2AHYJ-TVE1070MTablet

T3 10. 4 " Tablet User Manual Brand LincPlus Model T3 CPU MediaTek MT8 7 8 1 Octa-Core OS Android 13 Me mo r y 8G LpDDR4 Storage 1 2 8G eMMC/uFS+DDR Display 10.36 inch, 2000x1200, IPS Touch Incell,10piont Case Full Metal Battery 7000mAH/ 3 . 8V Camera Front 8M, Rear 13M, Flashlight Wi-Fi 2 . 4G/5G 8 0 2 . 1 1 a/b/g/n/ac Bluetooth Bluetooth 5.2 I/O USB port USB TypeC,USB data and audio out SD port Micro SD Button Power, VOL-, VOL+ Sensor G-sensor/L-Sensor/P-Sensor GNSS GPS/BeiDou/Glonass/Galileo Microphones 1x MIC Speaker 4x 1W Box Speaker Charger 20W, Support PD/PE+ quick charger Dimension 249x1 5 9x7 . 9mm,8 . 8mm narrow bezel Weight Tablet 480g Contains Tablet,Charging cable,Charging head,Ejection pin,Manual ①Power button ②Volume up/down ③Microphone ④Front camera ⑤Speakers ⑥USB port ⑦Charging indicator ⑧Micro SD ⑨Flash Light ⑩Rear camera Dear customer; LincPlus would like to thank you for your recent purchase. We truly care about your user experience. If you have any questions or concerns, please feel free to contact us. Our customer support team is standing by to assist you. Best regards LincPlus Service Team E2EURO Consulting HUNGARY (for Prodsg authorities only) Hoferstrasse 9b, 71636 Ludwigsburg Germany This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Information to the user. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Specific Absorption Rate (SAR) information: This mobile phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health. FCC RF Exposure Information and Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: Portable Equipment (FCC ID: 2AHYJ-TVE1070M) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the the body& worn is 0.422W/kg. This device was tested for typical body-worn operations with the back of the handset kept 0mm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 0mm separation distance between the user's body and the back of the handset. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that does not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.

(Techvision Intelligent Technology Co.,Ltd.) (May 10, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (2AHYJ-TVE1070M #) [Techvision Intelligent Technology Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Mr Tang shark / Design Quality Assurance Engineers ( Techvision Intelligent Technology Co.,Ltd.) (May 10, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (2AHYJ-TVE1070M #) [Techvision Intelligent Technology Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Mr Tang shark / Design Quality Assurance Engineers

Techvision Intelligent TechnologyCo.,Ltd. 2.911 (d)(7)USA Agentv1.3 Section 2.911(d)(7) USA Agent for Service of Process 2.911(d)(7) USA Designated Agent for Service of Company name: Techvision Intelligent TechnologyCo.,Ltd. Address: 5F，No.2 Building, District D,TCL international E City, Nanshan ,ShenZhen , China Product Name: Tablet FCC ID: 2AHYJ-TVE1070M Model(s): LincPlus T3 Process We, [Techvision Intelligent TechnologyCo.,Ltd.] (“the applicant”) designate [Wilson Tech Service LLC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Wilson Tech Service LLC Address: 1312 17th Street Suite 692, Denver, CO, 80202, US Contact Name: Wilson Cheung Telephone No: +1-716-965-5112 Email: [email protected] FCC Registation Number(FRN): 0033402033 Applicant Company name: Techvision Intelligent TechnologyCo.,Ltd. Product Name: Address: 5F，No.2 Building, District D, TCL international E City, Nanshan , ShenZhen , China Tablet FCC Grantee Code:2AHYJ-TVE1070M Contact Name: Tang Weimin FRN:0033402033 0033402033 Techvision Intelligent TechnologyCo.,Ltd. 2.911 (d)(7)USA Agentv1.3 Telephone No: +86-13724352034 Email: [email protected] Signature: Title: Manager Signature: Title: Manager Date: 2023-04-24 Date: 2023-04-24 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Techvision Intelligent Technology Co.,Ltd. Agent Authorization Letter (May 10, 2023) Eurofins MET Labs 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (WORLD STANDARDIZATION CERTIFICATION & TESTING GROUP (SHENZHEN) CO., LTD.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s name / title : Mr Tang shark / Design Quality Assurance Engineers Company Name: Techvision Intelligent Technology Co.,Ltd. Contact information / address: [email protected] / 5F, No.2 Building, District D,TCL international E City, Nanshan, ShenZhen, China.

Techvision Intelligent Technology Co.,Ltd. Long Term Confidentiality Request Letter (May 10, 2023) Eurofins MET Labs 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Tablet Model No : LincPlus T3 FCC ID: 2AHYJ-TVE1070M To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description - BOM - Tune up procedure required to be submitted with this application be permanently withheld from public review. The above-mentioned documents belong to internal documents, is our proprietary information, that could never get into the possession of our competition. Please contact me if there is any information you may need. Sincerely, Client’s name / title : Mr Tang shark / Design Quality Assurance Engineers Company Name: Techvision Intelligent Technology Co.,Ltd. Contact information / address: [email protected] / 5F, No.2 Building, District D,TCL international E City, Nanshan, ShenZhen, China.

Techvision Intelligent Technology Co.,Ltd. Short Term Confidentiality Request Letter (May 10, 2023) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Short Term Confidentiality Request For(Tablet / LincPlus T3 # 2AHYJ-TVE1070M #) To Whom It May Concern: In accordance with sections 0.457 and 0.459 of CFR 47, < Techvision Intelligent Technology Co.,Ltd>. requests short-term Confidentiality of following sections of this application for a period of 180 days after grant is issued. Test setup photos External Photo Internal photos User’s manual These documents contain detailed system and equipment descriptions and related information about the product, which < Techvision Intelligent Technology Co.,Ltd.> considers to be proprietary, confidential, and a custom design and otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, < Techvision Intelligent Technology Co.,Ltd .> feels that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give our competitors an unfair advantage in the market. Please contact me if there is any information you may need. Sincerely, Mr Tang shark / Manager Signature:

Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT Appearance photograph of EUT

Label Location: FCC ID: 2AHYJ-TVE1070M Model No.: LincPlus T3 Input:9V=2A Made in China SN:XXXXXXXXXX

Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT BT/Wi-Fi ANT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT Internal photograph of EUT

Report No.: WSCT-A2LA-R&E230300006A-15B Page 2 of 21 TABLE OF CONTENTS 1. Test Certification ..................................................................................... 3 2. GENERAL DESCRIPTION OF EUT .......................................................... 4 3. Test Result Summary .............................................................................. 5 4. TEST METHODOLOGY ............................................................................ 6 4.1. CONFIGURATION OF SYSTEM UNDER TEST ................................................................................. 7 4.2. DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) .......................................................... 8 5. MEASUREMENT INSTRUMENTS ............................................................ 9 6. Facilities and Accreditations ................................................................ 10 6.1. FACILITIES .......................................................................................................................................... 10 5.2. ACCREDITATIONS ............................................................................................................................ 10 5.3 MEASUREMENT UNCERTAINTY .............................................................................................................. 11 7. EMC EMISSION TEST ............................................................................ 12 7.1. CONDUCTED EMISSION MEASUREMENT .................................................................................... 12 7.2. RADIATED EMISSION MEASUREMENT ........................................................................................ 16 Report No.: WSCT-A2LA-R&E230300006A-15B Page 4 of 21 2. GENERAL DESCRIPTION OF EUT Equipment Type: Tablet Test Model: LincPlus T3 Trade Mark LincPlus Rechargeable Li-Polymer Battery: Li-ion Battery: U3158123PV Rated Voltage: 3.8V Rated Capacity: 7000mAh Adapter: Adapter: MX21PD-U Input: 100-240V~50/60Hz 0.5A Output: 5V3A/9V2.22A/12V1.67A Remark: N/A. Report No.: WSCT-A2LA-R&E230300006A-15B Page 5 of 21 3. Test Result Summary Requirement CFR 47 Section Result CONDUCTED EMISSION §15.107 PASS RADIATED EMISSION §15.109 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: WSCT-A2LA-R&E230300006A-15B Page 6 of 21 4. TEST METHODOLOGY To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 Video Recording Model 2 Video Playing Mode 3 Transferring with USB Disk (the worst case) Mode 4 TF Card Playing Report No.: WSCT-A2LA-R&E230300006A-15B Page 7 of 21 4.1. CONFIGURATION OF SYSTEM UNDER TEST Mode 1&2 Mode 3&4: (EUT: Tablet) I/O Port of EUT I/O Port Type Q’TY Cable Tested with Power 1 1m USB cable, unshielded 1 Earphone 1 1m USB cable, unshielded 1 EUT Adapter 1m USB cable TF Card/USB Disk EUT Mouse Keyboard 1.2m USB cable 1.2m USB cable Adapter 1.2m Power cable Report No.: WSCT-A2LA-R&E230300006A-15B Page 8 of 21 4.2. DESCRIPTION OF SUPPORT UNITS (CONDUCTED MODE) The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Item Equipment Mfr/Brand Model/Type No. Series No. Note 1 Adapter / MX21PD-U / / 2 Keyboard HP SK-2880 435302-AA- / 3 Mouse DELL MS111-1 / / Note: (1) The support equipment was authorized by Declaration of Confirmation. (2) For detachable type I/O cable should be specified the length in cm in『Length』 column. Report No.: WSCT-A2LA-R&E230300006A-15B Page 9 of 21 5. MEASUREMENT INSTRUMENTS Kind of Equipment Manufacturer Type No. Serial No. Last Calibrated Calibrated until Test software -- EZ-EMC CON-03A -- -- ESCI Test Receiver R&S ESCI 100005 11/05/2022 11/04/2023 LISN AFJ LS16 16010222119 11/05/2022 11/04/2023 LISN(EUT) Mestec AN3016 04/10040 11/05/2022 11/04/2023 pre-amplifier CDSI PAP-1G18-38 -- 11/05/2022 11/04/2023 System Controller CT SC100 - 11/05/2022 11/04/2023 Bi-log Antenna Chase CBL6111C 2576 11/05/2022 11/04/2023 Spectrum analyzer R&S FSU26 200409 11/05/2022 11/04/2023 Horn Antenna SCHWARZBECK 9120D 1141 11/05/2022 11/04/2023 Bi-log Antenna SCHWAREBECK VULB9163 9163/340 11/05/2022 11/04/2023 Pre Amplifier H.P. HP8447E 2945A02715 11/05/2022 11/04/2023 9*6*6 Anechoic -- -- -- 11/05/2022 11/04/2023 Report No.: WSCT-A2LA-R&E230300006A-15B Page 10 of 21 6. Facilities and Accreditations 6.1. Facilities All measurement facilities used to collect the measurement data are located at Building A-B, Baoshi Science & Technology Park, Baoshi Road, Bao’an District, Shenzhen, Guangdong, China of the World Standardization Certification & Testing Group(Shenzhen) CO., LTD The sites are constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 3. All receiving equipment conforms to CISPR Publication 16-1, ―Radio Interference Measuring Apparatus and Measurement Methods.‖ 6.2. ACCREDITATIONS CNAS - Registration Number: L3732 China National Accreditation Service for Conformity Assessment, The test firm Registration Number: L3732 FCC - Designation Number: CN1303 World Standardization Certification & Testing Group(Shenzhen) CO., LTD. has been accredited as a testing laboratory by FCC(Federal Communications Commission). The test firm Designation Number: CN1303. A2LA - Certificate Number: 5768.01 The EMC Laboratory has been accredited by the American Association for Laboratory Accreditation (A2LA).Certification Number: 5768.01 R…

Text truncated - open the document above for the full version.

CONDUCTED EMISSION RADIATED EMISSION BELOW 1GHz RADIATED EMISSION ABOVE 1GHz
