Shenzhen Yuejiang Technology Co., Ltd Declaration concerning Antenna Specification It is hereby declared that the product Model No.: DT-MZ-3ZSG-00C FCC ID: 2AHI4-MOOZ-3 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for External plastic rod antenna type(s) described below: Model No. of antenna: ANT1 Type of antenna: External plastic rod antenna Gain of the antenna: 2.75 dBi Frequency range: 2412-2462MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Shenzhen Yuejiang Technology Co., Ltd Address: Floor 9-10,Building 2,Chongwen Garden,No. 3370 Nanshan iPark, Liuxian Avenue, Nanshan District City: Shenzhen City ZIP / Postal code: Country: China Name: Barry Wang Date: 2020-01-08 Signature:

Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1905014FV00-1 FCC ID: 2AHI4-MOOZ-3 RF EXPOSURE EVALUATION EUT Specification EUT DOBOT MOOZ Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others(Bluetooth: 2.402GHz ~ 2.480GHz) Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 16.28 dBm (42.46mW) Antenna gain 2.75 dBi Evaluation applied MPE Evaluation SAR Evaluation Limits for Maximum Permissible Exposure (MPE) Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density(mW/cm 2 ) 300-1500 -- -- F/1500 1500-100000 -- -- 1 Dongguan Nore Testing Center Co., Ltd. Report No.: NTC1905014FV00-1 FCC ID: 2AHI4-MOOZ-3 Friis transmission formula: Pd=(Pout*G)\(4*pi*R 2 ) Where Pd= Power density in mW/cm 2 Pout=output power to antenna in Mw G= gain of antenna in linear scale Pi=3.1416 R= distance between observation point and center of the radiator in cm Pd the limit of MPE, 1mW/cm2. If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Channel Gain Channel Frequency (MHz) Max Output power (dBm) Tolerance Max Tune-UP power (mW) Power density at 20cm (mW/ cm 2 ) Power density Limits (mW/cm 2 ) 802.11b Low 2.75 2412 15.28 ± 0.5 37.844 0.01418 1 Middle 2.75 2437 14.97 ± 0.5 35.237 0.01320 1 High 2.75 2462 14.80 ± 0.5 33.884 0.01270 1 802.11g Low 2.75 2412 16.22 ± 0.5 46.989 0.01761 1 Middle 2.75 2437 16.15 ± 0.5 46.238 0.01733 1 High 2.75 2462 15.67 ± 0.5 41.400 0.01551 1 802.11n(HT20) Low 2.75 2412 16.28 ± 0.5 47.643 0.01785 1 Middle 2.75 2437 16.21 ± 0.5 46.881 0.01757 1 High 2.75 2462 15.71 ± 0.5 41.783 0.01566 1
