2AHDSTC600-02MeatStick X Charger

Label Label location

FCC ID: 2AHDSTC600-02 RF Exposure evaluation According to 447498 D04 Interim General RF Exposure Guidance v01 ERP/EIRP = P T +G T −L C ERP/EIRP is the equivalent (or effective) radiated power [in same units as P T , typically dBW, dBm, or power spectral density (psd)], relative to either a dipole antenna (ERP) or an isotropic antenna (EIRP). P T is the transmitter output power, in dBW, dBm, or psd (power over a specified reference bandwidth). G T is the gain of the transmitting antenna, in dBd (ERP) or dBi (EIRP). L C is the signal attenuation in the connecting cable between the transmitter and the antenna, in dB. For BLE mode Frequency (MHz) Output power (dBm) Ant gain (dBi) EIRP (dBm) EIRP (mw) ERP (dBm) ERP (mw) Distance (cm) P th (mW) 2440 -0.92 -4.32 -5.24 0.30 -7.39 0.18 0.5 2.8 ERP = EIRP −2.15 dB WORSE CASE 0.3mW<2.8mW Remark: Then SAR evaluation is not required

ReportNo.:RFI-LAB-RF-202408-HH05 QP030-E41 Page1of10 TestingReport CustomerName:GrandexInternationalCorporation ProductName:BT2.4GHzAntenna SampleModel:TC6XXANT ReferenceStandard:GB/T9410-2008;ANSI/IEEEStd149-1979 IssueDate:2024.8.6 Engineer:Date: Auditor:Date: Approver:Date: ReportNo.:RFI-LAB-RF-202408-HH05 QP030-E41 Page2of10 Version VersionNo.DateDescriptionFormulateApproval A02024.8.6Forthefirsttime,formulateZkrisEason Contents 1.GeneralInformation.........................................................................................................................3 1.1Generalinformationoftestinginstitutions...........................................................................3 1.2Testingprinciple...................................................................................................................3 1.3Testequipment......................................................................................................................4 1.4Testenvironment...................................................................................................................4 1.5Statement..............................................................................................................................4 2.SampleInformation.........................................................................................................................5 2.1Clientinformation.................................................................................................................5 2.2DescriptionofEUT(S)..........................................................................................................5 2.3EUTappearance....................................................................................................................6 2.4EUTsetupphotooffreespaceOTAtesting.........................................................................6 3.TestResults......................................................................................................................................7 3.1Teststandard.........................................................................................................................7 3.2Testuncertainty.....................................................................................................................7 3.3Testdata................................................................................................................................8 3.3.1S11parameters...........................................................................................................8 3.3.2S11data......................................................................................................................8 3.3.3Typicalfreespaceefficiencyandgain......................................................................8 3.3.4Typicalfreespaceradiationpattern...........................................................................9 （Thefollowingisblank）..............................................................................................................10 ReportNo.:RFI-LAB-RF-202408-HH05 QP030-E41 Page3of10 1.GeneralInformation 1.1Generalinformationoftestinginstitutions Name ShenzhenRFI-LABCommunicationTechnologyCo.,Ltd. Address 103Building1TingweilndustrialPark,No.6,LiufangRoad,Zone 67Xingdong,Xin'anSubdistrict,Bao'anDistrict,Shenzhen,Guangdong,China Tel 13682621346 E-mail [email protected] Equipment Alltheequipmentusedinthereportisfixedin103Building1Tingweilndustrial Park,No.6,LiufangRoad,Zone67Xingdong,Xin'anSubdistrict,Bao'anDistrict, Shenzhen,Guangdong,China 1.2Testingprinciple ReportNo.:RFI-LAB-RF-202408-HH05 QP030-E41 Page4of10 1.3Testequipment EquipmentModelNo.SerialNo.Manufacturer Calibration date Next calibration date OTATest System RayZone-5000 RFI-LAB-RF -D00 GTS2023.3.142025.3.13 Network Analyzer E5071C RFI-LAB-RF -D01 KEYSIGHT2024.5.62025.5.5 Network Analyzer E5071C RFI-LAB-RF -C02 KEYSIGHT2024.5.62025.5.5 1.4Testenvironment Temperature 23.9°C Humidity 58%RH Pressure 100.20kPa 1.5Statement (1)Thetestresultsinthereportareonlyapplicabletothetestedsamplesandthetestedsamples workundertheenvironmentdescribedinthereport. (2)OnlyShenzhenRFI-LABCommunicationTechnologyCo.,Ltd.havetherighttomodifythe report,andthemodificationinformationshallbeannotatedintherevisionform. (3)Anyobjectiontothisreportshallberaisedwithin30daysafterformalconfirmationofthe report. (4)Thisreportisinvalidifthereisanyevidencethatthesampleinformationprovidedisfalsified. (5)Thereportisinvalidwithoutthesignatureoftheauditorandapprover. ReportNo.:RFI-LAB-RF-202408-HH05 QP030-E41 Page5of10 2.SampleInformation 2.1Clientinformation Name GrandexInternationalCorporation Address 4F.,No.527,ZhongzhengRd.,XindianDist.,NewTaipeiCity23148, Taiwan(R.O.C.) Contacts / Tel / E-mail / Manufacturer GrandexInternationalCorporation 2.2DescriptionofEUT(S) ProductName BT2.4GHzAntenna SampleModel TC6XXANT AntennaSize / SerialNo. / AntennaType PCBAntenna TestItem VSWR;Returnloss;Impedance;Antennagain; Efficiency;Radiationpattern FrequencyRange 2400-2500MHz ReceivedDate 2024.8.5 TestDate 2024.8.5 Remark / ReportNo.:RFI-LAB-RF-202408-HH05 QP030-E41 Page6of10 2.3EUTappearance 2.4EUTsetupphotooffreespaceOTAtesting Planform Frontview ReportNo.:RFI-LAB-RF-202408-HH05 QP030-E41 Page7of10 3.TestResults 3.1Teststandard NameParameterMethodStandardno. Mobile communication antenna Antennagain Genericspecification forantennasusedinthe mobilecommunications GB/T 9410-2008 Radiationpattern VSWR Antenna Radiationefficiency IEEEStandardTest ProceduresforAntennas ANSI/IEEEStd 149-1979 Gainanddirectivity 3.2Testuncertainty TheuncertaintywascalculatedonthebasisoftheGUMpublishedbyISO,usingthe inclusionfactorofK=2andthe95%confidenceleveltoexpresstheextended uncertainty. ItemUncertainty VSWR±0.3 Antennagain±0.72dB Radiationefficiency±0.72dB ReportNo.:RFI-LAB-RF-202408-HH05 QP030-E41 Page8of10 3.3Testdata 3.3.1S11parameters 3.3.2S11data 3.3.3Typicalfreespaceefficiencyandgain Frequency/…

Text truncated - open the document above for the full version.

Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 1 of 28 1. Duty Cycle 1.1 Test Result Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) GFSK-1M SISO 2402 0.099 0.625 15.84 8.00 0.00 2440 0.100 0.625 16.00 7.96 0.00 2480 0.100 0.625 16.00 7.96 0.00 GFSK-2M SISO 2402 0.062 0.625 9.92 10.03 0.00 2440 0.062 0.625 9.92 10.03 0.03 2480 0.062 0.625 9.92 10.03 0.03 Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 28 1.2 Test Graph GFSK-1M_LCH_2402MHz_Ant1_NTNV GFSK-1M_MCH_2440MHz_Ant1_NTNV Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 28 GFSK-1M_HCH_2480MHz_Ant1_NTNV GFSK-2M_LCH_2402MHz_Ant1_NTNV Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 28 GFSK-2M_MCH_2440MHz_Ant1_NTNV GFSK-2M_HCH_2480MHz_Ant1_NTNV Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 5 of 28 2. Bandwidth 2.1 Test Result 2.1.1 OBW Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit GFSK-1M SISO 2402 1 1.041 / Pass 2440 1 1.041 / Pass 2480 1 1.045 / Pass GFSK-2M SISO 2402 1 2.076 / Pass 2440 1 2.079 / Pass 2480 1 2.082 / Pass 2.1.2 6dB BW Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit GFSK-1M SISO 2402 1 0.544 >=0.5 Pass 2440 1 0.559 >=0.5 Pass 2480 1 0.570 >=0.5 Pass GFSK-2M SISO 2402 1 0.858 >=0.5 Pass 2440 1 0.846 >=0.5 Pass 2480 1 0.849 >=0.5 Pass Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 6 of 28 2.2 Test Graph 2.2.1 OBW GFSK-1M_LCH_2402MHz_Ant1_NTNV GFSK-1M_MCH_2440MHz_Ant1_NTNV Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 7 of 28 GFSK-1M_HCH_2480MHz_Ant1_NTNV GFSK-2M_LCH_2402MHz_Ant1_NTNV Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 8 of 28 GFSK-2M_MCH_2440MHz_Ant1_NTNV GFSK-2M_HCH_2480MHz_Ant1_NTNV Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 9 of 28 2.2.2 6dB BW GFSK-1M_LCH_2402MHz_Ant1_NTNV GFSK-1M_MCH_2440MHz_Ant1_NTNV Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 10 of 28 GFSK-1M_HCH_2480MHz_Ant1_NTNV GFSK-2M_LCH_2402MHz_Ant1_NTNV Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 11 of 28 GFSK-2M_MCH_2440MHz_Ant1_NTNV GFSK-2M_HCH_2480MHz_Ant1_NTNV Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 12 of 28 3. Maximum Conducted Output Power 3.1 Test Result Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit GFSK-1M SISO 2402 -0.94 <=30 Pass 2440 -0.92 <=30 Pass 2480 -1.17 <=30 Pass GFSK-2M SISO 2402 -1.01 <=30 Pass 2440 -0.94 <=30 Pass 2480 -1.19 <=30 Pass Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 13 of 28 3.2 Test Graph GFSK-1M_LCH_2402MHz_Ant1_NTNV GFSK-1M_MCH_2440MHz_Ant1_NTNV Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 14 of 28 GFSK-1M_HCH_2480MHz_Ant1_NTNV GFSK-2M_LCH_2402MHz_Ant1_…

Text truncated - open the document above for the full version.

Global United Technology Services Co., Ltd. Report No.: GTS2024080048F01 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 30 TEST REPORT Applicant: Grandex International Corporation Address of Applicant: 4F, No.527, Zhongzheng Rd., Xindian Dist., New Taipei City 23148, Taiwan (R.O.C.) Manufacturer/Factory: Grandex International Corporation Address of Manufacturer/Factory: 4F, No.527, Zhongzheng Rd., Xindian Dist., New Taipei City 23148, Taiwan (R.O.C.) Equipment Under Test (EUT) Product Name: MeatStick X Charger Model No.: TC640EX, TC620EX, TC630EX, PXOVNPRB1VDM (PS860P+TC620EX) Trade Mark: Grandex/ The MeatStick FCC ID: 2AHDSTC600-02 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of sample receipt: August 06, 2024 Date of Test: August 07-20, 2024 Date of report issued: August 20, 2024 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 30 2 Version Version No. Date Description 00 August 20, 2024 Original Prepared By: Date: August 20, 2024 Project Engineer Check By: Date: August 20, 2024 Reviewer Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 30 3 Contents Page 1 COVER PAGE ........................................................................................................................................... 1 2 VERSION .................................................................................................................................................. 2 3 CONTENTS .............................................................................................................................................. 3 4 TEST SUMMARY ..................................................................................................................................... 4 5 GENERAL INFORMATION ...................................................................................................................... 5 5.1 GENERAL DESCRIPTION OF EUT ......................................................................................................... 5 5.2 TEST MODE ........................................................................................................................................ 7 5.3 DESCRIPTION OF SUPPORT UNITS ....................................................................................................... 7 5.4 DEVIATION FROM STANDARDS ............................................................................................................. 7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................... 7 5.6 TEST FACILITY .................................................................................................................................... 7 5.7 TEST LOCATION ................................................................................................................................. 7 5.8 ADDITIONAL INSTRUCTIONS ................................................................................................................. 7 6 TEST INSTRUMENTS LIST ..................................................................................................................... 8 7 TEST RESULTS AND MEASUREMENT DATA .................................................................................... 10 7.1 ANTENNA REQUIREMENT ................................................................................................................... 10 7.2 CONDUCTED OUTPUT POWER ........................................................................................................... 11 7.3 CHANNEL BANDWIDTH ...................................................................................................................... 12 7.4 POWER SPECTRAL DENSITY ............................................................................................................. 13 7.5 SPURIOUS EMISSION IN NON-RESTRICTED & RESTRICTED BANDS ....................................................... 14 7.5.1 Conducted Emission Method ..................................................................................................... 14 7.5.2 Radiated Emission Method ........................................................................................................ 15 8 TEST SETUP PHOTO ............................................................................................................................ 30 9 EUT CONSTRUCTIONAL DETAILS ..................................................................................................... 30 Report No.: GTS2024080048F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 4 of 30 4 Test Summary Test Item Section in CFR 47 Result Antenna requirement 15.203/15.247 (c) Pass AC Power Line Conducted Emission 15.207 N/A Conducted Output Power 15.247 (b)(3) Pass Channel Bandwidth 15.247 (a)(2) Pass Power Spectral Density 15.247 (e) Pass Band Edge 15.247(d) Pass Spurious Em…

Text truncated - open the document above for the full version.
