2AG5FAD-10Automatic Panoramic Head

1.Never trigger the Automatic Panorama Head around flammable gas or liquid gas (such as gasoline and solvents)! There will be danger of explosion! 2.Only use the battery listed in this manual! 3.Never place the battery in high-temperature environment, such as under the sun or in the fire. 4.Remove the drained battery from the Automatic Panorama Head while the liquid exuding from the battery will damage the Automatic Panorama Head. 5.Note to protect the Automatic Panorama Head under extremely hot or damp environment! 6.Never unpack the Automatic Panorama Head by yourself during three kinds warranty ! There will be danger of electricity shock! Non professional personal can not fix the component in the Automatic Panorama Head. 7.The quick change of temperature will cause vapor condensation. if this kind of situation happen, should give the Automatic Panorama Head enough time to gradually adapt to the environment temperature. Thank you for purchasing this Automatic Panorama Head. Please read carefully this manual before using, and then use this Automatic Panorama Head correctly on the base of through understanding. Safty instruction ·Automatic electric control Li-ion battery head. ·Workable for independent brand . wireless remote control signal ·Make it real of 360 degree of timing.Rotating head as well as panorama shooting. ·Small and portable 24 G Automatic Panorama Head AD - 10 product features ·Canon,Nikon,Sony,Pentax etc.,SLR/ Micro single/Cellphone Gopro all universal. ·Exclusive use connect with Camera,Cell phone holder,Rotate plate and Tripod. The controller par t Mode key On/Off key Power switch Camera locking screw Increase/counterclockwise rotation key Reduce/ rotation key counterclockwise Select key Set/confirm key The bottom swivel table Battery compartment Firmware upgrade interface The shutter output interface Non-slip mat TFT color display 3/8 Universal interface 1/4 universal screw Locking wheel 21 Preparation before use Install You can surf the internet for accurate lens hode. Do not recommend using telephoto lens. 2.Screw the Automatic Panorama Head clockwise 3.Put the camera on the screw above of Automatic Panorama Head. Fix camera on the Automatic Panorama Head by toggle locking wheel in the direction shown by the mark. 4.Through the camera shutter lines to connect the camera shutter interface and Automatic Panorama Head shutter output interface. 1.Connecting Automatic Panorama Head to the screw of the tripod bearing platform. Installing the batter y 4.As shown in the figure battery Looking for the lens hold Applicable to the Automatic Panorama Head for 1 section 7.4 V 1500 mAh rechargeable lithium battery.This battery has large capacity and low of self-discharge rate and in no need of maintenance.Prompted when the battery is low,please remove the battery Charge.Turn off the power and remove the battery if long time no use.Never use any defected battery to this Automatic Panorama Head.·Do not short-circuit the battery positive and negative electrodes·Do not disassemble·Do not immersed in the water or into the fire·Charge only with the specified charger. 43 Use detail Turn on the controller power.If the power is low,it will display low- battery-power interface (As Image 1),please change the battery ; if the power is ok,it will display the power-up interface(Product logo and Model as Image 2).The system initialize: System initialization finish,it will display the main interface operation. (Image 3,4) Present operation mode: Moving Mode Rotating direction of the head: Anticlockwise: Clockwise: Head mode: (H horizontal) Count of the present number of shots Output status Free Focus signal output Shutter signal output Horizontal rotation Angale Number of horizontal shots Motor rotation speed grade Wireless channel Total number of shots Batter y voltage Voice prompt: on off System operation status Free Operate Pause 1,Low batter y power 2,Power-up interface 3,Operate the main interface Battery Low Parameter setting Receipt of the equipment, if you need to change the shooting parameters, please enter the main interface for setting its own parameters.Long press the [SET] button 3 seconds into the main settings interface. Horizontal rotation angle The number of shots in the horizontal direction Horizontal shooting direction Horizontal speed rating Shutter output time Wireless Channels 1.Moving Mode mode Short press the【SUB】button to choose Settings .Options conversion among moving mode ,360 panorama and settings ,short press the【SET】 button to enter the corresponding parameter Settings. If you want to quit setup state, long press the 【SET】 key to save and exit return to the initial interface. 360° Single panorama shooting mode According to the setted information such as rotation angles, number of shots,control the swivel platform to run to finish the shooting. Moving Mode ()Spor t Mode 360 Panorama Set the interface Moving Mode model parameters, according to [SUB] button to select parameters need to be modified (Shown in red), Press the [ADD] [DEC] button to modify the parameters. Parameter setting development [SET] button for 3 seconds to save and exit, if you want to change or cancel the setup mode, press the [START] button to cancel and return to the previous menu. Present operation mode:360 Panorama Panorama head operation mode can be divided into Moving model and 360 degrees panorama mode. 4,Operate the main interface 65 360 ° horizontal angle shooting Horizontal shooting direction Horizontal speed rating Shutter output dwell time Wireless Channels Note: After setting the parameters for each mode by pressing[SET] to save and exit, then re-open the round of shooting. Beeper Promtp button Reset Voice selection (Can not be set) Version Information 2. 360 Panorama mode Parameter setting and adjustment method are the same as Moving Mode. 3. Settings (Set the interface) In the setup interface, complete the buzzer and initialization Settings. Buzzer :Turn hints.on or off the buzzer …

Text truncated - open the document above for the full version.

Dec.-31-15 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AG5FAD-10 Product Name: Automatic Panoramic Head Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics Long-term confidential Block diagram Long-term confidential Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name Joyce chen Position Manager Company Name Yueqing Originality Photography Equipment Co., LTD Address Building A, Shenfang Industrial Estate, Shifan Town, Yueqing City, Zhejiang Province, China Tel 0577-62318835 Fax 0577-62381234 Email [email protected] [email protected]

Label 30mm 15mm Label FCC ID: 2AG5FAD-10 Yueqing Originality Photography Equipment Co., LTD Model name: Automatic Panoramic Head Model No.: AD‐10 This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: 2AG5FAD‐10 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison eirp = pt x gt = (EXd) 2 /30 where: pt = transmitter output power in watts, gt = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 d = measurement distance in meters (m)---3m So pt = (EXd) 2 /30 x gt Field strength = 86.87 dBuV/m @3m Ant gain 0 dBi; so Ant numeric gain=1 So pt={[10 (86.87/20) /10 6 x3] 2 /30x1 }x1000 mW =0.146 mW So ( 0.146 mW/5mm)x √ 2.404 GHz = 0.045 <3 Then SAR evaluation is not required
