2AI7B-U14SCLED table lamp

CONGRATULATIONS! You’ve purchased the finest in natural lighting technology with your new OttLite ® product. WARNING: To prevent electric shock, make sure the lamp is not plugged in until all steps are complete. NOTE: THIS UNIT IS FULLY ASSEMBLED 1. Remove lamp from packing, placing lamp body base (A) flat on a steady surface. 2. Connect power adapter input (H) into connector (J) in the rear-bottom of the lamp. 3. Plug the power adapter (G) into a standard household 120V AC outlet. Note: Only use with the supplied power adapter to avoid damage or fire. 4. Turn the lamp ON & OFF using power switch in touch panel (B) located on top of base (A). 5. Touch panel (B) includes multiple “touch” keys that control the lamp’s mode and brightness within each mode. This lamp provides five levels of brightness. See Touch Key Panel Instructions section for operating instructions. 6. Control panel (Q) is used to set the lamp’s calendar, alarm setting and display screen light. See Calendar and Clock Setting section for operating instructions. 7. Wireless charger for Qi-certified devices (F) is located in the center of the base (A). See Wireless Charging Instructions section for details. 8. To reposition the light, hold base (A) steady and grasp either lamp body (C) or shade (D) depending on needed adjustment 9. Refer to Diagrams 1 and 2 for lamp maximum adjustment range. NOTE: DO NOT FORCE the shade or lamp body outside allowable adjustable range as excessive adjustment may cause damage. TOUCH KEY PANEL INSTRUCTIONS: To power lamp and operate LED settings, slightly touch required “key” to achieve the following: • Turn lamp “ON/OFF”: touch key as needed. • To adjust brightness: touch or key as needed. • Touch and hold M key to change modes. The three modes are; ClearSun LED, Sanitizing, and ClearSun + Sanitizing. ClearSun + Sanitizing mode utilizes both the Clearsun LEDs and Sanitizing LEDs simultaneously to provide continuous cleaning while using the lamp. NOTE: The active mode will be indicated by the lights (N and P) next to the icons. If indicator light (N) is illuminated, ClearSun mode is on. If indicator light (P) is illuminated, Sanitizing mode is on. If both indicator lights (N and P) are illuminated, Clearsun + Sanitize mode is on. CALENDAR AND CLOCK SETTING: NOTE: Control Panel (Q) to set Calendar and Clock is located on the backside of lamp body (C). • To set time, push key and the “hour” will flicker, then touch ˆ (up) key and ˇ (down) key to adjust “hour,” after “hour” setting, touch key again to set the “minute,” “year,” “month” and “day.” • In setting mode, touch M to exit function or operation will stop in one minute. • When not in setting mode, touch ˆ (up) key to switch between “12h” and “24h” display. ALARM & SNOOZE FUNCTION SETTING: • To set the alarm time, press M button located on control panel (Q) to activate alarm setting mode. In alarm mode, touch button to set alarm time sequence: “Hour,” “Minute,” “Snooze,” “Music”, then exit. NOTE: There are 8-music tones to select. • Touch ˆ (up) key and ˇ (down) key to adjust alarm time sequence. • To activate the alarm press M button to activate the alarm setting mode and then press ˆ (up) key and ˇ (down) key to turn ON/OFF alarm and snooze function. will light up on digital display to indicate alarm is set. will light up to indicate snooze is activated. • When alarm time is reached, alarm will ring for 1-minute, then snooze and ring again. Touch key to turn off alarm or touch ˆ (up) key or ˇ (down) key to activate snooze. NOTE: Snooze defaults to 60-minutes, if loss of power occurs. TEMPERATURE SWITCH SETTING: • In normal mode, touch ˇ (down) key to switch between º F and º C display. To adjust display screen brightness, touch to choose suitable brightness setting. NOTE: Display screen defaults to “highest” brightness setting when power initially applied. CONTROL PANEL (Q) icon legend (setting) button – to set calendar; in alarm mode, push key to turn off alarm. M (mode) button – push to set alarm and snooze ˆ (up) button – In setting mode, push ˆ to increase. ˇ (down) button – In setting mode, push ˇ to decrease. – Push display key for suitable brightness. WIRELESS CHARGING INSTRUCTIONS: Wireless charging requires a Qi-certified device. To determine if your device is Qi-certified, please visit the Wireless Power Consortium website. To wirelessly charge a device, perform the following: • Place the device, which supports Qi wireless charging standard, face up on the middle of the Qi wireless charging icon (F). • When the device is centered on the Qi wireless charging icon (F), a solid RED light (E) will indicate the device is charging properly. NOTE: If RED light is blinking, this indicates the device is not charging and needs to be properly centered. • Check the charge level on your device periodically to determine when device is fully charged. NOTE: Product DOES NOT provide any indication of when device is fully charged. CAUTION! DEVICE MAY BECOME WARM DURING CHARGING. THIS IS NORMAL AND PART OF THE PROCESS. CHARGING TIMES VARY BY DEVICE SAFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS 1. Turn lamp off and WAIT UNTIL LAMP HEAD (D) AND ADAPTER (G) ARE COOL before handling. 2. The LED panel (L) located in shade (D) might get hot after several hours of continuous use DO NOT place your hands directly on LED light panel. 3. Never use with an extension cord unless the plug can be fully inserted into the receptacles in the extension cord. 4. Do not alter the plug. 5. The lamp head included with this unit cannot be replaced by the consumer. 6. INDOOR USE ONLY NOTE: The important safety instructions appearing in this instruction sheet are not meant to cover all possible conditions and situations that may occur. It must be understood that common sense, caution, and care must be used with any electrical product. BATTERY REPLACEMENT • This lamp uses a CR2032 battery. For battery replacement see diagram 3. Battery compa…

Text truncated - open the document above for the full version.

Ottlite Technologies Inc 2021/4/26 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement Ottlite Technologies Inc FCC ID: 2AI7B-U14SC To Whom It May Concern: We, Ottlite Technologies Inc, hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number 2AI7B-U14SC under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is April 26, 2021. The Limited Agency Agreement expires on April 26, 2022, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Kyle Albinus Quality Manager

1(2) Ottlite Technologies Inc Attention: Certification reviewer RE: Request for Confidentiality FCC ID: 2AI7B-U14SC To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] Schematics Block Diagrams Operational Description Tune-up Procedure Parts List Internal Photos (see note) Users Manual (see note) Note 1: Internal Photos may be held confidential 1) if the circuit board or internal components are not accessible to users. For example, it is acceptable if the circuit board is enclosed in epoxy. 2) Also, it is acceptable if the device is not accessible to the public, for example, a device mounted on the top of a large tower (or in a fenced enclosure) such that it is only serviceable by professional designated technicians under a Non-Disclosure Agreement (NDA). All sales for these devices must be under a NDA restricting the disclosure of the propriety information, including internal photos. Users Manual may be held confidential only when the manual contains proprietary technical information intended for professional technicians obligated under a NDA. All sales and distribution of the user’s manual must be under a NDA that restricts the disclosure of the information. In the application cover letter requesting permanent confidentiality the following additional description and the NDA exhibit is required: 1.Describe in detail how internal photos and/or users manual information are controlled to prevent them from becoming public or disclosed to unauthorized persons. 2.Describe how public access is restricted for products serviceable by professional designated technicians. 3.A statement that all sales of the non-consumer device will be under a NDA to include third party sales and that the final user of the device is subject to the NDA. 4.Provide an example of the NDA between the grantee and a purchaser. The request for confidentiality must Note 2: For scanning receiver, the schematics, block diagrams, operational description, tune-up procedure, parts list and internal photos are always held permanently confidential. Short-term Confidentiality [Complete this section if short-term confidentiality is requested] Request to withhold from public review for a period of [please enter 1 to 180] days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept short-term confidential for a period above from the date of the grant [Select one or more of items below that are not selected in the list above, as appropriate] Schematics Block diagrams Operational Description Tune-up Procedure 2(2) Parts List Test Setup Photos External Photos Internal Photos Users Manual Rationale for request for confidentiality: We have invested considerable time and materials in research and development to produce the referenced product. Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Short-term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development. If you have questions or need further information, please contact the undersigned. Sincerely, _________________ Kyle Albinus Quality Manager 2021/1/13

Le symbole Qi est une marque de commerce du Wireless The Qi symbol is a trademark of the Wireless Power Consortium Power Consortium U14SC 9 U14SC -U14SC 0013/8036(SCEQB00Z-CA) 05 2021 U14SC -U14SC 0013/8036(SCEQB00Z-CA) 05 2021 Bottom Size: 60*48mm

OttLite Technologies, Inc. TEST REPORT SCOPE OF WORK SAR Assessment– U14SC REPORT NUMBER 210406012SZN-002 ISSUE DATE [REVISED DATE] 22 April 2021 [--------------------] PAGES 6 DOCUMENT CONTROL NUMBER RF Exposure © 2017 INTERTEK TEST REPORT Intertek No.: 210406012SZN-002 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page 1 of 6 RF Exposure 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 www.intertek.com Test Report Applicant : OttLite Technologies, Inc. 1715 N Westshore Blvd STE 950 Tampa, FL 33607 United States Sample Description Product : LED table lamp Model No. : U14SC Brand Name : OttLite Electrical Rating : Input: DC 12V, 2.5A from adapter Wireless charging output: DC5V, 1A USB port output: DC5V, 2.1A Date Received : 06 April 2021 Date Test Conducted : 06 April 2021 to 22 April 2021 Test Requested : Test for compliance with CFR 47 part 1 Test Method : Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(c) and (d), 1.1310 Test Result : Pass Conclusion : When determining of test conclusion, measurement uncertainty of tests have been considered. ******************************** End of Page ******************************** Prepared and Checked By: Approved By: Jeff Liang Kidd Yang Engineer Technical Supervisor Date: 22 April 2021 TEST REPORT Intertek No.: 210406012SZN-002 Version: 01-November-2017 Page 2 of 6 RF Exposure Test Report Test Setup Configuration Note - The RF exposure test is performed in the shield room. - The test distance is at or beyond 15 cm surrounding the device, and 20 cm away from the surface from all coils. Test Equipment List Name of instrument Model Manufacturer Cal. Date Due Date Electric and Magnetic Field Analyzer EHP-200A Narda 2020-08-03 2021-08-03 TEST REPORT Intertek No.: 210406012SZN-002 Version: 01-November-2017 Page 3 of 6 RF Exposure Reference Limit: Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(c) and (d), 1.1310 According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation. LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range ( MHz ) Electric Field strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A) Limits for Occupational/Controlled Exposure 0.3 – 3.0 614 1.63 (100) * 6 (B) Limits for General Population/Uncontrolled Exposure 0.3 – 1.34 614 1.63 (100) * 30 Note: * = Plane wave equivalent power density Test Result: H-Field Strength at 15 cm surrounding the EUT and 20cm away from the surface from the coil of the EUT Frequency Range (MHz) EUT Operation mode Probe Position Front (A/m) Probe Position Rear (A/m) Probe Position Left (A/m) Probe Position Right (A/m) Probe Position Top (A/m) Limits (A/m) 0.111- 0.205 1% Battery Level 0.0798 0.0791 0.0800 0.0800 0.0800 1.63 0.111- 0.205 50% Battery Level 0.0748 0.0772 0.08003 0.0821 0.0829 1.63 0.111- 0.205 99% Battery Level 0.0673 0.0729 0.0795 0.0782 0.0804 1.63 0.111- 0.205 Stand-by 0.0683 0.0719 0.0782 0.0745 0.0838 1.63 E-Field Strength at 15 cm surrounding the EUT and 20cm away from the surface from the coil of the EUT Frequency Range (MHz) EUT Operation mode Probe Position Front (V/m) Probe Position Rear (V/m) Probe Position Left (V/m) Probe Position Right (V/m) Probe Position Top (V/m) Limits (V/m) 0.111- 0.205 1% Battery Level 0.6311 0.6350 0.6328 0.6310 0.6319 614 0.111- 0.205 50% Battery Level 0.6301 0.6349 0.6334 0.6359 0.6339 614 0.111- 0.205 99% Battery Level 0.6295 0.6320 0.6385 0.6304 0.6329 614 0.111- 0.205 Stand-by 0.6339 0.6302 0.6392 0.6837 0.6339 614 TEST REPORT Intertek No.: 210406012SZN-002 Version: 01-November-2017 Page 4 of 6 RF Exposure Configuration photo of the test: H-Field & E-Field Strength test photos Front Rear TEST REPORT Intertek No.: 210406012SZN-002 Version: 01-November-2017 Page 5 of 6 RF Exposure Left Right TEST REPORT Intertek No.: 210406012SZN-002 Version: 01-November-2017 Page 6 of 6 RF Exposure Top ****************************** End of Report******************************

Ottlite Technologies Inc. TEST REPORT SCOPE OF WORK FCC TESTING–U14SC REPORT NUMBER 210406012SZN-001 ISSUE DATE [REVISED DATE] 22 April 2021 [--------------------] PAGES 19 DOCUMENT CONTROL NUMBER FCC ID 209_b © 2017 INTERTEK Test Report This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page: 1 of 19 FCC ID 209_b 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen. Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 www.intertek.com Ottlite Technologies Inc. Application For Certification FCC ID: 2AI7B-U14SC LED table lamp Model: U14SC Brand name: Transmitter Report No.: 210406012SZN-001 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-19] Prepared and Checked by: Approved by: Jeff Liang Kidd Yang Engineer Technical Supervisor Date: 22 April 2021 Test Report Intertek Report No.: 210406012SZN-001 Version: 01-November-2017 Page: 2 of 19 FCC ID 209_b MEASUREMENT/TECHNICAL REPORT This report concerns (check one) Original Grant X Class II Change Equipment Type: DCD - Part 15 Low Power Transmitter Below 1705 kHz Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [10-01-19] Edition] provision. Report prepared by: Jeff Liang Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen. Tel: (86 755) 8614 0743 Fax: (86 755) 8601 6751 Test Report Intertek Report No.: 210406012SZN-001 Version: 01-November-2017 Page: 3 of 19 FCC ID 209_b Table of Contents 1.0 Summary of Test Results ..................................................................................... 4 2.0 General Description .............................................................................................. 5 2.1 Product Description .............................................................................................. 5 2.2 Related Submittal(s) Grants ................................................................................. 5 2.3 Test Methodology ................................................................................................ 5 2.4 Test Facility ......................................................................................................... 5 3.0 System Test Configuration ................................................................................... 6 3.1 Justification ......................................................................................................... 6 3.2 EUT Exercising Software ..................................................................................... 6 3.3 Special Accessories ............................................................................................. 6 3.4 Equipment Modification ........................................................................................ 6 3.5 Measurement Uncertainty .................................................................................... 7 3.6 Support Equipment List and Description ............................................................. 7 4.0 Measurement Results ........................................................................................... 8 4.1 Field Strength Calculation .................................................................................... 8 4.2 Radiated Emission Configuration Photograph .................................................... 9 4.3 Radiated Spurious Emission ................................................................................ 9 4.4 Conducted Emission Configuration Photograph ................................................. 12 4.5 Conducted Emission.......................................................................................... 12 5.0 Equipment Photographs .................................................................................... 15 6.0 Product Labelling ................................................................................................ 15 7.0 Technical Specifications .................................................................................... 15 8.0 Instruction Manual .............................................................................................. 15 9.0 Miscellaneous Information ................................................................................. 16 9.1 20dB Bandwidth ................................................................................................ 16 9.2 Emissions Te…

Text truncated - open the document above for the full version.

The EUT is placed at the center of turntable
