MBOX600 Pro Industrial Controller Specifications MBOX600 Pro Industrial Controller Specifications www.novastar-led.cn 1 Change History Document Version Release Date Description V1.0.0 2024-06-07 First release Introduction The MBOX600 Pro is an LED display controller created by NovaStar. It integrates an industrial PC and the sending capability. This controller is used outdoors and applies to the scenarios where no PC is used for LED display control, for example, fixed outdoor displays. A mouse, keyboard and monitor can be connected to the MBOX600 Pro for software installation, screen configuration, content playback, etc. Working with VNNOXCare Configuration and LCT Lite, the MBOX600 Pro can enable remote control, cabinet configuration, local playback, playback preview and more. Certifications EMC, CE RED, CE ROHS, CQC, SRRC, IC, IC ID, FCC SDoC, FCC ID, UL, CB, RCM If the product does not have the relevant certifications required by the countries or regions where it is to be sold, please contact NovaStar to confirm or address the problem. Otherwise, the customer shall be responsible for the legal risks caused or NovaStar has the right to claim compensation. Features  4x Gigabit Ethernet outputs and pixel capacity: up to 2,600,000  Output scaling − The pixel width ranges from 64 to 4096. − The pixel height ranges from 64 to 1920. − Total pixel capacity cannot exceed 2,600,000.  Common resolutions supported: 1366×768, 1440×900, 1600×900, 1920×1080, 2048×1152  1x Stereo audio output  1x HDMI 1.3 output (for image output or output preview) Connecting to a display and allowing for output scaling on an LED display  1x HDMI 1.3 input In synchronous mode, this connector is used as the input source.  2x USB 2.0 and 2x USB 3.0 Connecting to peripherals such as a mouse, keyboard and USB drive  2x Sensor connectors Connecting to a light sensor or temperature and humidity sensor  1x 6-pin Phoenix connector Connecting to a central control device, or control the power on and off of the connected device  2x Gigabit Ethernet ports One for communication and the other for remote management of device networking MBOX600 Pro Industrial Controller Specifications www.novastar.tech 2 Appearance Front Panel Name Description Power button RESET Factory reset button Press and hold this button for 10 seconds to reset the product to its factory settings. USB 2.0 2x USB 2.0 Connecting to peripherals that support the USB protocol, such as a mouse, keyboard, and USB drive SIM SIM card slot Capable of preventing users from inserting a SIM card in the wrong orientation. SOURCE Button for switching between synchronous mode and asynchronous mode FN 1 Custom button (to be implemented in future updates) FN 2 Custom button (to be implemented in future updates) Ethernet port (default IP address: 192.168.0.10) Connecting to a router for remote management of device networking Rear Panel Name Description LED OUT 4x Gigabit Ethernet outputs MBOX600 Pro Industrial Controller Specifications www.novastar.tech 3 Name Description Maximum pixel capacity: 2,600,000 When scaling is enabled, the maximum capacity is 2,600,000 pixels. (The pixel width ranges from 64 to 4096 and the pixel height ranges from 64 to 1920.) SENSOR 1 Connecting to a light sensor or temperature and humidity sensor SENSOR 2 Connecting to a light sensor or temperature and humidity sensor WIFI Connecting to a Wi-Fi antenna 4G/5G Connecting to a 4G/5G antenna AUDIO OUT Audio output HDMI OUT 1x HDMI 1.3 output HDMI IN 1x HDMI 1.3 input USB3.0 2x USB3.0 Connecting to peripherals that support the USB protocol, such as a mouse, keyboard, and USB flash drive. ETHERNET Gigabit Ethernet port Connecting to the control computer, or connecting to a LAN or public network for content publishing and screen control 1x 6-pin Phoenix connector for communication with and control of all central control devices that support RS232. RELAY denotes a relay connector for controlling the power on and off of the connected device. I/O denotes a connector that will be implemented in future updates. Power input Indicators Indicator Color Status Description PWR (Power indicator) Red Staying on The system is powered on and in standby mode. Off No power supply or powered off MBOX600 Pro Industrial Controller Specifications www.novastar.tech 4 HDD (Hard disk drive indicator) Green Flashing HDD is functioning normally. Off Powered off RUN (FPGA indicator) Green Staying on/off FPGA not loaded/no clock Flashing 2 times every second Video source accessed Flashing once times every 2s No video source Flashing 4 times every second The primary Ethernet port fails and the backup port is currently in use. WIFI (Wi-Fi network indicator) Green Staying on Wi-Fi network connection normal Off No Wi-Fi network connection 4G/5G (4G/5G network indicator) Green Staying on Network normal Flashing 4 times every second 4G/5G module detected but network abnormal Off No 4G/5G module detected HDMI (Synchronous source/ external source indicator) Green Staying on Selected but video source abnormal Flashing 2 times every second Selected and video source accessed Off Not selected IPC (Asynchronous source/ internal source indicator) Green Staying on Selected but video source abnormal Flashing 2 times every second Selected and video source accessed Off Not selected Applications The HDMI connector can be connected to a monitor to inspect the playback on an LED display, as well as to install software and configure the product. MBOX600 Pro Industrial Controller Specifications www.novastar.tech 5 Dimensions Tolerance: ±0.3 Unit: mm MBOX600 Pro Industrial Controller Specifications www.novastar.tech 6 Specifications Performance CPU N97: 4 cores, 3.6 GHz RAM 4 GB (9U4A3) 8 GB (9U8A4) HDD 128 GB (9U4A3) 256 GB (9U8A4) Connectors Front panel connectors 2x USB2.0 1x Gigabit Ethernet port Rear panel connectors 4x LED Output Ethernet ports 2x Sensor connectors 1x Wi-Fi antenna connector 1x 4G/5G antenna connector 1x Audio output 1x HDM…

Text truncated - open the document above for the full version.

Xi'anNovaStarTechCo.,Ltd TheinformationprovidedinthisletterisbasedonthereferencedrulepartsofTitle47oftheCFRaswellasKDB986446D01. Anexpirationdateforthisletterdoesnotexist.IncasetheU.S.agentchanges,thegranteeisobligatedtonotifytheFCC. FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 7/26/24 U.S.AgentDesignation Xi'anNovaStarTechCo.,LtdacknowledgestheirconsentforthefollowingcontactlocatedintheUnited Statestoactastheiragentforserviceofprocessfortheequipmentforwhichauthorizationissought (FCCID:2AG8JMBOX600P): NameandcompanyofU.S.agent:NovaStarNorthAmericaInc. PhysicalU.S.addressofagent:750EPilotRdSuiteC,LasVegas,NV89119,US FRNofU.S.agent:0033682485 EmailaddressofU.S.agent:[email protected] [AOCECorporationInc.]acknowledgestheirobligationtoacceptserviceofprocessonbehalfof Xi'anNovaStarTechCo.,Ltd Xi'anNovaStarTechCo.,Ltdacceptsitsobligationtomaintainanagentforserviceofprocessinthe UnitedStatesfornolessthanoneyearaftereitherthegranteehaspermanentlyterminatedall marketingandimportationoftheapplicableequipmentwithintheU.S.,ortheconclusionofany Commission-relatedadministrativeorjudicialproceedinginvolvingtheequipment,whicheverislater. Bysigningthisform,weconfirmtheaboveandthatweareawareoftheapplicationrequirements listedunder§2.911(d)(7). Sincerely, Signature KailingXue Xi'anNovaStarTechCo.,Ltd Signature [GilbertMu] [NovaStarNorthAmericaInc.]

Covered Equipment Identification Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows: We, applicant Company Name: Xi'an NovaStar Tech Co., Ltd Address: Building 2, NovaStar Tech Park, No. 1699, Yunshui 3rd Road, Xi'an, Shaanxi, China Phone: +86-29-68216000 certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. FCC ID: 2AG8JMBOX600P If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-15 Signature Date Name / Title: Panpan Yang / Manager Company: Xi'an NovaStar Tech Co., Ltd Address: Building 2, NovaStar Tech Park, No. 1699, Yunshui 3rd Road, Xi'an, Shaanxi, China Phone: +86-29-68216000 Fax: +86-29-84507072 E-Mail: [email protected]

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2AG8JMBOX600P MBOX600 Pro, MBOX**********((Where '*' can be any alphanumeric character or blank for marketing purpose.) We, applicant Company Name: Xi'an NovaStar Tech Co., Ltd Address: Building 2, NovaStar Tech Park, No. 1699, Yunshui 3rd Road, Xi'an, Shaanxi, China Phone: +86-29-68216000 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-15 Signature Date Name / Title: Panpan Yang / Manager Company: Xi'an NovaStar Tech Co., Ltd Address: Building 2, NovaStar Tech Park, No. 1699, Yunshui 3rd Road, Xi'an, Shaanxi, China Phone: +86-29-68216000 Fax: +86-29-84507072 E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2AG8JMBOX600P MBOX600 Pro, MBOX**********((Where '*' can be any alphanumeric character or blank for marketing purpose.) For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-15 Signature Date Name / Title: Panpan Yang / Manager Company: Xi'an NovaStar Tech Co., Ltd Address: Building 2, NovaStar Tech Park, No. 1699, Yunshui 3rd Road, Xi'an, Shaanxi, China Phone: +86-29-68216000 Fax: +86-29-84507072 E-Mail: [email protected]

Page 1 of 1 Rev.2.0 Xi'an NovaStar Tech Co., Ltd WIFI Channel 12 and 13 Declaration Letter We declare the equipment identified below with regards to Channel 12 and 13 capabilities for FCC ID: 2AG8JMBOX600P Declaration Product hardware does not have the capability to operate on Channel 12 and 13. Product hardware has the capability to operate on Channel 12 and 13. However, these two channels will be disabled via software and will not be accessible to user. Product hardware has the capability to operate on Channel 12 and 13. However, all the operated channels can’t be changed in the RF parameter via software. All channels have complied with all of the requirements sets out in FCC Part 15.247. Product hardware has the capability to operate on WiFi Channel 12 and 13, and meets the requirements of KDB 594280 D01 v02r01. Please note: 1.) By default, this device operates in a mode that is compliant with the U.S. requirements. 2.) This device will also use supplemental information such as geo- location data to determine that it is operating outside the U.S., if necessary, to change its power. Such supplemental data will be derived from the following: Global Navigation Satellite System (GNSS)7 sensors in the device Mobile Country Code (MCC),8 or MCC with a Mobile Network code (MNC), received from a CMRS9 carrier and received directly by a receiver on the device Country information derived from multiple adjacent access points (for example using IEEE Std 802.11d provisions) may be permitted on case-by-case basis Other suitable geo-location data based on IP addresses or other reliable source. Name / Title: Panpan Yang / Manager Signature: Phone: +86-29-68216000 Email: [email protected] Date: 2024-08-15

Xi'an NovaStar Tech Co., Ltd Building 2, NovaStar Tech Park, No. 1699, Yunshui 3rd Road, Xi'an, Shaanxi, China Date: August 15, 2024 FCC ID: 2AG8JMBOX600P Model Number: MBOX600 Pro, MBOX**********((Where '*' can be any alphanumeric character or blank for marketing purpose.) To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Xi'an NovaStar Tech Co., Ltd hereby declare that our product (Industrial Controller) Model Number: MBOX600 Pro, MBOX**********((Where '*' can be any alphanumeric character or blank for marketing purpose.) board, Schematic, Hardware version, Software version, structure and internal photos are same, named and appearance differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: Panpan Yang / Manager Company: Xi'an NovaStar Tech Co., Ltd Address: Building 2, NovaStar Tech Park, No. 1699, Yunshui 3rd Road, Xi'an, Shaanxi, China Phone: +86-29-68216000 Fax: +86-29-84507072 E-Mail: [email protected]

FCC ID: 2AG8JMBOX600P Fig. 1 Fig. 2 LTE Antenna (Disables) WLAN Antenna FCC ID: 2AG8JMBOX600P Fig. 3 Fig. 4 FCC ID: 2AG8JMBOX600P Fig. 5 Fig. 6 FCC ID: 2AG8JMBOX600P Fig. 7 Fig. 8 FCC ID: 2AG8JMBOX600P Fig. 9

_____________________________________________________________________________________________________ LABEL AND LOCATION (Size: L9.0cm x 6.0cm) Label Location

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‟an District, Shenzhen, China RF Exposure evaluation Report Reference No. ................. : FCC ID. ......................................... : CTA24071501802 2AG8JMBOX600P Compiled by ( position+printed name+signature): File administrators Jinghua Xiao Supervised by ( position+printed name+signature): Test Engineer Lushan Kong Approved by ( position+printed name+signature) . : Manager Eric Wang Date of issue .................................... : Jul.31, 2024 Representative Laboratory Name ....................................................... : Shenzhen CTA Testing Technology Co., Ltd. Address ......................................... : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao„an District, Shenzhen, China Applicant’s name ............................ : Xi'an NovaStar Tech Co., Ltd Address ............................................ : Building 2, NovaStar Tech Park, No. 1699, Yunshui 3rd Road, Xi'an, Shaanxi, China Test specification ........................ : Standard ........................................ : 47CFR §1.1310 Basis and purpose 47CFR §2.1091 Radiofrequency radiation exposure evaluation: mobile devices TRF Originator .............................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ................................... : Dated 2014-12 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................. : Industrial Controller Trade Mark .................................... : N/A Manufacturer ................................. : Xi'an NovaStar Tech Co., Ltd Model/Type reference ................... : MBOX600 Pro Listed Models .............................. : MBOX**********((Where '*' can be any alphanumeric character or blank for marketing purpose.) Hardware Version ........................ : N/A Software Version ........................... : N/A Rating ............................................ : DC12.0V/3.0A by Adapter Result ............................................ : PASS Report No.: CTA24071501802 Page 2 of 11 T E S T R E P O R T Test Report No. : CTA24071501802 Jul. 31, 2024 ______________________________________________________________________________________________ Date of issue Equipment under Test : Industrial Controller Model /Type : MBOX600 Pro Listed model : MBOX**********((Where '*' can be any alphanumeric character or blank for marketing purpose.) Applicant : Xi'an NovaStar Tech Co., Ltd Address : Building 2, NovaStar Tech Park, No. 1699, Yunshui 3rd Road, Xi'an, Shaanxi, China Manufacturer : Xi'an NovaStar Tech Co., Ltd Address : Building 2, NovaStar Tech Park, No. 1699, Yunshui 3rd Road, Xi'an, Shaanxi, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA24071501802 Page 3 of 11 Contents 1. SUMMARY ............................................................................................................................................................. 4 1.1 EUT CONFIGURATION ........................................................................................................................................................ 4 1.2 PRODUCT DESCRIPTION ..................................................................................................................................................... 4 2. TEST ENVIRONMENT .............................................................................................................................................. 5 2.1 ADDRESS OF THE TEST LABORATORY ..................................................................................................................................... 5 2.2 TEST FACILITY .................................................................................................................................................................. 5 2.3 ENVIRONMENTAL CONDITIONS ............................................................................................................................................ 5 2.4 STATEMENT OF THE MEASUREMENT UNCERTAINTY .................................................................................................................. 5 3. METHOD OF MEASUREMENT ................................................................................................................................. 6 3.1 APPLICABLE STANDARD ...................................................................................................................................................... 6 3.2 REQUIREMENT ................................................................................................................................................................. 6 3.3 LIMIT ............................................................................................................................................................................. 6 3.4 MPE CALCULATION METHOD ............................................................................................................................................. 7 3.5 ANTENNA INFORMATION ................................................................................................................................................... 7 4. CONDUCTED POWER RESULTS ....................................................................................…

Text truncated - open the document above for the full version.

深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.    1 NOVA 2.4G/5G SpecificationApproval CustomerName: NOVA STAR Antennafrequencyband ：2400-2500/5150-5850MHz Version:A0 CustomerName: NOVA STAR Antennafrequencyband ：2400-2500/5150-5850MHz Version:A0Productiondate ： 2024-08-09Productiondate ： 2024-08-09 Number ：FS-WZ-JB-094Customerpart number ：120010041Number ：FS-WZ-JB-094Customerpart number ：120010041 Researchand developmentofFeishengElectronicsCo., Ltd. Structures ：： Xu LongRF ：： Guo Xi Auditing:LI ShengAppreval :LI Sheng Customerconfirmation Customerreview ：： Customer approval: FeishengElectronicsCo., Ltd. Address:Third Floor, No. 70 BaotongSouth Road, Yungu Street, Xikeng, HenggangTown, Shenzhen Phone number ： 0755-85218289FAX ：0755-85223189 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.    2 INDEX. 1) Cover cover.................................................................................1 2) Catalog........................................................................................2 3) 2D drawings ................................................................................3 4) Product specificationparameters................................................4 5) Test report ofpassive waveformloss value....... ....................5-10 6) Environmentaltest report.....................................................11-14 Modify the record VersionsDatesRFModify the content A02024-08-09Xu Long   3 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.    4 Product FeaturesSpecificationTable 一、一、 Basic characteristicsofthe product ：： Producttype ：Glue stick antennaWIFI dual frequency-5DB rubber sleeve SMA male and female needle-L=195MM DESCRIPTIONVALUE FrequencyRange2400-2500/5150-5850MHz Impedance50 Ω VSWR ≤2.3 Gain2DBi RadiationOmni-directional Polarizationlinear Vertical Powers1W ConnectormodelSMA Operatingtemperature-45°C~+85°C Storage temperature-45°C~+85°C 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.    5 1.Summary ：： This report toaccount for the measurementsetup and result ofthe Antenna. The measurement setup includes s-parameter,The measureddata for Antenna are presentedand analysis. 2.S-P arameterMeasurementS：： A.Reflectioncoefficient: (a) Instrument：Network Analyzer (b) Setup ： (1) Calibrate the Network Analyzer byone port calibrationusing O.S.L. calibrationkits. (2) Connect the antenna under test tothe Network Analyzer. (3) Measure the S11(reflectioncoefficient)shown inFig. 1. (4) Generally,the S11 isless than –10dB toensure the 90% VSWR 2.0:1 power into antenna and only less than 10% power back tosystem. 一 Fig.1 Antenna measuredinNetwork Analyzer 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.    6 3.S-ParameterMeasurementResult S： S-Parametertest data ： S-Parametertest image ： FrequencyMHz 24002450248051005800 Loss DB value1.171.291.442.171.39 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.  7 Antennaappearance：Antennaappearance： Passivenumericalvalue：Passivenumericalvalue： 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.    8 2D/3D: 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.    9 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.    10 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.    11 Environmentaltest requirementsEnvironmentaltest requirements PrefacePrefaceTest itemsTest itemsTest methodsand conditionsTest methodsand conditionsTest equipmentTest equipmentTest resultsTest results 1 Temperature and humidity test ReferenceE1A 364-31 Method Three, Test ConditionA The purpose of this test process is to conduct detailedstandardtests.The productsused are affectedby high humidityand heat.Influencethe performanceof the materialfor evaluation. K.SON INS THS-A4L-150 Qualified Requirements: Temperature:85°C Humidity :90~95% (R.H) Time :72 hours 2 Low temperature test Refer to FeishengElectronicTest Specification The measuredsample should be traveledin atemperature-balancedenvironment,and its temperaturesetting Set at -45 °C K.SON INS THS-A4L-150 Qualified Requirements: Time :24 hours 3 High temperature test Refer to FeishengElectronicTest Specification： The measuredsample should be placed in a constanttemperatureenvironment,and the gas temperatureshould be set at 70°C. K.SON INS THS-A4L-150 Qualified Requirements: TIne :24 hours 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHENGELECTRONICSCO.,LTD.    12 4 Hot and cold tests Refer to FeishengElectronicTest Specification： The measuredsample should be placed in a fixed environment,and the temperature should be set at -45~85°C. K.SON INS THS-A4L-150 Qualified Requirements: More than 8hours .(30 minutes/time,12 cycles) 5 Salt spray test Refer to FeishengElectronicTest Specification： The tested sample should be placed in a fixed environment： NaCL Concentration：40-60g/1Kg PH value ：6.5-7.2 Test time ：24 hours Salt spray tester Qualified 1.Gold-platedproductsare not allowed to peel with rust spots. 2.Othernickel-plated,tinnedand galvanizedproductsshall not have more than two rust points on the same shaft or surface. 深 圳 市 飞 胜 电 子 有 限 公 司 SHENZHENFEISHE…

Text truncated - open the document above for the full version.

FCC ID: 2AG8JMBOX600P 1 Case No. : CTA24071501801 Ambient Condition: 24 °C, 49 %RH, Test Date: 2024.7.31 Test Engineer: Lushan Kong Appendix A.1: DTS Bandwidth Test Result TestMode Antenna Frequency[MHz] DTS BW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 8.040 2407.960 2416.000 0.5 PASS 2437 9.040 2432.480 2441.520 0.5 PASS 2462 8.520 2458.000 2466.520 0.5 PASS 11G Ant1 2412 15.000 2404.520 2419.520 0.5 PASS 2437 14.400 2430.360 2444.760 0.5 PASS 2462 15.240 2454.520 2469.760 0.5 PASS 11N20SISO Ant1 2412 15.440 2405.080 2420.520 0.5 PASS 2437 14.560 2430.800 2445.360 0.5 PASS 2462 16.640 2454.120 2470.760 0.5 PASS 11N40SISO Ant1 2422 35.120 2404.480 2439.600 0.5 PASS 2437 33.920 2420.680 2454.600 0.5 PASS 2452 35.040 2434.480 2469.520 0.5 PASS FCC ID: 2AG8JMBOX600P 2 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID: 2AG8JMBOX600P 3 11G_Ant1_2412 11G_Ant1_2437 FCC ID: 2AG8JMBOX600P 4 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID: 2AG8JMBOX600P 5 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID: 2AG8JMBOX600P 6 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 FCC ID: 2AG8JMBOX600P 7 Appendix A.2: Occupied Channel Bandwidth Test Result TestMode Antenna Channel Frequency[MHz] OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11B Ant1 2412 13.682 2405.2376 2418.9196 --- --- 2437 13.430 2430.3501 2443.7801 --- --- 2462 13.383 2455.3436 2468.7266 --- --- 11G Ant1 2412 17.229 2403.4503 2420.6793 --- --- 2437 16.936 2428.5932 2445.5292 --- --- 2462 17.024 2453.5316 2470.5556 --- --- 11N20SISO Ant1 2412 18.002 2403.0451 2421.0471 --- --- 2437 17.881 2428.0988 2445.9798 --- --- 2462 17.872 2453.0861 2470.9581 --- --- 11N40SISO Ant1 2422 36.216 2404.0640 2440.2800 --- --- 2437 36.281 2419.0244 2455.3054 --- --- 2452 36.146 2434.0059 2470.1519 --- --- FCC ID: 2AG8JMBOX600P 8 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID: 2AG8JMBOX600P 9 11G_Ant1_2412 11G_Ant1_2437 FCC ID: 2AG8JMBOX600P 10 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID: 2AG8JMBOX600P 11 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID: 2AG8JMBOX600P 12 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 FCC ID: 2AG8JMBOX600P 13 Appendix A.3: Maximum conducted output power Test Mode Antenna Frequency[MHz] Peak power [dBm] Limit [dBm] Verdict 11B Ant1 2412 20.93 ≤30.00 PASS 2437 21.96 ≤30.00 PASS 2462 22.24 ≤30.00 PASS 11G Ant1 2412 23.35 ≤30.00 PASS 2437 24.47 ≤30.00 PASS 2462 24.80 ≤30.00 PASS 11N20SISO Ant1 2412 21.86 ≤30.00 PASS 2437 22.84 ≤30.00 PASS 2462 23.17 ≤30.00 PASS 11N40SISO Ant1 2422 21.79 ≤30.00 PASS 2437 22.39 ≤30.00 PASS 2452 22.58 ≤30.00 PASS FCC ID: 2AG8JMBOX600P 14 Appendix A.4: Maximum power spectral density Test Result TestMode Antenna Frequency[MHz] Result[dBm/3-100kHz] Limit[dBm/3kHz] Verdict 11B Ant1 2412 -4.38 ≤8.00 PASS 2437 -3.47 ≤8.00 PASS 2462 -3.86 ≤8.00 PASS 11G Ant1 2412 -8.92 ≤8.00 PASS 2437 -7.12 ≤8.00 PASS 2462 -6.88 ≤8.00 PASS 11N20SISO Ant1 2412 -8.36 ≤8.00 PASS 2437 -8.76 ≤8.00 PASS 2462 -8.81 ≤8.00 PASS 11N40SISO Ant1 2422 -13.19 ≤8.00 PASS 2437 -12.43 ≤8.00 PASS 2452 -13.01 ≤8.00 PASS FCC ID: 2AG8JMBOX600P 15 Test Graphs 11B_Ant1_2412 11B_Ant1_2437 11B_Ant1_2462 FCC ID: 2AG8JMBOX600P 16 11G_Ant1_2412 11G_Ant1_2437 FCC ID: 2AG8JMBOX600P 17 11G_Ant1_2462 11N20SISO_Ant1_2412 11N20SISO_Ant1_2437 FCC ID: 2AG8JMBOX600P 18 11N20SISO_Ant1_2462 11N40SISO_Ant1_2422 FCC ID: 2AG8JMBOX600P 19 11N40SISO_Ant1_2437 11N40SISO_Ant1_2452 FCC ID: 2AG8JMBOX600P 20 Appendix A.5: Band edge measurements Test Result TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 9.62 -29.46 ≤-10.38 PASS High 2462 11.01 -43.7 ≤-8.99 PASS 11G Ant1 Low 2412 5.42 -22.34 ≤-14.59 PASS High 2462 7.70 -36.77 ≤-12.31 PASS 11N20SISO Ant1 Low 2412 4.99 -25.55 ≤-15.01 PASS High 2462 5.34 …
