2AHVL-EWBLE01Music Bluetooth

江苏省昆山市花桥镇花安路169号中寰广场1325室 TEL: 0512-36874515 Mobile: 13818541390 FAX: 0512-36874525 http://www.xinxuandz.com Version: 1.0 第 1 页 共 5 页 Approved by Project Name&Item JW6900-5424 Working oltage 5V Picture Version V1.0 Remark SPECIFICATION 江苏省昆山市花桥镇花安路169号中寰广场1325室 TEL: 0512-36874515 Mobile: 13818541390 FAX: 0512-36874525 http://www.xinxuandz.com Version: 1.0 第 2 页 共 5 页 1. Features ★MP3 player with Bluetooth function ★ Support for USB flash drives; Support Mp3 format file playback； ★ 3 0 segment digital volume adjustment； 2. Operation Function： . On power, the default volume is maximum, there is no phone function, and the device name：X6-SPEAKER 3、schematic diagram After powering on, it starts to detect whether Bluetooth function is connected, and priority is given to inserting it later . The modes include: Bluetooth connection - music mode 江苏省昆山市花桥镇花安路169号中寰广场1325室 TEL: 0512-36874515 Mobile: 13818541390 FAX: 0512-36874525 http://www.xinxuandz.com Version: 1.0 第 3 页 共 5 页 4、Packaging diagram： 5、dimension： 江苏省昆山市花桥镇花安路169号中寰广场1325室 TEL: 0512-36874515 Mobile: 13818541390 FAX: 0512-36874525 http://www.xinxuandz.com Version: 1.0 第 4 页 共 5 页 6、note： 1、This player is a high-precision electronic product, please do not disassemble the components yourself； 2、Avoid strong falls and collisions with this player； 3、Avoid using this player in the following environments: high temperature, low temperature, humidity, dust, strong magnetic field, and long-term exposure to sunlight； 4、To prevent data loss, it is recommended that users backup important information, especially when repairing defective products, our company will clear all data in the defective products. W e are not responsible for any losses caused by data loss； 5、This player should not be subjected to water droplets or splashes； 6、Please c hoose an appropriate volume when listening to avoid damaging your hearing； 7、Please dispose of waste machinery and accessories in accordance with local environmental regulations； 8、If t here are any changes to the product, please do not notify us separately. We apologize f or any inconvenience caused。 FCC警語： Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s) and Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. FCC& IC Radiation Exposure Statement: This equipment complies with FCC and Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Déclaration d’IC sur l’exposition aux radiations: Cet équipement est conforme aux limites d’exposition aux radiations définies par le Canada pour des environnements non contrôlés. Cet équipement doit être installé et utilisé à une distance minimum de 20 cm entre l’antenne et votre corps. Cet émetteur ne doit pas être installé au même endroit ni utilisé avec une autre antenne ou un autre émetteur. The maximum antenna gain is -0.58 dBi. Second label must be place on the outside of the final device that contains the following text: “Contains FCC ID: 2AHVL-EWBLE01, IC: 22282-EWBLE01” The FCC ID and IC can be used only when all FCC and IC compliance requirements are met. HVIN: EWBLE-01, PMN: Music Bluetooth, HMN: Sporting goods, Electronic control products

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 1 of 4 Appendix External Photos for GZCR2311001201HS SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 2 of 4 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 3 of 4 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-02 Rev 1.1 Page: 4 of 4

音樂藍牙貼標呈現如下: IC : 22282-EWBLE01 FCC ID: 2AHVL-EWBLE01

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 1 of 2 Appendix Internal Photos for GZCR2311001201HS SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-ARF-03 Rev 1.1 Page: 2 of 2 EUT Constructional Details (EUT Photos) 2.4G BT ANT

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR231100120102 Page: 1 of 9 FCC ID: 2AHVL-EWBLE01 Ricky Liu Manager RF EXPOSURE EVALUATION REPORT Application No.: GZCR2311001201HS Applicant:Dyaco International Inc. Address of Applicant:12F, No.111, Songjiang Road, Taipei 104, Taiwan, China Manufacturer:Dyaco International Inc. Address of Manufacturer:12F, No.111, Songjiang Road, Taipei 10486, Taiwan, China Factory:Dyaco International Inc. Address of Factory:No.1, Gong 1st Rd., Cyuan Sing Industrial Park, Hemei Town, Changhua County, 50843, Taiwan, China Product Name:Music Bluetooth Model No.: EWBLE-01 Standard(s) : 47 CFR Part 1.1310 KDB447498 D01 General RF Exposure Guidance v06 Date of Receipt: 2023-11-29 Date of Evaluation: 2023-12-08 to 2024-01-26 Date of Issue: 2024-06-12 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR231100120102 Page: 2 of 9 Revision Record VersionReport No.DateRemark 01GZCR2311001201022024-06-12Original Authorized for issue by: Jim Li/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR231100120102 Page: 3 of 9 2Evaluation Summary ItemStandardMethodRequirementResult RF Exposure KDB447498 D01 General RF Exposure Guidance v06 KDB447498 D01 General RF Exposure Guidance v06 47 CFR Part 1.1310Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR231100120102 Page: 4 of 9 3Contents Page 1Cover Page...............................................................................................................................................1 2Evaluation Summary................................................................................................................................3 3Contents....................................................................................................................................................4 4General Information.................................................................................................................................5 4.1Details of E.U.T.................................................................................................................................5 4.2Evaluating Location...........................................................................................................................5 4.3Facility...............................................................................................................................................5 4.4Deviation from Standards..................................................................................................................5 4.5Abnormalities from Standard Conditions...........................................................................................6 5Technical Requirements Specification..................................................................................................7 5.1General Description of Applied Standards........................................................................................7 5.2RF Exposure Evaluation....................................................................................................................7 5.2.1Limit & Test Method......................................................................................................................7 5.2.2Conclusion....................................................................................................................................8 6EUT Constructional Details (EUT Photos).............................................................................................9 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-03 Rev 1.1 Report No.: GZCR231100120102 Page: 5 of 9 4General Information 4.1Details of E.U.T. Power supply:DC 5V Cable(s):N/A RF character:Refer to report GZCR231100120101 for 2.4G BT detail. 4.2Evaluating Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou Branch EMC Laboratory, No.198, Kezhu Road, Science City, Economic & Technological Development Area, Guangzhou, Guangdong, China 510663 Tel: +86 20 82155555 No tests were sub-contracted. 4.3Facility The facility is recognized, certified, or accredited by the following organizations: ● ACMA SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory can also perform testing for the Australian/New Zealand Regulatory Compliance Mark (RCM). ● SGS UK(Certificate No.: 32), SGS-TUV SAARLAND and SGS-FIMKO Have approved SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory as a supplier of EMC TESTING SERVICES and SAFETY TESTING SERVICES. ● FCC Recognized Accredited Test Firm(Registration No.: 486818) SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory has been accredited and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. Designation Number: CN5016, Test Firm Registration Number: 486818. ● ISED (Registration No.: 4620B, CAB identifier: CN0052) SGS-CSTC Standards Technical Services Co., Ltd., has been registered by Innovation Science and Economic Development Canada for Wireless Device Testing laboratories to test to Canadian radio equipment requirements. Registration No. 4620B, CAB identifier: CN0052. ● VCCI (Registration No.: R-12460, C-12584, G-20107 and T-11179) The 10m Semi-anechoic chamber, 966 Anechoic Chamber and Shielded Room of SGS-CSTC Standards Technical Services Co., Ltd. have been registered in accordance with the Regulations fo…

Text truncated - open the document above for the full version.

Inverted F Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.26 -0.76 -0.58 -5.25 -2.46 -1.86 MAX. Gain -0.58dB PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD 333 Kexing Road, Nanping Town, Zhuhai City Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(d B) Frequency (MHz) MaxMinAvg 2400-5.2537-22.1424-12.4294 2450-2.4652-24.5837-10.4702 2500-1.86120-29.5214-9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd. 2F, No.2 Building, Chaxi S anwei Industrial Zone, Gushu, Xixiang Street, Baoan District, Shenzhen

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR231100120101 Page: 1 of 77 FCC ID: 2AHVL-EWBLE01 Ricky Liu Manager TEST REPORT Application No.: GZCR2311001201HS Applicant: Dyaco International Inc. Address of Applicant: 12F, No.111, Songjiang Road, Taipei 104, Taiwan, China Manufacturer: Dyaco International Inc. Address of Manufacturer: 12F, No.111, Songjiang Road, Taipei 10486, Taiwan, China Factory: Dyaco International Inc. Address of Factory: No.1, Gong 1st Rd., Cyuan Sing Industrial Park, Hemei Town, Changhua County, 50843, Taiwan, China Product Name: Music Bluetooth Model No.: EWBLE-01 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2023-11-29 Date of Test: 2023-12-08 to 2024-01-26 Date of Issue: 2024-06-12 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR231100120101 Page: 2 of 77 Revision Record Version Report No. Date Remark 01 GZCR231100120101 2024-06-12 Original Authorized for issue by: Jim Li/Project Engineer Vico Cui/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR231100120101 Page: 3 of 77 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence N/A 47 CFR Part 15, Subpart C 15.247(a)(1),(g),(h) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 7.8.5 47 CFR Part 15, Subpart C 15.247(b)(1) Pass 20dB Bandwidth ANSI C63.10 (2013) Section 7.8.7 47 CFR Part 15, Subpart C 15.247(a)(1) Pass Carrier Frequencies Separation ANSI C63.10 (2013) Section 7.8.2 47 CFR Part 15, Subpart C 15.247a(1) Pass Hopping Channel Number ANSI C63.10 (2013) Section 7.8.3 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Dwell Time ANSI C63.10 (2013) Section 7.8.4 47 CFR Part 15, Subpart C 15.247a(1)(iii) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 7.8.6 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 7.8.8 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.1 Report No.: GZCR231100120101 Page: 4 of 77 3 Contents Page 1 Cover Page ......................................................................................................................................... 1 2 Test Summary ..................................................................................................................................... 3 3 Contents ............................................................................................................................................. 4 4 General Information............................................................................................................................ 6 4.1 Details of E.U.T. ........................................................................................................................... 6 4.2 Description of Support Units ......................................................................................................... 6 4.3 Measurement Uncertainty ............................................................................................................ 6 4.4 Test Location ............................................................................................................................... 7 4.5 Test Facility .................................................................................................................................. 7 4.6 Deviation from Standards ............................................................................................................. 7 4.7 Abnormalities from Standard Conditions ....................................................................................... 7 5 Equipment List ................................................................................................................................... 8 6 Radio Spectrum Technical Requirement ..........................................................................................12 6.1 Antenna Requirement .................................................................................................................12 6.1.1 Test Requirement: ..................................................................................................................12 6.1.2 Conclusion ..............................................................................................................................12 6.2 Other requirements Frequency Hopping Spread Spectrum System Hopping Sequence ...............13 6.2.1 Test Requirement: ..................................................................................................................13 6.2.2 Conclusion ..............................................................................................................................13 7 Radio Spectrum Matter Test Results…
