2AH25SCRADLEScanner Cradle

快速入门指南 * 仅适用商米整机设备 Only support for SUNMI 图片仅供参考，请以实物为准 The picture is for reference only, please prevail in kind 注意事项 当您发现有异常气味，过热或烟雾情形下，请立刻切断电源。 不要在极端冷、热环境中使用，例如靠近火源或点燃的香烟； 尽量在清洁无尘环境中使用，避免细小物品落入终端中； 在未获允许的情况下，不要在医疗设备附近使用。 声明 本公司不对以下行为负责 不在本指南说明的条件下使用和维护所造成的损坏； 对于如何因选件或耗材(非本公司提供之最初产品或认可产品)造成的损坏或问题，本 公司将不承担任何责任。 未经本公司同意，无权进行产品修改或变动。 免责申明 由于产品的更新，此文档的某些细节可能与产品不符，请以实物为准，此文档的解释 权归本公司。 保留不预先通知的情况下，修改本说明书的权利。 技术规格 技术规格信息请访问网站“www.sunmi.com”了解更多。 设备简介 扫码底座为智能金融终端提供（旋转）扫码、充电、USB接口扩展和Wi-Fi上网功能。 装上主机，开始充电，可通过底座进行扫码，或通过底座上网（可选）；未装上主机， 可通过搜索并连接底座WiFi进行上网；如果需要改变底座WiFi配置，先移除以太网接口 的网线，主机连接底座WiFi，在主机的浏览器网页输入“192.168.1.1”，进入路由器设 置系统（账号：admin，密码：admin)，进入“无线-热点设置”设置WiFi名称和密码。 输入: AC110 ～ 220V/0.3 ～ 0.4A 输出: DC5V/2A，USB Type-C 适配器 100mm 5 6 7 8 9 摄像头窗口 1 扫码区2 主机放置位 3 4连接弹针 复位孔（用于复位底座 WiFi） 5 RJ11口（选配）6 Type-C口 8 以太网口(选配) 9 旋转底座（选配） 10 7 USB口 Product Profile The scanner cradle provides charging, USB port expansion, and Wi-Fi Internet access functions for Smart Payment Terminal. Put the POS on the Scanner Cradle, then it will start charging , cradle now can scan code ,and pos can access internet through the Cradle（optional）. If you need to change the WiFi configuration of the POS Base , First remove the network cable of the Ethernet interface, connect the host to the POS Base WiFi, enter "192.168.1.1" on the host's browser page, enter the router setting system (account: admin, password: admin), and enter "Wireless-Hotspot Settings" to set the WiFi name and password. Quick Start Camera Window 1 Scan Area2 Device Area 3 4PogoPin Reset Hole（Reset Hole used for reset Cradle WiFi.） 5 RJ11（Optional）6 Type C Port 7 8 Ethernet Port (Optional) 9 Rotating Base (optional) 10 USB Type A Port 产品维修 产品名称： 产品型号： 产品编号： 购买日期： 保修期限：自购买之日起，我公司提供 天保修服务。 联系方式： · 公司地址： · 联系电话： 以下情况恕不提供免费保修： · 未经允许擅自拆卸修理的产品。 · 产品条码、易碎贴破损及保修卡涂改、残缺的。 · 未按照说明书的要求操作设备所引起的故障。 · 因进水或跌落而造成的故障、划伤或破损的人为损坏。 · 因不可抗拒因素造成的故障或损坏。 · 保修期限外。 1 3 4 2 210mm 本产品有毒有害物质名称及含量标识表 有毒有害物质或元素 部件名称 电路板组件 结构件 包装件 汞 (Hg) 镉 (Cd) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 铅 (Pb) 多溴二苯醚 (PBDE) ○：表示该有毒有害物质在该部件所有均质材料中的含量均在SJ/T11363-2006规定的限量要求以下。 Ｘ：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ/T11363-2006规定的限量要 求；但是上表中打“×”的部件，其含量超出是因为目前业界还没有成熟的可替代的技术。 对达到或超出环保使用年限的产品，应依据《电子信息产品控制管理办法》规定进行回收再利用， 不应随意丢弃。 10 制造商：上海商米科技集团股份有限公司 地 址：上海市杨浦区淞沪路388号创智天地7号楼505室 Shanghai Sunmi Technology Co., Ltd. Address: Room 505, KIC Plaza, No.388 Song Hu Road, Yang Pu District, Shanghai, China 检验合格 产品合格证 Input: AC110 ～ 220V/0.3 ～ 0.4A Output: DC5V/2A，USB Type-C Adapter M05054349 Scanner Cradle FCC compliance statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instru- ctions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installa- tion. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Caution: The user is cautioned that changes or modifictions not expressly approved by the party responsible for complliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interfere- nce that may cause undesired operation. Conformity CE This device complies with ISED Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interf- erence that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'ISDE Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:(1) L’appareil ne doit pas produire de brouillage, et (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This equipment complies with RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. ce matériel est conforme aux limites de dose d'exposition aux rayonnements, CNR-102 énoncée dans un autre environnement.cette eqipment devrait être installé et exploité avec distance minimale de 20 entre le radiateur et votre corps. ISED Canada compliance statements Technical specifications For more technical specifications, please visit: www.sunmi.com. * The product information listed on this page may be updated from time to time due to product upgrades or other reasons. SUNMI reserves the right to modify the product informtion and contents on this page without notice. Disclaimer Due to product updates, some details of this document may not match the product, please refer to the actual product, and the right to interpret this document belongs to the company. The right to modify this guide without prior notice is reserved. EU Representative :SU…
