2AH2IIGS03EBLE Beacon Gateway

INGICS​ ​TECHNOLOGY iGS03W/E/M is a gateway to bridge the local BLE( Bluetooth® Low Energy) tags, sensors, or beacons to remote server/cloud by WiFi, Ethernet or LTE-M. Through an easy web UI interface, user can configure the Internet access to upload reports to cloud server by TCP, HTTP(S), or MQTT(S). This guide is to help the user to figure out how to operate and configure the iGS03. Contents: Overview Block Diagram SIM WiFi Ethernet BLE GNSS Example case 1: The device is in fixed position: Example case 2: The device is moving: Payload Format BLE GPS Button Reset to Default WPS LEDs Configuration Web User Interface System Wi-Fi AP Mode Station Mode Network WiFi Address DHCP Server (WiFi AP) Applications TCP Server Guide Ver.01a Beacon Gateway iGS03W/E/M User Manual ​ ​INGICS TECHNOLOGY CO., LTD. • [email protected] • WWW.INGICS.COM 1 INGICS​ ​TECHNOLOGY TCP Client HTTP Client HTTPS MQTT Client MQTTS Common Settings Content Type Keep Alive Append Timestamp Request Interval Cache full handling Throttle Control Cloud IoT Helper Advanced BLE Configuration BLE-5 PHY Mode Active Scan Mode BLE Filter RSSI Threshold Payload Whitelist BLE MAC Whitelist Security Device Key/Certification/Server CA Upload LTE LET Settings APN Auth Username/Password GNSS Settings NTP Setting Certification Bluetooth SIG Qualification Japan MIC Reaulatory FCC Regulatory FCC Statements CE Regulatory Revision History ​ ​INGICS TECHNOLOGY CO., LTD. • [email protected] • WWW.INGICS.COM 2 INGICS​ ​TECHNOLOGY Overview The iGS03 BLE gateway scans beacons(like iBeacon or Eddystone), proprietary tags, or BLE sensors then sends the payload to TCP, HTTP or MQTT server. Users can configure the transmit period and server endpoint through a simple web UI. There are three models, iGS03W, iGS03E and iGS03M, representing different uploading interfaces, WiFi, Ethernet and LTE-M. Block Diagram ​ ​INGICS TECHNOLOGY CO., LTD. • [email protected] • WWW.INGICS.COM 3 INGICS​ ​TECHNOLOGY SIM To use iGS03M (LTE-M Model), you have to put a Cat-M1 micro SIM card into the socket of iGS03M. Please open the bottom cover to insert the SIM card. The steps to open the bottom cover are as below, Step 1. Remove external BLE antenna Step 2. Remove the screw from bottom cover Step 3. Use finger to press and hold the arrow part Step 4. Pull out the bottom cover ​ ​INGICS TECHNOLOGY CO., LTD. • [email protected] • WWW.INGICS.COM 4 INGICS​ ​TECHNOLOGY WiFi (iGS03W/iGS03M) The 2.4G WiFi AP connection is used to configure the unit through web UI. iGS03 works as an WiFi Access Point(AP) supporting DHCP. Users must connect to this AP to configure the unit. Ethernet (iGS03E) It supports 10BASE-T and 100BASE-TX with HP Auto-MDIX. Through the Ethernet, the gateway can bridge your BLE devices to the local TCP server or cloud server for management. iGS03E is a DHCP client by default. To configure it, you have to connect it to a router with DHCP enabled. The first thing is to find iGS03E’s IP address in this network so that you can get into it’s webUI for configuration. If you don’t know the IP address, you may need to use some tool to find it.(For example, “Fing” APP in Android & iOS. Join your smartphone or tablet with “Fing” in the same network. And use it to scan all the devices in this network) BLE The BLE subsystem operates in listening mode. It collects the messages advertised by BLE devices. These messages are then sent to the cloud server configured by the user. iGS03 supports two BLE modes 1.LE 1M PHY: including BLE4.2(Legacy)/BLE5, 1M in 100% duty cycle 2.LE Coded PHY: BLE5, 125K( long range) in 100% duty cycle The default PHYMODE is 1, LE 1M PHY mode. Users can use webUI or telnet command to configure the mode. GNSS (iGS03M) The GNSS function is turned “off” by default. Users can use webUI to enable or disable GNSS. For detail settings, use below telnet commands to manage the GNSS behavior: GNSS ENABLE Enable/Disable GNSS, default off GNSS FIXCOUNT Number of attempts for positioning, 0 indicates continuous positioning. default 0 GNSS FIXRATE The interval time between the first and second time positioning, default 1 (1 second) ​ ​INGICS TECHNOLOGY CO., LTD. • [email protected] • WWW.INGICS.COM 5 INGICS​ ​TECHNOLOGY GNSS RPTRATE The interval time for sending GPSR report, default 600 (10 minutes) GNSS INFO To get latest GPS status Example case 1: The device is in fixed position: e.g. GNSS ENABLE 1 GNSS FIXCOUNT 5 GNSS FIXRATE 60 GNSS RPTRATE 60 Then GNSS will be enabled and get positioned for 5 times with a 60 seconds interval. GNSS will be off automatically after getting position for 5 times. Example case 2: The device is moving: e.g. GNSS ENABLE 1 GNSS FIXCOUNT 0 GNSS FIXRATE 1 GNSS RPTRATE 60 Then GNSS will be enabled and continuously get position with 1 second interval, and it will send a GPSR report every 60 sec. You can also use the "GNSS INFO" command to get the latest coordinates. Payload Format There are several kinds of payload format that iGS03 will send to the server. BLE General format: $<report type>,<tag id>,<gateway id>,<rssi>,<raw packet content>,*<unix epoch timestamp>\r\n <report type> Different report type to distinguish the source of the report. <tag id> MAC address or ID of tag/beacon <gateway id> MAC address of gateway <rssi> RSSI of tag/beacon ​ ​INGICS TECHNOLOGY CO., LTD. • [email protected] • WWW.INGICS.COM 6 INGICS​ ​TECHNOLOGY Report Type: $GPRPBLE4.2 General Purpose Report $RSPRBLE4.2 Scan Response Report $LRAD BLE5 Long Range ADV $LRSR BLE5 Long Range Scan Response $1MAD BLE5 1M ADV $1MSR BLE5 1M Scan Response Examples: $GPRP,CCB97E7361A4,CB412F0C8EDC,-49,1309696773206D65736820233220285445535429020106,1574921085 $GPRP,E5A706E3923A,CB412F0C8EDC,-87,0201041AFF590002150112233445566778899AABBCCDDEEFF0000100C3BB,157 4921085 $LRAD,51A88AD374B7,CC4B73906F96,-87,02010212FF0D0083BC280100AAAAFFFF000010030000,1574921085 $GPRP,0C61CFC1452E,E7DAE08E6FC3,-44,0201061AFF4C000215B9A5D27D56CC4E3AAB511F2153BCB9670001452ED6 (iBeacon, UUID: …
