2AHST-SB9001KLED Controllers

09.SB901K5M.04754 Note:Before the first use, please remove the protective film on the battery. Function introduction Important: Read All Instructions Prior to Installation Back side RF+Bluetooth US Size Single Color Remote Controller Prog. RF+Bluetooth LED Receiver Output RF+Bluetooth Operation Frequency 2.4GHz Operating temperature 0-40°C Relative humidity 8% to 80% Dimensions 66x32.5x8.9mm Product Data • • DO NOT expose the device to moisture. This device contains a button lithium battery that shall be stored and disposed properly. Safety & Warnings Power Supply 3V(1xCR2032 battery) • • •Easy & quick pairing to the RF+Bluetooth receivers by simply pushing the buttons •Mesh network for further control distance, receivers can transmit signal to each other •Each remote can control numerous receivers •Each receiver can be paired to max. 8 remote controls •The controlled receiver status can be quickly synchronized to the smart APP •Transmission range between every two neighbor devices up to 30m •Bluetooth low power consumption technology, long battery life RF+Bluetooth Single color wall mounted remote control Enables to control 1 zone of receivers Pair with RF+Bluetooth receiver Step 3: the receiver flicker once means the receiver is paired to the remote successfully. Click any button of the remote(e.g. button ), LED lights connected with Step 2:Prog. KeyReset pairing status Click the “” or “” button on RF+Bluetooth receiver to set it into Note: one receiver can be paired with max 8 remote controls. Step 1: to the instruction of RF+Bluetooth receiver that you would like to pair with. Do wiring the RF+Bluetooth receiver according to wiring diagram(please refer Front side Press and hold down to increase light intensity Press and hold down to decrease light intensity Press and hold down to save color, click to recall the saved Click to turn on the light Click to turn off the light Bracket magnet Installation FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. IC STATEMENT This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

Differences Declaration To whom concern, We company Shenzhen Sunricher Technology Limited hereby declares: The product models SR-SB9001K5-RGBW, SR-SB9001K5-DIM, SR-SB9001K5-CCT, SR-SB9001K5-RGB, SR-BL9001K5-DIM, SR-BL9001K5-RGBW, SR-BL9001K5-CCT, SR-BL9001K5-RGB, SR-ZG9001K5-DIM, SR-ZG9001K5-RGB, SR-ZG9001K5-CCT, SR-ZG9001K5-CCT2, SR-ZG9001K5-RGBW, SR-2833N-K5-RGBW, SR-2833N-K5-CCT, SR-2833N-K5-RGB, SR-2833N-K5-US, RFD9001Z, RFD9001Z300 are identical in the same PCB layout, interior structure and electrical circuits, The differences are appearance color and model name for commercial purpose. Authorized signature: Date: 2020-11-17

Shenzhen Sunricher Technology Limited DA TE : 2020-11-17 E quipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 F CC ID: 2AHST-SB9001K Product Name: LED Controllers Request for Confidentiality T o Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. T hese documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description I n additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. I t is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature: Name: Sunny Zou Title: Manager Company: Shenzhen Sunricher Technology Limited

DATE : 2020-11-17 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Jason Wu of Global United Technology Services Co., Ltd.and No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Shenzhen Sunricher Technology Limited and 3rd Floor,B building,Jia'an Industrial Building, Liu Xian Third road,No.72 area, Xin'an Street, Baoan District, Shenzhen, China Signature: Name: Sunny Zou Title: Manager Company: Shenzhen Sunricher Technology Limited

Model:SR-SB9001K5-RGBW IC:20309-SB9001K FCC ID:2AHST-SB9001K 3V .d.c CR2032 10mA

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√ f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison Worse case is as below: [2402 MHz 2.86dBm（ 1.932 mW）output power] (1.932mW /5mm) ·[√2.402(GHz)]= 0.6 <3.0 for 1-g SAR Then SAR evaluation is not required

Radiated Emission
