2AGB8-0015.8G AV Transmitter

PRODUCT SPECIFICATION MODEL: FX795T FXT 5.8GHz 40 Channel AV Transmitter Modulate Wideband FM Modulate Video Format NTSC/PAL Characteristics Value Units Min. Typ. Max. 1 Output Impedance --- 50 --- Ohm 2 Output Power 12 13 14 dBm 3 Frequency Range 5645-5945 MHz 4 Operating Voltage 7.0 12 20 V 5 Current Consumption --- 70 --- mA 6 Output Voltage(VOUT) VOUT = 5V V 7 Operating Temperature -10 --- +85 °C 8 Video Band Width --- 6.0 --- MHz 9 Audio Carrier Frequency --- 6.5 --- MHz 10 Video Input Level 0.8 1.0 1.2 Vp-p 11 Video Input Impedance --- 75 --- Ohm 12 Audio Input Level 0.5 --- 2.0 Vp-p 13 Audio Input Impedance --- 10K --- Ohm 14 Weight ---- 7.5 --- Gram(s) 15 Antenna Connector SMA Female Connector 16 Dimensions (L x W) 31x22 mm 利用 pdfFactory Pro 测试版本创建的PDF文档 www.pdffactory.com Change frequency band & channel Single push to change CH, push and hold for 2 seconds to change FR Below is FX795T Channel table for your reference: CH FR CH CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 FR FR1(A) 5740 5760 5780 5800 5820 5840 5860 5880 FR2(B) 5705 5685 5665 5645 5885 5905 5925 5945 FR3(C) 5865 5845 5825 5805 5785 5765 5745 5725 FR4(D) 5658 5695 5732 5769 5806 5843 5880 5917 FR5(E) 5733 5752 5771 5790 5809 5828 5847 5866 利用 pdfFactory Pro 测试版本创建的PDF文档 www.pdffactory.com The output power of this device is less than 20mW.The SAR test is not required. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications or changes to this equipment. Such modifications or changes could void the user’s authority to operate the equipment. A certified modular has the option to use a permanently affixed label, or an electronic label. For a permanently affixed label, the module must be labelled with an FCC ID: 2AGB8-001. The OEM manual must provide clear instructions explaining to the OEM the labelling requirements, options and OEM user manual instructions that are required For a host using a this FCC certified modular with a standard fixed label, if (1) the module’s FCC ID is notvisible when installed in the host, or (2) if the host is marketed so that end users do not have straightforward commonly used methods for access to remove the module so that the FCC ID of the module is visible; then an additional permanent label referring to the enclosed module: “Contains Transmitter Module FCC ID: 2AGB8-001 or “Contains FCC ID: 2AGB8-001 ” must be used. The host OEM user manual must also contain clear instructions on how end users can find and/or access the module and the FCC ID. Host product is required to comply with all applicable FCC equipment authorizations regulations, requirements and equipment functions not associated with the transmitter module portion. compliance must be demonstrated to regulations for other transmitter components within the host product; to requirements for unintentional radiators (Part 15B). To ensure compliance with all non-transmitter functions the host manufacturer is responsible for ensuring compliance with the module(s) installed and fully operational. If a host was previously authorized as an unintentional radiator under the Declaration of Conformity procedure without a transmitter certified module and a module is added, the host manufacturer is responsible for ensuring that the after the module is installed and operational the host continues to be compliant with the Part 15B unintentional radiator requirements. Since this may depend on the details of how the module is integrated with the host, we suggest the host device to recertify part 15B to ensure complete compliance with FCC requirement: Part 2 Subpart J Equipment Authorization Procedures , KDB784748 D01 v07, and KDB 997198 about importation of radio frequency devices into the United States. The user can only use the manufacture provided antenna, cannot use any other antenna not provided by any others.

Date:2]15-12-03 To: FederalCommunicationsCommission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom lt May Concern: FXT Technology Co.,Limited the undersigned, hereby authorizes Mrs lvy Zhu from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of TCT Mobile Limited solely in matters relating to the application for an FCC equipment authorization for FCC lD: 2AGB8-001, including the signing of documents in connection with this Application. Necessary acts carried out by Shenzhen Morlab communications Technology co., Ltd on our behalf of FXT Technology Co.,Limited in connection with the Application shall have the same effect as acts of FXT Technology Co., Limited FXT Technology Co.,Limited also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C BS3(a). Thank you for your attention to this matter. Signatory l.Lr Honghua Val idation Pro.lect Manager FXT Technology Co., Limited

Date: 2015-12-03 To: FederalCommunicationsCommission, Authorization & Evaluation Division. 7435 Oakland Mills Road, Columbia. MD 21046 Re: TCT Mobile Limited FCC lD: 2AGB8-001 Confidentiality Req uest Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. FXT Technology Co,,Limited requests that the following documents regarding this submission for FCC lD: 2AGB8-001 be kept confidential: Exhibit Type File Name Block Diagram Block Diagram.pdf Schematics Schematics.pdf Operational Description perational Description.pdf Part list BOM.odf Tune-Up-Procedure Tune up procedure.pdf Those documents contain detailed system and equipment description and related information about the product which FXT Technology Co.,Limited considers to be confidential proprietary, a custom design and, othenrurse, not releasable to the general public Since this design is a basis form which future technological products will evolve, FXT Technology Co.,Limited considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Signatory

Date: 2015/12/9 To : Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: For FCC ID:2AGB8-001, has two model FX795T-2 and FX795T-6, the 2 models has same RF part, the only difference is that the FX795T-2 has horizontal direction SMA antenna connector and FX795T-6 has vertical direction SMA antenna connector. And the different SMA connector direction leads to the different LED array. No other changes except mentioned above. Thank you for your attention to this matter. Yours Sincerely,

RF_734_00, Issue 1 Modular Approval Request FCC (per DA 00-1407) FCC ID: 2AGB8-001 Items to be covered Answer from applicant 1. The modular transmitter must have its own RF shielding. No. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. All inputs to the modules are buffered through logic and microprocessor inputs(HR7P169FGNF ) 3. The modular transmitter must have its own power supply regulation. Module chipset incorporates voltage regulation to transceiver circuitry 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable).. The device has a fixed PCB antenna. 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. This is intended to demonstrate that the module is capable of complying with Part 15 emission limits regardless of the device into which it is eventually installed. Device is tested in a test fixture in a standalone configuration 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. FCC ID label format will be included in the filling. Host ID label will be displayed on the host system. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. For example, there are very strict operational and timing requirements that must be met before a transmitter is authorized for operation under Section 15.231. For instance, data transmission is prohibited, except for operation under Section 15.231(e), in which case there are separate field strength level and timing requirements. Compliance with these requirements must be assured. Please refer to “User Manual” Exhibit 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. RF exposure evaluation is exempted because of low output power. RF_734_00, Issue 1 Note: If compliance with one or more of the numbered requirements, listed above, cannot be demonstrated, it may be possible to obtain a “Limited Modular Approval” (LMA). Name and surname of applicant (or authorized representative): __Ivy Zhu________________ Date: 2015-12-09__ Signature:
