2AFWY-BS01DA01Blustream Portable Sensor

Protected by HUMIDITRAK™ USER GUIDE SET UP AND USE 1. Download and launch the D’Addario Humiditrak app. 2. IMPORTANT!! – Before removing the ribbon from the battery case of your new Humiditrak sensor, move to a location at least 30 feet away from any other active Humiditrak sensors to ensure the best pairing experience! 3. Remove the ribbon from the battery housing and place the Humiditrak sensor within six inches of your smart phone or tablet. 4. Follow the on screen instructions to begin pairing the sensor. 5. See http://www.blustream.com/humitrak-setup for detailed instructions, video guide, and troubleshooting tips. SAFETY AND HANDLING. WARNING. Please read all safety and operating instructions before operating this device. BATTERY. Always use the recommended type of battery. Keep batteries away from children. Keep batteries away from heat. Replace depleted batteries before reaching 5% remaining power. If Humiditrak device is to be unused for several months, remove battery. SERVICE AND REPAIR. Your Humiditrak device should be returned to the manufacturer in the event any of the following events occur which seem to inhibit the device’s function or causes the device to deliver inaccurate, erratic, or intermittent data. (1) The internal electronics are damaged; (2) the device has been submerged or subjected to any introduction of liquids or other significant moisture; (3) the device has obvious signs of damage from impact; (4) any indication that the information relayed to the smart phone app deviates significantly from the observed environmental conditions. FCC AND IC STATEMENTS OF COMPLIANCE FCC COMPLIANCE. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING. Changes or modifications not expressly approved by D’Addario and Blustream could void the user’s authority to operate the equipment. INTERFERENCE. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna; (2) Increase the separation between the equipment and receiver; (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected; (4) Consult the dealer or an experienced radio/TV technician for help. IC WARNING. This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. EXPOSURE TO RADIO ENERGY. This portable transmitter with its antenna complies with FCC and Industry Canada RF exposure limits for general population / uncontrolled exposure. WARRANTY INFORMATION ONE YEAR LIMITED WARRANTY. D’Addario and Company, Inc. (“D’Addario”) warrants to the original purchaser (“Purchaser”) of this D’Addario product, for the period of one (1) year following the date on which Purchaser purchases the product, that the product shall be free of defects in design, assembly, material, or workmanship. D’Addario will repair or replace, at its option, any defective product free of charge. In order to qualify for this warranty, the Purchaser must provide the defective product and a copy of the original receipt of purchase, to D’Addario for inspection. The receipt of purchase must indicate the product purchased, price paid, date of purchase, and name of merchant. To request service under this warranty, contact D’Addario at 1-800- XXX-XXX or at [email protected]. This warranty shall be null and void if D’Addario determines that the product has been improperly installed, altered, mishandled, submerged in liquid, or tampered with any way. This warranty does not protect against normal use, wear and tear, or damage due to abuse. THIS WARRANTY CONTAINS THE SOLE WARRANTY OF D’ADDARIO. THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING THE IMPLIED WARRANTY OR CONDITION OF QUALITY, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY, ARE LIMITED IN DURATION TO THE TERM OF THIS WARRANTY. IN NO EVENT SHALL D’ADDARIO BE LIABLE FOR INCIDENTAL, SPECIAL, DIRECT, INDIRECT OR CONSEQUENTIAL DAMAGES SUCH AS, BUT NOT LIMITED TO, LOST BUSINESS OR PROFITS ARISING OUT OF THE SALE OR USE OF ANY D’ADDARIO PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some jurisdictions do not allow exclusions or limitations on implied warranties or incidental, consequential or other damages, so the above exclusions and limitations may not apply to you. TRADEMARK AND COPYRIGHT COPYRIGHT NOTICE. Copyright 2015 D’Addario and Company, Inc. No part of this manual may be reproduced or modified without written consent from D’Addario. D’Addario and Blustream Corporation are not liable or responsible for any operational or technical errors or omissions made in this manual. TRADEMARKS. Humiditrak is a trademark of D’Addario. Blustream and Blustream Technology are registered trademarks of Blustream Corporation.

Authority to Act as Agent Date: 10/9/15 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Thomas T. Smith, Ryan Urness and Amanda Hauck of LS Research, LLC is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal b enefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: 10/9/16 By: __________________________ Michael Audi Title: Co-founder On behalf of: bluStream Corporation Telephone: (518) 322-5627

Request for Confidentiality Date: October 9, 2015 Confidentiality Request for: FCC ID: 2AFWY-BS01DA01 IC ID: 12387A-BS01DA01 To Whom It May Concern, Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 6.4, the applicant requests that a part of the subject FCC and/or IC application be held confidential. The applicant requests the exhibits listed below be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Block Diagram Schematics Theory of operation Applicant has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Sincerely, (Signature) Name: Michael Audi Title: Co-founder Phone: (518) 322-5627 Email: [email protected]

EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS01DA01 FCC ID # 2AFWY‐BS01DA01 IC # 12387A‐BS01DA01 Page 1 of 2 EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS01DA01 FCC ID # 2AFWY‐BS01DA01 IC # 12387A‐BS01DA01 Page 2 of 2

Permenantly adhered polyproplene clear label with Pantone 877C Color Text & Graphics. Mounted to the front edge of the case. A digital mockup is shown in the second image. The label is 0.25"x0.75" in size.

INTERNAL PHOTOS Company Name Blustream Corporation Model # BS01DA01 FCC ID # 2AFWY‐BS01DA01 IC # 12387A‐BS01DA01 Page 1 of 3 INTERNAL PHOTOS Company Name Blustream Corporation Model # BS01DA01 FCC ID # 2AFWY‐BS01DA01 IC # 12387A‐BS01DA01 Page 2 of 3 INTERNAL PHOTOS Company Name Blustream Corporation Model # BS01DA01 FCC ID # 2AFWY‐BS01DA01 IC # 12387A‐BS01DA01 Page 3 of 3

W66 N220 Commerce Court ● Cedarburg, WI 53012 Phone: 262.375.4400 ● Fax: 262.375.4248 www.lsr.com SAR Test Exclusion Exhibit For: Blustream Portable Sensor Prepared by: Michael Hintzke, EMC Engineer 10/20/15 W66 N220 Commerce Court ● Cedarburg, WI 53012 ● www.lsr.com Contents Product Description: ................................................................................................................................ 3 Associated Antenna: ................................................................................................................................ 3 Statement of compliance:........................................................................................................................ 3 Data and Calculations: ............................................................................................................................. 4 W66 N220 Commerce Court ● Cedarburg, WI 53012 ● www.lsr.com Product Description: The sensor uses patent pending intelligent technology to provide a constant stream of temperature and humidity data to an application on your smart phone to warn of hazardous conditions and prevent costly repairs, lost value of your valuable object. When the sensor detects dangerous conditions within its installed environment, push notifications are sent to your device, allowing you to take corrective action before damage occurs to your object. Associated Antenna: The antenna associated with the EUT is a trace antenna. The antenna has a peak gain of 1.26 dBi. Statement of compliance: The Blustream Portable Sensor was evaluated against the SAR test exclusion threshold listed in KDB 447498 D01 General RF Exposure Guidance v05r02 for 1-g body at a distance of 5mm, as well as, RSS-102 Issue 5 for a body-supported device at a distance of 5 mm. W66 N220 Commerce Court ● Cedarburg, WI 53012 ● www.lsr.com Data and Calculations: The EUT was evaluated against the SAR test exclusion threshold listed in KDB 447498 D01 General RF Exposure Guidance v05r02, section 4.3 (1). The EUT was found to be compliant with the SAR exclusion threshold, 1-g extremity, for 100MHz to 6000MHz. Frequency = 2.480 GHz ERP (dBm) = 1.1 dBm + 1 dBm (tune-up tolerance) = 2.1 dBm ERP (mW) = 1.6 mW Minimum separation distance ≤ 5mm [1.6mw/5mm]*[√2.48GHz] = 0.5 0.5 ≤ 3.0 When evaluated against RSS 102 issue 5 section 2.5, table 1: Frequency = 2.480 GHz EIRP (dBm) = 1.1 dBm + 1.3dBi + 1 dBm (tune-up tolerance) = 3.4 dBm EIRP (mW) = 2.2 mW Interpolating between 2450 and 3500 MHz for 2480 MHz at separation distance of 5 mm yields exemption limit of 3.94 mW 2.2 mW < 3.9 mW W66 N220 Commerce Court ● Cedarburg, WI 53012 ● www.lsr.com Screen Capture of maximum output power W66 N220 Commerce Court ● Cedarburg, WI 53012 ● www.lsr.com MPE Calculation: The following MPE calculations are based on a measured conducted RF power of +1.1 dBm as presented to the antenna plus 1 dBm for the tune-up tolerance. The peak gain of this antenna is 1.26 dBi.

W66 N220 Commerce Court ● Cedarburg, WI 53012 Phone: 262.375.4400 ● Fax: 262.375.4248 www.lsr.com Title Page ENGINEERING TEST REPORT #: 314310 LSR JOB #: C-2120 Compliance Testing of: Blustream Portable Sensor Test Date(s): 2/5/15 4/6/15 4/21/15 7/29/15 8/21/15 2/6/15 4/13/15 4/29/15 7/30/15 8/24/15 4/2/15 4/20/15 7/16/15 8/6/15 9/1/15 Prepared For: bluStream Corporation Attn: Michael Audi 3212 W. Wheeler St., Suite 111 Seattle, WA 98199 This Test Report is issued under the Authority of: Michael Hintzke, EMC Engineer Signature: Date: 10/21/15 Reviewed by: Khairul Aidi Zainal, Engineering Manager-EMC Test Services Signature: Date: 10/21/15 Project Engineer: Michael Hintzke, EMC Engineer Signature: Date: 10/21/15 This Test Report may not be reproduced, except in full, without written approval of LS Research, LLC. Prepared For: BluStream Corporation Name: Blustream Portable Sensor Report: TR 314310 Model: BS01DA01 LSR: C-2120 Serial: Engineering Sample Page 2 of 48 TABLE OF CONTENTS i. Title Page ........................................................................................................................... 1 TABLE OF CONTENTS ............................................................................................................. 2 3.0 Client Information .......................................................................................................... 5 3.1 Equipment Under Test (EUT) Information ..................................................................... 5 3.2 Product Information........................................................................................................ 5 3.3 Modifications Incorporated In the EUT for Compliance Purposes................................... 5 3.4 Deviations & Exclusions from Test Specifications .......................................................... 5 3.5 Additional Information ................................................................................................... 5 4.0 Conditions of Test .......................................................................................................... 6 5.0 Test Equipment .............................................................................................................. 6 6.0 Conformance Summary .................................................................................................. 7 Appendix A – Test Equipment.................................................................................................. 8 Appendix B – Test Data ........................................................................................................... 9 B.1 – RF Conducted Emissions ................................................................................................ 9 B.2 – Radiated Emissions ....................................................................................................... 26 Appendix C - Uncertainty Summary ....................................................................................... 46 Appendix D - References ........................................................................................................ 47 Prepared For: BluStream Corporation Name: Blustream Portable Sensor Report: TR 314310 Model: BS01DA01 LSR: C-2120 Serial: Engineering Sample Page 3 of 48 LS Research, LLC in Review As an EMC Testing Laboratory, our Accreditation and Assessments are recognized through the following: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025: 2005 with Electrical (EMC) Scope of Accreditation A2LA Certificate Number: 1255.01 Federal Communications Commission (FCC) – USA Listing of 3 Meter Semi-Anechoic Chamber based on Title 47 CFR – Part 2.948 FCC Registration Number: 90756 Industry Canada On file, 3 Meter Semi-Anechoic Chamber based on RSS-212 – Issue 1 File Number: IC 3088-A On file, 3 and 10 Meter OATS based on RSS-212 – Issue 1 File Number: IC 3088 U. S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U. S. Competent Body operating under the U. S./EU, Mutual Recognition Agreement (MRA) operating under the European Union Electromagnetic Compatibility –Council Directive 2004/108/EC (formerly 89/336/EEC, Article 10.2). Date of Validation: January 16, 2001 Validated by the European Commission as a U.S. Notified Body operating under the U.S. /EU, Mutual Recognition Agreement (MRA) operating under the European Union Telecommunication Equipment – Council Directive 99/5/EC, Annex V. Date of Validation: November 20, 2002 Notified Body Identification Number: 1243 Prepared For: BluStream Corporation Name: Blustream Portable Sensor Report: TR 314310 Model: BS01DA01 LSR: C-2120 Serial: Engineering Sample Page 4 of 48 Summary of Test Report Between February 2015 and September 2015 the EUT, Blustream Portable Sensor, as provided by bluStream Corporation, was tested and MEETS the following requirements: FCC and IC Paragraph Test Requirements Compliance (Yes/No) FCC:15.247 (a)(2) IC: RSS 247 Section 5.2 (1) 6 dB Bandwidth of a Digital Modulation System Yes FCC : 15.247(b) & 1.1310 IC : RSS 247 Section 5.4 (4) Maximum Output Power Yes FCC:15.247 (d) IC: RSS 247 Section 5.2 (2) Power Spectral Density of a Digital Modulation System Yes FCC :15.247(d) IC : RSS 247 Section 5.5 RF Conducted Spurious Emissions at the Transmitter Antenna Terminal Yes FCC : 15.247(c), 15.209 & 15.205 IC : RSS 247 Section 5.5 Transmitter Radiated Emissions Yes FCC : 15.109 IC : RSS GEN Receive Mode (Digital Device) Radiated Emissions Yes FCC : 2.1055 (d) Frequency Stability Yes FCC : 15.207 IC : RSS GEN sect. 7.2.2 Power Line Conducted Emissions Measurements N/A 1 Note 1: Device is only powered from battery. Test Facilities All testing was performed at: LS Research, LLC W66 N220 Commerce Court Cedarburg, Wisconsin, 53012 USA LS Research, LLC is accredited by A2LA (American Association for Laboratory Accreditation) to the requirements of ISO/IEC 17025, 2005 “General…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS Company Name Blustream Corporation Model # BS01DA01 FCC ID # 2AFWY‐BS01DA01 IC # 12387A‐BS01DA01 Page 1 of 2 TEST SETUP PHOTOS Company Name Blustream Corporation Model # BS01DA01 FCC ID # 2AFWY‐BS01DA01 IC # 12387A‐BS01DA01 Page 2 of 2
