2AFOZW3701Waterguard Hub with WiFi, Bluetooth and LTE Cat M1

Waterguard User and Installation Manual abrahelpcenter.zendesk.com/hc/en-us/articles/4433564776861-Waterguard-User-and-Installation-Manual- Introduction Congratulations on your new Waterguard water security system. Your house is now equipped with a reliable system that protects your assets from water damage. The system consists of the Waterguard Hub, a range of valve sizes from 1/2" to 2" (DN15 to DN50), the wireless Waterguard Water Sensor, installation brackets, and the Abra mobile application. Abra Hub The Abra Hub is the combined heart and brain of the Waterguard system. The Hub enables the use of wired Sensor Tapes and the wireless Waterguard Water Sensor. Waterguard Valves The Waterguard valve(s) are installed on the tap water supply pipe(s). When water leakage is detected, or the user requests the valve to close, the valve shuts off the water supply to reduce the consequences of water leakage. Waterguard Water Sensor The wireless Waterguard Water Sensor detects the presence of water while also measuring the temperature and humidity. When water is detected, the water supply is automatically shut off and a combined visible and audible alarm is triggered on both the sensor and on the Abra Hub. Abra Mobile App The Abra mobile application allows the user to set up, monitor, and control the status of up to two Valve Units, up to 50 wireless Water Sensors, and Sensor Tape. About the system Waterguard is a wireless, automatic water shut-off system that continuously monitors the tap water system in your home by sensing water or high moisture levels in specific locations. The system can detect water using a physically connected water sensor tape or one or more battery-powered, wireless sensor(s). Note: All wireless sensors must be paired with the Hub. The Waterguard automatic water shut-off system is developed for use in single-family home tap water systems with a separate water heater (valve on cold water inlet) and apartments with a direct supply of both cold and warm water (0°C to 60°C). The Waterguard system does not prevent water leakage but provides effective protection that limits the extent of the leakage. When a water leakage is detected, 1) the water shuts off and 2) the homeowner is notified through an audible alarm, light signals, as well as notifications in the mobile application. Optionally, the alarm will be distributed to a certified alarm central (available through a subscription) that may assist in reducing the impact of the water leakage. Detailed information about the water leakage is available in the mobile application, e.g. which wireless sensor(s) detects water and your options to facilitate the appropriate action. The Waterguard system is capable of controlling up to two valves per Hub for simultaneous control of two water pipelines (e.g. cold and warm water). Getting started Install the system Contact a certified installer and install the system. Download the Abra mobile application (optional) Download and install the Abra mobile application from App Store (Apple) or Google Play (Android). Register user account (optional) Setup your user account and register information about your home. Setup and configure your home If not already configured by the installer; consult the installation manual and follow the on-screen instructions to set up and configure your system, including paring wireless Water Sensors to the Hub. Waterguard Products - Overview Contents of the Waterguard base package for 1/2" and 3/4" valves 1. ABRA HUB The hub controls the Waterguard system and provides a physical control and signal interface to the user. 2. MOTORIZED BALL VALVE Waterguard motorized ball valves available in 1/2" (DN15) and 3/4" (DN20) sizes. 3. POWER ADAPTER 230V AC to 24V DC power supply for Hub 4. SENSOR TAPE 3 m long sensor tape with 3.5 mm Jack connector for installation to Hub, mounted to the floor in locations that may accumulate water from leakage. 5. VALVE CABLE 2 m long Cat.6 ethernet cable connecting the motorized ball valve to the Hub 6. HUB MOUNTING BRACKET AND MOUNTING KIT Bracket to securely mount the Hub to the wall using 2x screws (included). Contents of the Waterguard base package for 1" to 2" valves 1.ABRA HUB The hub controls the Waterguard system and provides a physical control and signal interface to the user. $OODFFHVVRULHVDUHVROGVHSDUDWHO\DQGSDFNDJHGVHSDUDWHO\ 2. POWER ADAPTER - SOLENOID VALVES 230 V AC supply for magnetic solenoid valve, 230V AC to 24V DC power supply and valve control interface for Hub 3. SENSOR TAPE 3 m long sensor tape with 3.5 mm Jack for installation in Hub, glued to the floor in places that may accumulate water from leakage 4. HUB MOUNTING BRACKET AND MOUNTING KIT Bracket to securely mount the Hub to the wall using 2x screws (included). Items bought separately 1. MAGNETIC SOLENOID VALVE Waterguard magnetic solenoid valves available in 1" (DN25), 1 1/4" (DN32), 1 1/2" (DN40) and 2" (DN50) sizes. 2. EXTENSION CABLE Extension cable to connect up to 3 magnetic solenoid valves in parallel for simultaneous operation. Accessories 1. WIRELESS WATER SENSOR Battery-powered, wireless water sensor with > 5 years battery change intervals and min. 20 m range (up to 100 m pending on installation conditions) 2. VALVE CABLE SPLITTER (AVAILABLE Q3/2022) Cable splitter for Valve Cable allowing simultaneous control of 2x ball valves (e.g. on hot and cold water supply in apartments with central water heater). 3. SENSOR TAPE EXTENSION CONNECTOR (AVAILABLE Q3/2022) Extension connector for Sensor Tape enabling the use of additional Sensor Tape (3m) for a total 6 m measurement range. NOTE: For additional range above 6 m, use the wireless Water Sensor. 4. SENSOR TAPE CABLE SPLITTER (AVAILABLE Q3/2022) Cable splitter for Sensor Tape w/3.5 mm Jack enabling simultaneous water detection on two (2x) Sensor Tapes. Accessories - Mounting Brackets 1. HUB - SAFETY BRACKET I&HAS (Intrusion & Hold-up Alarm System) compatible safety bracket for Hub Standard. Enab…

Text truncated - open the document above for the full version.

Fell Technology AS Date:2022/07/01 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Fell Technology AS the undersigned, hereby authorizes Mrs. Wendy Zhan from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Fell Technology AS solely in matters relating to the application for an FCC equipment authorization for FCC ID: 2AFOZW3701 including the signing of documents in connection with this Application. Necessary acts carried out Shenzhen Morlab Communications Technology Co., Ltd. on our behalf of the Fell Technology AS in connection with the Application shall have the same effect as acts of the Fell Technology AS. Fell Technology AS also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Thank you for your attention to this matter. Yours Sincerely, Signatory: Contact name: Fredrik Eriksen Title: CTO Tel: 004792412685 Email: [email protected] Company name: Fell Technology AS

Declaration To whom it may concern: We have declared below featured for FCC equipment authorization, Device FCC ID: 2AFOZW3701 Don't operate on Channels 12 and 13. US 2.4G channel 12-13 and Country code selection are disabled through proprietary software and are not user changeable Should you have any questions, please feel free to contact me. Date:2022/07/01 Signature : Title: Fredrik Eriksen, CTO Company name: Fell Technology AS

Fell Technology AS Date: 2022/07/01 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Request of Confidentiality for FCC ID: 2AFOZW3701 To Whom it may concern: Pursuant to sections 0.457 and 0.459 of Commission’s Rules (CFR 47), and Section 552(b)(4) of the Freedom of Information Act, Fell Technology AS hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days from grant date as outlined in Public Notice DA04-1705. This provision will give Fell Technology AS temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Operational Description 3 Schematics 4 BOM SHORT-TERM 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 User Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Signatory： Contact name: Fredrik Eriksen Title: CTO Tel: 004792412685 Email: [email protected] Company name: Fell Technology AS

Fell Technology AS Supplier’s Declaration Of Conformity for the FCC SDoC Procedure The following Equipment adapt FCC SDoC Procedure according to FCC part 2.906 : Product Name: Waterguard Hub Brand Name: Fell Technology AS Model Number: W3701 Report Number:SZ22020094E01 FCC ID: 2AFOZW3701 It’s herewith confirmed to comply with the requirements of FCC Part 15 Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesire d operation. It is understood that each unit marketed is identical to the device as tested, and any changes to the device that could adversely affect the emission characteristics will require retest. The following importer / responsible party in United States: Not Available at Certification Stage Company Name: Fell Technology AS Company Address: Bragernes Torg 2 3017 Drammen Norway Telephone: 004792412685 Fax: 32828280 Person is responsible for marking this declaration: Fredrik Eriksen CTO ____________________________________ ______________________________________ Name (Full name ) Position / Title 2022.07.01 ____________________________________ ______________________________________ Legal Signature Date

FCC ID: 2AFOZW3701, IC: 20622-W3701 External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

1、 Label 2、 Label location(on the back)

FCC ID: 2AFOZW3701, IC: 20622-W3701 Internal Photos 1. EUT uncover view 2. Antenna view CC1352R – Sub1 GHz CC1352P – Bluetooth/Zigbee ESP32-S2 - WiFi ME910G1-W1 – LTE Cat1

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 8 REPORT No.：SZ22020094S01 RF EXPOSURE EVALUATION REPORT APPLICANT : Fell Technology AS PRODUCT NAME : Waterguard Hub MODEL NAME : W3701 BRAND NAME : Fell Technology AS FCC ID : 2AFOZW3701 STANDARD(S) : FCC 47 CFR Part 2(2.1091) RECEIPT DATE : 2022-02-21 TEST DATE : 2022-04-02 to 2022-04-29 ISSUE DATE : 2022-08-11 Edited by: Xie Yiyun (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22020094S01 Page 2 of 8 DIRECTORY 1. Technical Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.1 Applicant and Manufacturer Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.2 Equipment under Test (EUT) Description ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.3 Applied Reference Documents ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 4 2. Device Category and RF Exposure Limit ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 3. RF Output Power ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 4. RF Exposure Assessment ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 Annex A General Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 8 Annex B Conducted Power Change History Version Date Reason for Change 1.0 2022-08-11 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22020094S01 Page 3 of 8 1. Technical Information Note: Provide by applicant. 1.1 Applicant and Manufacturer Information Applicant: Fell Technology AS Applicant Address: Bragernes Torg 2 3017 Drammen Norway Manufacturer: Fell Technology AS Manufacturer Address: Bragernes Torg 2 3017 Drammen Norway 1.2 Equipment under Test (EUT) Description Product Name: Waterguard Hub EUT No.: 2# Hardware Version: 1.0.0 Software Version: 1.0.0 Frequency Bands: LTE CAT-M1 Band 2: 1850 MHz ~ 1910 MHz LTE CAT-M1 Band 4: 1710 MHz ~ 1755 MHz LTE CAT-M1 Band 12: 699 MHz ~ 716 MHz LTE CAT-M1 Band 13: 777 MHz ~ 787 MHz WLAN 2.4GHz: 2412 MHz ~ 2462 MHz Bluetooth: 2402 MHz ~ 2480 MHz ISM Band: 906.5MHz- 922.5MHz Modulation Mode: LTE: QPSK,16QAM 802.11b: DSSS 802.11g/n-HT20/40: OFDM Bluetooth LE: GFSK ISM: GFSK Antenna Type: WWAN: Fixed Internal Antenna WLAN: Fixed Internal Antenna ISM: Fixed Internal Antenna Antenna Gain: Frequency Bands Antenna Gain (dBi) LTE CAT-M1 Band 2 3.0 LTE CAT-M1 Band 4 3.0 LTE CAT-M1 Band 12 -0.5 LTE CAT-M1 Band 13 -0.5 MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22020094S01 Page 4 of 8 WLAN 2.4GHz 0.5 Bluetooth 0.50 ISM 1.40 Note: When the test result is a critical value, we will use the measurement uncertainty give the judgment result based on the 95% confidence intervals. 1.3 Applied Reference Documents Leading reference documents for testing: Identity Document Title Method determination /Remark FCC 47CFR Part 2(2.1091) Radio Frequency Radiation Exposure Assessment: mobile devices No deviation KDB 447498 D04v01 General RF Exposure Guidance No deviation Note 1: The test item is not applicable. Note 2: Additions to, deviation, or exclusions from the method shall be judged in the "method determination" column of add, deviate or exclude from the specific method shall be explained in the "Remark" of the above table. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22020094S01 Page 5 of 8 2. Device Category and RF Exposure Limit Per user manual, Based on 47CFR 2.1091, this device belongs to mobile device category with General Population/Uncontrolled exposure. Mobile Devices: 47CFR 2.1091(b) For purposes of this section, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. In this context, the term “fixed location” means that the device is physically secured at one location and is not able to be easily moved to another location. Transmitting devices designed to be used by consumers or workers that can be easily re-located, such as wireless devices associated w…
