K1 User Guide Thank you for choosing this Spreadtrum Platformphone. This device will offer you unprecedented surprise for it can support GSM cards and multiple cards standby. Meanwhile, a MP3 Mobile Musicand a MP4 video player. Manual used the picture only as the functional diagram, may be different from the actual product, refer to the actual product. Because if the function upgrading caused by the manual content and the actual product does not match, please post in the company the information shall prevail. Enjoy yourself ! Safety Please go through, and comply with, the following considerations before using this phone.   Please take earphone if making or Answer incoming call while driving or after you car is parked.   The phone may interfere with aircraft telecommunication. So please turn if off or switch to flight mode during the flight.   Anyphone may be susceptible to interference, which could affect performance.   Please turn off your phone near the medical equipment or in the medical facility where anyphone must be out of service.   Please use the original battery and accessories in order to have optimal performance and prevent phone damage. Please don’t use unmatched products.   Please turn off yourphone in the gas station or near fuel or chemicals to prevent explosion.   To avoid interference with blasting work, please turn off thephone on the site or where two-way radio must be switched off. Please observe the local rules.   Burning or disposing ofphone battery as usual is prohibited, or it may cause life risk or environmental pollution. Please dispose of and recycle it in compliance with the local environmental regulations.   If yourphone needs to be connected with other device, please read the User Guide of the latter.   Some small components (e.g. memory card, etc.) shall be out of children’s reach; otherwise it may be swallowed or cause other hazards.   Please copy or keep a written copy of the vital information stored in your phone.  SOS  Ensure the phone is turned on and within the service area. Enter the emergency number, press the talking key to tell your location. Please don’t end the call without permission. i Contents Introduction ........................................................................................................................................................ 9 Insert SIM card and battery .................................................................................................................................... 9 Insert memory card ................................................................................................................................................. 9 Battery charging ..................................................................................................................................................... 9 Power on and off .................................................................................................................................................. 10 Idle .................................................................................................................................................................... 11 Switch to Idle Page ............................................................................................................................................... 11 Wallpaper Settings ................................................................................................................................................ 11 Task Manager ....................................................................................................................................................... 11 Settings ................................................................................................................................................................. 11 Open Option Menu ............................................................................................................................................... 11 Main menu ....................................................................................................................................................... 12 Use Function Menu of Main Menu ...................................................................................................................... 12 Call .................................................................................................................................................................... 13 Dialpad ................................................................................................................................................................. 13 Making an overseas call. ...................................................................................................................................... 13 Dialing via Contacts ............................................................................................................................................. 13 Calling an extension number ................................................................................................................................ 13 Making an emergency phone ................................................................................................................................ 13 Answer or reject incoming calls ........................................................................................................................... 13 Menu during a call ................................................................................................................................................ 13 Adjust volume ...................................................................................................................................................... 14 End a call ........................................................................................................................................…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 Access Telecom 2015-08-13 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ____ Access Telecom __ hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Product： RTEEK K1 Trade Name： RTEEK Model Name： K1 Serial Model： IGLOO K1 FCC ID： 2AFMZ-K1 Sincerely, Signature Client’s name / title : Albert Benhamu / Sales assistant Contact information / address : 1882 NW 97th Avenue, Miami, Florida 33172, United States

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 Access Telecom 2015-08-13 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AFMZ-K1 We hereby request confidential treatment of information accompanying this application as outlined below: - . Block Diagram - Schematics - Operational Description - BOM - - tune up procedure - The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Signature Client’s name / title : Albert Benhamu / Sales assistant Contact information / address : 1882 NW 97th Avenue, Miami, Florida 33172, United States

Access Telecom WIFI Channel 12 & 13 Declaration Letter To whom it may concern : We have declared below featured for FCC equipment authorization in regard to 802.11b/g/n channel 12 & 13 operating capability for FCC ID : 2AFMZ-K1 Please check Product hardware does not have the capability to operate on channel 12 & 13 Product hardware has the capability to operate on channel 12 & 13. However , these 2 channels will be disabled via software and user will not able to enable these 2 channels Product hardware has the capability to operate on channel 12 & 13. And meeting KDB 594280 D01 requirement. Pls explain detail here. Others Pls explain detail here. Signature Client’s name / title : Albert Benhamu / Sales assistant Contact information / address : 1882 NW 97th Avenue, Miami, Florida 33172, United States

Access Telecom Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2015-03-05 SUBJECT: FCC Application for ( FCC ID: 2AFMZ-K1) To Whom It May Concern: We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite device. We understand that devices subject to the DoC procedure are required to be tested to show compliance with the FCC technical regulations by a recognized accredited testing laboratory. The testing laboratory must be accredited by a Commission approved accreditation body or designated under the terms of a government-to-government Mutual Recognition Agreement (MRA). A listing of those accredited testing laboratories that have been recognized by the Commission is published on the FCC Webpage: https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm Select the "accredited" option to search for FCC recognized accredited test firms. Test facilities located in countries, where the U.S. does not have an operational Telcom MRA are not recognized by the FCC to test for the DoC procedure. Regards, Signatory Signature Client’s name / title : Albert Benhamu / Sales assistant Contact information / address : 1882 NW 97th Avenue, Miami, Florida 33172, United States

Access Telecom Model Difference FCC ID: 2AFMZ-K1 Model : K1, IGLOO K1 All the model are the same circuit and RF module, except the model name and colour. Regards, Client’s signature Signature Client’s name / title : Albert Benhamu / Sales assistant Contact information / address : 1882 NW 97th Avenue, Miami, Florida 33172, United States

FCC ID LABELING AND LOCATION FCC ID Label RTEEK K1 Model NO.: K1 Input Rating: DC 5V/ 2000mA FCC ID: 2AFMZ-K1 Access Telecom This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 2G/3G ANT Photo 3 Photo 4 Photo 5 Photo 6 WIFI/BT Anttena Photo 7 Photo 8 Photo 9 Photo 10

FCC RADIO TEST REPORT-WIFI FCC ID: 2AFMZ-K1 Product： RTEEK K1 Trade Name： RTEEK Model Name： K1 Serial Model： IGLOO K1 Report No.： NTEK-2015NT07012159F2 Prepared for Access Telecom 1882 NW 97th Avenue, Miami, Florida 33172, United States Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 50 Report No.: NTEK-2015NT07012159F2 TEST RESULT CERTIFICATION Applicant’s name ........ Access Telecom Address ......................... 1882 NW 97th Avenue, Miami, Florida 33172 , United States Manufacture's Name ... LOCOPO Technology Co, Limited Address ......................... Shenzhen futian district tianan digital city with four LuJinSong building 12 d Product description Product name ..................RTEEK K1 Model and/or type reference ..................... K1 Serial Model .................... IGLOO K1 Standards .................... FCC Part15.247 01 Oct. 2014 Test procedure ................ ANSI C63.10-2013 and KDB 558074: June 5, 2014 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ..................................... . Date (s) of performance of tests ....... . 06 Jul. 2015 ~27 Jul. 2015 Date of Issue .................................... . 27 Jul. 2015 Test Result ........................................ . Pass Testing Engineer : (Eileen Liu) Technical Manager : (Brown Lu) Authorized Signatory : (Sam Chen) Page 3 of 50 Report No.: NTEK-2015NT07012159F2 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 23 3.2.1 RADIATED EMISSION LIMITS 23 3.2.2 TEST PROCEDURE 24 3.2.3 DEVIATION FROM TEST STANDARD 24 3.2.4 TEST SETUP 25 3.2.5 EUT OPERATING CONDITIONS 26 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 27 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 28 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 30 4 . POWER SPECTRAL DENSITY TEST 31 4.1 APPLIED PROCEDURES / LIMIT 31 4.1.1 TEST PROCEDURE 31 4.1.2 DEVIATION FROM STANDARD 31 4.1.3 TEST SETUP 31 4.1.4 EUT OPERATION CONDITIONS 31 4.1.5 TEST RESULTS 32 5 . BANDWIDTH TEST 36 5.1 APPLIED PROCEDURES / LIMIT 36 5.1.1 TEST PROCEDURE 36 Page 4 of 50 Report No.: NTEK-2015NT07012159F2 Table of Contents Page TEST SETUP 36 5.1.2 EUT OPERATION CONDITIONS 36 5.1.3 TEST RESULTS 37 6 . PEAK OUTPUT POWER TEST 41 6.1 APPLIED PROCEDURES / LIMIT 41 6.1.1 TEST PROCEDURE 41 6.1.2 DEVIATION FROM STANDARD 41 6.1.3 TEST SETUP 41 6.1.4 EUT OPERATION CONDITIONS 41 6.1.5 TEST RESULTS 42 7 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 43 7.1 DEVIATION FROM STANDARD 43 7.2 TEST SETUP 43 7.3 EUT OPERATION CONDITIONS 43 7.4 TEST RESULTS 44 8 . ANTENNA REQUIREMENT 48 8.1 STANDARD REQUIREMENT 48 8.2 EUT ANTENNA 48 9 . EUT TEST PHOTO 49 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 50 Report No.: NTEK-2015NT07012159F2 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 50 Report No.: NTEK-2015NT07012159F2 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 50 Report No.: NTEK-2015NT07012159F2 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment RTEEK K1 Trade Name RTEEK Model Name K1 Serial Model IGLOO K1 Model Difference All the model are the same circuit and RF module, except the model name and colour. Product Description Operation Frequency: 802.11b/g: 2412~2462MHz Modulation Type: IEEE 802.11b : DSSS (CCK, QPSK, DBPSK) IEEE 802.11g : OFDM (64QAM, 16QAM, QPSK, BPSK) Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps Number Of Channel 802.11b/g:11CH Antenna Designation: Please see Note 3. Antenna Gain (dBi) 1.0 dbi Channel List Please refer to the Note 2. Ratings DC 3.7V Adapter Mode : YMK-12W050200B Input: 100-240V~, 50/60Hz, 0.15A Output: 5.0V , 2000mA Battery DC 3.7V, 1300mAh Connecting I/O Port(s) Please refer to the User's Manual Page 8 of 50 Report No.: NTEK-2015NT07012159F2 Note: 1. For a more detailed f…
