2AFSSMD-01Bluetooth Speaker

User’s Guide 1. Introduction 2. Battery Precautions 3. Getting Started 4. Bluetooth Connection 5. Function Guidance 6. LED Display Status 7. Microphone Usage 8. Battery Charging 9. Product Care 2 3 4 5 6 6 6 7 7 Please read the following safety warning and precaution before using your device. Contents -1- Power supply: Li-ion battery or USB cable Audio source: iPhone, iPad, Smartphone, Notebook, MP3, MP4, etc Function spec: Bluetooth, Microphone, Line-in Size:89.5mm x 74mm x 27mm Rechargeable battery with charging from USB cable -2- 1. Introduction Thank you for purchasing the MD-01, this device can be easily connected with smartphone, Tablet PC and other devices via Bluetooth during your outdoor activities or other daily use. It will bring you an easy lifestyle. Specifications MD-01 Output Power: 3W Frequency range: 2402MHz-2480MHz 2. Battery Precautions The device can be powered by a built-in rechargeable lithium battery. Please charge the battery for at least 8 hours before your first use of device. If the device is not used for a long period of time, the battery may be out of power. Please charge the battery. Rechargeable battery is only to be charged under adult supervision. Only use the supplied USB cable to charge the battery. Improper charging may damage the battery and the device. Do not attempt to open the rechargeable battery or battery pack. There aren't serviceable parts inside. Should a battery leak, the device may become damaged. Clean the battery compartment immediately, avoiding touching your skin. Keep the battery out of reach from children. If swallowed, consult a physician immediately. Avoid storing the battery in extremely hot or cold environment. A device with a hot or cold battery may not work temporarily, even when the battery is fully charged. Do not dispose battery in a fire as it may explode. Battery may also explode if damaged. Please dispose it according to local regulation. Do not dispose it as household waste. -3- 3. Getting Started -4- Long Press/Volume Down Short Press/Previous Short Press/Next Long Press/Volume Up Play/Pause/ LED MIC AUX/BT button USB port Answer/End a call -5- Notice: 4. Bluetooth Connection Pair MD-01 to your tablet or smartphone. 1. 2. 3. 4. 5. 6. 7. Activate pairing mode on MD-01 by switching”AUX/BT” button to “BT”.The LED will flash in blue color. On your device, navigate to the Bluetooth function (refer to the tablet owner’s manual to locate Bluetooth function). Select “Set Up” Bluetooth and turn “ON” Bluetooth. Select “Search” and “Discover” devices. Select “MD-01”. If requested, type the password 0000. Press the Enter key. After completing the steps above, a message on your tablet will appear to confirming that your device is now paired/connected. In case of unsuccessful pairing, turn off it and restart it to "BT", then do as steps above. 1.If you turn off the device, but the Bluetooth on your smart phone remains open, when you restart the device, the Bluetooth will be connected automatically. 2.When your smartphone and this speaker are apart beyond bluetooth receiving range, after 10 minutes, this speaker will disconnect with your smartphone and turn into pairing mode. If within 10 minutes your smartphone is back, will connect with this speaker automatically. 3.If long press “ ” buttom, the speaker will be disconnected and ready to pair with other smartphones. -6- 6. LED Display Status 7. Microphone Usage 5. Function Guidance Function Volume up/ Next song Play music from your MD-01. Volume down/ Previous song Play/Pause/Answer/End a call Button When a phone call comes in, you could talk through the microphone on speaker. Two short press the pause button, you could call the last number you called on your call records. LED Display Flash slowly Stay solid Stay solid OFF Light indication It’s ready to pair It's paired charging in process Fully charged Blue Light Red Light 8. Battery Charging 9. Product care -7- The device has a built-in rechargeable lithium battery that can be charged by connecting to the USB port of your computer. When it’s charging, the light will turn to red. After charging, the device can be used without the power connection. Your device is designed to be light, compact and durable. As an electronic device, it must be treated carefully. Putting unnecessary pressure on it or striking the device against other objects may cause damage. To avoid damage to your device please Do not drop, crush, bend or apply excessive force to the device. Do not expose your device to moisture, extreme or prolonged heat, cold, humidity, or other adverse conditions. Avoid storing it in damp, humid or wet places, as it is not waterproof. Clean the unit with a soft cloth or damp chamois leather. Never use solvents. The Unit can Only be opened by qualified personnel. This device contains magnets. Keep magnetic field sensitive products such as credit cards and video screen away from this device to avoid damage or malfunction. FCC Warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 Shenzhen MeiDong Acoustics Co., Ltd. 2016-1-20 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Shenzhen MeiDong Acoustics Co., Ltd. hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Bluetooth Speaker, MD-01 FCC ID: 2AFSSMD-01 Sincerely, Signature Li Jian/Manager E-mail: [email protected] Phone: +86-755-29166636 Fax: +86-755-29166636 Address: Cell B, 3th Floor, Tower B, Hongzhuyongqi Technology Park, Lezhujiao, Xixiang, Baoan,Shenzhen, Guangdong, China

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.0 5.0 Nov 19 2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 5.0 Shenzhen MeiDong Acoustics Co., Ltd. 2016-1-20 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AFSSMD-01 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Signature Li Jian/Manager E-mail: [email protected] Phone: +86-755-29166636 Fax: +86-755-29166636 Address: Cell B, 3th Floor, Tower B, Hongzhuyongqi Technology Park, Lezhujiao, Xixiang, Baoan,Shenzhen, Guangdong, China

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

FCC ID Label Bluetooth Speaker Model No.: MD‐01 Trade name: cowin FCC ID: 2AFSSMD‐01 Made in China FCC ID label Location

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT ANT Photo 3 Photo 4

FCC ID: 2AFSSMD-01 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz； Power and distance are rounded to the nearest mW and mm before calculation； The result is rounded to one decimal place for comparison； The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. We use 5mm as separation distance to calculate. Maximum measured transmitter power: BT DSS: Transmit Frequency (GHz) Mode Measured Power (dBm) Tune-up power (dBm) Max tune-up Result 1-g SAR power(dBm) calculation 2.402 GFSK 0.42 0±1 1 0.3902 3 2.441 GFSK 0.44 0±1 1 0.3934 3 2.48 GFSK -0.24 0±1 1 0.3965 3 2.402 π/4-DQPSK 0.52 0±1 1 0.3902 3 2.441 π/4-DQPSK 0.53 0±1 1 0.3934 3 2.48 π/4-DQPSK -0.12 0±1 1 0.3965 3 2.402 8DPSK 0.52 0±1 1 0.3902 3 2.441 8DPSK 0.53 0±1 1 0.3934 3 2.48 8DPSK -0.15 0±1 1 0.3965 3 Conclusion: For the max result : 0.3965≤ 3.0 for 1-g SAR extremity SAR, No SAR is required. Signature: Date: 2016-1-20 NAME AND TITLE (Please print or type): Brown Lu/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China.

FCC RADIO TEST REPORT-BT FCC ID:2AFSSMD-01 Product： Bluetooth Speaker Trade Name： cowin Model Name： MD-01 Serial Model： N/A Report No.： NTEK-2015NT12253576F Prepared for Shenzhen MeiDong Acoustics Co., Ltd. Cell B, 3th Floor, Tower B, Hongzhuyongqi Technology Park, Lezhujiao, Xixiang, Baoan,Shenzhen, Guangdong, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 74 Report No.:NTEK-2015NT12253576F TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen MeiDong Acoustics Co., Ltd. Address ................................. : Cell B, 3th Floor, Tower B, Hongzhuyongqi Technology Park, Lezhujiao, Xixiang, Baoan,Shenzhen, Guangdong, China Manufacture's Name ............ : Shenzhen MeiDong Acoustics Co., Ltd. Address ................................. : Cell B, 3th Floor, Tower B, Hongzhuyongqi Technology Park, Lezhujiao, Xixiang, Baoan,Shenzhen, Guangdong, China Product description Product name ........................... : Bluetooth Speaker Model and/or type reference : MD-01 Serial Model： N/A Standards ............................. : FCC Part15.247: 01 Oct. 2015 Test procedure .............................. ANSI C63.10-2013 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 25 Dec. 2015 ~16 Jan. 2016 Date of Issue ........................................... : 16 Jan. 2016 Test Result ............................................... : Pass Testing Engineer : (Susan Su) Technical Manager : (Brown Lu) Authorized Signatory : (Sam Chen) Page 3 of 74 Report No.:NTEK-2015NT12253576F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 12 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 13 3 . EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 14 3.1.2 TEST PROCEDURE 15 3.1.3 DEVIATION FROM TEST STANDARD 15 3.1.4 TEST SETUP 15 3.1.5 EUT OPERATING CONDITIONS 15 3.1.6 TEST RESULTS 16 3.2 RADIATED EMISSION MEASUREMENT 24 3.2.1 RADIATED EMISSION LIMITS 24 3.2.2 TEST PROCEDURE 25 3.2.3 DEVIATION FROM TEST STANDARD 25 3.2.4 TEST SETUP 26 3.2.5 EUT OPERATING CONDITIONS 27 3.2.6 TEST RESULTS (BELOW 30 MHZ) 28 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 29 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 31 4 . NUMBER OF HOPPING CHANNEL 33 4.1 APPLIED PROCEDURES / LIMIT 33 4.1.1 TEST PROCEDURE 33 4.1.2 DEVIATION FROM STANDARD 33 4.1.3 TEST SETUP 33 4.1.4 EUT OPERATION CONDITIONS 33 4.1.5 TEST RESULTS 34 5 . AVERAGE TIME OF OCCUPANCY 35 5.1 APPLIED PROCEDURES / LIMIT 35 Page 4 of 74 Report No.:NTEK-2015NT12253576F Table of Contents Page 5.1.1 TEST PROCEDURE 35 5.1.2 DEVIATION FROM STANDARD 35 5.1.3 TEST SETUP 36 5.1.4 EUT OPERATION CONDITIONS 36 5.1.5 TEST RESULTS 37 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 43 6.1 APPLIED PROCEDURES / LIMIT 43 6.1.1 TEST PROCEDURE 43 6.1.2 DEVIATION FROM STANDARD 43 6.1.3 TEST SETUP 43 6.1.4 EUT OPERATION CONDITIONS 43 6.1.5 TEST RESULTS 44 7 . BANDWIDTH TEST 50 7.1 APPLIED PROCEDURES / LIMIT 50 7.1.1 TEST PROCEDURE 50 7.1.2 DEVIATION FROM STANDARD 50 7.1.3 TEST SETUP 50 7.1.4 EUT OPERATION CONDITIONS 50 7.1.5 TEST RESULTS 51 8 . PEAK OUTPUT POWER TEST 57 8.1 APPLIED PROCEDURES / LIMIT 57 8.1.1 TEST PROCEDURE 57 8.1.2 DEVIATION FROM STANDARD 57 8.1.3 TEST SETUP 57 8.1.4 EUT OPERATION CONDITIONS 57 8.1.5 TEST RESULTS 58 9 . 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE 64 9.1 DEVIATION FROM STANDARD 64 9.2 TEST SETUP 64 9.3 EUT OPERATION CONDITIONS 64 9.4 TEST RESULTS 65 10 . ANTENNA REQUIREMENT 72 10.1 STANDARD REQUIREMENT 72 10.2 EUT ANTENNA 72 11 . EUT TEST PHOTO 73 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 74 Report No.:NTEK-2015NT12253576F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 74 Report No.:NTEK-2015NT12253576F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 74 Report No.:NTEK-2015NT12253576F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Bluet…

Text truncated - open the document above for the full version.

Radiated Measurement Photos CONDUCTED EMISSION Photos
