2AG7C-BABY5MBaby Monitor

Hangzhou Meari Technology Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Apr 01, 2026
Application Purpose: Original Equipment
Equipment Note: Baby Monitor
Frequency Range: 905.00000000 - 925.00000000
Company: Hangzhou Meari Technology Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Baby 5M Please consult this checklist for all parts. In the Box 1 Quick guide X1Power adapter X1 Power cable X1RESET pin X1 Monitor X1 2 DC 5V/2APower supply DescriptionName Status light of charging Orange light: Charging Green light: Fully charged Camera switch Press to switch between cameras bound to the screen MenuAccess the settings and options DirectionNavigate and select options OKConfirm selections or wake the screen CallMake a call after pressing the button BackPress to back up; Long press to stop playing music Menu OK Call Back Microphone Status light of charging Zoom in/out Direction Camera switch RESET Micro SD card slot Power port ON/OFF button Volume button Stand Speaker Antenna Baterry cover plate Zoom in/outAdjust the image magnification in 1X, 2X or 4X 3 ON/OFF buttonLong press 5 seconds to turn on/turn off the monitor AntennaAdjust the angle to get better signals Micro SD card slot Micro SD card storage (up to 128GB) RESETPress with pin to reset the monitor DescriptionName Battery cover plate Cannot be removed for individual charging, used for battery maintenance and environmental requirements (Factory specific batteries are required) Volume buttonPress to adjust the volume 4 Monitor Using Tips Pairing of camera and monitor1 •Bind the monitor and camera Power on the camera and the monitor, and they will automatically connect. If the connection fails, please follow the steps below to pair. The pairing is distance limited, please determine the appropriate distance according to the signal strength of the monitor. 1. Press the Menu button on the monitor, and select > Camera. Select Camera 1 or Camera 2 which you need to pair. 2. Long press the camera pairing button until you hear the prompt tone. 3. Press the OK button on the monitor to start pairing. 4. If you need pair 2 cameras, please repeat step 2~ step 4. •Unbind the monitor and camera 1. Press the Menu button on the monitor, and select > Camera. 2. Select Camera 1 or Camera 2 which you need to unbind. 3. Long press the OK button to release the binding. 5 Camera switching method2 If you have added 2 cameras, the monitor will display 2 live views at the same time. If you want to set parameters or enable functions of one of the cameras, you need to select and switch to the camera first (the number shown in the represents the selected camera). Rotate the camera 3 You can adjust the monitoring angle for better vision. The Direction buttons on the monitor screen are available On the home page, press Camera switch button to switch the camera between Cam1 or 2 if you have added 2 cameras. Press the Menu button after you select one camera and set parameters or enable functions according to your needs. You can also press Zoom in/out button to zoom in and zoom out after selection of camera. 6 Photo & video4 •Take a photo •Record a video •View the taken photos and recorded videos 1. Press the Menu button on the monitor, select and press OK to enter the interface. 2. Select the camera and date, then select the photo or video you want to view and press OK to enter preview mode. * Press OK to play or pause the video in the preview mode. * Press the Back button to the quit preview or back to the main menu. You can take a photo when you want to capture an interesting scene of the baby. Press Menu button on the monitor, select and press OK to take a photo. You can record a video when you want to capture a meaningful moment for the baby. Press Menu on the monitor, select and press OK to record a video. when the camera is powered on. Press the Direction buttons to rotate the camera horizontally and vertically for better vision. 7 Play music5 You can use the monitor to play music when your baby needs to be soothed. There are various soft music to select. Press the Menu button on the monitor screen, select and press OK to enter the music interface. You can select different music, change the music cycle mode, or adjust the music volume. Feeding reminder6 Remind you to feed your baby when you are too busy, or when you want to give your baby a regular diet. 1. Press the Menu button on the monitor, and select > Feeding Reminder. 2. Select on or off to open or close feeding reminders. You can set up to 10 feeding times one day. And when the set time is up, a feeding alarm will appear on the monitor screen. 3. Press UP and DOWN Direction buttons to select between 10 time options, and press OK to start the time setting. 8 Smart care7 1. Press Menu on the monitor and select > Smart Care. 2. Press UP and DOWN Direction buttons to select options between several smart detections, and alarm volume, then press OK to save. 3. When set up one detection mode, please press LEFT and RIGHT Direction buttons to change options, and press UP and DOWN Direction buttons to adjust the sensitivity. * You can select different sensitivity according to your needs. Low refers to low sensitivity, and high refers to high sensitivity. Note: This function is only available when the camera supports it. 9 Temperature and humidity detection 8 You can monitor the temperature and humidity of your baby's room in real-time. When the temperature and humidity are out of range, you will receive the alarms immediately, so that you can take measures. 1. Press the Menu button on the monitor, and select > Temperature and humidity. 2. Press UP and DOWN Direction buttons to select options between Temperature Range, Humidity Range and Out of range Reminder, then press OK to set up. 3. Press LEFT and RIGHT buttons to change options, then press UP and DOWN buttons to change values and units. In the Out of range Reminder option, select to turn on or off the alarm when the temperature and humidity are out of range. Safety protection9 •Wi-Fi network channel If you turn off the Wi-Fi network channel, the App will not be able to view the camera. Note: This function is only available when the camera supports it. 10 •Visited records You can also view the visited records as all visits through the Ap…

Text truncated - open the document above for the full version.

Attestation Statements

LocalRepresentativeLetter ForCertificationServiceintheUSA FederalCommunicationsCommission EquipmentAuthorizationDivision,ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21048 Towhomitmayconcern PursuanttoSection2.911(d)(7),oftheCommission’sRules(47C.F.R.)weattestasfollowsfor theproductlistedbelow: FCCIDModelname 2AG7C-BABY5MBaby5M,Baby5MB,Baby5MA,AInannyS5,AInanny-LCD,Alnanny- Screen5 Weherebyacknowledgeasfollows: i.bothsigneesconfirmthatthepointofcontactacceptsresponsibilitytoactasaUS- AmericanRepresentativeonbehalfoftheapplicant ii.thepointofcontactprovidesthephysicalU.S.addressandemailaslistedbelow iii.bothpartiesmaintaintherequirementsofthisagreementwithoutexpirationdate US-AmericanPointofContactApplicant/ApprovalHolder SignaturSignature Date: 2026-03-26e CompanyName:FCCUSAgent,LL Date: 2026-03-26 CHangzhouMeariTechnologyCo., Ltd. FRN:00334028840025181900 ContactName:TimRayneZhiyangChai Address:3722IllinoisAvenue,SaintCharles, IL,60174,USA Building4,HuidingIntelligent InnovationCenter,No.825,Ruquan Road,ChangheStreet,Binjiang District,Hangzhou,Zhejiang,China Phone:708-571-3148+86-571-56565099 Email:[email protected]@meari.com.cn

Attestation Statements

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2AG7C-BABY5M Baby 5M, Baby 5MB, Baby 5MA, AInanny S5, AInanny-LCD, Alnanny-Screen5 We, Applicant Company Name: Hangzhou Meari Technology Co., Ltd. Address: Building 4, Huiding Intelligent Innovation Center, No.825, RuquanRoad, Changhe Street, Binjiang District, Hangzhou, Zhejiang, China Phone: +86-15869048127 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. This includes the cybersecurity and anti-virus software produced or provided by Kaspersky Lab, Inc. or any of ist successors and assignees. We certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2026-03-26 Signature Date Name / Title: Zhiyang Chai / Manager Company: Hangzhou Meari Technology Co., Ltd. Address: Building 4, Huiding Intelligent Innovation Center, No.825, RuquanRoad, Changhe Street, Binjiang District, Hangzhou, Zhejiang, China Phone: +86-15869048127 Fax: N/A E-Mail: [email protected]

Attestation Statements

Due Diligence Letter For Certification Service in the USA Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern FCC ID Model name 2AG7C-BABY5M Baby 5M, Baby 5MB, Baby 5MA, AInanny S5, AInanny-LCD, Alnanny-Screen5 Pursuant to KDB 986446 D01 Covered Equipment Guidance the evaluation of the product above shows compliance for the following reasons: Compliance Evaluation process Results Inherent compliance The chipset(s) used is not capable of running the cybersecurity and/or anti-virus software Compliance The memory used does not allow the running the cybersecurity and/or anti-virus software Compliance The storage capacity does not allow the running the cybersecurity and/or anti-virus software Compliance The operating system used is not capable of running the cybersecurity and/or anti-virus software Compliance No inherent compliance Based on software bill of material Based on scan for running software on the device Based on filesystem scan for cybersecurity and/or anti-virus software The equipment for which authorization is sought complies with the rules and fulfils the requirements as detailed in the above mentioned KDB. Evaluation performed by Company Name: Shenzhen Global Test Service Co., Ltd. Contact Name: Peter Xiao Address: No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong, China Phone: +86-755-28717088 Email: [email protected] Date: 2026-03-25 Signature:

Cover Letter(s)

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2AG7C-BABY5M Baby 5M, Baby 5MB, Baby 5MA, AInanny S5, AInanny-LCD, Alnanny-Screen5 For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2026-03-26 Signature Date Name / Title: Zhiyang Chai / Manager Company: Hangzhou Meari Technology Co., Ltd. Address: Building 4, Huiding Intelligent Innovation Center, No.825, RuquanRoad, Changhe Street, Binjiang District, Hangzhou, Zhejiang, China Phone: +86-15869048127 Fax: N/A E-Mail: [email protected]

Cover Letter(s)

Hangzhou Meari Technology Co., Ltd. Building 4, Huiding Intelligent Innovation Center, No.825, RuquanRoad, Changhe Street, Binjiang District, Hangzhou, Zhejiang, China Date: March 26, 2026 FCC ID: 2AG7C-BABY5M Model Number: Baby 5M, Baby 5MB, Baby 5MA, AInanny S5, AInanny-LCD, Alnanny-Screen5 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Hangzhou Meari Technology Co., Ltd. hereby declare that our product (Baby Monitor) Model Number: Baby 5M, Baby 5MB, Baby 5MA, AInanny S5, AInanny-LCD, Alnanny-Screen5 board, Schematic, Hardware version, Software version, structure and internal photos are same, model name differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Printed Name of Signee / Title: Zhiyang Chai / Manager Company: Hangzhou Meari Technology Co., Ltd. Address: Building 4, Huiding Intelligent Innovation Center, No.825, RuquanRoad, Changhe Street, Binjiang District, Hangzhou, Zhejiang, China Phone: +86-15869048127 Fax: N/A Email: [email protected]

External Photos

ReportNo.:GTS20260309001-3-02Page 28 of 36 6.EXTERNALANDINTERNALPHOTOSOFTHEEUT 6.1.ExternalphotosoftheEUT Fig.1 Fig.2 ReportNo.:GTS20260309001-3-02Page 29 of 36 Fig.3 Fig.4 ReportNo.:GTS20260309001-3-02Page 30 of 36 Fig.5 Fig.6 ReportNo.:GTS20260309001-3-02Page 31 of 36 Fig.7 Fig.8 ReportNo.:GTS20260309001-3-02Page 32 of 36 Fig.9

ID Label/Location Info

Labellocation

Internal Photos

ReportNo.:GTS20260309001-3-02Page 33 of 36 6.2.InternalphotosoftheEUT Fig.10 Fig.11 Antenna ReportNo.:GTS20260309001-3-02Page 34 of 36 Fig.12 Fig.13 ReportNo.:GTS20260309001-3-02Page 35 of 36 Fig.14 Fig.15 ReportNo.:GTS20260309001-3-02Page 36 of 36 Fig.16 Fig.17 .......................EndofReport.........................

RF Exposure Info

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road,Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong RFExposureevaluation ReportReferenceNo........................: FCCID..................................................: GTS20260309001-3-03 2AG7C-BABY5M Compiledby (position+printedname+signature) .. :FileadministratorsPeterXiao Supervisedby (position+printedname+signature)..:TestEngineerEvanOuyang Approvedby (position+printedname+signature) .. : ManagerJasonHu Dateofissue ......................................... :Mar.25,2026 RepresentativeLaboratoryName . :ShenzhenGlobalTestServiceCo.,Ltd. Address.................................................: No.7-101and8A-104,Building7and8,DCCCulturalandCreative Garden,No.98,PingxinNorthRoad,ShangmuguCommunity, PinghuStreet,LonggangDistrict,Shenzhen,Guangdong Applicant’sname...............................:HangzhouMeariTechnologyCo.,Ltd. Address.................................................:Building4,HuidingIntelligentInnovationCenter,No.825,Ruquan Road,ChangheStreet,BinjiangDistrict,Hangzhou,Zhejiang,China Testspecification..............................: Standard ................................................ : 47CFR§1.1310 47CFR § 2.1091 KDB447498D01GeneralRFExposureGuidancev06 TRFOriginator......................................:ShenzhenGlobalTestServiceCo.,Ltd. MasterTRF...........................................:Dated2014-12 ShenzhenGlobalTestServiceCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenGlobalTestServiceCo.,Ltd.isacknowledgedascopyrightownerandsourceofthematerial. ShenzhenGlobalTestServiceCo.,Ltd.takesnoresponsibilityforandwillnotassumeliabilityfordamages resultingfromthereader'sinterpretationofthereproducedmaterialduetoitsplacementandcontext. Testitemdescription ........................ :BabyMonitor TradeMark............................................:N/A Manufacturer.........................................:HangzhouMeariTechnologyCo.,Ltd. Model/Typereference.........................:Baby5M ListedModels ...................................... :Baby5MB,Baby5MA,AInannyS5,AInanny-LCD,Alnanny-Screen5 HardwareVersion ............................... :BABY5M-A3MBREV2_0 SoftwareVersion .................................. :N/A Rating.....................................................:DC3.7VFrombatteryandDC5.0VFromadapter Result.....................................................:PASS ReportNo.:GTS20260309001-3-03Page 2 of 8 TESTREPORT TestReportNo.: GTS20260309001-3-03 Mar.25,2026 ______________________________________________________________________________________________ Dateofissue EquipmentunderTest: BabyMonitor Model/Type: Baby5M Listedmodel: Baby5MB,Baby5MA,AInannyS5,AInanny-LCD,Alnanny-Screen5 Applicant : HangzhouMeariTechnologyCo.,Ltd. Address :Building4,HuidingIntelligentInnovationCenter,No.825,Ruquan Road,ChangheStreet,BinjiangDistrict,Hangzhou,Zhejiang,China Manufacturer : HangzhouMeariTechnologyCo.,Ltd. Address: 2ndto4thFloor,Building2and3ndto4thFloor,Building1,No.91, ChutianRoad,XixingStreet,BinjiangDistrict,Hangzhou,Zhejiang, China TestResult:PASS Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetest laboratory. ReportNo.:GTS20260309001-3-03Page 3 of 8 Contents 1.SUMMARY...................................................................................................................................................................4 1.1EUTCONFIGURATION........................................................................................................................................................4 1.2PRODUCTDESCRIPTION......................................................................................................................................................4 2.TESTENVIRONMENT....................................................................................................................................................5 2.1ADDRESSOFTHETESTLABORATORY.....................................................................................................................................5 2.2TESTFACILITY...................................................................................................................................................................5 2.3ENVIRONMENTALCONDITIONS.............................................................................................................................................5 2.4STATEMENTOFTHEMEASUREMENTUNCERTAINTY..................................................................................................................5 3.METHODOFMEASUREMENT......................................................................................................................................6 3.1APPLICABLESTANDARD......................................................................................................................................................6 3.2REQUIREMENT..................................................................................................................................................................6 3.3LIMIT..............................................................................................................................................................................6 3.4MPECALCULATIONMETHOD.............................................................................................................................................7 3.5ANTENNAINFORMATION....................................................................................................................................................7 4.CONDUCTEDPOWERRESULTS.....................................................................................................................................8 5.MANUFACTURING…

Text truncated - open the document above for the full version.

Test Report

上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载第 1 页共 16 页零件承认书供方：上海杰盛康通信工程有限公司产品名称：868-915天线图号：26B054A 版本：T:E 物料编码：112010294 日期：2026.03.10 Pleasereturntousonecopyof“SPECIFICATIONFORAPPROVAL”withyour approvedsignature.//客户确认签字，盖章后请回传一份承认书给我司. ADD:No.358LiuyuanRD.,BaoshanUrbanIndustrialDistrict.,Shanghai,PR.China. 地址：上海市宝山城市工业园区柳园路358号2号楼1楼 TEL:+86-21-66276925(26/29/35)－615 供方确认拟制/日期审核/日期批准/日期郑湘杰/20260310 客户确认质量/日期研发/日期产品经理/日期上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载第 2 页共 16 页目录零件承认书...................................................................................................................................................1 目录................................................................................................................................................................3 1 修订履历 ....................................................................................................................................................4 2天线外形图................................................................................................................................................5 3名词解释....................................................................................................................................................6 4测试设备....................................................................................................................................................6 5 适用频段 ....................................................................................................................................................6 6 基本测试项目 ............................................................................................................................................7 6.1 驻波比图 .........................................................................................................................................7 6.2 史密斯阻抗图 .................................................................................................................................7 6.3辐射方向图.....................................................................................................................................7 6.4增益和效率.....................................................................................................................................7 7 测试指标和数据图表 ................................................................................................................................7 7.1 驻波比 .............................................................................................................................................7 7.1.1 驻波比图 ..............................................................................................................................7 7.1.2驻波比数据..........................................................................................................................8 7.2史密斯阻抗圆图.............................................................................................................................8 7.3辐射方向图.....................................................................................................................................9 7.3.1H-plane..................................................................................................................................9 7.3.2E-plane.................................................................................................................................10 7.4增益和效率...................................................................................................................................12 8环境处理建议..........................................................................................................................................12 上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载第 3 页共 16 页 9阻抗匹配要求..........................................................................................................................................12 10 天线安装指导 ........................................................................................................................................13 10.1 天线安装位置说明 .....................................................................................................................13 11.全尺寸检测报告....................................................................................................................................14 12.包装图....................................................................................................................................................15 13.天线检测项目........................................................................................................................................16 上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载第 4 页共 16 页 1. 修订履历版本修订内容及理由修订日期修订人审核人批准人 T:A新增2025.03.17ZXJ T:B新增客户物料编码2025.03.24ZXJ T:C更新图纸清晰度2025.04.02ZXJ T:D新增天线检测项目2025.04.14ZXJ T:E更新测试数据2026.03.10ZXJ 上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载第 5 页共 16 页 2. 天线外形图上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载第 6 页共 16 页 3名词解释 dBiDecibelrelativeisotropicantenna TxTransmitfrequency RxReceivefrequency TRPTotalRadiatedPower TISTotalIsotropicSensitivity VSWRVoltageStandingWaveRatio GSMGlobalServiceforMobilecommunication DCSDigitalCommunicationSystem CDMACodeDivisionMultipleAccess WCDMAWidebandCodeDivisionMultipleAccess 4 测试设备可根据实际情况自行增减矢量网络分析仪综合测试仪 SATIMO64位暗室 5 适用频段将适用的频段用其他颜色标出。制式频段 868M-915M868M-915M 上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载第 7 页共 16 页 6基本测试项目 6.1驻波比图 6.2史密斯阻抗图 6.3辐射方向图 6.4增益和效率 7 测试指标和数据图表 7.1驻波比 7.1.1 驻波比图上海杰盛康通信工程有限公司 ShanghaiJesoncomCommunicationEngineeringCo.,Ltd Confidential 杰盛康机密，未经允许，请勿转载第 8 页共 16 页 7.1.2 驻波比数据 Freq/MHz868915 VSWR2.791.37 7.2史密斯阻抗…

Text truncated - open the document above for the full version.

Test Report

FCCID:2AG7C-BABY5M 1 CaseNo.:GTS20260309001-3-02 AmbientCondition:23°C,49%RH,Atmos100.1Kpa, TestDate:2026.3.24TestEngineer:Evanouyang AppendixA.1:DTSBandwidth TestResult TestModeAntennaFrequency[MHz] DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict SRDAnt1 9051.756904.100905.8560.5PASS 9151.744914.100915.8440.5PASS 9251.776924.120925.8960.5PASS TestGraphs SRD_Ant1_905 FCCID:2AG7C-BABY5M 2 SRD_Ant1_915 SRD_Ant1_925 FCCID:2AG7C-BABY5M 3 AppendixA.2:OccupiedChannelBandwidth TestResult TestModeAntennaFrequency[MHz] OCB[MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict SRDAnt1 9051.7820904.106905.888------ 9151.7880914.103915.891------ 9251.7880924.093925.881------ TestGraphs SRD_Ant1_905 SRD_Ant1_915 FCCID:2AG7C-BABY5M 4 SRD_Ant1_925 FCCID:2AG7C-BABY5M 5 AppendixA.3:Maximumconductedoutputpower TestResultPeak Test Mode AntennaFrequency[MHz] ConductedPeak Powert[dBm] Conducted Limit[dBm] Verdict SRDAnt1 90528.57≤30PASS 91528.75≤30PASS 92528.43≤30PASS FCCID:2AG7C-BABY5M 6 AppendixA.4:Maximumpowerspectraldensity TestResult TestModeAntennaFrequency[MHz]Result[dBm/3kHz]Limit[dBm/3kHz]Verdict SRDAnt1 9052.99≤naPASS 9154.2≤naPASS 9254.38≤naPASS FCCID:2AG7C-BABY5M 7 TestGraphs SRD_Ant1_905 SRD_Ant1_915 FCCID:2AG7C-BABY5M 8 SRD_Ant1_925 FCCID:2AG7C-BABY5M 9 AppendixA.5:Bandedgemeasurements TestResult TestModeAntennaChNameFrequency[MHz]RefLevel[dBm]Result[dBm]Limit[dBm]Verdict SRDAnt1 Low90515.99-32.79≤-4.01PASS High92516.78-31.28≤-3.22PASS FCCID:2AG7C-BABY5M 10 TestGraphs SRD_Ant1_Low_905 SRD_Ant1_High_925 FCCID:2AG7C-BABY5M 11 AppendixA.6:ConductedSpuriousEmission TestResult TestModeAntennaFrequency[MHz] FreqRange [MHz] RefLevel [dBm] Result[dBm]Limit[dBm]Verdict SRDAnt1 905 Reference16.5216.52---PASS 30~100016.52-48.61≤-3.48PASS 1000~2650016.52-40.29≤-3.48PASS 915 Reference16.8816.88---PASS 30~100016.88-50.1≤-3.12PASS 1000~2650016.88-39.76≤-3.12PASS 925 Reference17.8217.82---PASS 30~100017.82-50.73≤-2.18PASS 1000~2650017.82-41.92≤-2.18PASS FCCID:2AG7C-BABY5M 12 TestGraphs SRD_Ant1_905_0~Reference SRD_Ant1_905_30~1000 FCCID:2AG7C-BABY5M 13 SRD_Ant1_905_1000~26500 SRD_Ant1_915_0~Reference FCCID:2AG7C-BABY5M 14 SRD_Ant1_915_30~1000 SRD_Ant1_915_1000~26500 SRD_Ant1_925_0~Reference FCCID:2AG7C-BABY5M 15 SRD_Ant1_925_30~1000 SRD_Ant1_925_1000~26500 FCCID:2AG7C-BABY5M 16 AppendixA.7:EmissionsinRestrictedBands TestModeAntennaChNameFreq(MHz)Detector Freq [MHz] Result [dBm] Limit [dBm] Result [dBuV/m] Limit [dBuV/m] Verdict SRDAnt1 Low905 AV872.61-51.34≤-41.2043.86≤54PASS AV900.69-45.99≤-41.2049.21≤54PASS Peak886.65-31.34≤-21.2063.86≤74PASS Peak901.23-26.96≤-21.2068.24≤74PASS High925 AV928.98-44.35≤-41.2050.85≤54PASS AV940.08-52.25≤-41.2042.95≤54PASS Peak928.20-27.34≤-21.2067.86≤74PASS Peak935.80-39.98≤-21.2055.22≤74PASS Note： 1.TheAntennaGainiscompensatedinthegraph. 2.ThelimitindBmforaveragedetectorisconversionfrom54dBuV/m,accordingto15.209(a).The limitindBmforpeakdetectoris20dBabovethelimitofaveragedetectorindBm. FCCID:2AG7C-BABY5M 17 TestGraphs SRD_Ant1_Low_905_AV SRD_Ant1_Low_905_Peak SRD_Ant1_Low_925_AV FCCID:2AG7C-BABY5M 18 SRD_Ant1_Low_925_Peak

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Zhiyang Chai(Manager)

[email protected]Fax: +86-571-56565100

Technical Contact

FCC US Agent, LLCTim Rayne

[email protected]

3722 Illinois Avenue, Saint Charles, · Illinois, 60174 · United States

Test Firm

SHENZHEN GLOBAL TEST SERVICE CO., LTD.Simon Hu

[email protected]

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	905 MHz - 925 MHz	749.90 mW

Confidentiality

Long Term

Grant Notes

Power listed is maximum peak conducted output power. The product must be installed such that its antenna(s) can provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other transmitter, except in accordance with FCC multi-transmitter product procedures or as described in this filing.
