2AH3O-SKYTRAKMAXST MAX

CONTENTS What’s in The Box SkyTrak + Unit USB Cable USB Adaptor 2 UNIT OVERVIEW Your SkyTrak + unit has three LEDs, a USB port and a power button. All configuration and usage of the device is via the SkyTrak + application on your computer, tablet or smart phone. COMPATIBLE PLATFORMS SkyTrak + is compatible across many platforms such as smartphone, iPad, Android Tablet, or PC. You can refer to www.skytrakg olf.com for the latest list of compatible devices. SET UP TIP For optimum performance, we recommend that you use a mat for both indoor and outdoor use. 3 POWERING ON AND CHARGING Powering On/Off To turn on SkyTrak +, press the power butt on. The power LED w ill turn GREEN , the WiFi LED will turn RE D and the Read y LED will tur n RED, you can start connecting SkyTrak + to your mobile devi ce. To tur n off SkyTrak +, press th e po wer button again. Chargi ng Charge the SkyTrak + unit for 6 hours prior to i nitial use. Plug the US B ca ble into a PC or other USB char ger,such as your mobile phon e cha rger,to charge the internal battery. The power LED will turn AMBER wh en SkyTrak + is charg ing. SkyTrak + contains a Li-Polym er rechargea ble battery that can op erate up to 4 hours o n a full cha rge. 4 CONNECTING THE WIRELESS Activate Wi-Fi on your mobile device or PC. Make sure that the SkyTrak + unit is powered on. Connect your mobile device or PC to the access point that starts with "STPLUS”. Start the SkyTrak + application on your mobile device or PC. You can go to www.Skytrakgolf.com to download the application. Once the SkyTrak + unit detects the connection from the application, the ‘Wi-Fi’ LED will turn green while the 'Ready’ LED will turn red and a laser dot will be shown on mat. Place your golf ball on this laser dot. Once the golf ball is found, ‘Ready’ LED will turn green. 5 HITTING YOUR FIRST SHOT Once the SkyTrak + unit is connected and dis playing the red laser on the mat, plac e the golf ball or tee on the dot. Make su re the SkyTrak + unit is placed on the same levell as the hitting surface. Whe n a ball is it, the red laser will tur n off and you can view your data in the application. The red laser will turn on again when the unit ready for you to hit yo ur next s hot . 6 7 CARE INSTRUCTIONS SkyTrak + uses advanced optics that are behind the plastic window. Scratches and dust or other issues that impact the window quality may interfere with SkyTrak Plus operation. Keeping the window clean and scratch-free will ensure the measurement accuracy and longevity of your SkyTrak + system. You may purchase a carrying case to keep your SkyTrak + unit protected from www.skytrakgolf.com. To clean the plastic window, use a small amount of water and wipe with a clean cotton cloth in a single wipe. Do not use any chemicals to clean the window. TROUBLESHOOTING Problem Solution When charging, Power LED does not come on. Check if USB cable is connected to valid power socket. Power LED blinking red and unit turns off after 50 seconds. Battery is low. Connect the USB cable and charge the unit. The Power LED will turn GREEN when the unit is charged and device is in operational mode. It will turn AMBER if the device is in charging mode. Wi-Fi LED is not turning green, Make sure to start the application AFTER connecting to the unit's Wi-Fi to your device. The SkyTrak + unit LEDs show connected only when the application is open. Wi-Fi and Power LEDs are green, but Ready LED is red. Ball is not found. Ensure the SkyTrak + unit is placed correctly and not tilting. For the SkyTrak + unit to operate correctly, it must be placed perpendicular to the ground. Results seem inaccurate. Be sure to position the ball correctly on the red dot and make sure the unit sits level with the hitting surface. If using a tee, make sure the base of the tee is on the red dot. 8 DOWNLOADING THE APPLICATION Go to www.skytrakgolf.com from your smartphone, tablet, or computer’s browser to download and install the windows Application. 9 10 WARNINGS AND SAFETY INFORMATION FCC Regulatory Information This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including Interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1) Reorient or relocate the receiving antenna. 2) Increase the separation between the equipment and receiver. 3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. 4) Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications not expressly approved by the party responsible for compliance to this equipment would void the user's authority to operate this device This equipment complies with FCC RF radiation exposure limit set forth for an uncontrolled environment. To comply with FCC RF exposure compliance requirements, this equipment should be installed and operated with a minimum distance of 20cm between the radiator and user. This device must not be co-located or operating in conjunction with any other antenna or transmitter. 11 This host device (FCC ID: 2AH3O-SKYTRAKMAX)…

Text truncated - open the document above for the full version.
