RGB Gaming Monitor Riser With Embedded Qi Wireless Charger Model: STB-172-01 Input: 5V==0.5A Wireless charger input: 5V==3A,9V==2A,12V==1.5A Wireless charger output: 15W max serial number: xxxxxxxxx Importer: Name: xxxxx Address: xxxxx LUMI LEGEND CORPORATION 22/F., Building 1, Lisi Plaza, Huifeng East Road, Ningbo, China 315100 FCC ID: 2AG62STB-172 冗

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Antenna

China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070061-00 Page 27 of 30 5 MAXIMUM PERMISSIBLE EXPOSURE (MPE) 5.1 Applicable Standard According to subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According with KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 clause 3 c) According to 680106 D01 RF Exposure Wireless Charging App v03r01 clause 5 b) China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070061-00 Page 28 of 30 5.2 Block Diagram of Test Setup Note: 20 cm for Top test. China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070061-00 Page 29 of 30 5.3 Test Data: Serial Number: CR22070061-RF -S1 Test Date: 2022-08-11 Test Site: RF Test Mode: Transmitting Tester: Ted Min Test Result: Pass Environmental Conditions: Temperature: (°C) 26.8 Relative Humidity: (%) 57 ATM Pressure: (kPa) 100.3 Test Equipment List and Details: Manufacturer Description Model Serial Number Calibration Date Calibration Due Date Narda Electric and Magnetic Field Probe-Analyzer EHP-200AC 180ZX10204 2021-06-07 2024-06-06 * Statement of Traceability: China Certification ICT Co., Ltd (Dongguan) attests that all calibrations have been performed, traceable to National Primary Standards and International System of Units (SI). Test Data: H-Field Strength Frequency Range (kHz) Position A (A/m) Position B (A/m) Position C (A/m) Position D (A/m) Position E (A/m) 50% Limit (A/m) Limit (A/m) 110-148 0.176 0.1789 0.1845 0.3435 0.6775 0.815 1.63 Note: Test with 15cm distance from the center of the probe(s) to the edge of the device, 20 cm for top test. E-Field Strength Frequency Range (kHz) Position A (V/m) Position B (V/m) Position C (V/m) Position D (V/m) Position E (V/m) 50% Limit (V/m) Limit (V/m) 110-148 1.0249 0.3578 0.9766 2.5006 4.5358 307 614 Note: Test with 15cm distance from the center of the probe(s) to the edge of the device, 20 cm for top test. Result: Compliance China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070061-00 Page 30 of 30 Considerations of compliance 680106 D01 RF Exposure Wireless Charging App v03r01 clause 5 b: (1) Power transfer frequency is less than 1 MHz Yes, the operation frequency is 110-148 kHz. (2) Output power from each primary coil is less than or equal to 15 watts. Yes, the maximum output power of primary coil is 15 Watts. (3) The system may consist of more than one source primary coils, charging one or more clients. If more than one primary coil is present, the coil pairs may be powered on at the same time. The transfer system includes only single primary coil, and system detect and allow coupling only between individual pairs of coils. (4) Client device is placed directly in contact with the transmitter. Yes, client device is placed directly in contact with the transmitter (5) Mobile exposure conditions only (portable exposure conditions are not covered by this exclusion). Yes, mobile exposure conditions only. (6) The aggregate H-field strengths anywhere at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils that by design can simultaneously transmit, and while those coils are simultaneously energized, are demonstrated to be less than 50% of the applicable MPE limit. Yes, the test result for H and E-field strength less than 50% of the MPE limit. ***** END OF REPORT *****

TEST REPORT Applicant: Lumi Legend Corporation Address: 22/F., Building 1, Lisi Plaza, Huifeng East Road, Ningbo, China 315100 FCC ID: 2AG62STB-172 Product Name: RGB GAMING MONITOR RISER Model Number: STB-172-01 Standard(s): 47 CFR Part 15, Subpart C ANSI C63.10-2013 The above equipment has been tested and found compliance with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: CR22070061-00 Date Of Issue: 2022-08-29 Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China Tel: +86-769-82016888 China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070061-00 Page 2 of 30 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the No. 113, Pingkang Road, Dalang Town, Dongguan, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. China Certification ICT Co., Ltd (Dongguan) Report No.: CR22070061-00 Page 3 of 30 CONTENTS TEST FACILITY ............................................................................................................................................................. 2 DECLARATIONS ............................................................................................................................................................ 2 1. GENERAL INFORMATION ................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 1.2 DESCRIPTION OF TEST CONFIGURATION ................................................................................................................ 5 1.2.2 Support Equipment List and Details .............................................................................................................. 5 1.2.3 Support Cable List and Details ...................................................................................................................... 5 1.2.4 Block Diagram of Test Setup ......................................................................................................................... 6 1.3 MEASUREMENT UNCERTAINTY .............................................................................................................................. 7 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 8 3. REQUIREMENTS AND TEST PROCEDURES ................................................................................................... 9 3.1 AC LINE CONDUCTED EMISSIONS .......................................................................................................................... 9 3.1.1 Applicable Standard ....................................................................................................................................... 9 3.1.2 EUT Setup.................................................................................................................................................... 10 3.1.3 EMI Test Receiver Setup ............................................................................................................................. 10 3.1.4 Test Procedure ............................................................................................................................................. 11 3.1.5 Corrected Amplitude & Margin Calculation ................................................................................................ 11 3.2 RADIATION SPURIOUS EMISSIONS ........................................................................................................................ 12 3.2.1 Applicable Standard ..................................................................................................................................... 12 3.2.2 EUT Setup.................................................................................................................................................... 12 3.2.3 EMI Test Receiver & Spectrum Analyzer Setup ......................................................................................... 13 3.2.4 Corrected Amplitude & Margin Calculation ................................................................................................ 14 3.3 ANTENNA REQUIREMENT ..................................................................................................................................... 14 3.3.1 Applicable Standard ..................................................................................................................................... 14 3.3.2 Judgment .................................................…
