2AHXM-FUNK5Bluetooth speaker

第 1页， 共 5页File Number: WI-EN-CF-I-185 Instruction Manual of FUNK 5 Introduction This high-endBluetoothaudio is speciallydesignedfor music lovers,with elegantand fashionableappearance,streamlinedshape and humanizeddesign.It boastsa new type of Bluetoothstereo built with unconventionalinvertedtube box structuredesignconcept.And under the loadingof multi-directionalsound processingchip DSP, the sound is more beautiful. Specificeion ◎Basic Functions：AUXIN+Mic+BT+USB+FM+TWS+Light ◎Music Format：MP3 ◎BluetoothVersion：5.0. ◎FrequncyResponse：90Hz- 20kHz . ◎SNR：≥80dB. ◎FM FrequencyRange：87.5MHz-108MHz. ◎Power Input：TYPEC 5V. ◎LithiumBattery：7.4V5400mAh. 第2页，共5页FileNumber:WI-EN-CF-I-185 ◎Screen：LEDscreen. ◎SpeakerPower：55W. ◎SpeakerImpedance：4Ω. ◎ OperatingTemperature：-45to55°C. ◎Speakersize:7"4Ω*1+1.5"6Ω*2 ◎ Unitsiae:W310mm+H65mm+D300mm BootOperation ◎Poweron：Pressandholdthe“POWER”buttonforabout3seconds,andtheLEDscreen lightsup,indicatingthattheunithasbeenturnedon. ◎Poweroff：Pressandholdthe“POWER”buttonforabout3seconds,andtheLEDscreen goesout,indicatingthattheunitisturnedoff. FunctionDescription BluetoothMode ◎Turnonthespeaker,andtheLEDscreenshowsBLUEflashing; ◎TurnontheBluetoothmodeofthemobilephone,searchandselect"PROFIT"inthelist, andafterconnectedsuccessfully,youcanenjoybeautifulmusic.(Limitedbythesystem,itis notexcludedthatsomemobilephonesarenotsuccessfullypaired,andourcompanywill wholeheartedlysolvetheproblemforourcustomers.） MusicPlayingMode ◎WhenTFcardorUSBdriveisdetecteditwillautomaticallyswitchtomusicplayingmode; ◎Pressthepausebuttontopause,andthenpressitagaintocontinueplaying. ◎PREVButton：BULE/USB/TFmodeplaysthelastsong,FMmodeslongpressthisbutton willsearchforthelastchannel,andLINEmodeisinvalid. ◎NEXTButton:BULE/USB/TFmodeplaysthenextsong，FMmodeslongpressthisbutton willsearchforthenextchannel,andLINEmodeisinvalid. ◎LIGHTButton:Shortpressistoswitchthelightmode1-2-3-4,pressandholdtoturnon/off light. ◎POWERButton:Longpressistheon-offfunction,Shortpressittoswitch 第3页，共5页FileNumber:WI-EN-CF-I-185 BT/FM/AUX/USB/TFfunctions. ◎Play/PauseButton:Shortpresstoplay/pausethemusic. FMRadioMode ◎Pressthe“Power”buttontoswitchtotheFMmode,theLEDshowsXX.XXMHZ,and thespeakerpromptsFMmode. ◎LongPressthe“PREV”and“NEXT”buttonstoswitchradiostations. ◎Pressthe“Mode”buttontoswitchtootherfunctions InterfaceDescription ◎USBInterface：DirectlyinsertUSBflashtoplay. ◎TFCardInterface：DirectlyinsertTFcardtoplay. ◎AudioInput（AUX-in）：Theheadphonejackforexternaldevicessuchasmobile phones/tablets. ◎MICMicrophone：Connectedtothemicrophoneforspeaking. ◎ChargingInterface：ForType-Ccharging.ACchargerisnotincluded. FunctionExplanation Aux-in ◎PressthepowerbuttontoswitchtotheAux-inmode. ◎Plugtheaudiocable(notincluded)intotheexternalAuxinputportofthismachine,and connecttheotherendtotheearphoneoutputholeofmobilephone/tabletcomputerandother devices. ◎Pressthe“play”buttontomute. ◎Pressthe“Power”toswitchotherfunctions. DetailedExplanationofLightingFunction ◎ RGBlightsaresurroundingthespeaker.Pressthe“LIGHT”buttontoswitchthelightmodes. Eachlightpatternswillpulsetomusic,whichisdynamic. ◎EchoFunction：Pressthe“Echo”Buttonanditshows“H”ontheLEDscreen,youcanadjust 第4页，共5页FileNumber:WI-EN-CF-I-185 thevolumemicrophoneorspeakerunitby“+”“-”. TWSFunctionalOperationInstruction ◎Turnontwospeakerunitsatthesametimeanddon’tpairBT,andpressthe“TWS”button. AftertheTWSpairingissuccessful,thespeakerwillgiveaprompttoneandtheleddisplaywill stopshining“BLUE”. ◎Atthistime,turnonyourBluetoothdevicetofindthehost'sBluetoothname,andclick “match”toconnect. ◎Ifyoudon'twanttouseTWS,youcanshortpressthebutton. ChargingInstructions ◎Whencharging,redlightison. ◎Whenfinished,lightoff. Warning：Astheproductsareconstantlyupdatedandupgraded,someofthemareinconsistent withtheinstructions.Pleaserefertothekindoftheproduct! Accessories SpeakerUnit*1 USB-CChargingCable*1 Manual*1 Troubleshoot ● IncaseoftheBluetoothaudiosystemencountersunexpecteddisconnection,battery protectionandotherconditions,causingtheBluetoothaudiosystemtobeunableto connect,andithasnofunctionwhenconnectingandothercrashconditions,itis necessarytoturnoffthepowersupplyandthenturnitbackon;； MattersNeedingAttention Pleasedonottouchtheconnectorwithyourfingersormetal; Avoidstrongvibration; 第5页，共5页FileNumber:WI-EN-CF-I-185 Itcannotbepersonallydisassembled,modifiedorrepaired; Keepitawayfromdamp,hightemperature,oilfume,etc.; Whenconnectingthisproductwiththeremotecontrolorremovingit,pleasepayattention tomoderateexertion； FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC …

Text truncated - open the document above for the full version.

- PHIMAX INTERNATIONAL LIMITED - The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 1/12/2024 U.S. Agent Designation [PHIMAX INTERNATIONAL LIMITED] acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: [2AHXM-FUNK5]): Name and company of U.S. agent: Stone Trading Limited Physical U.S. address of agent: 6547 N Academy Blvd #2266, Colorado Springs, United States FRN of U.S. agent: 0033401936 Email address of U.S. agent: [email protected] [Stone Trading Limited] acknowledges their obligation to accept service of process on behalf of [PHIMAX INTERNATIONAL LIMITED]. [PHIMAX INTERNATIONAL LIMITED] with the FRN [0025470196] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanentl y te rminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm th e above and that we are aware of the application requirements listed under § 2.911(d)(7). Sincerely, Signature [Name] Phibe Yang [Title] Manager [Company] PHIMAX INTERNATIONAL LIMITED Signature [Name of U.S. agent] Dongmei Fang [Title of U.S. agent] Manager [Company of U.S. agent] Stone Trading Limited 48_[mo del] US_Agent_2.911(d)(7) - U, V04

PHIMAX INTERNATIONAL LIMITED The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 1/12/2024 To whom it may concern: We, [PHIMAX INTERNATIONAL LIMITED], hereby certif y that the equipment for which authorization is sought (FCC ID: [2AHXM-FUNK5]) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the fi lin g of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist ) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). Sincerely, Signature [Name] Phibe Yang [Title] Manager [Company] PHIMAX INTERNATIONAL LIMITED 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V02

Page 1 of 4 Report No.: 8135EU011502W-AB ANNEX B EXTERNAL PHOTOS PHOTO 1 PHOTO 2 Page 2 of 4 Report No.: 8135EU011502W-AB PHOTO 3 PHOTO 4 Page 3 of 4 Report No.: 8135EU011502W-AB PHOTO 5 PHOTO 6 Page 4 of 4 Report No.: 8135EU011502W-AB PHOTO 7 --- End ---

Label Location On EUT Label Product Name: Bluetooth speaker Model Number: FUNK 5 Trademark: N/A FCC ID: 2AHXM-FUNK5 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 3 Report No.: 8135EU011502W-AC ANNEX C INTERNAL PHOTOS PHOTO 1 PHOTO 2 BT/BLE Antenna Page 2 of 3 Report No.: 8135EU011502W-AC PHOTO 3 PHOTO 4 Page 3 of 3 Report No.: 8135EU011502W-AC PHOTO 5 PHOTO 6 --- End ---

RF EXPOSURE EVALUATION FCC ID: 2AHXM-FUNK5 According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b): Routine SAR eva luation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to qualify for TCB approval. Channel (MHz) Maximum output power (dBm) Tune up tolerance (dBm) Max Tune Up Power (dBm) Distance (mm) Calculation results Limit Operating Mode 2402 -0.05 -0.05±1 0.95 5 0.386 3 BDR&EDR 2441 -0.17 -0.17±1 0.83 5 0.378 3 2480 -0.80 -0.80±1 0.20 5 0.330 3 2402 2.13 2.13±1 3.13 5 0.637 3 2441 2.42 2.42±1 3.42 5 0.687 3 2480 1.85 1.85±1 2.85 5 0.607 3 2402 2.58 2.58±1 3.58 5 0.707 3 2441 2.91 2.91±1 3.91 5 0.769 3 2480 2.27 2.27±1 3.27 5 0.669 3 2402 2.08 2.08±1 3.08 5 0.630 3 BLE 2440 1.45 1.45±1 2.45 5 0.549 3 2480 1.22 1.22±1 2.22 5 0.525 3 Note: BT and BLE cannot support simultaneous transmission. Test Results: PASS.

TEST REPORT Report No.: 8135EU011502W2 Applicant: PHIMAX INTERNATIONAL LIMITED Address: Room 1303, No.95 XinYan Building, YanLing Road TianHe Distirct, Guangzhou, China Product Name: Bluetooth speaker Model No.: FUNK 5 Trademark: N/A FCC ID: 2AHXM-FUNK5 Test Standard(s): 47 CFR Part 15 Subpart C Date of Receipt: Dec. 15, 2023 Test Date: Dec. 15, 2023 – Jan. 03, 2024 Date of Issue: Jan. 12, 2024 ISSUED BY: SHENZHEN EU TESTING LABORATORY LIMITED Prepared by: Reviewed and Approved by: ____________________ _____________________ Mikey Zhu/ Engineer Sally Zhang/ Manager Page 2 of 32 Report No.: 8135EU011502W2 TRF No.: FCC Part 15.247_BLE (A01) Revision Record Report Version Issued Date Description Status V0 Jan. 12, 2024 Original Valid Page 3 of 32 Report No.: 8135EU011502W2 TRF No.: FCC Part 15.247_BLE (A01) Table of Contents 1 COVER PAGE .................................................................................................................................. 1 2 GENERAL INFORMATION ...................................................................................................................... 5 2.1 APPLICANT INFORMATION .................................................................................................................. 5 2.2 MANUFACTURER INFORMATION .......................................................................................................... 5 2.3 FACTORY INFORMATION ..................................................................................................................... 5 2.4 GENERAL DESCRIPTION OF E.U.T. ..................................................................................................... 5 2.5 TECHNICAL INFORMATION OF E.U.T. .................................................................................................. 6 3 TEST SUMMARY ...................................................................................................................................... 7 3.1 TEST STANDARD ............................................................................................................................... 7 3.2 TEST VERDICT ................................................................................................................................... 7 3.3 TEST LABORATORY ........................................................................................................................... 7 4 TEST CONFIGURATION .......................................................................................................................... 8 4.1 TEST ENVIRONMENT .......................................................................................................................... 8 4.2 TEST EQUIPMENT .............................................................................................................................. 8 4.3 DESCRIPTION OF SUPPORT UNIT ........................................................................................................ 9 4.4 TEST MODE ...................................................................................................................................... 9 4.5 MEASUREMENT UNCERTAINTY ........................................................................................................... 9 4.6 DEVIATION FROM STANDARDS ........................................................................................................... 9 4.7 ABNORMALITIES FROM STANDARD CONDITION ................................................................................... 9 5 TEST ITEMS ........................................................................................................................................... 10 5.1 ANTENNA REQUIREMENT .................................................................................................................. 10 5.1.1 Test Requirement .............................................................................................................. 10 5.1.2 Antenna Anti-Replacement Construction .......................................................................... 10 5.1.3 Antenna Gain .................................................................................................................... 10 5.2 CONDUCTED EMISSION AT AC POWER LINE ..................................................................................... 11 5.2.1 Test Requirement .............................................................................................................. 11 5.2.2 Test Setup Diagram .......................................................................................................... 11 5.2.3 Test Procedure .................................................................................................................. 11 5.2.4 Test Data ........................................................................................................................... 11 5.3 OCCUPIED BANDWIDTH ................................................................................................................... 14 5.3.1 Test Requirement .............................................................................................................. 14 5.3.2 Test Setup Diagram .......................................................................................................... 14 5.3.3 Test Procedure .................................................................................................................. 14 5.3.4 Test Data ........................................................................................................................... 14 5.4 MAXIMUM CONDUCTED OUTPUT POWER .......................................................................................... 15 5.4.1 Test Requirement .............................................................................................................. 15 5.4.2 Test Setup Diagram ................................................................................…

Text truncated - open the document above for the full version.

Page 1 of 24 Report No.: 8135EU011502W-AE ANNEX E TEST DATA For Project No.: 8135EU011502W Client: PHIMAX INTERNATIONAL LIMITED Manufacturer: PHIMAX INTERNATIONAL LIMITED Product Description: Bluetooth speaker / FUNK 5 Technology: Bluetooth BLE Test Engineer: Test Date: 2023-12-22 Page 2 of 24 Report No.: 8135EU011502W-AE Test Summary Item Result Duty Cycle Pass Bandwidth Pass Maximum Conducted Output Power Pass Maximum Power Spectral Density Pass Unwanted Emissions In Non-restricted Frequency Bands Pass Unwanted Emissions In Restricted Frequency Bands Pass Page 3 of 24 Report No.: 8135EU011502W-AE 1. Duty Cycle 1.1 Ant1 1.1.1 Test Result Ant1 Mode TX Type Frequency (MHz) T_on (ms) Period (ms) Duty Cycle (%) Duty Cycle Correction Factor (dB) Max. DC Variation (%) 1M SISO 2402 2.186 2.500 87.44 0.58 0.03 2440 2.185 2.500 87.40 0.58 0.03 2480 2.186 2.500 87.44 0.58 0.03 Page 4 of 24 Report No.: 8135EU011502W-AE 1.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 5 of 24 Report No.: 8135EU011502W-AE 1M_HCH_2480MHz_Ant1_NTNV Page 6 of 24 Report No.: 8135EU011502W-AE 2. Bandwidth 2.1 OBW 2.1.1 Test Result Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result 1M SISO 2402 1 1.025 Pass 2440 1 1.024 Pass 2480 1 1.025 Pass Page 7 of 24 Report No.: 8135EU011502W-AE 2.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 8 of 24 Report No.: 8135EU011502W-AE 1M_HCH_2480MHz_Ant1_NTNV Page 9 of 24 Report No.: 8135EU011502W-AE 2.2 6dB BW 2.2.1 Test Result Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 0.666 >=0.5 Pass 2440 1 0.663 >=0.5 Pass 2480 1 0.671 >=0.5 Pass Page 10 of 24 Report No.: 8135EU011502W-AE 2.2.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 11 of 24 Report No.: 8135EU011502W-AE 1M_HCH_2480MHz_Ant1_NTNV Page 12 of 24 Report No.: 8135EU011502W-AE 3. Maximum Conducted Output Power 3.1 Power 3.1.1 Test Result Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 1M SISO 2402 2.08 <=30 Pass 2440 1.45 <=30 Pass 2480 1.22 <=30 Pass Page 13 of 24 Report No.: 8135EU011502W-AE 3.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 14 of 24 Report No.: 8135EU011502W-AE 1M_HCH_2480MHz_Ant1_NTNV Page 15 of 24 Report No.: 8135EU011502W-AE 4. Maximum Power Spectral Density 4.1 PSD 4.1.1 Test Result Mode TX Type Frequency (MHz) Maximum PSD (dBm/3kHz) Verdict ANT1 Limit 1M SISO 2402 -13.99 <=8 Pass 2440 -14.71 <=8 Pass 2480 -15.00 <=8 Pass Page 16 of 24 Report No.: 8135EU011502W-AE 4.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 17 of 24 Report No.: 8135EU011502W-AE 1M_HCH_2480MHz_Ant1_NTNV Page 18 of 24 Report No.: 8135EU011502W-AE 5. Unwanted Emissions In Non-restricted Frequency Bands 5.1 Ref 5.1.1 Test Result Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) 1M SISO 2402 1 1.70 2440 1 1.01 2480 1 0.17 Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. Page 19 of 24 Report No.: 8135EU011502W-AE 5.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV Page 20 of 24 Report No.: 8135EU011502W-AE 1M_HCH_2480MHz_Ant1_NTNV Page 21 of 24 Report No.: 8135EU011502W-AE 5.2 CSE 5.2.1 Test Result Mode TX Type Frequency (MHz) ANT Level of Reference (dBm) Limit (dBm) Verdict 1M SISO 2402 1 1.70 -18.30 Pass 2440 1 1.70 -18.30 Pass 2480 1 1.70 -18.30 Pass Note1: Refer to FCC Part 15.247 (d) and ANSI C63.10-2020, the channel contains the maximum PSD level was used to establish the reference level. Page 22 of 24 Report No.: 8135EU011502W-AE 5.2.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_LCH_2402MHz_Ant1_NTNV Page 23 of 24 Report No.: 8135EU011502W-AE 1M_MCH_2440MHz_Ant1_NTNV 1M_HCH_2480MHz_Ant1_NTNV Page 24 of 24 Report No.: 8135EU011502W-AE 1M_HCH_2480MHz_Ant1_NTNV --------- End of Report -------

version01 PHIMAX INTERNATIONAL LIMITED Declaration concerning Antenna Specification It i s hereby declared that the product Model No.: FUNK 5 FCC ID: 2AHXM-FUNK5 fulfill s the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for PCB antenna type(s) described below: Model No. of antenna: 2.4G ANT Type of antenna: PCB Antenna Gain of the antenna: -0.58 dBi Frequency range: 2400-2500 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: PHIMAX INTERNATIONAL LIMITED Address: Room 1303, No.95 XinYan Building, YanLing Road TianHe Distirct, City: Guangzhou, ZIP / Postal code: Country: China Place: Place: Date: 2024-01-12 Signature:

Inverted F Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.26-0.76-0.58-5.25-2.46-1.86 MAX. Gain -0.58dBi PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) AddressNo.333 Kexing Road, Nanping Town, Xiangzhou District, Zhuhai City Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 -1.86120 -29.5214 -9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd.
