2AFWY-BS10TY01Blustream In Instrument Sensor

Protected by TAYLORSENSE™ USER GUIDE SET UP AND USE 1 . Download and launch the Taylor Owner’s app. 2. IMPORTANT!! – Before connecting to your TaylorSe nse, move to a location at least 30 feet away from any other active TaylorSens e sensors to ensure the best pairing experience! 3. Remove and replace the 9V battery then place the TaylorSense sensor within six inches of your smart phone or tablet. 4. Follow the on screen instructions to begin pairi ng the sensor. 5. See http://www.blustream.com/taylorsense-setup f or detailed instructions, video guide, and troubleshooting tips. SAFETY AND HANDLING. WARNING. Please read all safety and operating instructions before operating this device. BATTERY. Always use the recommended type of battery. Keep b atteries away from children. Keep batteries away from heat. Repl ace depleted batteries before reaching 10% remaining power. To preserve battery life, do not leave an instrument cord plugged into your guitar when not i n use. SERVICE AND REPAIR. In the United States and Canada, please contact Tay lor Guitars at our El Cajon, California service center at 1-800-943-6782 between the hours of 8:00 AM and 4:30 PM PST. FCC AND IC STATEMENTS OF COMPLIANCE FCC COMPLIANCE. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) thi s device may not cause harmful interference, and (2) this device must accept any i nterference received, including interference that may cause undesired operation. WARNING. Changes or modifications not expressly approved b y Taylor and Blustream could void the user’s authority to operat e the equipment. INTERFERENCE. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Pa rt 15 of the FCC Rules. These limits are designed to provide reasonable protection again st harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used i n accordance with the instructions, may cause harmful interference to rad io communications. However, there is no guarantee that interference will not oc cur in a particular installation. If this equipment does cause harmful interference t o radio or television reception, which can be determined by turning the equipment of f and on, the user is encouraged to try to correct the interference by on e or more of the following measures: (1) Reorient or relocate the receiving an tenna; (2) Increase the separation between the equipment and receiver; (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected; (4) Consult the dealer or an experienced radio/TV techn ician for help. IC WARNING. This device complies with Industry Canada license-e xempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device mus t accept any interference, including interference that may cause undesired ope ration of the device. EXPOSURE TO RADIO ENERGY. This portable transmitter with its antenna complies with FCC and Industry Canada RF exposure l imits for general population / uncontrolled exposure. TRADEMARK AND COPYRIGHT COPYRIGHT NOTICE. Copyright 2015 Taylor Guitars. No part of this ma nual may be reproduced or modified without written consent f rom Taylor Guitars. Taylor Guitars and Blustream Corporation are not liable or responsible for any operational or technical errors or omissions made i n this manual. TRADEMARKS. Taylor Guitars. TAYLOR, TAYLOR (Stylized); TAYLO R GUITARS, TAYLOR QUALITY GUITARS and Design are registered tr ademarks of the company. TaylorSense is a trademark of the company. Blustre am and Blustream Technology are trademarks of Blustream Corporation.

Authority to Act as Agent Date: 10/9/15 American Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 To Whom It May Concern: Thomas T. Smith, Ryan Urness and Amanda Hauck of LS Research, LLC is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal b enefits, that includes FCC benefits. Thank you, Agency Agreement Expiration Date: 10/9/16 By: __________________________ Michael Audi Title: Co-founder On behalf of: bluStream Corporation Telephone: (518) 322-5627

Request for Confidentiality Date: October 9, 2015 Confidentiality Request for: FCC ID: 2AFWY-BS10TY01 I C ID: 12387A-BS10TY01 To Whom It May Concern, Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 6.4, the applicant requests that a part of the subject FCC and/or IC application be held confidential. The applicant requests the exhibits listed below be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Block Diagram Schematics Theory of operation Applicant has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Sincerely, (Signature) Name: Michael Audi Title: Co-founder Phone: (518) 322-5627 Email: [email protected]

EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 1 of 5 EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 2 of 5 EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 3 of 5 EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 4 of 5 Close up of antenna EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 5 of 5

SilkscreenBottom-1_1_1.pho Scale=2.61 Thu Dec 10 17:17:20 2015 SilkscreenTop-1_1_1.pho Scale=2.61 Thu Dec 10 17:17:20 2015

EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 1 of 5 EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 2 of 5 EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 3 of 5 EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 4 of 5 Close up of antenna EXTERNAL PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 5 of 5

W66 N220 Commerce Court ● Cedarburg, WI 53012 Phone: 262.375.4400 ● Fax: 262.375.4248 www.lsr.com SAR Test Exclusion Exhibit For: Blustream In Instrument Sensor Prepared by: Michael Hintzke, EMC Engineer 10/20/15 W66 N220 Commerce Court ● Cedarburg, WI 53012 ● www.lsr.com Contents Product Description: ................................................................................................................................ 3 Associated Antenna(s): ............................................................................................................................ 3 Statement of compliance:........................................................................................................................ 3 Data and Calculations: ............................................................................................................................. 4 W66 N220 Commerce Court ● Cedarburg, WI 53012 ● www.lsr.com Product Description: The sensor uses patent pending intelligent technology to provide a constant stream of temperature and humidity data to an application on your smart phone to warn of hazardous conditions and prevent costly repairs, lost value of your valuable object. When the sensor detects dangerous conditions within its installed environment, push notifications are sent to your device, allowing you to take corrective action before damage occurs to your object. Associated Antenna(s): The antenna associated with the EUT is a trace antenna. The antenna has a peak gain of 2.27 dBi. Statement of compliance: The Blustream In Instrument Sensor was evaluated against the SAR test exclusion threshold listed in KDB 447498 D01 General RF Exposure Guidance v05r02 for 1-g body at a distance of 5mm, as well as, RSS-102 Issue 5 for a body-supported device at a distance of 5mm. W66 N220 Commerce Court ● Cedarburg, WI 53012 ● www.lsr.com Data and Calculations: The EUT was evaluated against the SAR test exclusion threshold listed in KDB 447498 D01 General RF Exposure Guidance v05r02, section 4.3 (1). The EUT was found to be compliant with the SAR exclusion threshold, 1-g extremity, for 100MHz to 6000MHz. Frequency = 2.440 GHz ERP (dBm) = 1.1 dBm + 1 dBm (tune-up tolerance) = 2.1 dBm ERP (mW ) = 1.6 milliwatt Minimum separation distance ≤ 5mm [1.6mw/5mm]*[ √2.44GHz] = 0.5 0.5 ≤ 3.0 When evaluated against RSS 102 issue 5 section 2.5, table 1: Frequency = 2.480 GHz EIRP (dBm) = 1.1 dBm + 2.3 dBi + 1 dBm (tune-up tolerance) = 4.4 dBm EIRP (mW) = 2.75 mW Interpolating between 2450 and 3500 MHz for 2480 MHz at separation distance of 5 mm yields exemption limit of 3.94 mW 2.75 mW < 3.94 mW W66 N220 Commerce Court ● Cedarburg, WI 53012 ● www.lsr.com Screen Capture of maximum output power W66 N220 Commerce Court ● Cedarburg, WI 53012 ● www.lsr.com MPE Calculation: The following MPE calculations are based on a measured conducted RF power of +1.1 dBm as presented to the antenna. The peak gain of this antenna 2.27 dBi.

W66 N220 Commerce Court ● Cedarburg, WI 53012 Phone: 262.375.4400 ● Fax: 262.375.4248 www.lsr.com ENGINEERING TEST REPORT #: 314312 LSR JOB #: C-2122 Compliance Testing of: Blustream In Instrument Sensor Test Date(s): 2/4/15 4/2/15 7/16/15 8/5/15 8/21/15 2/5/15 4/20/15 7/29/15 8/6/15 8/24/15 4/1/15 4/21/15 7/30/15 8/20/15 9/1/15 Prepared For: bluStream Corporation Attn: Michael Audi 3213 W. Wheeler St., Suite 111 Seattle, WA 98199 This Test Report is issued under the Authority of: Michael Hintzke, EMC Engineer Signature: Date: 10/23/15 Reviewed by: Peter Feilen, EMC Engineer Signature: Date: 10/23/15 Project Engineer: Michael Hintzke, EMC Engineer Signature: Date: 10/23/15 This Test Report may not be reproduced, except in full, without written approval of LS Research, LLC. Prepared For: bluStream Corporation Name: Blustream In Instrument Sensor Report: TR 314312 Model: BS10TY01 LSR: C-2122 Serial: Engineering Sample Page 2 of 48 TABLE OF CONTENTS TABLE OF CONTENTS ............................................................................................................. 2 3.0 Client Information .......................................................................................................... 5 3.1 Equipment Under Test (EUT) Information ..................................................................... 5 3.2 Product Information........................................................................................................ 5 3.3 Modifications Incorporated In the EUT for Compliance Purposes................................... 5 3.4 Deviations & Exclusions from Test Specifications .......................................................... 5 3.5 Additional Information ................................................................................................... 5 4.0 Conditions of Test .......................................................................................................... 6 5.0 Test Equipment .............................................................................................................. 6 6.0 Conformance Summary .................................................................................................. 7 Appendix A – Test Equipment.................................................................................................. 8 Appendix B – Test Data ........................................................................................................... 9 B.1 – RF Conducted Emissions ................................................................................................ 9 B.2 – Radiated Emissions ....................................................................................................... 26 Appendix C - Uncertainty Summary ....................................................................................... 46 Appendix D - References ........................................................................................................ 47 Prepared For: bluStream Corporation Name: Blustream In Instrument Sensor Report: TR 314312 Model: BS10TY01 LSR: C-2122 Serial: Engineering Sample Page 3 of 48 LS Research, LLC in Review As an EMC Testing Laboratory, our Accreditation and Assessments are recognized through the following: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025: 2005 with Electrical (EMC) Scope of Accreditation A2LA Certificate Number: 1255.01 Federal Communications Commission (FCC) – USA Listing of 3 Meter Semi-Anechoic Chamber based on Title 47 CFR – Part 2.948 FCC Registration Number: 90756 Industry Canada On file, 3 Meter Semi-Anechoic Chamber based on RSS-212 – Issue 1 File Number: IC 3088-A On file, 3 and 10 Meter OATS based on RSS-212 – Issue 1 File Number: IC 3088 U. S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U. S. Competent Body operating under the U. S./EU, Mutual Recognition Agreement (MRA) operating under the European Union Electromagnetic Compatibility –Council Directive 2004/108/EC (formerly 89/336/EEC, Article 10.2). Date of Validation: January 16, 2001 Validated by the European Commission as a U.S. Notified Body operating under the U.S. /EU, Mutual Recognition Agreement (MRA) operating under the European Union Telecommunication Equipment – Council Directive 99/5/EC, Annex V. Date of Validation: November 20, 2002 Notified Body Identification Number: 1243 Prepared For: bluStream Corporation Name: Blustream In Instrument Sensor Report: TR 314312 Model: BS10TY01 LSR: C-2122 Serial: Engineering Sample Page 4 of 48 Summary of Test Report Between February 2015 and September 2015 the EUT, Blustream In Instrument Sensor, as provided by bluStream Corporation, was tested and MEETS the following requirements: FCC and IC Paragraph Test Requirements Compliance (Yes/No) FCC:15.247 (a)(2) IC: RSS 247 Section 5.2 (1) 6 dB Bandwidth of a Digital Modulation System Yes FCC : 15.247(b) & 1.1310 IC : RSS 247 Section 5.4 (4) Maximum Output Power Yes FCC:15.247 (d) IC: RSS 247 Section 5.2 (2) Power Spectral Density of a Digital Modulation System Yes FCC :15.247(d) IC : RSS 247 Section 5.5 RF Conducted Spurious Emissions at the Transmitter Antenna Terminal Yes FCC : 15.247(c), 15.209 & 15.205 IC : RSS 247 Section 5.5 Transmitter Radiated Emissions Yes FCC : 15.109 IC : RSS GEN Receive Mode (Digital Device) Radiated Emissions Yes FCC : 2.1055 (d) Frequency Stability Yes FCC : 15.207 IC : RSS GEN sect. 7.2.2 Power Line Conducted Emissions Measurements N/A 1 Note 1: Device is only powered from battery. Test Facilities All testing was performed at: LS Research, LLC W66 N220 Commerce Court Cedarburg, Wisconsin, 53012 USA LS Research, LLC is accredited by A2LA (American Association for Laboratory Accreditation) to the requirements of ISO/IEC 17025, 2005 “General Requirements for the Competence of Calibration and Testing Laboratories”. LS Research, LLC’s scope of accreditation includes all test methods listed herein, u…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 1 of 4 TEST SETUP PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 2 of 4 TEST SETUP PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 3 of 4 TEST SETUP PHOTOS Company Name Blustream Corporation Model # BS10TY01 FCC ID # 2AFWY‐BS10TY01 IC # 12387A‐BS10TY01 Page 4 of 4
