LIGHTWAVE CAMP ROCKER LANTERN F-CAMPROCKER-BK QUICK START GUIDE BR-Manual-CampRocker 6.0.indd 19/9/15 3:45 PM 2 IMPORTANT Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. BEFORE FIRST USE Before first and every use, charge the unit battery fully following the instructions on “HOW TO CHARGE”. When the lantern is not in use for a long period, the runtime of the light will be shortened due to the self-discharge of the battery. PRODUCT FEATURES • 3 Light Modes: High, Low, Red Light • Integrated wireless BLUETOOTH® speaker connection, BLUETOOTH 3.0 Audio • BLUETOOTH On / Off power switch • Built in 3.7V 2600mAh Lithium Battery • DC 5V/2.1A USB output, for charging USB electronic devices • DC 5V/1A micro-USB input (Charger Port) • Connect audio cable (not included) directly to AUX audio plug to play music without BLUETOOTH connection 1. Integrated handle with hook 2. Main Button (Power and mode selection) 3. Battery Power Indicator (BPI) 4. USB cover 5. Micro-USB Charging Port 6. USB Output 7. BLUETOOTH “On / Off” Switch 8. Speaker 9. AUX audio plug (not included) 10. Micro-USB charging cable BR-Manual-CampRocker 6.0.indd 29/9/15 3:45 PM 3 2 3 8 5 6 7 9 4 10 SPECIFICATIONS Illumination (Lumens): High—120 Low—45 Runtime (ANSI FL-1 Standard): High—6 Hrs 15 Mins Low—22 Hrs Red —30 Hrs Battery Type: 3.7V 2600mAh Lithium battery Operating Temperature: -4 ̊F to 113 ̊F (-20 ̊C to 45 ̊C) Operating Humidity: ≤ 90% HOW TO CHARGE Fully charge the lantern using the supplied micro-USB charging cable. 1. Connect the micro-USB charging cable into the charging port at the back of the CAMP ROCKER, and the USB end of the micro-USB charging cable into your home power outlet (DC5V power sources}, computer, or other USB power source. Plug the USB charging cable into the USB port. 2. Standard charging time is approximately 4.5 hours. Be careful not to charge it for more than 8 hours. Over charging will damage the battery. NOTE: The charging time and the operation time may vary depending on the use environment. A. STATUS INDICATOR: The battery power indicator light indicates how much battery life remains for the mode in use. B. Light flashing = Charging C. All lights on = Fully charged 100% battery life D. Three lights on = Around 75% battery life E. Two lights on = Around 50% battery life F. One light on = Low battery > Below 25% battery life A BCDEF BR-Manual-CampRocker 6.0.indd 39/9/15 3:45 PM 4 OPERATING INSTRUCTIONS LIGHT FUNCTION To turn the lantern ON, press the main button. Adjust the light mode (High / Low / Red / Off) by pressing the main button. To turn the lantern OFF, press the main button once after Red light mode. AUDIO FUNCTION To play audio from a BLUETOOTH® device, you need to first pair the device with the lantern speaker. A. On your Bluetooth device, turn on BLUETOOTH and scan for devices in its Bluetooth menu. B. Turn BLUETOOTH switch to ‘on’ position on CAMP ROCKER inside USB charging door. The lantern speaker is discoverable for 2 minutes and is ready for pairing. A short sound will indicate the BLUETOOTH is on. C. The device code of this lantern “BRUNTON C-ROCKER” will appear on the device list of your BLUETOOTH device, select the lantern. The BLUETOOTH status will show on your BLUETOOTH menu after pairing is established. The lantern speaker is ready to play music. D. Adjust volume using controls on your BLUETOOTH device. If the BLUETOOTH turns off after five minutes without playing audio, it enters power saving mode. Slide the power switch off and then turn on to wake the BLUETOOTH, and try pairing your device again. Repeat step 3. The lantern speaker operates with a single pair devices mode. If you pair the speaker with another device, the device least recently connected needs to be un-paired with the speaker first. Repeat steps 2 and 3 above Connect audio cable (not included) directly to AUX audio plug to play music without BLUETOOTH connection. B C > > SEARCHING A ON Select this CONNECT BRUNTON C-ROCKER PAIRED POWER BANK FUNCTION 1. Select the suitable USB charging cable (different devices require different charging cables for charging). 2. Plug the USB cable into lantern USB output port, then plug the other side of the cable into the charging device (mobile, tablet, etc.) The device will then start charging. BR-Manual-CampRocker 6.0.indd 49/9/15 3:45 PM 5 3. When the lantern battery is discharged, it will stop charging. Discharging battery will also disable light functionality until recharged. NOTE: Different devices require different charging cables for charging - Cable(s) not included. TROUBLE SHOOTING The lantern speaker doesn’t work or it won’t pair: • Try moving your device closer. • Is the lantern turned on and charged? • Is BLUETOOTH enabled on your device or computer? • Turn the BLUETOOTH off and then on to wake it. • Try repeating the …

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/14/2015 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AFQH-CAMPROCKER including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature Company Officer: Trent Bush Company address： 1900 Taylor Ave. Louisville, CO 80027 USA Email: [email protected]

Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 9/8/2015 Request for Confidentiality Company name: Brunton Outdoor Inc. FCC ID: 2AFQH-CAMPROCKER FCC Part 15 Certification Gentlemen, In accordance with CFR 47 § 0.459, Brunton Outdoor Inc. hereby requests confidentiality of following attachments: (1) schematic diagrams, (2) parts lists. (3)block diagrams (4)operational description These documents contain detailed system and equipment description and related information about the product which Brunton Outdoor Inc. considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Brunton Outdoor Inc. considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Company Officer: Trent Bush Company address： 1900 Taylor Ave. Louisville, CO 80027 USA Email: [email protected]

External Photos TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT VIEW OF EUT (PORT)

FCC ID Label Location FCC ID: 2AFQH‐CAMPROCKER CAMP ROCKER

Internal Photos OPEN VIEW OF EUT INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4 INTERNAL VIEW OF EUT-5 INTERNAL VIEW OF EUT-6 INTERNAL VIEW OF EUT-7 INTERNAL VIEW OF EUT-8 Antenna INTERNAL VIEW OF EUT-9

Declaration concerning Antenna Specification It is hereby declared that the product Model No.:CAMP ROCKER FCC ID: 2AFQH-CAMPROCKER fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for PCB antenna type described below: Model No. of antenna: N/A Type of antenna: PCB Antenna (Permanent Antenna) Gain of the antenna: 0 dBi Frequency range: 2.402 GHz to 2.480GHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Brunton Outdoor Inc. Address: 1900 Taylor Ave. Louisville, City: CO ZIP / Postal code: 80027 Country: USA Place: CO Date: 2015-09-14 Signature:

RF Exposure evaluation Product Description:LIGHTWAVE LANTERN Model Number: CAMP ROCKER FCC ID: 2AFQH-CAMPROCKER According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation According to the follow transmitter output power（P t ）formula： P t =（E x d） 2 /（30 x g t ） P t =transmitter output power in watts g t =numeric gain of the transmitting antenna (unitess) E=electric field strength in V/m d=measurement distance in meters (m) According to the above test data, Emax=92.56dBuv/m=0.042V/m,d=3m,g t =1 P t =（E x d） 2 /（30 x g t ）=(0.042x3) 2 /(30x1)=0.000529W=0.53mW The result is rounded to one decimal place for comparison Worse case is as below: [2441MHz -0.53mW output power] (0.53mW /5mm) .[√2.441(GHz)]= 0.166<3.0 for 1-g SAR Then SAR evaluation is not required NOTE: For the maximum power, you can refer FCC test report.
