2AFQL-SC3003BOOM TOWER

Dear Valued customers, thanks for your choosing this product. In order to better understand its performance and use it safely, please read this user manual carefully before using. ProductFeatures: 1. Support iphone, ipad, Samsung, HTC, MP3/MP4, laptops and other devices with Bluetooth function. Also support TF card and 3.5mm AUX IN. 2. With Hand-free function, Built-in microphone for clear voice call. 3. Built-in LED lights show that pulses to your music. 4. Built-in high quality loudspeaker to guarantee the perfect sound of playing music. 5 Built-in 3.7V/2300mAh rechargeable lithium battery, can be charged by connecting to PC via USB cable. Also can be charged by 5V/1A AC charger. ProductSpecifications: 01. Working Mode: Bluetooth/TF Card/AUX IN 02.LED Light Mode: 5 modes (2 modes – LEDs follows the music to dance, 3 modes – LEDsdance without music) 03.Music Format: MP3,WMA,WAV,APE,FLAC etc 04.Audio Output Power: 2 x 5W 05. Frequency Response: 100Hz-20KHz 06.Maximum SPL: 80db 07.Volume: Total 8 levels(voice prompt will occur when it comes to the highest and lowest) 08.Bluetooth Version: 4.0 09.Operation Range: 10M 10.Connecting Cable: 3.5mm stereo audio cable 11.Battery Type: Lithium(built-in)3.7V 2300mAh 12.Working Time: 5 hours 13.Charge Time: 3 hours (Indicator light goes to red when charging, and turns to green when fully charged) 14. Power: DC 5.0V/1A BluetoothParing Step 1: Turn on the speaker (voice prompt will occur when it successfully be turned on). Step 2: Activate your Bluetooth function on your phone or tablet and searchthe name ‘ColourFull’ to pair, no password needed (voice prompt will occur when pairing succeeds). Hand-free: While playing music, just press Pause button to answer calls when call comes, and then you can communicate handsfree through the speaker, and press it again to end the call. (This automatic switch may be slightly different sue to the differences of cell phone brands, if not available, please answer calls on your phone) PackingList: Portable stereo bluetooth speaker LED lighting 1pcs 3.5mm stereo audio cable 1pcs USB cable 1pcs User manual 1pcs Troubleshooting: 1.C annot pair with Bluetooth Pls make sure the Bluetooth speaker is fully charged and can be searched. 2.No Sound Pls check and make sure the Bluetooth speaker is fully charged and volume is not at the lowest. 3.B luetooth speaker cannot be turned on Make sure the Bluetooth is with battery, check the status of indicator light. Caution: When the speaker is not use, please turn the power switch to the “OFF” to avoid unnecessary power loss. Not e: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device.

DATE:Spet1,2015 EquipmentAutorisationDivision FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 FCCID:2AFQL-SC3003 ProductName:BOOMTOWER RequestforConfidentiality PursuanttoSections0.457and0.459ofthecommissionsrules,weherebyrequestthat thefollowingdocumentsbeheldconfidential: (Listherethedocumentsforwhichyouareseekingconfidentiality–forexample...)  Schematics Blockdiagram Operationdescription Thesematerialscontaintradesecretsandproprietaryinformationandarenot customarilyreleasedtothepublic.Thepublicdisclosureofthisinformationmightbe harmfultothecompanyandprovideunjustifiedbenefitstoourcompetitors. Dated this Agencyagreementexpirationdate:Spet1,2015toAugust31,2016 By:BRIANCHAN SignaturePrinted Title:manager Onbehalfof:DUSTSTUDIOLTD Telephone:35684706

SC3003Labelinformation FCCID：2AFQL-SC3003 ThisdevicecomplieswithPart15oftheFCCrules.Operationissubjecttothefollowingtwo conditions:1)thisdevicemaynotcauseharmfulinterference,and2)thisdevicemustaccept anyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.

RF Exposure evaluation report RF Exposure Compliance Requirement 1. Standard Requirement 15.247(b)(4) requirement: The conducted output power limit specified in paragraph (b) of this section is based on the use of antennas with directional gains that do not exceed 6dBi. Except as shown in paragraph (c) of this section. if transmitting antennas of directional gain greater than 6dBi are used. the conducted output power from the intentional radiator shall be reduced below the stated values in paragraphs (b)(1). (b)(2). and (b)(3) of this section. as appropriate. by the amount in dB that the directional gain of the antenna exceeds 6dBi. 2. Limits According to KDB447498 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances
50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]  [  f(GHz)]
3.0 for 1-g SAR and
7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is
50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 3. EUT RF Exposure The Max Conducted Peak Output Power is 2.133 dBm (1.63mW) in low channel and the Max Conducted Average Output Power is less than 1.63mW. The best case gain of the antenna is 0dBi. 1.63 /5*  2.480=0.51
3.0 Conclusion: No SAR is required.

Report No. : EED32H000894-1Page 1 of 64 1COVER PAGE TEST REPORT Product:BOOM TOWER Trade mark:SOUNDCANDY Model/Type reference :SC3003 Serial Number:N/A Report Number:EED32H000894-1 FCC ID:2AFQL-SC3003 Date of Issue:July 23, 2015 Test Standards: 47 CFR Part 15 Subpart C (2014) Test result:PASS Prepared for: DUST STUDIO LTD 7/f, Flat B-03, Cheong Wah Factory Building, Tokwawan, Kowloon, HK Prepared by: Centre Testing International Group Co., Ltd. Hongwei Industrial Zone, Bao’an 70 District, Shenzhen, Guangdong, China TEL: +86-755-3368 3668 FAX: +86-755-3368 3385 Tested by:Reviewed by: Approved by:Date:July 23, 2015 Sheek Luo Lab supervisor Check No.: 1022581390 Report No. : EED32H000894-1Page 2 of 64 2 Version Version No.DateDescription 00 July 23, 2015 Original Report No. : EED32H000894-1Page 3 of 64 3TestSummary Test ItemTest RequirementTest methodResult Antenna Requirement 47 CFR Part 15 Subpart C Section 15.203/15.247 (c) ANSI C63.10-2013PASS AC Power Line Conducted Emission 47 CFR Part 15 Subpart C Section 15.207 ANSI C63.10-2013PASS Conducted Peak Output Power 47 CFR Part 15 Subpart C Section 15.247 (b)(1) ANSI C63.10-2013PASS 20dB Occupied Bandwidth 47 CFR Part 15 Subpart C Section 15.247 (a)(1) ANSI C63.10-2013PASS Carrier Frequencies Separation 47 CFR Part 15 Subpart C Section 15.247 (a)(1) ANSI C63.10-2013PASS Hopping Channel Number 47 CFR Part 15 Subpart C Section 15.247 (b) ANSI C63.10-2013PASS Dwell Time 47 CFR Part 15 Subpart C Section 15.247 (a)(1) ANSI C63.10-2013PASS Pseudorandom Frequency Hopping Sequence 47 CFR Part 15 Subpart C Section 15.247(b)(4)&TCB Exclusion List (7 July 2002) ANSI C63.10-2013PASS RF Conducted Spurious Emissions 47 CFR Part 15 Subpart C Section 15.247(d) ANSI C63.10-2013PASS Radiated Spurious emissions 47 CFR Part 15 Subpart C Section 15.205/15.209 ANSI C63.10-2013PASS Test according to ANSI C63.4-2014 & ANSI C63.10-2013. Report No. : EED32H000894-1Page 4 of 64 4 Content 1COVERPAGE..................................................................................................................................................................... 1 2 VERSION..............................................................................................................................................................................2 3 TEST SUMMARY................................................................................................................................................................3 4CONTENT.............................................................................................................................................................................4 5 TEST REQUIREMENT.......................................................................................................................................................5 5.1 T EST SETUP................................................................................................................................................................... 5 5.1.1For Conducted test setup...................................................................................................................................5 5.1.2For Radiated Emissions test setup...................................................................................................................5 5.1.3For Conducted Emissions test setup............................................................................................................... 6 5.2 T ESTENVIRONMENT......................................................................................................................................................6 5.3 T ESTCONDITION............................................................................................................................................................6 6 GENERAL INFORMATION...............................................................................................................................................7 6.1 C LIENTINFORMATION.................................................................................................................................................... 7 6.2 G ENERALDESCRIPTION OFEUT..................................................................................................................................7 6.3 P RODUCTSPECIFICATION SUBJECTIVE TO THIS STANDARD........................................................................................7 6.4 D ESCRIPTION OFSUPPORTUNITS...............................................................................................................................8 6.5 T ESTLOCATION............................................................................................................................................................. 8 6.6 T ESTFACILITY................................................................................................................................................................8 6.7 D EVIATION FROMSTANDARDS...................................................................................................................................... 9 6.8 A BNORMALITIES FROMSTANDARDCONDITIONS..........................................................................................................9 6.9 O THERINFORMATIONREQUESTED BY THECUSTOMER..............................................................................................9 6.10 M EASUREMENTUNCERTAINTY(95%CONFIDENCE LEVELS,K=2)......................................................................... 10 7EQUIPMENTLIST............................................................................................................................................................ 11 8 RADIO TECHNICAL REQUIREMENTS SPECIFICATION........................................................................................15 Appendix A) 20dB Occupied Bandwidth............................................................................…
