4 t h Aug, 2015 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 15 Certification FCC ID: 2AFMM-ACUBF Request is hereby submitted by E HOME PRODUCTS CO., LIMITED to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and EHOME PRODUCTS CO., LIMITED reserves the right to discern which parties can obtain access to these information: Schematics Detailed Block diagrams Detailed Operational/Functional Description The rationale for request for confidentiality is as followings: This information represents intellectual property of EHOME PRODUCTS CO., LIMITED and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Eyllina S ales manager

Label size: 13.1mm(W)*37.5mm (L) Main Unit with BT module Plastic Host

INTERTEK TESTING SERVICES RF Exposure The equipment under test (EUT) is a ACTIVITY TRACKER with Bluetooth function. The EUT was powered by a 3.7 VDC Li-ion rechargeable battery which is charged by USB Power Adapter with AC 120V, 60Hz. For more detail information pls. refer to the user manual. Bluetooth Version: 4.0 (single mode) Low Energy Standard Modulation Type: GFSK Antenna Type: Integral antenna. Antenna Gain: 0.0dBi. The nominal conducted output power specified: -5dBm +/-1dB. The nominal radiated output power (e.i.r.p) specified: -5dBm (+/- 1dB) According to the KDB 447498: The ma ximun peak radiated emission for the EUT is 91.2dBμV/m at 3m in the frequency 2442MHz The EIRP = [(FS*D) ^2 / 30] mW =-4.03dBm which is within the production variation. The minimum peak radiated emission for the EUT is 90.0dBμV/m at 3m in the frequency 2402M Hz Th e EIRP = [(FS*D) ^2 / 30] mW = -5.23dBm which is within the production variation. The maximun conducted output power specified is -4.0dBm = 0.4mW The source- based time-averaging conducted output power = 0.4 * Duty Cycle mW (where Duty Cycle≤1) ≤ 0.4 mW The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.480) mW = 9.5 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. FCC ID: 2AFMM-ACUBF
