2AI7B-OT33HLED Desk Lamp with Multi Charging

ENGLISHLED Desk Light with Multi Charging Station LED Desk Light with Multi Charging Station CSVQCG5Z-CA CSVQC02Z-CA 3703705 OT33H INS-24-0782 REV031224 CONGRATULATIONS! You’ve purchased the finest in natural lighting technology with your new OttLite ® product. WARNING: To prevent electric shock, make sure the lamp is not plugged in until all steps are complete. NOTE: THIS UNIT IS FULLY ASSEMBLED 1. R emove lamp from packing, placing lamp body base (A) flat on a steady surface. 2. C onnect power adapter input (J) into connector (K) in the rear-bottom of the lamp. 3. P lug the power adapter (L) into a standard household 120V outlet. Note: Only use with the supplied power adapter to avoid damage or fire. When lamp is first plugged in and receives power, green lights (S & V) will illuminate momentarily and a beep sound will occur, indicating that a proper electrical connection is made. 4. P ower switch (B) is a “touch” switch that controls ON/OFF power, the LED brightness settings and the colour mode function of the lamp. 5. T o power the main light, slightly touch the switch (B) to achieve the following: • Turn lamp “ON” to 1st brightness setting; touch the switch “once”; • for 2nd brightness setting; touch the switch “two-times”; • for 3rd brightness setting; touch the switch “three-times”; • to turn lamp “OFF”; touch the switch “four-times”. 6. T his lamp provides three colour modes. To adjust lighting colour mode slightly “press and hold” switch (B) for three seconds to switch light colour temperature mode; 5000K, 2700K, 4000K. 7. T o reposition the light, hold the lamp base (A) steady and grasp either lamp body (H) or shade (F) depending on needed adjustment. 8. Refer to Diagrams 1 and 2 for lamp maximum adjustment range. NOTE: DO NOT FORCE the shade outside the allowable adjustment range as excessive adjustment may cause damage. REFER TO THE FOLLOWING ICON LEGEND), AS IT PERTAINS TO THE INSTRUCTIONS FOR VARIOUS SETTING FUNCTIONS BELOW. “SETTING BUTTON” (C) – to set time, date. and alarm. ˆ “UP BUTTON” (D) – In setting mode, push to increase. ˇ “DOWN BUTTON” (E) – In setting mode, push to decrease. CLOCK SETTING: • When in Normal Mode and time is displayed, press and hold “SETTING BUTTON” to enter Setting Mode, press “SETTING BUTTON” again for next setting. The sequence of setting is: 12 HR or 24 HR Mode, HOUR - MINUTE • Press “SETTING BUTTON” to quit setting, or it will automatically quit to Normal Mode if idle. CALENDAR SETTING: • Press “SETTING BUTTON” to display date. When date is displayed (i.e. 501 for May 1), press and hold the “SETTING BUTTON” to adjust the date. The sequence of setting is: YEAR – MONTH - DAY. • When in Normal Mode, the date can also be displayed by pressing the “UP BUTTON.” The date will automatically quit to Normal Mode if idle. • Press “SETTING BUTTON” to quit setting, or it will automatically quit to Normal Mode if idle. ALARM SETTING: • Press “SETTING BUTTON” twice to display A1. Once the alarm is displayed, press and hold the “SETTING BUTTON” to adjust the alarm time. • The sequence of setting is: HOUR – MINUTE • Press “SETTING BUTTON” to quit setting, or it will automatically quit to normal mode if idle. TURNING ALARM ON AND OFF • To turn ON the alarm, Press “SETTING BUTTON” twice to display A1. Press “UP BUTTON” to turn alarm ON and OFF. When alarm is enabled, the left two characters on the display will switch from “ -- ” to “ on ” and an “Alarm Clock” icon will appear on the display. • Press “SETTING BUTTON” to quit setting, or it will automatically quit to normal mode if idle. • When the alarm sounds, press any of the buttons to turn off the alarm. The alarm will automatically shut off within 10 minutes if buttons are not pressed. • Snooze feature is not provided. ADJUST CLOCK DISPLAY BRIGHTNESS • To adjust the clock display brightness, press “DOWN BUTTON”. There are 4 settings: OFF, L1, L2, L3. WIRELESS CHARGING INSTRUCTIONS: Wireless charging requires a Qi-certified device. To determine if your device is Qi-certified, please visit the Wireless Power Consortium website. Wireless charging area (M) is for mobile phones. Wireless charging (N) can be used for earbuds. To wirelessly charge a device, perform the following: • Place the device face up on the middle of the wireless charging area (M) or (N). • When the device is centered on the wireless charging areas (M) or (N), solid RED lights (S) or (V) respectively will come on noting charging mode active. Your device should show charging is taking place. • Check charge level on your device periodically to determine when device is fully charged NOTE: Product DOES NOT provide any indication of when device is fully charged. CAUTION! Device may become warm during charging. This is normal and part of the process. Charging times vary by device. WATCH CHARGING STAND INSTRUCTIONS: • To charge a watch, a wireless watch charger will need be provided (not included) . • Remove cover (T) and insert the watch charger cable into the slot located by watch stand (P). Guide the cable through so it fits inside the compartment. If the watch charger doesn’t fit securely into the watch stand, use one of the two silicone covers provided before placing into watch stand (P). • Connect wireless watch charger with USB-A or USB-C connector into appropriate port (Q) or (R) and replace cover (T). NOTE: Check the device periodically to determine if device is fully charged, as lamp DOES NOT give any indication of when the device is fully charged. NOTE: USB ports (Q) and (R) are rated 5V, 1A and can be used to charge items such as smartwatches, tablets, cellular phones, etc. Only one USB port will function at a time with priority going to the first one plugged in. SAFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS 1. T urn lamp off and WAIT UNTIL LAMP HEAD (F) IS COOL before handling. 2. The LED panel (G) might get hot after several hours of continuous use DO NOT place your hands directly on LED light panel…

Text truncated - open the document above for the full version.

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 OttLite Technologies, Inc. Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to 47 CFR part §2.911(d)(7) of the FCC rules To whom it may concern, This letter is to certify that [OttLite Technologies, Inc. / Joseph Custode] (“Applicant”) accepts responsibilities to act as its own agent pursuant to 47 CFR part §2.911(d)(7) of the FCC rules for service of process. I consent to the obligation to accept service of process on behalf of the applicant in regard to the FCC ID designated below. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : OttLite Technologies, Inc. Contact Name : Joseph Custode Address : 1715 N. Westshore Boulevard Suite 950 Tampa, Florida 33607 Telephone No : (813) 621-0058 Email : [email protected] FCC ID : 2AI7B-OT33H Applicant FRN : 0025699091 Signature: Date: 2024-03-05

Form: RFT-AMER-TCB-OP-19n Revision: 1 Page 1 of 1 Date: 1/25/2023 OttLite Technologies, Inc. Attention: Application Examiner Re: Covered List, located at https://www.fcc.gov/supplychain/coveredlist and 47 CFR parts §2.903 and §2.911(d)(5)(ii) of the FCC rules Applicant: OttLite Technologies, Inc. FCC ID: 2AI7B-OT33H To whom it may concern, [OttLite Technologies, Inc. / Joseph Custode] (“Applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to 47 CFR part §2.903 of the FCC rules and does not originate directly or indirectly from any company named on the covered list located in the link above or any subsidiary or affiliate thereof. Applicant further certifies that, as of the date of the filing of the application, the Applicant [is not] identified on the Covered List as an entity producing “covered” equipment and is not a subsidiary or affiliate of any such entity pursuant to 47 CFR part §1.50002 and required by 47 CFR part §2.911(d)(5)(ii) of the FCC rules. I HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant and agree to immediately notify Intertek if there is any change in the status identified above. ______________________________ [Signature of authorized Proprietor, Partner or Authorized Officer] [Printed Name: Joseph Custode] [Title: Senior Quality Control Engineer] [Company name: OttLite Technologies, Inc.] [Date: 2024-03-05]

OttLite Technologies, Inc. March 5, 2024 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement OttLite Technologies, Inc. FCC ID: 2AI7B-OT33H To Whom It May Concern: We, OttLite Technologies, Inc., hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number 2AI7B-OT33H under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is March 5, 2024. The Limited Agency Agreement expires March 5, 2025, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Joseph Custode Senior Quality Control Engineer

1(2) OttLite Technologies, Inc. Attention: Certification reviewer RE: Request for Confidentiality FCC ID: 2AI7B-OT33H To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] Schematics Block Diagrams Operational Description Tune-up Procedure Parts List Internal Photos (see note) Users Manual (see note) Note 1: Internal Photos may be held confidential 1) if the circuit board or internal components are not accessible to users. For example, it is acceptable if the circuit board is enclosed in epoxy. 2) Also, it is acceptable if the device is not accessible to the public, for example, a device mounted on the top of a large tower (or in a fenced enclosure) such that it is only serviceable by professional designated technicians under a Non-Disclosure Agreement (NDA). All sales for these devices must be under a NDA restricting the disclosure of the propriety information, including internal photos. Users Manual may be held confidential only when the manual contains proprietary technical information intended for professional technicians obligated under a NDA. All sales and distribution of the user’s manual must be under a NDA that restricts the disclosure of the information. In the application cover letter requesting permanent confidentiality the following additional description and the NDA exhibit is required: 1. Describe in detail how internal photos and/or users manual information are controlled to prevent them from becoming public or disclosed to unauthorized persons. 2. Describe how public access is restricted for products serviceable by professional designated technicians. 3. A statement that all sales of the non-consumer device will be under a NDA to include third party sales and that the final user of the device is subject to the NDA. 4. Provide an example of the NDA between the grantee and a purchaser. The request for confidentiality must Note 2: For scanning receiver, the schematics, block diagrams, operational description, tune-up procedure, parts list and internal photos are always held permanently confidential. Short-term Confidentiality [Complete this section if short-term confidentiality is requested] Request to withhold from public review for a period of [please enter 1 to 180] days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept short-term confidential for a period above from the date of the grant [Select one or more of items below that are not selected in the list above, as appropriate] Schematics Block diagrams Operational Description Tune-up Procedure 2(2) Parts List Test Setup Photos External Photos Internal Photos Users Manual Rationale for request for confidentiality: We have invested considerable time and materials in research and development to produce the referenced product. Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Short-term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development. If you have questions or need further information, please contact the undersigned. Sincerely, _________________ Joseph Custode Senior Quality Control Engineer 2024-03-05

TEST REPORT TEST REPORT TEST REPORT TEST REPORT TEST REPORT

Label & Label Location Size：60*40mm

TEST REPORT TEST REPORT TEST REPORT TEST REPORT TEST REPORT TEST REPORT

Ottlite Technologies Inc. TEST REPORT SCOPE OF WORK SAR Assessment– OT33H REPORT NUMBER 240124049SZN-002 ISSUE DATE [REVISED DATE] 08 March 2024 [--------------------] PAGES 8 DOCUMENT CONTROL NUMBER RF Exposure © 2017 INTERTEK TEST REPORT Intertek No.: 240124049SZN-002 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page 1 of 8 RF Exposure 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 www.intertek.com Test Report Applicant : Ottlite Technologies Inc. 1715 N Westshore Blvd STE 950 Tampa, FL 33607 United States Sample Description : LED Desk Lamp with Multi Charging Product Model No. : OT33H Brand Name Electrical Rating : DC 12V/2.5A from adapter Wireless charging output: 5W (mobile phones area), 4W (earbuds area) USB-A port output: DC5V, 1A USB-C port output: DC5V, 1A Date Received : 25 January 2024 Date Test Conducted : 25 January 2024 to 08 March 2024 Test Requested : Test for compliance with CFR 47 part 1 Test Method : Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(c) and (d), 1.1310 KDB 680106 D01 RF Exposure Wireless Charging App v04r01 Test Result : Pass Conclusion : When determining of test conclusion, measurement uncertainty of tests have been considered. Prepared and Checked By: Approved By: Vito Pan Ryan RQ Chen Project Engineer Sr. Project Engineer Date: 08 March 2024 TEST REPORT Intertek No.: 240124049SZN-002 Version: 01-November-2017 Page 2 of 8 RF Exposure Test Report Test Setup Configuration Note - The RF exposure test is performed in the shield room. - The test distance is between the edge of the charger and the geometric centre of probe. Test Equipment List Equipment No. Equipment Manufacturer Model No. Serial No. Cal. Date Due Date SZ186-04 Electric and Magnetic Field Analyzer Narda EHP-50F 510WY90119 2023-07-10 2024-07-10 TEST REPORT Intertek No.: 240124049SZN-002 Version: 01-November-2017 Page 3 of 8 RF Exposure This product was tested in the following configuration: Description Manufacturer Detail Mobile Phone Samsung (Provided by Intertek) S7 Earbuds Samsung (Provided by Intertek) SM-R510 Adapter NIL (Provided by applicant) Model: K36C120250U Input: 100-240Vac 50/60Hz 0.9A Output: DC 12.0V/2.5A Cement resistor NIL (Provided by Intertek) / USB cable NIL (Provided by applicant) Unshielded, Length 20cm Justification Pertest mode Description Mode 1 Standby mode Mode 2 Mobile phone is charging at 1% battery power Mode 3 Mobile phone is charging at 50% battery power Mode 4 Mobile phone is charging at 99% battery power Mode 5 Earbuds is charging at 1% battery power Mode 6 Earbuds is charging at 50% battery power Mode 7 Earbuds is charging at 99% battery power Mode 8 Mobile phone+Earbuds is charging at 1% battery power Mode 9 Mobile phone+Earbuds is charging at 50% battery power Mode 10 Mobile phone+Earbuds is charging at 99% battery power The EUT was powered by an adapter with 120V/60Hz input during the test. The test system was pre-scanning tested based on the consideration of following EUT operation mode. and only the worst-case data was shown in this report. TEST REPORT Intertek No.: 240124049SZN-002 Version: 01-November-2017 Page 4 of 8 RF Exposure Reference Limit: Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(c) and (d), 1.1310 According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation. LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range ( MHz ) Electric Field strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A) Limits for Occupational/Controlled Exposure 0.3 – 3.0 614 1.63 (100) * 6 (B) Limits for General Population/Uncontrolled Exposure 0.3 – 1.34 614 1.63 (100) * 30 Note: * = Plane wave equivalent power density Test Result: During test, the mobile and earbud is being charged. Worst Case Operating Mode: Mode 5 Test Result for wireless power transmit part: H-Field Strength at 20 cm surrounding the EUT and 20cm above the top surface of the EUT Frequency Range (MHz) EUT Operation mode Probe Position Front (A/m) Probe Position Rear (A/m) Probe Position Left (A/m) Probe Position Right (A/m) Probe Position Top (A/m) Limits (A/m) 0.112- 0.205 1% Battery Level 0.55 0.87 0.36 0.38 0.46 1.63 0.112- 0.205 50% Battery Level 0.54 0.86 0.35 0.37 0.45 1.63 0.112- 0.205 99% Battery Level 0.52 0.84 0.34 0.36 0.44 1.63 0.112- 0.205 Stand-by 0.51 0.81 0.33 0.35 0.42 1.63 TEST REPORT Intertek No.: 240124049SZN-002 Version: 01-November-2017 Page 5 of 8 RF Exposure E-Field Strength at 20 cm surrounding the EUT and 20cm above the top surface of the EUT Frequency Range (MHz) EUT Operation mode Probe Position Front (V/m) Probe Position Rear (V/m) Probe Positi…

Text truncated - open the document above for the full version.

Ottlite Technologies Inc. TEST REPORT SCOPE OF WORK FCC TESTING–OT33H REPORT NUMBER 240124049SZN-001 ISSUE DATE [REVISED DATE] 08 March 2024 [---------------------] PAGES 20 DOCUMENT CONTROL NUMBER FCC ID 209_b © 2017 INTERTEK Intertek Report No.: 240124049SZN-001 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page: 1 of 20 FCC ID 209_b TEST REPORT 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 www.intertek.com Ottlite Technologies Inc. Application For Certification FCC ID: 2AI7B-OT33H LED Desk Lamp with Multi Charging Model: OT33H Brand name: Transmitter Report No.: 240124049SZN-001 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-22] Prepared and Checked by: Approved by: ___________________________ Vito Pan Ryan RQ Chen Project Engineer Sr. Project Engineer Date: 08 March 2024 Intertek Report No.: 240124049SZN-001 Version: 01-November-2017 Page: 2 of 20 FCC ID 209_b TEST REPORT MEASUREMENT/TECHNICAL REPORT This report concerns (check one) Original Grant X Class II Change Equipment Type: DCD - Part 15 Low Power Transmitter Below 1705 kHz Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until : date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [10-01-22] Edition] provision. Report prepared by: Vito Pan Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen. Tel: (86 755) 8614 0743 Fax: (86 755) 8601 6751 Intertek Report No.: 240124049SZN-001 Version: 01-November-2017 Page: 3 of 20 FCC ID 209_b TEST REPORT Table of Contents 1.0 Summary of Test Results ........................................................................................... 4 2.0 General Description .................................................................................................. 5 2.1 Product Description ............................................................................................... 5 2.2 Related Submittal(s) Grants .................................................................................... 5 2.3 Test Methodology ................................................................................................. 5 2.4 Test Facility........................................................................................................... 5 3.0 System Test Configuration ........................................................................................ 6 3.2 EUT Exercising Software ......................................................................................... 6 3.3 Special Accessories ................................................................................................ 6 3.4 Equipment Modification ......................................................................................... 6 3.5 Measurement Uncertainty ...................................................................................... 7 3.6 Support Equipment List and Description ................................................................. 7 4.0 Measurement Results ............................................................................................... 8 4.1 Field Strength Calculation ....................................................................................... 8 4.2 Radiated Emission Configuration Photograph ............................................................ 9 4.3 Radiated Spurious Emission .................................................................................... 9 4.4 Conducted Emission Configuration Photograph ....................................................... 13 4.5 Conducted Emission ............................................................................................ 13 5.0 Equipment Photographs ......................................................................................... 16 6.0 Product Labelling ................................................................................................... 16 7.0 Technical Specifications .......................................................................................... 16 8.0 Instruction Manual ................................................................................................ 16 9.0 Miscellaneous Information ...................................................................................... 17 9.1 20dB Bandwidth ................................................................…

Text truncated - open the document above for the full version.

Page 1 of 1 TEST REPORT RADIATED EMISSION TEST SET-UP Front View (Below 1GHz) Back View (Below 1GHz) The EUT is placed at the center of turntable

Page 1 of 1 TEST REPORT CONDUCTED EMISSION TEST SET-UP Front View Slide View
