2AHGM-S-PFW01-UWIFI socket

Function Key and Indicator Description: Short press the power button, red indicator lights up means power on, red indicator lights off means power off. Long press the power button for about 5 seconds, blue indicator flashes means the product begin enter into the distribution network mode. Blue indicator flashes slowly means the network connection is abnormal, please check the router or network configuration. Technical Parameters: Maximum current: 10A Rated voltage: 110-130V Rated power: 1200W（Max） Input voltage: 110-130V Wireless Type: Wi-Fi 2.4GHz Operating temperature: -10 °C-50 °C Support system: Android \IOS Turn On Intelligence Software Thefree“smart life”Appis requiredto operate yourWi- FiSmartSocket. It’savailableonthe App storeand GooglePlay storeforAndroid andIOSdevices. 1.EnsureyourIOS/Androiddeviceis connected to the internetusingaWi-Finetwork. 2.OpentheAppstore/GooglePlay storeonyour phone. 3.Searchfor “smart life” intheApp store/GooglePlay store. 4.Downloadthe “smart life” Appto yourphone. WIFI SMART SOCKET Work with Amazon Echo And Google Home On/OffPlug-InSwitch Connecting yourSmart SockettoWi-Fi 1.Plug your Wi-Fi Smart Socket into an electrical socket and Switch it on. 2.Open up your app and select the + Icon on the top right of the App to add device. 3.Select “Plug” as the Device Type. The App can also be used to control other compatible Smart Devices. 4.Select “Plug” as the Device Type. The App can also be used to control other compatible Smart Devices. Select “Finish Network Configuration” when the blue LED is flashing quickly. If the blue LED light isn’t flashing quickly when you’ve plugged in your Smart Socket keep the Power button in the centre of your Wi-Fi Smart Socket pressed for 5 seconds to reset the device. 5. The App will automatically detect the Wi-Fi network you are connected to. Enter the password of the Wi-Fi Router you are connected to. Click “Next” when you’ve entered your Wi-Fi password and the blue LED light is flashing every two seconds 6. Once paired, you will see the following screen with the device you have successfully added. If you do not see this message repeat from Step 1 or refer to the FAQS at the back of the manual for more information. Note:The configuration process shouldtake about 1 minute Max. CORRECTDISPOSALOFBATTERIESINTHISPRODUCT Thismarkingontheproduct,accessoriesorliteratureindicatesthattheproduct anditselectronicaccessoriesshouldnotbedisposedofwithotherhouseholdwaste. Topreventpossibleharmtotheenvironmentorhumanhealthfromuncontrolled wastedisposal,pleaseseparatetheseitemsfromothertypesofwasteandrecycle themresponsiblytopromotethesustainablereuseofmaterialresources. Householdusersshouldcontacteithertheretailerwheretheypurchasedthis product,ortheirgovernmentoffice,fordetailsofwhereandhowtheycantakethese itemsforenvironmentallysaferecycling. Businessusersshouldcontacttheirsupplierandcheckthetermsandconditions ofthepurchasecontract.Thisproductanditselectronicaccessoriesshouldnotbe mixedwithotherwastesfordisposal. Thismarkingonthebattery,manualorpackagingindicatesthatthebatteriesin thisproductshouldnotbedisposedofwithotherhouseholdwaste.Wheremarked, thechemicalsymbolsHg,CdorPbindicatethatthebatterycontainsmercury, cadmiumorleadabovethereferencelevelsinECDirective2006/66.Ifbatteriesare notproperlydisposedof,thesesubstancescancauseharmtohumanhealthorthe environment. Registration You’ll need to register an account on your “smart life” app before you can connect your Wi-Fi Smart Socket. 1.Open the App on your IOS / Android device 2.Ensure you click on ALLOW to enable you to control your Wi- Fi Smart Socket. 3.Please register by clicking on Register in the top right corner of the App. You will be prompted to enter your mobile number or email address to register. Note: If you use a Mobile number you will be sent a text message with your confirmation code to complete your account registration. 4.Once you receive your confirmation code type it in along with a password for the “smart life” App and select confirm. You can use this to log in to APP. 5.You are now ready to set up your Wi-Fi Smart Socket. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. RF exposure warning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with a…

Text truncated - open the document above for the full version.

SCS-F019: Confidentiality Request Letter Page 1 of 2 Rev 7.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] W ebsite: https://www.cps.bureauveritas.com/ Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 Updated References and Contact Info 6.0 7.0 Aug-30-2020 SCS-F019: Confidentiality Request Letter Page 2 of 2 Rev 7.0 NINGBO YUSING LIGHTING CO., LTD October 16, 2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046-1609 Cc: Bureau Veritas Consumer Products Services Inc. 775 Montague Expressway Milpitas, CA 95035 Subject: Confidentiality Request for FCC ID: 2AHGM-S-PFW01-U Pursuant to CFR 47 sections 0.457 and 0.459, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application be held confidential: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagram Short Term External Photos Short Term Permanent i Internal Photos Short Term Permanent Operational Description/ Theory of Operation Short Term Permanent Parts List Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent i User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: To avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of not to exceed 180 days from the Grant Date The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Client’s name / title: Lei Cai/Manager Contact information / address: 86 0574-83028369/[email protected]/ No.1199, MINGGUANG RD. JIANGSHAN TOWN, NINGBO i Permanent confidentiality may be requested in accordance with FCC KDB 726920

Page 1 of 4 External Photo Page 2 of 4 Page 3 of 4 Page 4 of 4

Page 1 of 5 Internal Photo Page 2 of 5 Page 3 of 5 Page 4 of 5 Antenna Page 5 of 5

Report No.: PYU-ESH-P20092485B-2 Page 1 of 22 FCC/IC-ITE V1.1 FCC TEST REPORT Report No.: PYU-ESH-P20092485B-2 FCC ID: 2AHGM-S-PFW01-U Product: WIFI socket Test Model: smart-PFW01-U Received: Oct.10, 2020 ISSUED: Dec.23, 2020 Applicant: NINGBO YUSING LIGHTING CO.,LTD Address: NO.1199 Mingguang Road, Jiangshan Town,Ningbo,China Issued By: BUREAU VERITAS ADT (Shanghai) Corporation Lab Location: No. 829, Xinzhuan Road, Shanghai, P.R.China (201612) This test report consists of 25 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by A2LA, CNAS, or any government agency. The test results in the report only apply to the tested item. The test results in this report are traceable to the national or international standards. Report No.: PYU-ESH-P20092485B-2 Page 2 of 22 FCC/IC-ITE V1.1 Contents 1. TEST PROGRAM .................................................................................................................................... 3 2. Summary of Test Procedure and Test Results ..................................................................................... 4 3. Test Configuration of Equipment under Test ....................................................................................... 5 3.1 Manufacturer information............................................................................................................. 5 3.2 Feature of Equipment under Test ................................................................................................. 5 3.3 Description of support units ......................................................................................................... 5 3.4 Measurement Uncertainty ........................................................................................................... 6 4 Test of Conducted Emission ................................................................................................................. 7 4.1 Test Limit .................................................................................................................................... 7 4.2 Test Procedures .......................................................................................................................... 8 4.3 Typical Test Setup ....................................................................................................................... 8 4.4 Measurement Equipment ............................................................................................................ 9 4.5 Test Result and Data ................................................................................................................. 10 4.6 Test Photographs ...................................................................................................................... 12 5 Test of Radiated Emission .................................................................................................................. 13 5.1 Test Limit .................................................................................................................................. 13 5.2 Test Procedures ........................................................................................................................ 14 5.3 Typical Test Setup ..................................................................................................................... 14 5.4 Measurement Equipment .......................................................................................................... 15 5.5 Test Result and Data (30MHz ~ 1GHz) ...................................................................................... 16 5.6 Test Result and Data (1GHz ~ 18GHz) ...................................................................................... 18 5.7 Test Photographs (30MHz ~ 1000MHz) ..................................................................................... 20 5.8 Test Photographs (1000MHz ~ 18000MHz) ............................................................................... 21 6 Photographs of EUT ............................................................................................................................ 22 Report No.: PYU-ESH-P20092485B-2 Page 4 of 22 FCC/IC-ITE V1.1 2. Summary of Test Procedure and Test Results EMISSION (47 CFR FCC Part15, Subpart B) Test Item Normative References Test Result Conducted Emission 47 CFR FCC Part15, Subpart B 15.107 Meets the Class B requirements Radiated Emission 47 CFR FCC Part15, Subpart B 15.109 Meets the Class B requirements Report No.: PYU-ESH-P20092485B-2 Page 5 of 22 FCC/IC-ITE V1.1 3. Test Configuration of Equipment under Test 3.1 Manufacturer information Manufacturer : NINGBO YUSING LIGHTING CO.,LTD Address : NO.1199 Mingguang Road, Jiangshan Town,Ningbo,China 3.2 Feature of Equipment under Test Product Name: WIFI socket Test Model: smart-PFW01-U Model Discrepancy: -- EUT Power Rating: 110-130V~,10A Note: 1. Please refer to user manual. 3.3 Description of support units NO. PRODUCT BRAND MODEL NO. 1 Mobile Phone Vivo -- Report No.: PYU-ESH-P20092485B-2 Page 6 of 22 FCC/IC-ITE V1.1 3.4 Measurement Uncertainty Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT: This listed uncertainties are the worst case uncertainty for the entire range of measurement. Please note that the uncertainty values are provided for informational purposes only and are not used in determining the PASS/FAIL results. Measurement Value Conducted emissions 2.55 dB Radiated emissions 30 MHz ~ 1GHz 3.22 dB Above 1GHz 2.89 dB Report No.: PYU-ESH-P20092485B-2 Page 7 of 22 FCC/IC-ITE V1.1 4 Test of Conducted Emission 4.1 Test Limit TEST STANDARD: CFR 47 FCC Part 15, Subpart B (Section: 15.107) FREQUENCY (MHz) Class A (dBμV) C…

Text truncated - open the document above for the full version.

Page 1 of 3 Test Setup Photo Page 2 of 3 1. Radiated Emission Below 1GHz Above 1GHz Page 3 of 3 2. Conducted Emission
