2AFOIRPTRepeater

Tripleplus Ltd. | 5 Hamada St., High Tech Park, Yoqneam, 2069200, Israel | +972-(0)72-2211370 | [email protected] | www.tripleplus.io Triple+ CLM ™ Repeater Installer Guide v3.0 P/N: CLM-RNAMAP-3-00, CLM-RNEMEA-4-00, CLM-RNAMAP-3-02  Welcome Thank you for choosing Triple+ CLM™. Triple+ CLM™ is the ultimate IoT cloud-based system for home safety. The system is managed via an App and is designed to prevent damage due to water leakage. Triple+ offers you a total peace of mind at home or away.  Please note Please read these instructions carefully and follow the system's installation and commissioning steps. Maintain this document in a safe place for future reference. Contact your authorized installer with any questions. Warning! This product was designed to prevent water leakage damages and should be used for this purpose only.  Triple+ CLM™ system Triple+ CLM™ line of products includes innovative battery-operated devices which enables the automated control of water valves. This is unified under the “Smart Home” umbrella. The Triple+ CLM™ HUB serves as a Gateway that ensures a secured communication between the system devices, Triple+ cloud and App. Triple+ CLM™ integrates easily into the Smart Home IoT ecosystem, providing a unique cloud-based secured platform for Water Leak Management.  Repeater specification Part No. CLM-RNAMAP-3-00, CLM-RNEMEA-3-00, CLM- RNAMAP-3-02 Product description The wireless repeater is used to extend the communication range between the system devices and the HUB. Generally, the repeater is used when the signal between the devices and the HUB is too weak. Dimensions 5.9x8.0x2.5cm (2.32x3.15x0.98'') Weight 110gr (3.8 Oz) Power supply External Adaptor Input 110-240 V AC Operation voltage 5V (2 X AAA back up batteries included Up to two hours) Operating RF 868/915 MHz Transmission range Open space - up to 230 m (750 ft.) In enclosed space - up to 120 m (390 ft.) Avoid installing in a metal cabinet. Working temperature -20 to +500C (-4 to +1220F) Certifications FCC ID: 2AFOIRPT IC: 20798-RPT   Backup Batteries Installation 1. Slide down the batteries case cover. 2. Insert 2 x AAA batteries (included). 3. Slide back up the batteries case cover.  Repeater description A. Power cable. B. LED indicator  Repeater installation Steps 1. Locate the best location for installation. 2. Use screws or the double-sided adhesive tape to mount the back cover of the Repeater to the wall  Repeater LED behavior  GREEN flashes every 30 seconds – OK  BLUE flashes every 30 seconds – communication problems  RED flashes every 30 seconds – low battery  System component synchronization and activation Triple+ CLM™ devices are installed and activated using the Triple+ CLM™ installer’s or End-User APP available on AppStore and Google Play. It is recommended to test the unit before installation. This Repeater is designed for indoor use only and should be installed by an authorized installer. Warranty instructions Please visit www.tripleplus.io/support for warranty, technical support, terms and conditions or troubleshooting PW0000 109 B A Tripleplus Ltd. | 5 Hamada St., High Tech Park, Yoqneam, 2069200, Israel | +972-(0)72-2211370 | [email protected] | www.tripleplus.io FCC STATEMENTS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help. WARNING – RF EXPOSURE COMPLIANCE: This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body. -This Class B digital apparatus complies with Canadian ICES-003. -Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada. IC STATEMENTS This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) L’appareil ne doit pas produire de brouillage; 2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. AVERTISSEMENT – CONFORMITÉ AUX NORMES D'EXPOSITION AUX RF : Cet équipement doit être installé et utilisé à une dista…

Text truncated - open the document above for the full version.

Triple Plus Ltd. FCC ID: 2AFOIRPT IC: 20798-RPT Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Triple Plus Ltd. FCC ID: 2AFOIRPT IC: 20798-RPT Page 2 of 3 Photograph No.1 Repeater unit front view Triple Plus Ltd. FCC ID: 2AFOIRPT IC: 20798-RPT Page 3 of 3 Photograph No.2 Repeater unit bottom view

Triple Plus Ltd. FCC ID:2AFOIRPT IC:20798-RPT Page 1 of 2 Label Model number CLM-RNAMAP-3-02 Triple Plus Ltd. FCC ID:2AFOIRPT IC:20798-RPT Page 2 of 2 Label location Label with FCC ID:2AFOIRPT and IC:20798-RPT will be located at the bottom part of the unit’s shell. The statement according to FCC part 15 §15.19(a)(3).

Triple Plus Ltd. FCC ID: 2AFOIRPT IC: 20798-RPT Page 1 of 5 INTERNAL PHOTOGRAPHS This document contains 4 photographs Triple Plus Ltd. FCC ID: 2AFOIRPT IC: 20798-RPT Page 2 of 5 Photograph No.1 Repeater unit internal view Triple Plus Ltd. FCC ID: 2AFOIRPT IC: 20798-RPT Page 3 of 5 Photograph No.2 Repeater unit PCB front view Triple Plus Ltd. FCC ID: 2AFOIRPT IC: 20798-RPT Page 4 of 5 Photograph No.3 Print side of the main PCB Triple Plus Ltd. FCC ID: 2AFOIRPT IC: 20798-RPT Page 5 of 5 Photograph No.4 Repeater unit antenna

Triple+ Repeater Product/technical description Triple+ Repeater communicate with Triple+ Hub, Triple+ flood detector and Triple+ actuator. The repeater powered with external power supply 5VDC and use AAA battery for backup. Antenna description: 1. Antenna type: Helical 2. Gain: 2dBi 3. Triple+ production 4. Operational frequency: single channel 915MHz Power operation range: 1. From 0dBm to 10dBm Hopping Transceiver: Not Applicable

Hermon Laboratories Ltd. P.O. Box 23, Binyamina 3055001, Israel Tel. +972 4628 8001 Fax. +972 4628 8277 E-mail: [email protected] Page 1 of 37 Report ID: TRIRAD_FCC.34184.Repeater_Rev2 Date of Issue: 24-Feb-20 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC CFR 47 Part 15 subpart C, section 15.231 RSS-210 issue 9 Annex A FOR: Triple Plus Ltd. CLM Repeater oval US V2 Model: CLM-RNAMAP-3-02 FCC ID: 2AFOIRPT IC: 20798-RPT This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: TRIRAD_FCC.34184.Repeater_Rev2 Date of Issue: 24-Feb-20 Page 2 of 37 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details .................................................................................................................................................................... 3 5 Tests summary .............................................................................................................................................................. 4 6 EUT description ............................................................................................................................................................. 5 6.1 General information ....................................................................................................................................................... 5 6.2 Test configuration .......................................................................................................................................................... 5 6.3 Changes made in EUT .................................................................................................................................................. 5 6.4 Transmitter characteristics ............................................................................................................................................ 6 7 Transmitter tests according to 47CFR part 15 subpart C requirements ........................................................................ 7 7.1 Periodic operation requirements ................................................................................................................................... 7 7.2 Field strength of emissions .......................................................................................................................................... 11 7.3 Occupied bandwidth test ............................................................................................................................................. 21 7.4 Conducted emissions .................................................................................................................................................. 23 7.5 Antenna requirements ................................................................................................................................................. 26 8 APPENDIX A Test equipment and ancillaries used for tests ....................................................................................... 27 9 APPENDIX B Test equipment correction factors ......................................................................................................... 28 10 APPENDIX C Test laboratory description ................................................................................................................... 34 11 APPENDIX D Measurement uncertainties .................................................................................................................. 35 12 APPENDIX E Specification references........................................................................................................................ 36 13 APPENDIX F Abbreviations and acronyms ................................................................................................................. 37 Report ID: TRIRAD_FCC.34184.Repeater_Rev2 Date of Issue: 24-Feb-20 Page 3 of 37 1 Applicant information Client name: Triple Plus Ltd. Address: 5 Hamada street, Yokneam 2069200, Israel Telephone: +972-72-22-11-370 Fax: +972-4-959-3991 E-mail: [email protected] Contact name: Mr. Yuval Abraham 2 Equipment under test attributes Product name: CLM Repeater oval US V2 Product type: Repeater Model(s): CLM-RNAMAP-3-02 Serial number: Prototype Hardware version: 1.1 Software release: 3.0.2.0 Receipt date 15-Sep-19 3 Manufacturer information Manufacturer name: Triple Plus Ltd. Address: 5 Hamada street, Yokneam 2069200, Israel Telephone: +972-72-22-11-370 Fax: +972-4-959-3991 E-Mail: [email protected] Contact name: Mr. Yuval Abraham 4 Test details Project ID: 34184 Location: Hermon Laboratories Ltd. P.O. Box 23, Binyamina 3055001, Israel Test started: 06-Oct-19 Test completed: 15-Oct-19 Test specification(s): FCC 47CFR part 15, subpart C, §15.231; RSS-210 issue 9 Annex A Report ID: TRIRAD_FCC.34184.Repeater_Rev2 Date of Issue: 24-Feb-20 Page 4 of 37 5 Tests summary Test Status Transmitter characteristics FCC Part 15, Section 231(a) / RSS-210, Section A1.1, Periodic operation requirements Pass FCC Part 15, Section 231(a) / RSS-210, Section A1.2, Field strength of emissions Pass FCC Part 15, Section 231(c) / RSS-210, Section A1.3, Occupied bandwidth Pas…

Text truncated - open the document above for the full version.

Triple Plus Ltd. FCC ID:2AFOIRPT IC:20798-RPT Page 1 of 4 SETUP PHOTOGRAPHS This document contains 3 photographs Triple Plus Ltd. FCC ID:2AFOIRPT IC:20798-RPT Page 2 of 4 Photograph No.1 Setup for spurious emission field strength measurements in the anechoic chamber below 30 MHz Triple Plus Ltd. FCC ID:2AFOIRPT IC:20798-RPT Page 3 of 4 Photograph No.2 Setup for carrier field strength measurements in the anechoic chamber in 30 – 1000 MHz range Triple Plus Ltd. FCC ID:2AFOIRPT IC:20798-RPT Page 4 of 4 Photograph No.3 Setup for spurious emission field strength measurements in the anechoic chamber above 1000 MHz range
