2AHGM-LR1321-RGB-TVLED STRIP

Dynamic mode cycle OFF ON Brightness +/-Dynamic mode +/- Dynamic mode speed +/- Color switching Motion Sensor OFF Automatic sensor (not working during the day) photosensitive switch on The lights are bright at night when someone enters the induction zone Static color Motion Sensor ON Four length set up ONOFF Brightness/Speed +- Static color Static red blue white 3 colors Static purple and orange 7 color running water 16 color running water Dynamic mode +/- Static red and green 3 color water gradient running Timer 4 H /8H Four length set up ONOFF Brightness/Speed +- Static color Static red blue white 3 colors Static purple and orange 7 color running water 16 color running water Dynamic mode +/- Static red and green 3 color water gradient running Time 4H/8H ON OFF Brightness/Speed +- Static color Static red blue white 3 colors Static purple and orange 7 color running water 16 color running water Dynamic mode +/- Static red and green 3 color water gradient running Timer 4H/8H Music Rhythm 1, fine blinding boxMusic rhythm 2, dance dance beat Dynamic mode cycle ONOFF Brightness +/- Dynamic mode +/- Speed+/- Static color TV screen capture FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

NINGBO YUSING LIGHTING CO., LTD 2023.3.9 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (Shenzhen LGT Test Service Co., Ltd.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signature: Date: 2023. 03.9 Name: Lei Cai Title: Certification Engineer Company: NINGBO YUSING LIGHTING CO., LTD

NINGBO YUSING LIGHTING CO., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023.3.9 Subject; Request for Confidentiality FCC ID: 2AHGM-LR1321-RGB-TV To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Part List In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Lei Cai/ NINGBO YUSING LIGHTING CO., LTD Title: Certification Engineer

Page 1 of 3 Report No.: LGT23A002 Appendix - External Photographs of EUT Constructional Details FCC ID: Model: Photo 1 Photo 2 Page 2 of 3 Report No.: LGT23A002 Photo 3 Photo 4 Page 3 of 3 Report No.: LGT23A002 Photo 5 Photo 6

Label & Location FCC ID: 2AHGM-LR1321-RGB-TV

Page 1 of 3 Report No.: LGT23A002 Appendix - Internal Photographs of EUT Constructional Details FCC ID: Model: Photo 1 Photo 2 Page 2 of 3 Report No.: LGT23A002 Photo 3 Photo 4 Page 3 of 3 Report No.: LGT23A002 Photo 5 ANT

FCC ID:2AHGM-LR1321-RGB-TV RF EXPOSURE EVALUATION METHOD SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID:2AHGM-LR1321-RGB-TV BT The Worst Case Mode 2402-2480MHz Detector PEAK 2402MHz 4±1dBm 2440MHz 4.5±1dBm 2480MHz 4.5±1dBm Remark: The worst case gain of the antenna is 0dBi. 0dBi logarithmic terms convert to numeric result is nearly 1 2.4024.8653.162277660.98023 2.445.175.53.5481338921.10853 2.484.925.53.5481338921.11753 Limit Maximum Peak Conducted Output Power (dBm) frequency (GHz) Tune up Power (dBm) Tune up Power (mW) Result Threshold at which no SAR required is 1.1175≤ 3.0 for 1-g SAR, Separation distance is 5mm.

Antenna Spc. Frequency Total(dBi) 2402 MHz -1.46 -1.02 0.00 2440 MHz 2480 MHz Model: LR1321 RGB TV 3.8M 1024 Manufacturer: NINGBO YUSING LIGHTING CO., LTD Address: NO.1199, Mingguang RD. Jiangshan Town, Ningbo, 315195 P.R.China Typical Free Space Radiation Pattern 3D Radiation Pattern Typical Free Space Radiation Pattern 2D Radiation Pattern PHI=0 Prepared Checked Approved Jack ma Tom yang Tony tse PHI=90 THETA=90

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China RF TEST REPORT Product Name: LED STRIP Model Name: LR1321-RGB-TV-3.8M-1024 FCC ID: 2AHGM-LR1321-RGB-TV Issued For : NINGBO YUSING LIGHTING CO., LTD NO.1199, Mingguang RD. Jiangshan Town, Ningbo, 315195 P.R.China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Report Number: LGT23A002RF01 Sample Received Date: Jan. 03, 2023 Date of Test: Jan. 03, 2023 – Feb. 07, 2023 Date of Issue: Feb. 07, 2023 Report No.: LGT23A002RF01 Page 2 of 53 TEST REPORT CERTIFICATION Applicant NINGBO YUSING LIGHTING CO., LTD Address NO.1199, Mingguang RD. Jiangshan Town, Ningbo, 315195 P.R. China Manufacturer NINGBO YUSING LIGHTING CO., LTD Address NO.1199, Mingguang RD. Jiangshan Town, Ningbo, 315195 P.R. China Product Name LED STRIP Trademark Yusing Model Name LR1321-RGB-TV-3.8M-1024 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2013 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT23A002RF01 Page 3 of 53 Table of Contents 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.5 EQUIPMENTS LIST 12 3. EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.2 TEST PROCEDURE 14 3.3 TEST SETUP 14 3.4 EUT OPERATING CONDITIONS 14 3.5 TEST RESULTS 14 4. RADIATED EMISSION MEASUREMENT 15 4.1 RADIATED EMISSION LIMITS 15 4.2 TEST PROCEDURE 17 4.3 TEST SETUP 18 4.4 EUT OPERATING CONDITIONS 18 4.5 FIELD STRENGTH CALCULATION 19 4.6 TEST RESULTS 20 4.7 RADIATED BAND EDGE 28 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 32 5.1 LIMIT 32 5.2 TEST PROCEDURE 32 5.3 TEST SETUP 32 5.4 EUT OPERATION CONDITIONS 32 5.5 TEST RESULTS 32 6. POWER SPECTRAL DENSITY TEST 33 6.1 LIMIT 33 6.2 TEST PROCEDURE 33 6.3 TEST SETUP 33 Report No.: LGT23A002RF01 Page 4 of 53 Table of Contents 6.4 EUT OPERATION CONDITIONS 33 6.5 TEST RESULTS 33 7. BANDWIDTH TEST 34 7.1 LIMIT 34 7.2 TEST PROCEDURE 34 7.3 TEST SETUP 34 7.4 EUT OPERATION CONDITIONS 34 7.5 TEST RESULTS 34 8. PEAK OUTPUT POWER TEST 35 8.1 LIMIT 35 8.2 TEST PROCEDURE 35 8.3 TEST SETUP 35 8.4 EUT OPERATION CONDITIONS 35 8.5 TEST RESULTS 36 9. ANTENNA REQUIREMENT 37 9.1 STANDARD REQUIREMENT 37 9.2 EUT ANTENNA 37 APPENDIX I:TEST RESULTS 38 DUTY CYCLE 38 MAXIMUM PEAK CONDUCTED OUTPUT POWER 40 -6DB BANDWIDTH 41 OCCUPIED CHANNEL BANDWIDTH 43 MAXIMUM POWER SPECTRAL DENSITY LEVEL 45 BAND EDGE 47 CONDUCTED RF SPURIOUS EMISSION 50 APPENDIX II- TEST SETUP PHOTOS 53 Report No.: LGT23A002RF01 Page 5 of 53 Revision History Rev. Issue Date Contents 00 Feb. 07, 2023 Initial Issue Report No.: LGT23A002RF01 Page 6 of 53 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Report No.: LGT23A002RF01 Page 7 of 53 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Chen Hsong Industrial Park, No.177 Renmin West Road, Jinsha Community, Kengzi Street, Pingshan New District, Shenzhen, China Accreditation Certificate A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. Parameter Uncertainty Occupied Channel Bandwidth ±3.2 % RF Output Power, Conducted ±0.71dB Power Spectral Density, Conducted ±1.57 dB Unwanted Emission, Conducted ±0.63dB Conducted emission ±2.80dB All Emissions, Radiated (0.009-30MHz) ±2.16dB All Emissions, Radiated (30MHz-1GHz) ±4.40dB All Emissions, Radiated (1GHz-18GHz) ±5.49dB Temperature ±0.5°C Humidity ±2% Duty Cycle ±2.3% Report No.: LGT23A002RF01 Page 8 of 53 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name LED STRIP Trademark Yusing Model Name LR1321-RGB-TV-3.8M-1024 Series Model N/A Model Difference N/A Product Description The EUT is a LED STRIP Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: BLE (1M PHY) Number Of Channel: 40 Antenna Designation: Please refer to the Note 3. Antenna Gain (dBi) 0dBi Channel List Please refer to the Note 2. Battery Model: CR2025 Capacity: 150mAh Rated Voltage: 3V Hardware Version N/A Software Version N/A Connecting I/O Port(s) Please refer to the Note 1. Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User Manual. Report No.: LGT23A002RF01 Page 9 of 53 2. Channel List Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (…

Text truncated - open the document above for the full version.

Page 1 of 1 Report No.: LGT23A002 Appendix - Test Setup photos FCC ID: 2AHGM-LR1321-RGB-TV Model: LR1321-RGB-TV-3.8M-1024 Radiated Spurious Emission Test Setup Photo - Below 1GHz Radiated Spurious Emission Test Setup Photo - Above 1GHz
