2AHVL-CSI-PHA1i-Strength Resistance Module

Dyaco International Inc.

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Dec 17, 2025
Application Purpose: Original Equipment
Equipment Note: i-Strength Resistance Module
Frequency Range: 5180.00000000 - 5240.00000000
Company: Dyaco International Inc.
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

Dyaco International Inc. 12F No.111 Songiiang Road Taipei 104, Taiwan Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 11-07-2025 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AHVL-CSI-PHA1 Dyaco International Inc. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Dyaco International Inc. certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, Applicant Printed Name: Kevin Liao Applicant’ s Signature: 2025.11.27 Dyaco International Inc. 12F No.111 Songiiang Road Taipei 104, Taiwan Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 11-07-2025 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AHVL-CSI-PHA1 Dyaco International Inc. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Applicant Printed Name: Kevin Liao Applicant’s Signature: 2025.11.27

Attestation Statements

DyacoInternationalInc. 12FNo.111SongiiangRoadTaipei104,Taiwan FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:12-09-2025 SUBJECT: ToWhomItMayConcern: I,theundersigned,herebystatesthisequipmenthasbeentestedandfoundtocomply withthelimitsforaClassAdigitaldevice,pursuanttopart15oftheFCCRules,and willapplytheSupplier'sDeclarationofConformityproceduretotheClassA commercial,industrialorbusinessenvironmentdevices’requirements.Iunderstand thefollowingFCCrequirements: 1.DevicessubjecttotheSDoCprocedurearerequiredtobetestedtoshow compliancewiththeFCCtechnicalregulationsbyarecognizedaccreditedtesting laboratory.ThetestinglaboratorymustbeaccreditedbyaCommissionapproved accreditationbodyordesignatedunderthetermsofagovernment-to-government MutualRecognitionAgreement(MRA).Alistingofthoseaccreditedtesting laboratoriesthathavebeenrecognizedbytheCommissionispublishedontheFCC Webpage:https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm(Selectthe "accredited"optiontosearchforFCCrecognizedaccreditedtestfirms.) 2.Pt2.1077containsthelistofinformationthatmustbeincludedintheSupplier's DeclarationofConformity,whichmustbesuppliedwitheachproductsold.The SDoCcomplianceinfoshallbeincludedintheUser’sManualorasaseparate sheet.Theinfomustcontainthename,address,andphonenumberofthe responsibleparty,whichmustbelocatedwithintheUnitedStates.Accordingto 2.909(b),theresponsiblepartyiseithertheManufactureroriftheproductis importedtheImporter. Regards, ApplicantPrintedName:KevinLiao 2025.12.09 ------------------------------- (Applicant’sSignature)

Cover Letter(s)

Dyaco International Inc. 12F No.111 Songiiang Road Taipei 104, Taiwan Family Model Similarity Declaration Date: 2025-11-07 SUBJECT: Family Model Similarity Declaration Letter To Whom It May Concern: We declare that the family models listed below are electrically identical. Product Information Applicant Name: Dyaco International Inc. Product Description: i-Strength Resistance Module Model (s): IS-2001, IS-2002, IS-2003, IS-1001, CSI-CPSP, CSI-BCTE, CSI-LELC, CSI-LROW The only differences between the certified model IS-2001 and the listed variant models (IS-2002, IS-2003, IS-1001, CSI-CPSP, CSI-BCTE, CSI-LELC, CSI-LROW) are color and the length differences of the pipes supporting the display control system. These differences do not affect the RF characteristics or EMC performance of the product. All listed variants are therefore electrically and functionally equivalent to the certified model IS-2001. Regards Applicant Printed Name: Kevin Liao Applicant’s Signature: Company: Dyaco International Inc. Job Title: E.E. Dept. Manager Email: [email protected] Telephone: +886-4-7977888#650 2025.11.27

Cover Letter(s)

Dyaco International Inc. 12F No.111 Songiiang Road Taipei 104, Taiwan Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AHVL-CSI-PHA1 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name* Schematics Schematics.pdf Block Diagram Block Diagram.pdf Operation description Operation description.pdf NII security information NII security information.pdf BOM BOM.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application for 180 days as outlined below: Exhibit Type File Name* External Photos External Photos.pdf Internal Photos Internal Photos.pdf Test Setup Photos Test Photos.pdf User Manual User Manual.pdf Sincerely, Applicant Printed Name: Kevin Liao Applicant’s Signature: 2025.11.27

Cover Letter(s)

Dyaco International Inc. 12F No.111 Songiiang Road Taipei 104, Taiwan Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 11-07-2025 SUBJECT: FCC Application for 2AHVL-CSI-PHA1 To Whom It May Concern: We, the undersigned, hereby authorize Mr. Bob Dai at ITL Co., Ltd on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Mr. Bob Dai on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Applicant’s Printed Name: Kevin Liao Applicant’s Signature: 2025.11.27

RF Exposure Info

MPEEvaluation Applicant:DyacoInternationalInc. FCCID: 2AHVL-CSI-PHA1 Model: IS-2001,IS-2002,IS-2003,IS-1001,CSI-CPSP,CSI-BCTE,CSI-LELC,CSI-LROW MPEEvaluation RFExposureComplianceRequirement StandardRequirement AccordingtoKDB447498D01GeneralRFExposureGuidancev06andFCC1.1310Radio frequencyradiationexposurelimitsforGeneralPopulation/UncontrolledExposure. EUTRFExposure Pd=PG/4 π R 2 Pd=powerdensityinmW/cm 2 P=outputpowertoantennainmW G=gainofantennainlinearscale π =3.14 R=distancebetweenobservationpointandcenteroftheradiatorincm Remark:Thisdevicecouldn’tsupport2.4&5GWIFIsimultaneoustransmission. For2.4GWIFI TheMaxOutputPoweris20.565dBmin802.11g2462MHz; Antennagain:1.95dBi,gainofantennainlinearscale:1.57 R=20cm Pd=PG/(4πR 2 )=0.035mW/cm 2 <1(limits)mW/cm 2 For5GWIFIBandI TheMaxOutputPoweris9.81dBm802.11ax40in5230MHz; Antennagain:3.96dBi,gainofantennainlinearscale:2.49 R=20cm Pd=PG/(4πR 2 )=0.0047mW/cm 2 <1(limits)mW/cm 2 For5GWIFIBandII TheMaxOutputPoweris9.76dBmin802.11n405310MHz; Antennagain:3.96dBi,gainofantennainlinearscale:2.49 R=20cm Pd=PG/(4πR 2 )=0.0046mW/cm 2 <1(limits)mW/cm 2 For5GWIFIBandIII TheMaxOutputPoweris13.81dBmin802.11ax205700MHz; Antennagain:3.96dBi,gainofantennainlinearscale:2.49 R=20cm Pd=PG/(4πR 2 )=0.0119mW/cm 2 <1(limits)mW/cm 2 For5GWIFIBandIV TheMaxOutputPoweris12.84dBmin802.11a5745MHz; Antennagain:3.96dBi,gainofantennainlinearscale:2.49 R=20cm Pd=PG/(4πR 2 )=0.0095mW/cm 2 <1(limits)mW/cm 2 --END--

Test Report

ITL Page 1 of 169 Report No.: 250925014-2 Page: 1 of 169 TEST REPORT Applicant: Dyaco International Inc. Address of Applicant: 12F No.111 Songiiang Road Taipei 104, Taiwan Manufacturer: Guangzhou Yuandong Smart Sports Technology Co., Ltd. Address of Manufacturer: Room 1002, Building 2, No. 6, Yunpu 4th Road, Huangpu District, Guangzhou Product name: i-Strength Resistance Module Model(s): IS-2001, IS-2002, IS-2003, IS-1001, CSI-CPSP, CSI-BCTE, CSI-LELC, CSI-LROW Rating(s): AC 100-240V 50/60 Hz 1500W Trademark: Standards: FCC CFR Title 47 Part 15 Subpart E Section 15.407 FCC ID: 2AHVL-CSI-PHA1 Data of Receipt: 2025-09-28 Date of Test: 2025-09-28~2025-10-18 Date of Issue: 2025-10-18 Test Result Pass* * In the configuration tested, the test item complied with the standards specified above. Authorized for issue by: Test by: Reviewed by: Oct.18, 2025 Chivas Tsang Oct.18, 2025 Victor Meng Project Engineer Project Manager Date Name/Position Signature Date Name/Position Signature ITL Page 2 of 169 Report No.: 250925014-2 Testing Laboratory information: Testing Laboratory Name .......... : ITL Co., Ltd Address ...................................... : No. 8 Jinqianling Street 5, Huangjiang Town, Dongguan, Guangdong, 523757 P.R.C. Testing location .......................... : Same as above Tel ............................................... : 0086-769-39001678 Fax .............................................. : 0086-20-62824387 E-mail .......................................... : [email protected] Possible test case verdicts: - test case does not apply to the test object .. : N/A - test object does meet the requirement ........ : P (Pass) - test object does not meet the requirement . : F (Fail) General remarks: The test results presented in this report relate only to the object tested. The results contained in this report reflect the results for this particular model and serial number. It is the responsibility of the manufacturer to ensure that all production models meet the intent of the requirements detailed within this report. This report would be invalid test report without all the signatures of testing technician and approver. This report shall not be reproduced, except in full, without the written approval of the Issuing testing laboratory. General product information: The only differences between the certified model IS-2001 and the listed variant models (IS-2002, IS-2003, IS-1001, CSI-CPSP, CSI-BCTE, CSI-LELC, CSI-LROW) are color and the length differences of the pipes supporting the display control system. This device doesn’t support Resource Units characteristic. These differences do not affect the RF characteristics or EMC performance of the product. All listed variants are therefore electrically and functionally equivalent to the certified model IS-2001. ITL Page 3 of 169 Report No.: 250925014-2 Contents 1. TEST STANDARDS AND REPORT VERSION 4 1.1. Test Standards 4 1.2. Report Version 4 2. TEST DESCRIPTION 5 3. SUMMARY 6 3.1. Client Information 6 3.2. Product Description 6 3.3. Operation state 7 3.4. EUT configuration 8 3.5. Discontinue transmitting with absence of Data or operational failure states 8 4. TEST ENVIRONMENT 8 4.1. Address of the test laboratory 8 4.2. Test Facility 8 4.3. Environmental conditions 9 4.4. Statement of the measurement uncertainty 9 4.5. Equipments Used during the Test 10 5. TEST CONDITIONS AND RESULTS 11 5.1. Antenna requirement 11 5.2. Conducted Emissions (AC Main) 12 5.3. Maximum Conducted Output Power 15 5.4. Power Spectral Density 18 5.5. -26dB&-6 bandwidth and 99% Occupied bandwidth 59 5.6. -6dB Bandwidth 130 5.7. Band Edge 141 5.8. Radiated Spurious Emissions 144 5.9. Frequency stability 153 5.10. Radiated Emissions which fall in the restricted bands 157 5.11. Dynamic Frequency Selection(DFS) 160 ITL Page 4 of 169 Report No.: 250925014-2 1. TEST STANDARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: FCC Rules Part 15.407: General technical requirements. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB789033 D02 v02r01: GUIDELINES FOR COMPLIANCE TESTING OF UNLICENSED NATIONAL INFORMATION INFRASTRUCTURE (U-NII) DEVICES PART 15, SUBPART E KDB662911 D01 v02r01: Multiple Transmitter Output 1.2. Report Version Revision No. Date of issue Description N/A / / ITL Page 5 of 169 Report No.: 250925014-2 2. TEST DESCRIPTION Test Item FCC Rule Result Antenna Requirement 15.203 PASS Line Conducted Emissions (AC Main) 15.207 PASS Maximum Conducted Output Power 15.407(a) PASS Power Spectral Density 15.407(a) PASS -26dB Bandwidth and 99% Occupied bandwidth 15.407(a) PASS -6dB Bandwidth 15.407(a) PASS Band Edge 15.407(b) PASS Radiated Spurious Emissions 15.209 PASS Frequency Stability 15.407(g) PASS Dynamic Frequency Selection(DFS) 15.407(h) PASS Radiated Emissions which fall in the restricted bands 15.209(c) PASS Remark: The measurement uncertainty is not included in the test result. ITL Page 6 of 169 Report No.: 250925014-2 3. SUMMARY 3.1. Client Information Applicant: Dyaco International Inc. Address: 12F No.111 Songiiang Road Taipei 104, Taiwan Manufacturer: Guangzhou Yuandong Smart Sports Technology Co., Ltd. Address: Room 1002, Building 2, No. 6, Yunpu 4th Road, Huangpu District, Guangzhou 3.2. Product Description Name of EUT i-Strength Resistance Module Trade Mark: Model No.: IS-2001 Listed Model(s): IS-2001, IS-2002, IS-2003, IS-1001, CSI-CPSP, CSI-BCTE, CSI-LELC, CSI- LROW Power supply: AC 100-240V 50/60 Hz 1500W 5G WIFI Supported type: 802.11a 802.11n(HT20) 802.11n(HT40) 802.11ac(HT20) 802.11ac(HT40) 802.11ax(HT20) 802.11ax(HT40) Function: Outdoor AP Indoor AP Fixed P2P Client DFS type: master devices Slave devices with radar detection Slave devices without radar detection Modulation: CCK, OFDM, QPSK, BPSK, 16QAM, 64QAM, 1024QAM Operation frequency: Band I: 5150MHz~5250MHz Band II: 5250MHz~5350MHz Band III: 5470MHz~5725MHz Band IV: 5725MHz~5850MHz Supported Bandwidth 20MHz:…

Text truncated - open the document above for the full version.

Test Report

ITL Page 61 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT a 5200MHz Ant1 -26dB Bandwidth NVNT a 5240MHz Ant1 ITL Page 62 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ac20 5180MHz Ant1 -26dB Bandwidth NVNT ac20 5200MHz Ant1 ITL Page 63 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ac20 5240MHz Ant1 -26dB Bandwidth NVNT ac40 5190MHz Ant1 ITL Page 64 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ac40 5230MHz Ant1 -26dB Bandwidth NVNT ax20 5180MHz Ant1 ITL Page 65 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ax20 5200MHz Ant1 -26dB Bandwidth NVNT ax20 5240MHz Ant1 ITL Page 66 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ax40 5190MHz Ant1 -26dB Bandwidth NVNT ax40 5230MHz Ant1 ITL Page 67 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT n20 5180MHz Ant1 -26dB Bandwidth NVNT n20 5200MHz Ant1 ITL Page 68 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT n20 5240MHz Ant1 -26dB Bandwidth NVNT n40 5190MHz Ant1 ITL Page 69 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT n40 5230MHz Ant1 Band II Mode Frequency (MHz) -26 dB Bandwidth (MHz) Limit -26 dB Bandwidth (MHz) Verdict a 5260 24.39 0.5 Pass a 5280 24.678 0.5 Pass a 5320 24.663 0.5 Pass ac20 5260 28.101 0.5 Pass ac20 5280 26.637 0.5 Pass ac20 5320 28.236 0.5 Pass ac40 5270 47.214 0.5 Pass ac40 5310 45.522 0.5 Pass ax20 5260 25.644 0.5 Pass ax20 5280 26.64 0.5 Pass ax20 5320 25.989 0.5 Pass ax40 5270 45.042 0.5 Pass ax40 5310 44.004 0.5 Pass n20 5260 27.975 0.5 Pass n20 5280 28.23 0.5 Pass n20 5320 26.97 0.5 Pass n40 5270 46.452 0.5 Pass n40 5310 46.392 0.5 Pass ITL Page 70 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT a 5260MHz Ant1 -26dB Bandwidth NVNT a 5280MHz Ant1 ITL Page 71 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT a 5320MHz Ant1 -26dB Bandwidth NVNT ac20 5260MHz Ant1 ITL Page 72 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ac20 5280MHz Ant1 -26dB Bandwidth NVNT ac20 5320MHz Ant1 ITL Page 73 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ac40 5270MHz Ant1 -26dB Bandwidth NVNT ac40 5310MHz Ant1 ITL Page 74 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ax20 5260MHz Ant1 -26dB Bandwidth NVNT ax20 5280MHz Ant1 ITL Page 75 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ax20 5320MHz Ant1 -26dB Bandwidth NVNT ax40 5270MHz Ant1 ITL Page 76 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ax40 5310MHz Ant1 -26dB Bandwidth NVNT n20 5260MHz Ant1 ITL Page 77 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT n20 5280MHz Ant1 -26dB Bandwidth NVNT n20 5320MHz Ant1 ITL Page 78 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT n40 5270MHz Ant1 -26dB Bandwidth NVNT n40 5310MHz Ant1 ITL Page 79 of 169 Report No.: 250925014-2 Band III Mode Frequency (MHz) -26 dB Bandwidth (MHz) Limit -26 dB Bandwidth (MHz) Verdict a 5500 24.744 0.5 Pass a 5600 24.633 0.5 Pass a 5700 24.48 0.5 Pass ac20 5500 27.66 0.5 Pass ac20 5600 27.945 0.5 Pass ac20 5700 27.978 0.5 Pass ac40 5510 46.836 0.5 Pass ac40 5590 46.194 0.5 Pass ac40 5670 46.356 0.5 Pass ax20 5500 25.482 0.5 Pass ax20 5600 25.551 0.5 Pass ax20 5700 25.62 0.5 Pass ax40 5510 44.478 0.5 Pass ax40 5590 44.646 0.5 Pass ax40 5670 44.61 0.5 Pass n20 5500 27.723 0.5 Pass n20 5600 26.868 0.5 Pass n20 5700 27.747 0.5 Pass n40 5510 47.034 0.5 Pass n40 5590 46.578 0.5 Pass n40 5670 46.902 0.5 Pass -26dB Bandwidth NVNT a 5500MHz Ant1 ITL Page 80 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT a 5600MHz Ant1 -26dB Bandwidth NVNT a 5700MHz Ant1 ITL Page 81 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ac20 5500MHz Ant1 -26dB Bandwidth NVNT ac20 5600MHz Ant1 ITL Page 82 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ac20 5700MHz Ant1 -26dB Bandwidth NVNT ac40 5510MHz Ant1 ITL Page 83 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ac40 5590MHz Ant1 -26dB Bandwidth NVNT ac40 5670MHz Ant1 ITL Page 84 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ax20 5500MHz Ant1 -26dB Bandwidth NVNT ax20 5600MHz Ant1 ITL Page 85 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ax20 5700MHz Ant1 -26dB Bandwidth NVNT ax40 5510MHz Ant1 ITL Page 86 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT ax40 5590MHz Ant1 -26dB Bandwidth NVNT ax40 5670MHz Ant1 ITL Page 87 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT n20 5500MHz Ant1 -26dB Bandwidth NVNT n20 5600MHz Ant1 ITL Page 88 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT n20 5700MHz Ant1 -26dB Bandwidth NVNT n40 5510MHz Ant1 ITL Page 89 of 169 Report No.: 250925014-2 -26dB Bandwidth NVNT n40 5590MHz Ant1 -26dB Bandwidth NVNT n40 5670MHz Ant1 ITL Page 90 of 169 Report No.: 250925014-2 99% Occupied Bandwidth Band I Mode Frequency (MHz) 99% OBW (MHz) a 5180 16.645 a 5200 16.651 a 5240 16.627 ac20 5180 18.01 ac20 5200 18.022 ac20 5240 18.001 ac40 5190 36.692 ac40 5230 36.728 ax20 5180 19.138 ax20 5200 19.156 ax20 5240 19.144 ax40 5190 37.97 ax40 5230 37.982 n20 5180 18.004 n20 5200 18.016 n20 5240 17.986 n40 5190 36.698 n40 5230 36.704 OBW NVNT a 5180MHz Ant1 ITL Page 91 of 169 Report No.: 250925014-2 OBW NVNT a 5200MHz Ant1 OBW NVNT a 5240MHz Ant1 ITL Page 92 of 169 Report No.: 250925014-2 OBW NVNT ac20 5180MHz Ant1 OBW NVNT ac20 5200MHz Ant1 ITL Page 93 of 169 Report No.: 250925014-2 OBW NVNT ac20 5240MHz Ant1 OBW NVNT ac40 5190MHz Ant1 ITL Page 94 of 169 Report No.: 250925014-2 OBW NVNT ac40 5230MHz Ant1 OBW NVNT ax20 5180MHz Ant1 ITL Page 95 of 169 Report No.: 250925014-2 OBW NVNT ax20 5200MHz Ant1 OBW NVNT ax20 5240MHz Ant1 ITL Page 96 of 169 Report No.: 250925014-2 OBW NVNT ax40 5190MHz Ant1 OBW NVNT ax40 5230MHz Ant1 ITL Page 97 of 169 Report No.: 250925014-2 OBW NVNT n20 5180MHz Ant1 OBW NVNT n20 5200MHz Ant1 ITL Page 98 of 169 Report No.: 250925014-2 OBW NVNT n20 5240MHz Ant1 OBW NVNT n40 5190MHz Ant1 ITL Page 99 of 169 Report No.: 250925014-2 OBW NVNT n40 5230MHz Ant1 Band II Mode Frequency (MHz) 99% OBW (MHz) a 5260 16.627 a 5280 16.618 a 5320 16.603 ac20 5260 18.004 ac20 5280 17.995 ac20 5320 18.01 ac40 5270 36.8 ac40 5310 36.764 ax20 5260 19.198 ax20 5280 19…

Text truncated - open the document above for the full version.

Test Report

ITL Page 121 of 169 Report No.: 250925014-2 OBW NVNT a 5785MHz Ant1 OBW NVNT a 5825MHz Ant1 ITL Page 122 of 169 Report No.: 250925014-2 OBW NVNT ac20 5745MHz Ant1 OBW NVNT ac20 5785MHz Ant1 ITL Page 123 of 169 Report No.: 250925014-2 OBW NVNT ac20 5825MHz Ant1 OBW NVNT ac40 5755MHz Ant1 ITL Page 124 of 169 Report No.: 250925014-2 OBW NVNT ac40 5795MHz Ant1 OBW NVNT ax20 5745MHz Ant1 ITL Page 125 of 169 Report No.: 250925014-2 OBW NVNT ax20 5785MHz Ant1 OBW NVNT ax20 5825MHz Ant1 ITL Page 126 of 169 Report No.: 250925014-2 OBW NVNT ax40 5755MHz Ant1 OBW NVNT ax40 5795MHz Ant1 ITL Page 127 of 169 Report No.: 250925014-2 OBW NVNT n20 5745MHz Ant1 OBW NVNT n20 5785MHz Ant1 ITL Page 128 of 169 Report No.: 250925014-2 OBW NVNT n20 5825MHz Ant1 OBW NVNT n40 5755MHz Ant1 ITL Page 129 of 169 Report No.: 250925014-2 OBW NVNT n40 5795MHz Ant1 ITL Page 130 of 169 Report No.: 250925014-2 5.6. -6dB Bandwidth LIMIT FCC CFR Title 47 Part 15 Subpart E Section 15.407(e) Within the 5.725-5.85 GHz band, the minimum 6 dB bandwidth of U-NII devices shall be at least 500 kHz TEST CONFIGURATION TEST PROCEDURE 1. The testing follows the KDB 789033 D02 v02r01 Section I.C.D and ANSI C63.10-2013Section 12.4. 2. The RF output of EUT was connected to spectrum analyzer by RF cable and attenuator, the path loss was compensated to the results for each measurement. 3. Use the spectrum analyzer “Channel Bandwidth” functions to measurement the 26dB EBW, 6dB EBW and 99% OBW. 4. Set center frequency to the nominal EUT channel center frequency. 5. Set span = 1.5 times to 5.0 times the OBW or EBW.6. For 26dB EBW and 99% OBW Measurement: Set RBW = approximately 1% EBW or 1.5 times to 5.0 times the OBW, VBW ≥ 3 x RBW. 7. For 6dB EBW Measurement: Set RBW=100kHz.VBW>3x RBW. 8. Set Detector = Peak, Trace mode = max hold and Sweep time = auto couple. 9. Allow the trace to stabilize. 10. Replace the EUT center frequency and repeat steps 3~9. TEST MODE: Please refer to the clause 3.3 TEST RESULTS Passed Not Applicable ITL Page 131 of 169 Report No.: 250925014-2 -6dB Bandwidth Band IV Mode Frequency (MHz) -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict a 5745 16.428 0.5 Pass a 5785 16.377 0.5 Pass a 5825 16.416 0.5 Pass ac20 5745 17.553 0.5 Pass ac20 5785 17.571 0.5 Pass ac20 5825 17.568 0.5 Pass ac40 5755 36.312 0.5 Pass ac40 5795 36.33 0.5 Pass ax20 5745 18.909 0.5 Pass ax20 5785 19.074 0.5 Pass ax20 5825 18.99 0.5 Pass ax40 5755 37.956 0.5 Pass ax40 5795 38.106 0.5 Pass n20 5745 17.568 0.5 Pass n20 5785 17.565 0.5 Pass n20 5825 17.574 0.5 Pass n40 5755 36.318 0.5 Pass n40 5795 36.324 0.5 Pass -6dB Bandwidth NVNT a 5745MHz Ant1 ITL Page 132 of 169 Report No.: 250925014-2 -6dB Bandwidth NVNT a 5785MHz Ant1 -6dB Bandwidth NVNT a 5825MHz Ant1 ITL Page 133 of 169 Report No.: 250925014-2 -6dB Bandwidth NVNT ac20 5745MHz Ant1 -6dB Bandwidth NVNT ac20 5785MHz Ant1 ITL Page 134 of 169 Report No.: 250925014-2 -6dB Bandwidth NVNT ac20 5825MHz Ant1 -6dB Bandwidth NVNT ac40 5755MHz Ant1 ITL Page 135 of 169 Report No.: 250925014-2 -6dB Bandwidth NVNT ac40 5795MHz Ant1 -6dB Bandwidth NVNT ax20 5745MHz Ant1 ITL Page 136 of 169 Report No.: 250925014-2 -6dB Bandwidth NVNT ax20 5785MHz Ant1 -6dB Bandwidth NVNT ax20 5825MHz Ant1 ITL Page 137 of 169 Report No.: 250925014-2 -6dB Bandwidth NVNT ax40 5755MHz Ant1 -6dB Bandwidth NVNT ax40 5795MHz Ant1 ITL Page 138 of 169 Report No.: 250925014-2 -6dB Bandwidth NVNT n20 5745MHz Ant1 -6dB Bandwidth NVNT n20 5785MHz Ant1 ITL Page 139 of 169 Report No.: 250925014-2 -6dB Bandwidth NVNT n20 5825MHz Ant1 -6dB Bandwidth NVNT n40 5755MHz Ant1 ITL Page 140 of 169 Report No.: 250925014-2 -6dB Bandwidth NVNT n40 5795MHz Ant1 ITL Page 141 of 169 Report No.: 250925014-2 5.7. Band Edge LIMIT FCC CFR Title 47 Part 15 Subpart E Section 15.407(b) Un-restricted band emissions above 1GHz Operating Band Frequency EIRP Limit Value 5150-5250MHz Above 1GHz -27dBm/MHz (68.2dBuV/m@3m) Peak 5250-5350MHz Above 1GHz -27dBm/MHz (68.2dBuV/m@3m) Peak 5470-5725MHz Above 1GHz -27dBm/MHz (68.2dBuV/m@3m) Peak 5725-5850 MHz 1GHz-5.65GHz -27dBm/MHz (68.2dBuV/m@3m) Peak 5.65GHz-5.7GHz -27*dBm/MHz to 10dBm/MHz (68.2* dBuV/m to 105.6dBuV/m@3m) Peak 5.7GHz-5.72GHz 10*dBm/MHz to 15.6dBm/MHz (105.6*dBuV/m to 110.8dBuV/m@3m) Peak 5.72GHz-5.725GHz 15.6*dBm/MHz to 27dBm/MHz (110.8dBuV/m to* 122.2dBuV/m@3m) Peak 5.85GHz-5.855GHz 27dBm/MHz to 15.6*dBm/MHz (122.2dBuV/m to110.8* dBuV/m@3m) Peak 5.855GHz-5.875GHz 15.6dBm/MHz to 10*dBm/MHz (110.8dBuV/m to 105.6* dBuV/m@3m) Peak 5.875GHz-5.925GHz 10dBm/MHz to -27*dBm/MHz (105.6dBuV/m to 68.2* dBuV/m@3m) Peak Above 5.925GHz -27dBm/MHz (68.2dBuV/m@3m) Peak * Increase/Decreases with the linearly of the frequency. For emission above 1GHz and in restricted band, according to FCC KDB 789033 D02 General UNII Test Procedure, all emission that complies with both the average and peak limits of Section 15.209 is not required to satisfy the -27 dBm/MHz peak emission limit. E[dBμV/m] = EIRP[dBm] + 95.2, for d = 3 meters. TEST CONFIGURATION ITL Page 142 of 169 Report No.: 250925014-2 TEST PROCEDURE 1. The EUT was setup and tested according to ANSI C63.10:2013 requirements. 2. The EUT is placed on a turn table which is 1.5 meter above ground. The turn table is rotated 360 degrees to determine the position of the maximum emission level. 3. The EUT waspositioned such that the distance from antenna to the EUT was 3 meters. 4. The antenna is scanned from 1 meter to 4 meters to find out the maximum emission level. This is repeated for both horizontal and vertical polarization of the antenna. In order to find themaximum emission, all of the interface cables were manipulated according to ANSI C63.10:2013 on radiated measurement. 5. The receiver set as follow: RBW=1MHz, VBW=3MHz Peak detector for Peak value. RBW=1MHz, VBW=3MHz RMS detector for Average value. TEST MODE: Please refer to the clause 3.3 TEST RESULTS Passed Not Applicable ITL Page 143 of 169 Report No.: 250925014-2 Band: I&II Worst mode: 802.11a Test Channel: CH…

Text truncated - open the document above for the full version.

Test Report

PH100 Acknowledgment Letter SupplierName：SichuanBo'antongCommunicationTechnologyCo.,Ltd. MaterialDescription：Built-inAntenna-2.4/5G-Gray1.13TinWire-1stGeneration Terminal-L=75mm-FPC-38.2×6.7mm MaterialCode：004.032.005271_3__ AcknowledgmentEdition：__A0-0915 （Note:ThisacknowledgmentisforusebyGuangzhouYuandong IntelligentSportsTechnologyCo.,Ltd.） SourceDriveAcknowledgment Column Researchand Development QualityEnvironmenta lprotection SupplierAcknowledgment Column formulateReviewApprove QiucuipinHuchongLiulihua DocumentRevisionHistory VersionDate Modified Page number ModifycontentReviser Effective Date A02023.05.19 17 Formulatedforthefirsttime Huangfeih ui 2023.05.19 A0-09122023.09.12 17 Updatepartnumbers,frequencybands,FPC, cablelengths,andelectricalperformance reports Huangfeih ui 2023.09.14 A0-09152023.09.15 16 UpdatetotheYuandongformattemplate Huangfeih ui 2023.09.15 管控文件 DocumentControl Catalog 1. Structural drawing.............................................................................................................................................................4 2.Product physical photos....................................................................................................................................................5 3.Production process diagram..............................................................................................................................................6 4.QC Engineering Drawing...................................................................................................................................................7 5.Supplier Test Report........................................................................................................................................................ 8-9 6.Reliability Test Report.................................................................................................................................................10-14 7.Packaging & Shipping Methods........................................................................................................................................15 8.Certification of Restricted Substance................................................................................................................................16 管控文件 DocumentControl 1.Structuraldrawing 管控文件 DocumentControl 2.Product physical photos To be provided 管控文件 DocumentControl 3.Productionprocessdiagram(tobeprovided) 4.QCEngineeringDrawing…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Kevin Liao(E.E. Dept. Manager)

[email protected]Fax: +886-4-7977-123

Technical Contact

IT CREATIVE ELECTRONICS INCVictor Meng

[email protected]

7901 4TH STNSTE 300, ST. · PETERSBURG, Florida, 33702 · United States

Test Firm

ITL Co., LTDBob Dai

[email protected]Fax: 86-020-62824387

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15E	5.18 GHz - 5.24 GHz	10.00 mW
2	15E	5.26 GHz - 5.32 GHz	9.00 mW
3	15E	5.50 GHz - 5.70 GHz	24.00 mW
4	15E	5.75 GHz - 5.83 GHz	19.00 mW

Confidentiality

Long Term

Grant Notes

Output power listed is the maximum conducted output power. Device must be operated to provide a separation distance of at least 20cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20MHz and 40MHz bandwidth mode.
