2AH2IIBS07Sensor Beacon

INGICSTECHNOLOGY Guide Ver.0b iBS07UserGuide Introduction ThedocumentisaguideforiBS07.Toquicklyverifyit,pleasedownloadINGICSiBS01TagUtilityAPPfrom belowlink(Androidonly):https://play.google.com/store/apps/details?id=com.ingics.tag.igstagconfig Overview Operation Basically,iBS07willalwaystransmitBLEpayloadintheconfiguredtimeintervalinthebackgroundafterpoweron.The transmittedBLEpayload/messageisthenreceivedanduploadedtotheinternet/cloudserverbythebeacongateway,such asiGS01SoriGS03W/M/E.Besidesbackgroundtransmission,buttonorsensorstatuschangewillalsotriggeranimmediate BLEtransmissionformonitoringthesensorinrealtime. Poweron iBS07isinstandbymodeatshipping.Youcanpoweronitbypressingthefrontbutton.TheLEDwillflash“Red”toindicateit ispoweredon.Afterpoweron,thebuttonbecomesthealarmbutton. INGICSTECHNOLOGYCO.,LTD.•[email protected]•WWW.INGICS.COM 1 INGICSTECHNOLOGY Poweroff Whennecessary,userscanpoweroffiBS07byapplyingapencilwithablunttiptotherubberbuttononthebottomside.The LEDwillflash“Orange”toindicateitispoweredoffandenteringthestandbymode. AlarmButton Afterpoweron,thefrontbuttonactsasanalarmbutton.Aspressingthebutton,theLEDwilllightup“green”andtriggeran immediateBLEtransmissionwiththebuttonactivationevent.Asthebackendserverreceivedthisstatuschange,itcanbe usedasawarningoralarming. SettingADVInterval ADVintervalisconfiguredbyswitch.TheADVintervaltableas: B1B0ADVInterval LL1min LH5min HL15min HH30min LED Poweron(StartofConfigmode)Redblinking EndofConfigmodeGreenblinking AlarmButtonGreenonwhenpressed Batteryinserted/PoweroffOrangeblinking INGICSTECHNOLOGYCO.,LTD.•[email protected]•WWW.INGICS.COM 2 INGICSTECHNOLOGY WorkingMode LuxSensor InsideiBS07,thereisaluxsensorthatcanbeusedtodetectluxofanenvironment. Accelerometer iBS07reportsrawaccelerometerreadingsinx,y,zaxles.. Temperature/HumiditySensor iBS07isalwaysmonitoringtheenvironmenttemperatureandtransmittingthe temperaturevalueintheconfiguredtimeinterval. Verifying 1.PoweroniBS07 2.OpeniBS01TagUtilityAPPandPress“STARTSCAN”. 3.Waitforawhile,youshouldseetheBLEpayloadofiBS07receivedbytheAPP. BelowisanexplanationofthepayloadshownintheAPP. INGICSTECHNOLOGYCO.,LTD.•[email protected]•WWW.INGICS.COM 3 INGICSTECHNOLOGY Battery Level iBS07usesaCR2450coinbatteryasthepowersource.Itconsumesonlyalittlepowerandkeepsworkingforalongtime. Belowisasuggestionfortranslatingthebatteryvoltagetotheremainingcapacityatroomtemperature. CapacityVoltage High>2.9V Middle>2.7V Low>2.6V Changebattery<=2.6V Remember,aproperfilteringonthevoltageisnecessary.WheniBS07worksinalowtemperatureenvironment,thebattery voltagewillbelower.Forexample,in-20 ºC,thevoltageshouldbeadjustedto0.1V~0.3Vlower. ChangingBattery 1.Removethe3screwsandopen thebottomcase. Itisveryimportantthatwithoutthe enclosureprotection 2.Youcannowremovethebattery andchangeanewbattery TheinternalofiBS07issensitive toelectrostatics.Beforeopening thebottomcover,pleasemakesure theproperprocedureisexecutedto avoidanyelectrostaticdamageto iBS07 3.Beforeclosingthebottomcover, pleasemakesuretheO-ringisinthe properposition 4.Closethebottomcover5.Fixthe3screws INGICSTECHNOLOGYCO.,LTD.•[email protected]•WWW.INGICS.COM 4 INGICSTECHNOLOGY Configuration Whenpoweredon,iBS07willbeinconfigurationmodefor20sec.UserscanuseiBS01TagUtilitytoscanandconnectiBS07 toconfigurethetransmitpowerandADV(advertising)interval. Steps 1.PoweroniBS07 (ifiBS07isalreadypoweredon, pleasepoweroffitfirstthenpower onagain) 2.PresstheCONFIGiconontheup-right corneroftheutilitywithin20secs.Select iBS07forconfiguration. 3.IntheSETTINGpage,youcan configureTXpowerandADVMode. Afterconfiguring,pressSAVEand DISCONNECTfortheparametersto takeeffect. Parameters IniBS07,therearetwoparametersthatcanbeconfigured. a.TXpower:High(+4dBm),Mid(0dBm,default),Low(-4dBm). b.ADVmode:Legacy,CodedPhy INGICSTECHNOLOGYCO.,LTD.•[email protected]•WWW.INGICS.COM 5 INGICSTECHNOLOGY Certification TBD Statement FederalCommunicationCommissionInterferenceStatement ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttoPart15ofthe FCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential installation. Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe instructions,maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewill notoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,which canbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneofthe followingmeasures: .Reorientorrelocatethereceivingantenna. .Increasetheseparationbetweentheequipmentandreceiver. .Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected. .Consultthedealeroranexperiencedradio/TVtechnicianforhelp. FCCCaution: Toassurecontinuedcompliance,anychangesormodificationsnotexpresslyapprovedbytheparty responsibleforcompliancecouldvoidtheuser'sauthoritytooperatethisequipment.(Example-useonlyshieldedinterface cableswhenconnectingtocomputerorperipheraldevices). FCCRadiationExposureStatement ThisequipmentcomplieswithFCCRFradiationexposurelimitssetforthforan uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperatedwithaminimumdistanceof20cmcentimeters betweentheradiatorandyourbody. Thistransmittermustnotbeco-locatedoroperatinginconjunctionwithanyotherantennaortransmitter.Theantennasused forthistransmittermustbeinstalledtoprovideaseparationdistanceofatleast20cmfromallpersonsandmustnotbe co-locatedoroperatinginconjunctionwithanyotherantennaortransmitter. ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:(1)Thisdevicemay notcauseharmfulinterference,and(2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay causeundesiredoperation. NCC警語 「取得審驗證明之低功率射頻器材，非經核准，公司、商號或使 用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。低功率射 頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應 立即停用，並改善至無干擾時方得繼續使用。前述合法通信，指依電信管理 法規定作業之無線電通信。低功率射頻器材須忍受合…

Text truncated - open the document above for the full version.

INGICS TECHNOLOGY CO., LTD. Agent letter FCC attestation statement (FCC CFR 47 2.911(d) U.S. Agent for Service of Process Attestation To the attention of Federal Communications Commission Authorization and Evaluation Division U.S. Agent Name: Ivy Hsu FRN: 0033415266 Street Address: 8 Ravendale, Irvine CA. 92602 Email Address: [email protected] This letter is to confirm that we (“The Designated U.S. Agent) have accepted the responsibility to act as the designated U.S. Agent for service of process as required by section 47 CFR §2.911(d) (7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: 2023-06-05 Signed by (printed name): Applicant Company name:INGICS TECHNOLOGY CO., LTD. FCC ID: 2AH2I Contact Name:JK Fan Street Address:2F., No.15-2, Changshou St., Shulin Dist., City/Province/Zip:New Taipei City 238, Taiwan (R.O.C.) Telephone No:+886-2-26868632 Email:[email protected] This letter is to confirm that the Applicant has designated the U.S Agent noted above for the purpose of accepting service of process on their behalf as required by §2.911(d)(7). The Applicant further acknowledges acceptance to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission- related proceeding involving the equipment. Applicant Signature: Date: 2023-06-05 Signed by (printed name): JK Fan

Covered list attestation FCC application letter KiwaPage 1 of 2 RF_755_0215-02-2023 INGICS TECHNOLOGY CO., LTD. 2F., No.15-2, Changshou St., Shulin Dist., New Taipei City 238, Taiwan (R.O.C.) Certification Application Attestation Statements <Company name> INGICS TECHNOLOGY CO., LTD. 2F., No.15-2, Changshou St., Shulin Dist., New Taipei City 238, Taiwan (R.O.C.) Subject: FCC ID: < 2AH2IIBS07 > To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) [INGICS TECHNOLOGY CO., LTD.] certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) [INGICS TECHNOLOGY CO., LTD.] (“the applicant”) certifies that, as of the date of the filing of this application, the applicant - is / - is not (3) identified on the Covered List as an entity producing “covered” equipment. Date:2023/06/02 City:New Taipei City Name :JK Fan Function:President Telephone number:+886-2-26868632 Email address:[email protected] Signature: 1 - The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . (2): For FCC it must be the Grantee Code “owner” or the authorized agent. (3): double click on the appropriate box and select ‘’checked” then “OK”

RF_160_05 Declaration of Authorisation Date of issue 02-01-2023 INGICS TECHNOLOGY CO., LTD. Declaration of Authorization We Name:INGICS TECHNOLOGY CO., LTD. Address:2F., No.15-2, Changshou St., Shulin Dist., City:New Taipei City 238, Country:Taiwan (R.O.C.) Declare that: Name Representative of agent:Chieh Tseng Agent Company name:Worldwide Testing Services (Taiwan) Co., Ltd Address:6F., No. 58, Lane 188, Ruey Kuang Road, Neihu district, City:Taipei 114, CountryTaiwan is authorized to apply for Certification of the following product(s): Product description: Sensor Beacon Type designation: iBS07 Trademark: INGICS Validity/ expiry date on our behalf. Date: 2023/06/02 City: New Taipei City Name: JK Fan Function: President Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosureDate: 02-01-2022 RF_501, Issue 10 Company Name:INGICS TECHNOLOGY CO., LTD. Address:2F., No.15-2, Changshou St., Shulin Dist., City:New Taipei City 238, Country:Taiwan (R.O.C.) To: Kiwa Netherlands B.V., Dept. FCC TCB Wilmersdorf 50 7327 AC Apeldoorn The Netherlands Subject: Request for confidentiality FCC ID: 2AH2IIBS07 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Date: 2023/06/02Name and signature of applicant: J.K. Fan Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should state in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Kiwa NL B.V. at least 7 days before date of actual marketing or before expiration of the STC period

Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 2 of 19 External Photos Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 3 of 19 Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 4 of 19 Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 5 of 19 Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 6 of 19 Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 7 of 19

Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 8 of 19 Internal Photos Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 9 of 19 Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 10 of 19 Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 11 of 19 Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 12 of 19 Registration number: W6M22304-22613-FCC FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Appendix page 13 of 19

of Applicant: INGICS TECHNOLOGY CO., LTD. Address: 2F., No.15-2, Changshou St., Shulin Dist., New Taipei City 238, Taiwan (R.O.C.) Tested and Prepared by Worldwide Testing Services (Taiwan) Co., Ltd. FCC Registration No.: TW1477, TW1072 Industry Canada filed test laboratory Reg. No.: 20037, 5107A Report No.: W6M22304-22613-EE 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E- mail: [email protected] FCC RF Exposure Exemption report for Sensor Beacon Model No.: iBS07 FCC ID: 2AH2IIBS07 Registration number: W6M22304-22613-EE FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Page 1 of 9 TABLE OF CONTENTS 1 GENERAL INFORMATION .......................................................................................................... 2 1.1 NOTES .......................................................................................................................................... 2 1.2 TESTING LABORATORY ................................................................................................................ 3 1.3 APPLICATION DETAILS ................................................................................................................. 3 1.4 GENERAL INFORMATION OF TEST ITEM ........................................................................................ 4 1.5 POWER SETTING ........................................................................................................................... 5 1.6 DUTY CYCLE AND FACTOR ........................................................................................................... 5 1.7 T EST STANDARDS ......................................................................................................................... 6 2 TEST CONFIGURATION .............................................................................................................. 6 2.1 T EST ENVIRONMENT .................................................................................................................... 6 2.2 MEASUREMENT UNCERTAINTY .................................................................................................... 6 2.3 TEST EQUIPMENT LIST ................................................................................................................. 7 3 EQUIVALENT ISOTROPIC RADIATED POWER (EIRP)....................................................... 8 3.1 EXEMPTION LIMITS FOR ROUTINE EVALUATION .......................................................................... 8 Registration number: W6M22304-22613-EE FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Page 2 of 9 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. Laboratory disclaimer- 1. The test results of this test report relate exclusively to the item tested as specified in 1.5. 2. The test report may only be reproduced or published in full. 3. Reproduction or publication of extracts from the report requires the prior written approval of the Worldwide Testing Services(Taiwan) Co., Ltd. 4. Antenna gain is provided by applicant and laboratory issue relevant data and results. Tester: May 31, 2023 Sora Kuo Date WTS-Lab. Name Signature Technical responsibility for area of testing: May 31, 2023 Kevin Wang Date WTS Name Signature Registration number: W6M22304-22613-EE FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Page 3 of 9 1.2 Testing laboratory 1.2.1 Location 10m OATS No.5-1, Lishui, Shuang Sing Village, Wanli Dist., New Taipei City 207, Taiwan (R.O.C.) 3 meter semi-anechoic chamber No.35, Aly. 21, Ln. 228, Ankang Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Tel: 886-2-6613-0228 Worldwide Testing Services (Taiwan) Co., Ltd. 6F., No. 58, Ln. 188, Ruiguang Rd., Neihu Dist., Taipei City 114 , Taiwan (R.O.C.) Tel: 886-2-6606-8877 1.2.2 Details of accreditation status Accredited testing laboratory FCC filed test laboratory Reg. No.: TW1477, TW1072 Industry Canada filed test laboratory Reg. No.: 20037, 5107A Test location, where different from Worldwide Testing Services (Taiwan) Co., Ltd. : Name: ./. Accredited no.: ./. Street: ./. Town: ./. Country: ./. 1.3 Application details Approval holder Name: INGICS TECHNOLOGY CO., LTD. Street: 2F., No.15-2, Changshou St., Shulin Dist., Town: New Taipei City 238, Country: Taiwan (R.O.C.) Manufacturer: (if applicable) Name: ./. Street: ./. Town: ./. Country: ./. Registration number: W6M22304-22613-EE FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Page 4 of 9 Date of receipt of test item: April 28, 2023 Date of test: from May 02, 2023 to May 30, 2023 1.4 General information of Test item Type of test item: Sensor Beacon Model no.: iBS07 Multi-listing model no.: ./. Brand name: INGICS Power supply: Battery 3Vd.c. (CR2450) Type of antenna: 2.4-GHz Inverted F Antenna Antenna gain: 3.3 dBi Technical data Mode Channel Conducted Power (dBm) BLE Ch 0 : 2402 MHz 1.85 Ch 19 : 2440 MHz 1.42 Ch 39 : 2480 MHz 0.89 Operation modes: Duplex Modulation type: GFSK Sample no.: #04 Special statement: ./. Classification: Fixed Device Mobile Device (Human Body distance ＞ 20cm) Portable Device (Human Body distance ＜ 20cm) Registration number: W6M22304-22613-EE FCC ID: 2AH2IIBS07 Worldwide Testing Serv…

Text truncated - open the document above for the full version.

of Applicant: INGICS TECHNOLOGY CO., LTD. Address: 2F., No.15-2, Changshou St., Shulin Dist., New Taipei City 238, Taiwan (R.O.C.) Tested and Prepared by Worldwide Testing Services (Taiwan) Co., Ltd. FCC Registration No.: TW1477, TW1072 Industry Canada filed test laboratory Reg. No.: 20037, 5107A Report No.: W6M22304-22613-C-1 6F, NO. 58, LANE 188, RUEY-KUANG RD., NEIHU TAIPEI 114, TAIWAN, R.O.C. TEL: 886-2-66068877 FAX: 886-2-66068879 E- mail: [email protected] 47 CFR PART 15 SUBPART C TEST REPORT for Sensor Beacon Model No.: iBS07 FCC ID: 2AH2IIBS07 Registration number: W6M22304-22613-C-1 FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Page 1 of 24 TABLE OF CONTENTS 1 GENERAL INFORMATION ......................................................................................................................................... 2 1.1 NOTES ...................................................................................................................................................................... 2 1.2 TESTING LABORATORY ............................................................................................................................................. 3 1.2.1 Location .............................................................................................................................................................. 3 1.2.2 Details of accreditation status ............................................................................................................................ 3 1.3 APPLICATION DETAILS .............................................................................................................................................. 3 1.4 GENERAL INFORMATION OF TEST ITEM ..................................................................................................................... 4 1.5 DUTY CYCLE AND FACTOR ........................................................................................................................................ 4 1.6 TEST STANDARDS ..................................................................................................................................................... 5 2 TEST CONFIGURATION ............................................................................................................................................. 6 2.1 TEST ENVIRONMENT ................................................................................................................................................. 6 2.2 MEASUREMENT UNCERTAINTY ................................................................................................................................. 6 2.3 TEST EQUIPMENT LIST .............................................................................................................................................. 7 3 TEST RESULTS (ENCLOSURE) ................................................................................................................................. 9 3.1 PEAK OUTPUT POWER (TRANSMITTER) ................................................................................................................... 10 3.2 SPURIOUS EMISSIONS RADIATED – TRANSMITTER OPERATING ............................................................................... 13 3.3 EMISSIONS IN NONRESTRICTED FREQUENCY BANDS ................................................................................................ 15 3.4 MINIMUM 6 DB BANDWIDTH .................................................................................................................................. 17 3.5 PEAK POWER SPECTRAL DENSITY .......................................................................................................................... 20 3.6 POWER LINE CONDUCTED EMISSION ...................................................................................................................... 23 Appendix: Diagrams Registration number: W6M22304-22613-C-1 FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Page 2 of 24 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. Laboratory disclaimer- 1. The test results of this test report relate exclusively to the item tested as specified in 1.5. 2. The test report may only be reproduced or published in full. 3. Reproduction or publication of extracts from the report requires the prior written approval of the Worldwide Testing Services(Taiwan) Co., Ltd. 4. Antenna gain is provided by applicant and laboratory issue relevant data and results. Tester: June 26, 2023 Sora Kuo Date WTS-Lab. Name Signature Technical responsibility for area of testing: June 26, 2023 Kevin Wang Date WTS Name Signature Registration number: W6M22304-22613-C-1 FCC ID: 2AH2IIBS07 Worldwide Testing Services(Taiwan) Co., Ltd. Page 3 of 24 1.2 Testing laboratory 1.2.1 Location 10m OATS No.5-1, Lishui, Shuang Sing Village, Wanli Dist., New Taipei City 207, Taiwan (R.O.C.) 3 meter semi-anechoic chamber No.35, Aly. 21, Ln. 228, Ankang Rd., Neihu Dist., Taipei City 114, Taiwan (R.O.C.) Tel: 886-2-6613-0228 Worldwide Testing Services (Taiwan) Co., Ltd. 6F., No. 58, Ln. 188, Ruiguang Rd., Neihu Dist., Taipei City 114 , Taiwan (R.O.C.) Tel: 886-2-6606-8877 1.2.2 Details of accreditatio…

Text truncated - open the document above for the full version.

1 SWRU120C–April 2007–Revised February 2017 Submit Documentation Feedback Copyright©2007–2017, Texas Instruments Incorporated 2.4-GHz InvertedFAntenna Texas Instruments isatrademark of Texas Instruments. All other trademarks are the property of their respective owners. Application Report SWRU120C–April 2007–Revised February 2017 2.4-GHz InvertedFAntenna ABSTRACT This document describesaprinted-circuit board (PCB) design that can be used with all 2.4-GHz transceivers and transmitters from Texas Instruments™.The maximum gain is measured to be +3.3 dBi, and the overall size requirements for this antenna are 25.7×7.5 mm. Thus, this antenna is compact, low cost, and high performance. Contents 1Description of InvertedFAntenna Design................................................................................2 1.1 Implementation of InvertedFAntenna...........................................................................2 2Results........................................................................................................................3 2.1 Radiation Pattern...................................................................................................3 2.2 Reflection...........................................................................................................10 2.3 Bandwidth..........................................................................................................10 3Conclusion..................................................................................................................11 4References..................................................................................................................11 Description of InvertedFAntenna Design 2 SWRU120C–April 2007–Revised February 2017 Submit Documentation Feedback Copyright©2007–2017, Texas Instruments Incorporated 2.4-GHz InvertedFAntenna 1Description of InvertedFAntenna Design Because the impedance of the invertedFAntenna (IFA) is matched directly to 50,no external matching components are required. 1.1 Implementation of InvertedFAntenna It is important to make an exact copy of the antenna dimensions to obtain optimum performance. The easiest approach to implement the antenna inaPCB CAD tool is to import the antenna layout froma gerber file oraDXF file. Such files are included in CC2430DB reference design[1].The gerber file is called Inverted_F_Antenna.spl and the DXF file is called Inverted_F_Antenna.dxf. If the antenna is implemented onaPCB that is wider than the antenna, avoid placing components or havingaground plane close to the end points of the antenna. If the CAD tool being used does not support importing gerber or DXF files, seeFigure1andTable1. Figure 1. IFA Dimensions Table 1. IFA Dimensions H15.70 mmW20.46 mm H20.74 mmL125.58 mm H31.29 mmL216.40 mm H42.21 mmL32.18 mm H50.66 mmL44.80 mm H61.21 mmL51.00 mm H70.80 mmL61.00 mm H81.80 mmL73.20 mm H90.61 mmL80.45 mm W11.21 mm Because there is no ground plane beneath the antenna, the PCB thickness will have little effect on the performance. The results presented in this document are based on an antenna implemented onaPCB witha1-mm thickness. Results 3 SWRU120C–April 2007–Revised February 2017 Submit Documentation Feedback Copyright©2007–2017, Texas Instruments Incorporated 2.4-GHz InvertedFAntenna 2Results All of the results presented in this section are based on measurements performed with CC2430DB[1]. 2.1 Radiation Pattern Figure2shows how to relate all of the radiation patterns to the orientation of the antenna. The radiation patterns were measured with the CC2430 device programmed to 0-dBm output power. Figure 2. Relating Antenna to Radiation Patterns Results 4 SWRU120C–April 2007–Revised February 2017 Submit Documentation Feedback Copyright©2007–2017, Texas Instruments Incorporated 2.4-GHz InvertedFAntenna Figure3shows the XY plane vertical polarization. Figure 3. XY Plane–Vertical Polarization Results 5 SWRU120C–April 2007–Revised February 2017 Submit Documentation Feedback Copyright©2007–2017, Texas Instruments Incorporated 2.4-GHz InvertedFAntenna Figure4shows the XY plane horizontal polarization. Figure 4. XY…

Text truncated - open the document above for the full version.
