2AFXO-EUREKAMinut Eureka wireless module

www.minut.com EurekaWirelessModule IntegrationUserManual 2023-11-06 HVIN:MT-EUREKA 1Features ● IEEE802.11b/g/nWLANradio ● Bluetooth5.2radio ● 2xARMCortex-Mmicrocontrollerforuserapplication ● USB-Cportfordatatransfer,powersupplyanddebugging ● 8MBNORFlash ● Fullyintegratedpowerregulationwithwideunregulatedoperatingrange ● Airqualitysensor(temperature/humidity/pressure/VOC)(optional) ● Accelerometer(optional) ● MonoClassDamplifierfordrivinganexternalspeaker(optional) 2Pindescription ConnectorJ1 PinnumberNameDescription 1GNDModuleGround 2VBATModulePowerInput 3TXModuleTransmitData(Applicationspecific) 4RXModuleReceiveData(Applicationspecific) Minut,Inc. 440NBarrancaAve#8080,Covina,CA91723 [email protected] www.minut.com 3Specifications ParameterValueUnit StorageTemperature-20...+70Celsius OperatingTemperature-10...+50Celsius Supplyvoltage(VBAT)2.0...5.0Volt WLANFrequencyrange2400...2500 1 MHz WLANTransmitpower(conducted)≤20dBm BLEFrequencyrange2400...2483.5MHz BLETransmitpower(conducted)≤6dBm 1 ThisisthefulltunablerangeasspecifiedintheWLANradiodatasheet.Itisfurtherrestrictedbasedoncountry settings,suchthattheactualrangeintheUSandCanadais2401-2473MHz(channels1-11). Minut,Inc. 440NBarrancaAve#8080,Covina,CA91723 [email protected] www.minut.com 4ModuleUserRequirements 4.1USA-FCC ThisdevicecomplieswithPart15oftheFCCRuleswhenoperatingwiththeembeddedantenna. Operationissubjecttothefollowingtwoconditions: 1.Thisdevicemaynotcauseharmfulinterference,and 2.Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause undesirableoperation. AnychangesormodificationsnotexpresslyapprovedbyMinut,Inc.couldvoidtheuser’sauthorityto operatetheequipment. ListofapplicableFCCRules ● 47CFRPart15,SubpartC15.203 ● 47CFRPart15,SubpartC15.205 ● 47CFRPart15,SubpartC15.207 ● 47CFRPart15,SubpartC15.209 ● 47CFRPart15,SubpartC15.247 ● 47CFRPart2.1091 Approvedoperationaluseconditions ThemoduleistobeusedinIOTdevices.Theinputvoltagetothemoduleisnominally2-5V. Limitedmoduleprocedures Themoduleisnotalimitedmodule. Traceantennadesigns Theantennaisnotatraceantenna. FCCRFRadiationExposureStatement ThisModulecomplieswithFCCradiationexposurelimitssetforthforanuncontrolledenvironment. Thisequipmentshouldbeinstalledandoperatedwithaminimumdistanceof20cmbetweenthe radiatorandyourbody.Thistransmittermustnotbeco-locatedoroperatinginconjunctionwithany otherantennaortransmitter. Antennachangenotice Ifyoudesiretoincreaseantennagainandeitherchangeantennatypeorusesameantennatype certified,aClassIIpermissivechangeapplicationisrequiredtobefiledbyus,oryou(host manufacturer)cantakeresponsibilitythroughthechangeinFCCID(newapplication)procedure followedbyaClassIIpermissivechangeapplication. OEMResponsibilitiestocomplywithFCCRegulations ThismodulehasbeentestedforcompliancetoFCCPart15.Ithasbeentestedasasubsystem,and itscertificationdoesnotcovertheFCCPart15SubpartB(unintentionalradiator)rulerequirement. OEMintegratorsareresponsiblefortestingtheirend-productforanyadditionalcompliance requirementsneededwiththismoduleinstalled(e.gradiatedemissions). Minut,Inc. 440NBarrancaAve#8080,Covina,CA91723 [email protected] www.minut.com End Product Labeling § 15.19 Labelling requirements shall be c omplied on the end user device. Labelling rules for special devices, please refer to §2.925, § 15.19 (a)(5) and relevant KDB publications. For E-label, please refer to §2.935. Information on test modes and additional testing requirements The OEM integrator is responsible for ensuring that the end-user has no manual instruction to remove or install the module. The module is limited to installation in mobile applications, a separate approval is required for all other operating configurations, including portable configurations with respect to §2.1093 and different antenna configurations. Test software to access different test modes: p2radio Testing item, frequencies, transmit power, modulation type can be selected following the test script instructions. The module is labeled with its own FCC ID. If the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. In that case, the final end product must be labeled in a visible area with the following: ●“Contains FCC ID: 2AFXO-EUREKA” ●“Contains Transmitter Module FCC ID: 2AFXO-EUREKA” The OEM integrator is responsible for ensuring that no information is provided to the end user regarding how to install or remove the module or how to change RF related parameters. Class B Device Notice - Part 15B Compliance Requirements for Host product manufacturer This modular transmitter is only FCC authorized for the specific rule parts listed on our grant, the host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not covered by the modular transmitter grant of certification. Host manufacturer in any case shall ensure the host product, in which the module is installed and operating, is compliant with Part 15B requirements. Please note that for a Class B or Class A digital device or peripheral, the instructions furnished the user manual of the end-user product shall include the statement set out in§15.105 Information to the useror such similar statement and place it in a prominent location in the text of the host product manual. Original texts as following: Note:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to ra…

Text truncated - open the document above for the full version.

SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Declaration Applicant Legal Business Name Minut, Inc. Address 440 N Barranca Ave #8080 Covina California 91723 United States Grantee Code 2AFXO FCC ID2AFXO-EUREKA Authorized Contact Name Fredrik Ahlberg Contact Email [email protected] Contact Phone +46705518852 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1)labeling the equipment with the exact FCC ID as specified in this application, (2)compliance statement labeling pursuant to the applicable rules, (3)compliance of the equipment with the applicable technical rules, c)if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1)the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2)the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3)the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [ Minut, Inc.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [ Minut, Inc. ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature:Date: 2023-09-13 Print Name: Fredrik Ahlberg Title: Co-founder *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023Page 1 of 1 Original Issue: Jan. 4, 2021

UNITEDSTATESDESIGNATEDAGENTLETTER Date:2023-09-06 TO:FederalCommunicationCommission EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MID21046 ApplicantU.S.designatedagent CompanyName:Minut,Inc.CompanyName:Minut,Inc. GranteeCode:2AFXOFRN0024886939 ContactName:FredrikAhlbergContactName:FredrikAhlberg Address:440NBarrancaAve#8080 CovinaCalifornia91723 UnitedStates Address:440NBarrancaAve#8080 CovinaCalifornia91723United States City/Province/Zip:City/Province/Zip: Telephone:+46705518852Telephone:+46705518852 Fax:Fax: Email:[email protected]:[email protected] ApplicableEquipment:FCCID:2AFXO-EUREKA ATTN:DirectorofCertification: We,Minut,Inc.understandandacknowledgetheapplicantsconsentandthedesignatedagent’s obligationtoacceptserviceofprocessintheUnitedStatesformattersrelatedtotheapplicable equipment,andatthephysicalU.S.addressande-mailofthedesignatedagentlistedabove. We,Minut,Inc.acknowledgetheapplicant’sacceptanceofitsobligationtomaintainanagentforservice ofprocessintheUnitedStatesfornolessthanoneyearaftereitherthegranteehaspermanently terminatedallmarketingandimportationoftheapplicableequipmentwithintheU.S.,ortheconclusionof anyCommission-relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheverislater. ApplicantU.S.designatedagent Name (Printed) : FredrikAhlberg Name (Printed) : FredrikAhlberg Title: Co-founder Title: Co-founder Signature:Signature:

www.minut.com 2023-09-13 TO:FederalCommunicationCommission EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MID21046 Regarding:FCCID:2AFXO-EUREKA Towhomitmayconcern: We,theundersigned,herebyauthoriseSGS-CSTCStandardsTechnicalServicesCo.,Ltd.(SGS) ShenzhenBranchandKenyXuinSGS-CSTCStandardsTechnicalServicesCo.,Ltd.(SGS) ShenzhenBranchtoactonourbehalfinallmannersrelatingtoapplicationforequipment authorizationwithrespecttotheFCCIDabove,includingsigningofalldocumentsrelatingto thesematters.Anyandallactscarriedoutbytheagentonourbehalfshallhavethesameeffect asactsofourown.. We,theundersigned,herebycertifythatwearenotsubjecttoadenialoffederalbenefits,that includesFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21U.S.C. 853(a). Whereouragentsignstheapplicationforcertificationonourbehalf,Iacknowledgethatall responsibilityforcomplyingwiththetermsandconditionsforCertification,asspecifiedbySGS NorthAmerica,Inc.,stillresideswithMinut,Inc. Thisauthorizationisvaliduntilfurtherwrittennoticefromtheapplicant. Sincerely, FredrikAhlberg (Signature)(Printname) Title:Co-founderandHeadofHardware Onbehalfof: Minut,Inc. (CompanyName) Telephone:+46705518852 E-mail: [email protected] Minut,Inc. 440NBarrancaAve#8080,Covina,CA91723 [email protected]

www.minut.com 2023-09-13 To:FederalCommunicationCommission EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MID21046 Regarding:ConfidentialityRequestregardingapplicationforFCCID:2AFXO-EUREKA Longtermconfidentiality Pursuantto47CFRSection0.457and0.459ofthecommission’srules,theapplicanthereby requestsconfidentialtreatmentofthedocumentslistedbelow,associatedwiththecertification applicationreferencedabove. ● Schematic(s) ● BlockDiagrams ● OperationalDescription Thedocumentsabovecontainproprietaryinformationnotreleasedtothepublic.Publicdisclosure ofthisinformationmayproveharmfultothebusinessoftheapplicant. Sincerely, FredrikAhlberg (Signature)(Printname) Title:Co-founderandHeadofHardware Onbehalfof: Minut,Inc. (CompanyName) Telephone:+46705518852 E-mail: [email protected] Minut,Inc. 440NBarrancaAve#8080,Covina,CA91723 [email protected]

www.minut.com 2023-09-13 Request for Modular Approval In accordance with FCC Part 15, we,Minut,Inc., hereby request a modular level approval for the device listed below. The specified product,MinutEurekawirelessmodulewith its designed features and specified description, meets the requirements for Full modular approval as defined in FCC KDB996369, as outlined below. CompanyMinut, Inc. Model Name Minut Eureka Wireless Module Model NumberEureka FCC ID2AFXO-EUREKA Requirement in FCC KDB996369 Compliance 1. The modular transmitter must have its own RF shielding. The EUT has integrated RF shielding. See EUT photo. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. The EUT transmitters employ integrated, on-chip digital modulators that are not under the direct influence of any external inputs. External inputs to the EUT are buffered. Please see the Schematic Diagram. 3. The modular transmitter must have its own power supply regulation. The EUT has its own power supply regulation. Please see the Schematic Diagram. 4. The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The EUT meets the FCC antenna requirements; PCB trace antennas are integral to the EUT and permanently attached to the transceivers. Please see the EUT photo, schematic diagram and antenna test report. 5. The modular transmitter must be tested in a stand‐alone configuration, i.e., the module must not be inside another device during testing. The EUT was tested in a stand-along configuration, please see the test report and setup photo Minut,Inc. 440 N Barranca Ave #8080, Covina, CA 91723 [email protected] www.minut.com 6. The modular transmitter must be labelled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: 2AFXO-EUREKA” or “Contains FCC ID: 2AFXO-EUREKA” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. Please see the attached label sample for the FCC ID of this module, as well as the attached Users manual, where there are instructions to the OEM on how to label the end product. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are given in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). The EUT complies with RF exposure requirements. Minut,Inc. 440 N Barranca Ave #8080, Covina, CA 91723 [email protected] www.minut.com Sincerely, FredrikAhlberg (Signature)(Printname) Title:Co-founderandHeadofHardware Onbehalfof: Minut,Inc. (CompanyName) Telephone:+46705518852 E-mail: [email protected] Minut,Inc. 440NBarrancaAve#8080,Covina,CA91723 [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 2 External Photos for SZCR2308002797AT FCC ID: 2AFXO-EUREKA SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 2 EUT Constructional Details (EUT Photos)

www.minut.com EurekaLabel History RevisionDateAuthorChange 12023-08-23FAInitialrevision 22023-10-12FAAddedHVIN MinutAB.Registeredaddress:Baltzarsgatan23,21136,Malmö. Companyregistrationnumber:559006-3920. Email:[email protected]:SE559006392001 www.minut.com Theinformationispermanentlymarkedinthesilkscreenonthetopsideofthecircuitboardmodule. TheFCCIDandICIDare1.0mmhigh. MinutAB.Registeredaddress:Baltzarsgatan23,21136,Malmö. Companyregistrationnumber:559006-3920. Email:[email protected]:SE559006392001

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 2 Internal Photos for SZCR2308002797AT FCC ID: 2AFXO-EUREKA SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 2 EUT Constructional Details (EUT Photos) - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230800279704 Page: 1 of 12 Keny Xu EMC Laboratory Manager 1 Cover Page RF Exposure Report Application No.: SZCR2308002797AT Applicant: Minut, Inc. Address of Applicant: 440 N Barranca Ave #8080 Covina California 91723 United States Manufacturer: Minut, Inc. Address of Manufacturer: 440 N Barranca Ave #8080 Covina California 91723 United States Factory: Scanfil Malmö AB Address of Factory: Bronsyxegatan 6B, 213 75 Malmö, Sweden Equipment Under Test (EUT): EUT Name: Minut Eureka wireless module Model No.: Eureka Trade Mark: Minut FCC ID: 2AFXO-EUREKA Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2023-08-29 Date of Test: 2023-09-22 to 2023-10-11 Date of Issue: 2023-10-11 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230800279704 Page: 2 of 12 Revision Record Version Chapter Date Modifier Remark 01 2023-10-11 Original Authorized for issue by: Leo Li/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230800279704 Page: 3 of 12 2 Contents Page 1 COVER PAGE .............................................................................................................................. 1 2 CONTENTS .................................................................................................................................. 3 3 GENERAL INFORMATION ........................................................................................................... 4 3.1 GENERAL DESCRIPTION OF E.U.T. ............................................................................................ 4 3.2 DETAILS OF E.U.T. .................................................................................................................. 4 3.3 TEST LOCATION ...................................................................................................................... 6 3.4 TEST FACILITY ........................................................................................................................ 6 4 FCC RADIOFREQUENCY RADIATION EXPOSURE LIMITS ........................................................ 7 4.1 BLANKET 1 MW BLANKET EXEMPTION........................................................................................ 7 4.2 MPE-BASED EXEMPTION.......................................................................................................... 7 4.3 SAR-BASED EXEMPTION .......................................................................................................... 8 5 MEASUREMENT AND CALCULATION ...................................................................................... 11 5.1 MAXIMUM TRANSMIT POWER ................................................................................................... 11 5.2 RF EXPOSURE CALCULATION ................................................................................................. 12 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230800279704 Page: 4 of 12 3 General Information 3.1 General Description of E.U.T. Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Power supply: DC 3V For BLE: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.2 LE Data Rate: 1M/bps & 2M/bps Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: PCB Antenna Antenna Gain: -0.25dBi For 2.4G: Operation Frequency: 802.11b/g/n(HT20): 2412MHz to 2462MHz Modulation Type: 802.11b: DSSS (CCK, DQPSK, DBPSK);802.11g/n: OFDM (64QAM, 16QAM, QPSK, BPSK) Number of Channels: 802.11b/g/n(HT20):11 Channel Spacing: 5MHz Antenna Type: PCB Antenna Antenna Gain: -0.93dBi Remark: The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230800279704 Page: 5 of 12 Separation Distance Minimum test separation distance: 20cm Remark: This minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230800279704 Page: 6 of 12 3.3 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen Branch No. 1 Workshop, M-10, Middle Section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China. 518057. Tel: +86 755 2601 2053 Fax: +86 755 2671 0594 No tests were sub-contracted. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI (Member No. 1937) The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen EMC laboratory have been registered in accordance with the Regulations for Voluntary Control Measures with Registration No.: G-20026, R-14188, C-12383 and T-11153 respectively. • FCC –Designation Number: CN1336 SGS-CSTC Standa…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZEWM2308001289OA01 Rev.00 Page: 1 of 23 ANTENNA PASSIVE TEST REPORT Application No. ZEWM2308001289OA Applicant Minut AB Manufacturer Minut AB Product Name Minut Eureka wireless module Model No. Eureka_2.4GHz_Left/Right Standards ANSI/IEEE Std 149-2008 Date Initial Sample(s) Received 2023.08.31 Testing Start Date 2023.08.31 Testing Finish Date 2023.08.31 Report Issue Date 2023.09.11 * In the configuration tested, the EUT detailed in this report complied with the standards specified above. Prepared by Reviewed By Approved by SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZEWM2308001289OA01 Rev.00 Page: 2 of 23 Revision Version Report No. Version Date Memo ZEWM2308001289OA 00 2023.09.11 Initial creation of report SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZEWM2308001289OA01 Rev.00 Page: 3 of 23 TABLE OF CONTENTS 1 GENERAL INFORMATION ................................................................................................4 1.1 Testing Laboratory................................................................................................................................ 4 1.2 Details of Applicant .............................................................................................................................. 4 1.3 Details of Manufacturer ....................................................................................................................... 4 1.4 General Description of EUT................................................................................................................... 5 1.5 Test Procedure ..................................................................................................................................... 5 1.6 Test Specification ................................................................................................................................. 6 1.7 Laboratory Environment....................................................................................................................... 6 2 OTA MEASUREMENTS SYSTEM CONFIGURATION ....................................................7 2.1 Test Configuration ................................................................................................................................ 7 3 TEST EQUIPMENT LIST ....................................................................................................8 4 MEASUREMENT UNCERTAINTY ....................................................................................9 5 TEST RESULTS................................................................................................................. 10 6 PATTERN PLOTS ............................................................................................................ 14 6.1 Return Loss ......................................................................................................................................... 14 6.2 VSWR ................................................................................................................................................. 15 6.3 Stimulus ............................................................................................................................................. 16 7 2-D ANTENNA PATTERN(THETA=90°) .................................................................... 17 8 3-D ANTENNA PATTERN .............................................................................................. 18 9 THE EUT AND TEST CONFIGURATION ...................................................................... 20 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZEWM2308001289OA01 Rev.00 Page: 4 of 23 1 General Information 1.1 Testing Laboratory Test Lab SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Address No. 1 Workshop, M-10, Middle section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China 518057 Contact Ervin Li Tel. +86 18823369694 Fax +86-755-25328600 E-mail [email protected] 1.2 Details of Applicant Applicant’s Name Minut AB Applicant’s Address Baltzarsgatan 23, 211 36 Malmö, Sweden Contact HW Design Group Tel. N/A Fax N/A E-mail [email protected] 1.3 Details of Manufacturer Manufacturer’s Name Minut AB Manufacturer’s Address Baltzarsgatan 23, 211 36 Malmö, Sweden Contact HW Design Group Tel. N/A Fax N/A E-mail [email protected] SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: ZEWM2308001289OA01 Rev.00 Page: 5 of 23 1.4 General Description of EUT Device Description: Minut Eureka wireless module Device Manufacturer: Minut AB Device Model: Eureka_2.4GHz_Left/Right Hardware Version: N/A Software Version: N/A Antenna Dimensions: Left ： 14.40 x 4.90 x 0.68 mm Right ： 14.45 x 4.88 x 0.68 mm 1.5 Test Procedure Testing is performed according to the ANSI/IEEE Std 149-2008. SGS-C…

Text truncated - open the document above for the full version.
