................…

Text truncated - open the document above for the full version.

发件人：[email protected] 收件人：Chen, Frank-xh (Shenzhen) 主题：[EXTERNAL] Response to Inquiry to FCC (Tracking Number 249964) 日期：2022 年 6 月 15 日 21:00:37 *** WARNING: this message is from an EXTERNAL SENDER. Please be cautious, particularly with links and attachments. *** Inquiry on 06/15/2022 : Inquiry: Dear sir, This is an EMC engineer from SGS China. I got a QI wireless car charger to apply certificate. This device can only be installed on the air event blades. Please refer to the RF exposure report for specific differences. The user will install the device and the device does not contain any battery itself. It is powered by wireless car charger from car power source. Please find its' specification as below: Model No.: GTS12W Max. output power: 15W No. of turns: 12 operation frequency: 110.4kHz to 136.6kHz The passenger may use his phone while telephone is being charged by the QI wireless charger. Given this situation, we consider 4cm to be the worst case. So we have conducted the RF exposure tests with a various distance of 4/6/8/10/15cm. The minimum exposure distance is 4cm, A RF exposure report, user manuals, internal photos, external photos ,operation description?operation environment and RF test setup photos have submitted. Base on my inquiry above, could you help to review it and give your comments? Thank you very much and looking forward to your reply. FCC response on 06/15/2022 This appears to meet the current guidance. You may proceed. Attachment Details: GTS12W Operation Description GTS12W Operating environment Appendix_ExternalPhoto Appendix_InternalPhoto RF Exposure Setup Photos MPE report Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry.

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 1 of 2 Setup Photos for FYCR2204000053AT FCC ID: 2AFKNGTS12W Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 2 of 2 Test Setup Photo Radiated Emissions (30MHz-1GHz) Radiated Emissions (9kHz-30MHz)

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 1 of 6 RF Exposure Setup Photos for FYCR2204000053AT FCC ID: 2AFKNGTS12W Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 2 of 6 1 RF Exposure Setup Photos 15cm Side 1: Side 2: Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 3 of 6 Side 3: Side: 4 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 4 of 6 Top: 4cm: Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 5 of 6 6cm: 8cm: Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 6 of 6 10cm:
