2AFMZ-K3RTEEK K3

I Modelo: K3 II
Manual del Usuario Para asegurarse del buen funcionamiento de su equipo móvil le recomendamos leer cuidadosamente este Manual. Este Manual del Usuario ha sido validado y actualizado a la última versión disponible de nuestro Modelo: RTEEK K3. Por tanto toda su información, descripciones y detalles sobre el funcionamiento de la unidad se ajustan perfectamente a este modelo. RTEEK® se reserva el derecho a modificar, actualizar o editar este Manual del Usuario en caso de ser necesario en cualquier momento y sin notificación previa. Esperamos que disfrute su Nuevo Teléfono RTEEK! III
Tabla de Contenido 1 Su Telefono ................................................... 1 1.1 Botones e Interfaz ........................................ 1 1.2 Comenzando a utilizar su Telefono ......................... 2 1.2.1 Instalacion ........................................... 2 1.2.2 Encendido ............................................. 3 1.2.3 Apagado ............................................... 3 1.3 Pantalla Principal ........................................ 3 1.3.1 Utilizando el Touch Screen ........................... 4 1.3.2 Barra de Estado ....................................... 4 1.3.3 Bloquear y Desbloquear su Patalla .................... 6 1.3.5 Ajustar el Volumen .................................... 6 1.4 Lista de Aplicaciones y Perifericos ....................... 6 2 Creando Textos ................................................ 7 2.1 Usando el Teclado en la Pantalla .......................... 7 2.2 Editando Textos ........................................... 7 3 Telefono ...................................................... 8 3.1 Telefono .................................................. 8 3.2 Responder o Desviar una Llamada ........................... 9 4 Contactos ..................................................... 9 4.1 Agregar Nuevo Contacto ................................... 10 4.2 Importar, Exportar o Compartir Contactos ................. 10 5 Mensajes ..................................................... 11 5.1 Nuevo Mensaje ............................................ 11 5.2 Enviando un Mensaje SMS .................................. 11 5.3 Enviando un Mensaje MMS .................................. 12 6 Correo Electronico ........................................... 12 7 Conectate .................................................... 13 7.1 Connectarse a Internet ................................... 13 7.1.1 GPRS/3G .............................................. 13 7.1.2 WLAN ................................................. 13 7.2 Internet ................................................. 14 7.3 Conectarse a la Computadora via USB ...................... 14 7.4 Compartir la Coneccion de Datos de su Telefono ........... 15 IV
8 Funciones y Descripcion del Menu ............................. 15 9 Restaurar la Configuracion de Fabrica ........................ 17 10 Otros ....................................................... 17 1 1 Su Teléfono 1.1 Botones e Interfaz Su teléfono luce como el modelo descrito en la parte baja de este texto. Sírvase a leer y repasar las principales características de su unidad. Botones del Teléfono y sus Funciones: Boton Funcion Boton de Encendido Presione y manténgalo para el Encendido Presione y manténgalo por un periodo de varios segundos para entrar en el menú de Encendido Presiónelo brevemente para bloquear o desbloquear la pantalla. Boton de Menu Presiónelo para obtener todas las Opciones del Menú Boton “Home” Presiónelo para acceder a las ultimas aplicaciones en curso Presiónelo una vez solamente para volver a la pantalla principal del teléfono. Boton de volver Presiónelo para volver a la aplicación o menú anterior En modo edición, presiónelo para ocultar el teclado en la pantalla 电源键 返回键 2 Boton Funcion Boton de Volumen Presiónelo para ajustar el volumen Presiónelo para bajar, subir o cancelar el sonido del ringtone Presiónelo para ajustar el volumen de cualquier aplicación multimedia 1.2 Comenzando a Utilizar su Teléfono 1.2.1 Instalación: Inserte su tarjeta Sim (Simcard) 1. Inserte su tarjeta SIM para poder efectuar o recibir cualquier llamada. Inserte o remueva la tarjeta SIM y remueva la o inserte la batería de la unidad. 2. Localice la ranura para colocar la tarjeta SIM, recuerde que la tarjeta SIM se coloca con los contactos dorados hacia abajo. Insertar o Remover la Tarjeta Micro SD 1. Localizar la ranura para la tarjeta Micro SD que está al lado de la tarjeta SIM, recuerde que los contactos de la tarjeta Micro SD deben ir hacia abajo y siga el dibujo de cómo insertar la tarjeta. 2. Para remover la tarjeta se recomienda cerrar todas las aplicaciones y apagar el teléfono antes de sacar la Memoria Micro SD, dado que si no sigue este procedimiento puede perder información de su memoria externa Cargando la Batería Recuerde colocar siempre la batería en el aparato y conectar este al cargador original provisto por nuestra empresa． Para prolongar la vida de su batería y para ahorrar el consume de energía se le recomienda desconectar el cargador una vez que la batería este completamente cargada. Mantener funciones como: LAN, GPS, Bluetooth, luz del desktop, etc. apagadas pueden ayudarle a extender la carga. 3 1.2.2 Encendido Presione el botón de poder (power) hasta que el teléfono haya encendido. Espere cerca de 2 segundos hasta que la pantalla encienda. 1.2.3 Apagado Presione del botón de poder (power) hasta que el aparato le brinda la opción en menú de “apagado”, seleccione el mismo y la unidad se apagara de inmediato. 1.3 Pantalla Principal La Pantalla de Inicio es un panel extendido o interfaz que le permite visualizar todas las aplicaciones instaladas en el aparato. Esta pantalla puede apreciarse en formato vertical o horizontal (según de sostenga la unidad). Esta pantalla puede ser configurada a la medida de sus necesidades con las aplicaciones, carpetas o archivos de su preferencia y en el orden que más le haga sentir cómod…
