2AGKTEJ81Electric Jukebox

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna. 14 USB Port Note: The TV stick is only used on TV.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 MAGIC MEDIA WORKS LIMITED 2015-11-30 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, MAGIC MEDIA WORKS LIMITED hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): Electric Jukebox, EJ80, EJ81 FCC ID: 2AGKTEJ81 Sincerely, signature William Morgan/Chief Operations Officer E-mail: [email protected] Phone: +44 (0) 20 7099 2750 Fax: +44 (0) 20 7099 2750 Address: One West Smithfield London EC1A 9JU UK.

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (current) 4.0 5.0 Nov 19 2015 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 5.0 MAGIC MEDIA WORKS LIMITED 2015-11-30 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AGKTEJ81 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, William Morgan/Chief Operations Officer E-mail: [email protected] Phone: +44 (0) 20 7099 2750 Fax: +44 (0) 20 7099 2750 Address: One West Smithfield London EC1A 9JU UK.

MAGIC MEDIA WORKS LIMITED Family models declaration letter. 2015-12-08 We MAGIC MEDIA WORKS LIMITED Of One West Smithfield London EC1A 9JU UK. Product: Electric Jukebox FCC ID: 2AGKTEJ81 Model Name: EJ80, EJ81 These models are identical in circuitry and electrical, mechanical and physical construction; the only differences are the silk-screen, color and model no. for trading purpose. Thanks Sincerely, Signature William Morgan/Chief Operations Officer E-mail: [email protected] Phone: +44 (0) 20 7099 2750 Fax: +44 (0) 20 7099 2750 Address: One West Smithfield London EC1A 9JU UK.

PHOTOGRAPHS OF EUT (EXTERNAL PHOTO) Electric Jukebox-Controller

Electric Jukebox-Controller Label Location

Electric Jukebox-Controller 2.4G Module 2.4G Antenna

TRF No.: FCC 15.249/A Page 1 of 38 Report No.: ES151110025E4 Ver.1.0 Access to the World FCC 47 CFR PART 15 SUBPART C CERTIFICATION TEST REPORT For Electric Jukebox Model No.: EJ80, EJ81 FCC ID: 2AGKTEJ81 Trademark: Electric Jukebox REPORT NO.: ES151110025E4 ISSUE DATE: December 14, 2015 Prepared for MAGIC MEDIA WORKS LIMITED One West Smithfield London EC1A 9JU UK. Prepared by EMTEK (SHENZHEN) CO., LTD Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China TEL: 86-755-26954280 FAX: 86-755-26954282 TRF No.: FCC 15.249/A Page 2 of 38 Report No.: ES151110025E4 Ver.1.0 Access to the World TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION .................................................................................................................... 4 3 SUMMARY OF TEST RESULT ........................................................................................................................... 6 4 TEST METHODOLOGY ...................................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................................. 7 4.2 MEASUREMENT EQUIPMENT USED ........................................................................................................ 7 4.3 DESCRIPTION OF TEST MODES ................................................................................................................. 8 5 FACILITIES AND ACCREDITATIONS ............................................................................................................. 9 5.1 FACILITIES..................................................................................................................................................... 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 9 6 TEST SYSTEM UNCERTAINTY ...................................................................................................................... 10 7 SETUP OF EQUIPMENT UNDER TEST ......................................................................................................... 11 7.1 RADIO FREQUENCY TEST SETUP 1 ......................................................................................................... 11 7.2 RADIO FREQUENCY TEST SETUP 2 ......................................................................................................... 11 7.3 CONDUCTED EMISSION TEST SETUP .................................................................................................... 13 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ..................................................................... 14 7.5 SUPPORT EQUIPMENT ............................................................................................................................... 14 8 TEST REQUIREMENTS .................................................................................................................................... 15 8.1 BANDWIDTH TEST ..................................................................................................................................... 15 8.2 RADIATED SPURIOUS EMISSION ............................................................................................................ 18 8.3 CONDUCTED EMISSIONS TEST ............................................................................................................... 33 8.4 ANTENNA APPLICATION .......................................................................................................................... 38 TRF No.: FCC 15.249/A Page 3 of 38 Report No.: ES151110025E4 Ver.1.0 Access to the World 1 TEST RESULT CERTIFICATION Applicant: MAGIC MEDIA WORKS LIMITED One West Smithfield London EC1A 9JU UK. Manufacturer: LITE STAR ELECTRONICS TECHNOLOGY CO., LTD. Xingchen Science & Technology Park, Lianbi Road, Wulian Industry Area, Fenggang Town, Dongguan, China. Product Description: Electric Jukebox Model Number: EJ80, EJ81 File Number: ES151110025E4 Date of Test: November 11, 2015 to November 30, 2015 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J:2014 FCC 47 CFR Part 15, Subpart C:2014 PASS The above equipment was tested by EMTEK (SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.249 The test results of this report relate only to the tested sample identified in this report. Date of Test : November 11, 2015 to November 30, 2015 Prepared by : Jack Li/Editor Reviewer : Joe Xia/Supervisor Approve & Authorized Signer : Lisa Wang/Manager TRF No.: FCC 15.249/A Page 4 of 38 Report No.: ES151110025E4 Ver.1.0 Access to the World 2 EUT TECHNICAL DESCRIPTION Device Type: Fixed Device Exposure Category: Uncontrolled Environment/General Population Product Name: Electric Jukebox (Note: The device consists of a TV stick and controller.) Model Number: EJ80, EJ81 (Note:These models are identical in circuitry and electrical, mechanical and physical construction; the only differences are the silk-screen, color and model no. for trading purpose. We prepare EJ80 for test. and the worst result recorded in the report.) Controller information as below: Power supply: DC supply: DC 3.7V/550mAh from Li-ion Battery or DC 5V from USB Port. Adapter supply: Model: TKAC-201-DC Input: AC 100-240V, 50/60Hz, 0.6A Max Output: DC 5V 1.5A Output: USB 5V 0.5A Operating Mode(s) & Operating Frequency Range(s): 2.4G ISM Band: 2404MHz-2480MHz Test Modulation: GFSK;…

Text truncated - open the document above for the full version.

Conducted Measurement Photo Electric Jukebox-Controller Radiated Emission Test Electric Jukebox-Controller
