2AIKX-F104BVIIPROTABLET PC

1 TABLETPC F104BvII_PRO 2 Usermanual Theactualproduct,accompanyingaccessoriesandsomeofits featuresmaydifferfromthepresentedinthismanualimages anddescriptions. 2.Safety.................................................................3 3.Theuseofthemanual......................................5 4.Importantinformation.....................................5 5.TechnicalSpecification....................................5 5.1Packagecontent............................................6 6.Appearanceofthetablet..................................6 7.Beforethefirststart.........................................7 7.1Installationofthememorycard...................7 7.2Chargingthebattery.....................................7 8.Computerconnection.......................................8 9.Applications......................................................9 10.Setting............................................................10 10.1Network&Internet..................................11 10.2Connecteddevice.....................................12 10.3Display.....................................................13 10.4Storage......................................................14 10.5System......................................................14 10.5.1Language...........................................15 10.5.2Resetoptions.....................................15 10.5.3Abouttablet.......................................16 11.Safeuseofthebattery..................................17 12.Maintenanceofthedevice...........................17 13.Surroundingssecurity..................................18 14.Theuseofthemanual..................................18 14.1Consents...................................................18 14.2Appearance...............................................18 14.3Trademarks...............................................18 3 2.Safety Readtheseguidelinescarefully.Notfollowingthemmaybe dangerousorillegal. —DONOTRISK— Allwirelessdevicesmaycauseinterference,which couldaffecttheperformanceofotherdevices. Donotswitchonthedevicewhentheuseof mobilephonesisprohibitedorifitmightcause interferenceordanger. —RESTRICTEDAREAS— SwitchOFFthedeviceinanairplanesinceitmaydisturbthe operationofotherequipmentlocatedtherein.Thedevicemay interferewithoperationofthemedicalequipmentinhospitals andhealthprotectionentities.Abidebyanykindsof prohibitions,regulationsandwarningsconveyedbythe medicalstaff. —PETROLSTATIONS— Alwaysturnoffthedevicewhilerefuellingyourcaronpetrol station.Donotuseyourdeviceclosetochemicals. —WI-FI(WLAN)— aWLANnetworkmaybeusedindoorswithoutany restrictions. —ROADSAFETY— Donotusethisdevicewhiledrivinganykindofvehicle. —QUALIFIEDSERVICE— Onlyqualifiedpersonneloranauthorizedservicecentermay installorrepairthisproduct.Repairingbyanunauthorizedor unqualifiedservicemaycausedevicedamageandwarranty loss. —CHILDRENANDPHYSICALLYORMENTALLY DISABLEDPEOPLE— Thisdeviceshouldnotbeoperatedbypeople(including children)withlimitedphysicalormentalabilities,aswellas 4 bypeoplewithnoearlierexperienceinoperationofelectronic equipment.Theymayusethedeviceonlyundersupervisionof peopleresponsiblefortheirsafety.Thisdeviceisnotatoy. MemorycardandSIMcardaresmallenoughtobeswallowed byachildandcausechoking.Keepthedeviceandits accessoriesoutofreachforchildren. —WATERANDOTHERLIQUIDS— Protectthedevicefromwaterandotherliquids.Itcan influenceworkandthelifespanofelectroniccomponents. Avoidusingthedeviceinenvironmentswithhighhumidity likekitchens,bathroomsorduringrainyweather.Particlesof watercancausetheliquefactionofmoistureinthedevice,and thismayhaveanegativeimpactontheworkofelectronic components. —BATTERYANDACCESSORIES— Avoidexposingthebatterytoveryhigh/lowtemperatures (below0°C/32°Fandover40°C/104°F).Extreme temperaturesmayinfluencecapacityandbatterylife.Avoid contactwithliquidsandmetalobjectsasitmaycausepartial orcompletebatterydamage.Thebatteryshouldbeused accordingtoitspurpose.Donotdestroy,impairorthrowthe batteryintoflames-itmightbedangerousandmaycausefire. Worn-outorimpairedbatteryshouldbeplacedinadedicated container.Excessivechargingthebatterycancausedamage. Thereforeasinglebatterychargeshouldnotlastlongerthan3 days.Installinganincorrectbatterytypecancausean explosion.Neveropenthebattery.Pleasedisposeofbattery accordingtotheinstructions.Disconnectanunusedcharger frompowergrid.Incaseofthechargerwiredamage,itshould notberepairedbutreplacedwithanewone.Usetheoriginal manufacturer’saccessoriesonly. —HEARING— Toavoidhearingdamage,donotusethedeviceat highvolumelevelsforalongperiodoftime,donot putoperatingdevicedirectlytotheear. —EYESIGHT— 5 Toavoideyesightdamagedonotlookcloselyonto theflashlightduringitswork.Astrongbeanoflight maycausepermanenteyedamage! 3.Theuseofthemanual Thedeviceandscreenshotscontainedinthismanualmay differfromtheactualproduct.Accessoriesattachedtotheset maydifferfromtheillustrationsincludedinmanual.Options describedinthemanualarefoundinAndroid™system.Those descriptionsmaydiffer,dependingontheversionofthe operatingsystemandapplicationsinstalledonthedevice. 4.Importantinformation Themajorityofapplicationswhichcanbeinstalledonthe devicearemobileapps.Modusoperandiofsuchapplications maybedifferentfromtheircounterpartsinstalledona personalcomputer.Appsinstalledonthedevicemayvary dependingoncountry,region,andhardwarespecifications. Themanufacturerisnotliableforproblemscausedbythird partysoftware.Themanufacturerisnotresponsiblefor anomaliesthatmayoccurwheneditingtheregistrysettings andmodifyingtheoperatingsystemsoftware.Attemptsto modifytheoperatingsystemcancausemalfunctionsand problemswithapplications.Itmaycausealossofwarranty. 5.TechnicalSpecification AndroidSystem Android TM operatingsystem-incredibleopportunitiesare withinyourhand-allapplicationsareavailableatanytime; thelatestGmail™emailclientorbrowser,itisonlythe beginningofwhatyoucanfindinthisdevice-therestyou willfindintheonlineGooglePlay™. GooglePlay Manufacturer'stabletscanusetheapplicationspurchasedin GooglePlay.Todothisyoushouldregisteraindividual Google TM accountprov…

Text truncated - open the document above for the full version.

F5CS LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020.11.10 Subject; Request for Long Term Confidentiality FCC ID: 2AIKX-F104BVIIPRO To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Gand Hi Title: Managerr

F5CS LTD 19C Trolley Sq, Wilmington, Delaware 19806, United States Statement Product: TABLET PC Model: F104BvII_PRO Additional Model: F704Bv2, 705B, 805B, 103B, 101A, 108Bv2, S14+, C60Bv2, FWIN232 PRO S2 Trademark: FUSION5 We hereby state that All models above are identical in interior structure, electrical circuits and components, and just model names and colour are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Date: 2020/11/10 Name: Gand Hi Company Name : F5CS LTD Address: 19C Trolley Sq, Wilmington, Delaware 19806, United States Tel / Fax: +47940998787/+47940998787 E-Mail: [email protected]

F5CS LTD Agent Authorization C ompany: F5CS LTD A ddress: 19C Trolley Sq, Wilmington, Delaware 19806, United States P roduct Name: TABLET PC M odel Number(s): F104BvII_PRO, F704Bv2, 705B, 805B, 103B, 101A, 108Bv2, S14+, C60Bv2, FWIN232 PRO S2 P roduct Description: TABLET PC W e authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. W e declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-11-10 Name: Gand Hi Title: Managerr Company: F5CS LTD

Page 1 of 4 Appendix B: Photographs of EUT Product: TABLET PC Model: F104BvII_PRO External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: F104BvII_PRO Label: Size: L*W=65*35mm TABLET PC Model: F104BvII_PRO FCC ID: 2AIKX-F104BVIIPRO This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Location

Page 1 of 5 Appendix B: Photographs of EUT Product: TABLET PC Model: F104BvII_PRO Internal Photos Antenna Page 2 of 5 Page 3 of 5 Page 4 of 5 Page 5 of 5

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AIKX-F104BVIIPRO Product: TABLET PC Model No.: F104BvII_PRO Additional Model No.: F704Bv2, 705B, 805B, 103B, 101A, 108Bv2, S14+, C60Bv2, FWIN232 PRO S2 Trade Mark: FUSION5 Report No.: TCT201110E908 Issued Date: Nov. 10, 2020 Issued for: F5CS LTD 19C Trolley Sq, Wilmington, Delaware 19806, United States Issued By: Shenzhen Tongce Testing Lab. 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China TEL: +86-755-27673339 FAX: +86-755-27673332 This test report was based on TCT190723E028; Only change product additional model No. Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT201110E908 Page 2 of 34 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification ..................................................................................... 3 2. Test Result Summary .............................................................................. 4 3. EUT Description ....................................................................................... 5 4. General Information ................................................................................. 6 4.1. Test environment and mode ................................................................................. 6 4.2. Description of Support Units ................................................................................ 6 5. Facilities and Accreditations .................................................................. 7 5.1. Facilities ................................................................................................................. 7 5.2. Location ................................................................................................................. 7 5.3. Measurement Uncertainty ..................................................................................... 7 6. Test Results and Measurement Data ..................................................... 8 6.1. Antenna requirement ............................................................................................ 8 6.2. Conducted Emission ............................................................................................. 9 6.3. Conducted Output Power ................................................................................... 13 6.4. Emission Bandwidth ........................................................................................... 16 6.5. Power Spectral Density ....................................................................................... 19 6.6. Conducted Band Edge and Spurious Emission Measurement ....................... 22 6.7. Radiated Spurious Emission Measurement ...................................................... 25 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT201110E908 Page 3 of 34 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: TABLET PC Model No.: F104BvII_PRO Additional Model No.: F704Bv2, 705B, 805B, 103B, 101A, 108Bv2, S14+, C60Bv2, FWIN232 PRO S2 Trade Mark: FUSION5 Applicant: F5CS LTD Address: 19C Trolley Sq, Wilmington, Delaware 19806, United States Manufacturer: Top Sky Technology International Co., Ltd Address: East 5th of Shangxue Industry Area, Bantian Street, Longgang District, Shenzhen, China Date of Test: Jul. 24, 2019 – Aug. 09, 2019 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: Aug. 09, 2019 Kevin Huang Reviewed By: Date: Nov. 10, 2020 Beryl Zhao Approved By: Date: Nov. 10, 2020 Tomsin Report No.: TCT201110E908 Page 4 of 34 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(3) PASS 6dB Emission Bandwidth §15.247 (a)(2) PASS Power Spectral Density §15.247 (e) PASS Band Edge §15.247(d) PASS Spurious Emission §15.205/§15.209 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT201110E908 Page 5 of 34 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product: TABLET PC Model No.: F104BvII_PRO Additional Model No.: F704Bv2, 705B, 805B, 103B, 101A, 108Bv2, S14+, C60Bv2, FWIN232 PRO S2 Trade Mark: FUSION5 BT Version: V4.0(This report is for BLE) Operation Frequency: 2402MHz~2480MHz Channel Separation: 2MHz Number of Channel: 40 Modulation Technology: GFSK Antenna Type: Internal Antenna Antenna Gain: 2.1dBi Power Supply: Rechargeable Li-ion Battery DC 3.7V AC adapter: Adapter Information: MODEL: FJ-SW266B50502000U INPUT: AC 100-240V, 50/60Hz, 0.4A Max OUTPUT: DC 5V, 2000mA Remark: All models above are identical in interior structure, electrical circuits and components, just model names and colors are different for the market…

Text truncated - open the document above for the full version.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AIKX-F104BVIIPRO Product: TABLET PC Model No.: F104BvII_PRO Additional Model No.: F704Bv2, 705B, 805B, 103B, 101A, 108Bv2, S14+, C60Bv2, FWIN232 PRO S2 Trade Mark: FUSION5 Report No.: TCT201110E909 Issued Date: Nov. 1 0, 2020 Issued for: F5CS LTD 19C Trolley Sq, Wilmington, Delaware 19806, United States Issued By: Shenzhen Tongce Testing Lab. 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China TEL: +86-755-27673339 FAX: +86-755-27673332 This test report was based on TCT190723E029; Only change product additional model No. Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT201110E909 Page 2 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification ..................................................................................... 3 2. Test Result Summary .............................................................................. 4 3. EUT Description ....................................................................................... 5 4. General Information ................................................................................. 7 4.1. Test environment and mode ................................................................................. 7 4.2. Description of Support Units ................................................................................ 8 5. Facilities and Accreditations .................................................................. 9 5.1. Facilities ................................................................................................................. 9 5.2. Location ................................................................................................................. 9 5.3. Measurement Uncertainty ..................................................................................... 9 6. Test Results and Measurement Data ................................................... 10 6.1. Antenna requirement .......................................................................................... 10 6.2. Conducted Emission ........................................................................................... 11 6.3. Maximum Conducted (Average) Output Power ................................................ 15 6.4. Emission Bandwidth ........................................................................................... 16 6.5. Power Spectral Density ....................................................................................... 17 6.6. Conducted Band Edge and Spurious Emission Measurement ....................... 18 6.7. Radiated Spurious Emission Measurement ...................................................... 20 Appendix A: Test Result of Conducted Test Appendix B: Photographs of Test Setup Appendix C: Photographs of EUT Report No.: TCT201110E909 Page 3 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: TABLET PC Model No.: F104BvII_PRO Additional Model No.: F704Bv2, 705B, 805B, 103B, 101A, 108Bv2, S14+, C60Bv2, FWIN232 PRO S2 Trade Mark: FUSION5 Applicant: F5CS LTD Address: 19C Trolley Sq, Wilmington, Delaware 19806, United States Manufacturer: Top Sky Technology International Co., Ltd Address: East 5th of Shangxue Industry Area, Bantian Street, Longgang District, Shenzhen, China Date of Test: Jul. 24, 2019 – Aug. 09, 2019 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: Aug. 09, 2019 Kevin Huang Reviewed By: Date: Nov. 10, 2020 Beryl Zhao Approved By: Date: Nov. 10, 2020 Tomsin Report No.: TCT201110E909 Page 4 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(3) PASS 6dB Emission Bandwidth §15.247 (a)(2) PASS Power Spectral Density §15.247 (e) PASS Band Edge §15.247(d) PASS Spurious Emission §15.205/§15.209 PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT201110E909 Page 5 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product: TABLET PC Model No.: F104BvII_PRO Additional Model No.: F704Bv2, 705B, 805B, 103B, 101A, 108Bv2, S14+, C60Bv2, FWIN232 PRO S2 Trade Mark: FUSION5 Operation Frequency: 2412MHz~2462MHz (802.11b/802.11g/802.11n(HT20)) 2422MHz~2452MHz (802.11n(HT40)) Channel Separation: 5MHz Number of Channel: 11 for 802.11b/802.11g/802.11n(HT20) 7 for 802.11n(HT40) Modulation Technology: (IEEE 802.11b) Direct Sequence Spread Spectrum (DSSS) Modulation Technology: (IEEE 802.11g/802.11n) Orthogonal Frequency Division Multiplexing(OFDM) Data speed (IEEE 802.11b): 1Mbps, 2Mbps, 5.5Mbps, 11Mbps Data speed (IEEE 802.11g): 6Mbps, 9Mbps, 12Mbps, 18Mbps, 24Mbps, 36Mbps, 4…

Text truncated - open the document above for the full version.

Report No.: TCT201110E909 Page 46 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11N20SISO/HCH 11N40SISO/LCH 11N40SISO/HCH Report No.: TCT201110E909 Page 47 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com RF Conducted Spurious Emissions Result Table Mode Channel Pref [dBm] Max.Spurious Level [dBm] Limit [dBm] Verdict 11B LCH -3.628 -39.78 -33.63 PASS 11B MCH -3.285 -40.67 -33.29 PASS 11B HCH -3.357 -39.79 -33.36 PASS 11G LCH -8.271 -41.27 -38.27 PASS 11G MCH -8.233 -40.86 -38.23 PASS 11G HCH -8.120 -40.86 -38.12 PASS 11N20SISO LCH -8.520 -39.59 -38.52 PASS 11N20SISO MCH -7.867 -41.02 -37.87 PASS 11N20SISO HCH -8.082 -40.35 -38.08 PASS 11N40SISO LCH -11.264 -41.94 -41.26 PASS 11N40SISO MCH -11.339 -42.10 -41.34 PASS 11N40SISO HCH -11.625 -42.14 -41.63 PASS Test Graph 11B_LCH_Graphs Pref/11B/LCH Report No.: TCT201110E909 Page 48 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11B/LCH Report No.: TCT201110E909 Page 49 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11B_MCH_Graphs Pref/11B/MCH Report No.: TCT201110E909 Page 50 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11B/MCH Report No.: TCT201110E909 Page 51 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11B_HCH_Graphs Pref/11B/HCH Report No.: TCT201110E909 Page 52 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11B/HCH Report No.: TCT201110E909 Page 53 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11G_LCH_Graphs Pref/11G/LCH Report No.: TCT201110E909 Page 54 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11G/LCH Report No.: TCT201110E909 Page 55 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11G_MCH_Graphs Pref/11G/MCH Report No.: TCT201110E909 Page 56 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11G/MCH Report No.: TCT201110E909 Page 57 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11G_HCH_Graphs Pref/11G/HCH Report No.: TCT201110E909 Page 58 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11G/HCH Report No.: TCT201110E909 Page 59 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11N20SISO_LCH_Graphs Pref/11N20SIS O/LCH Report No.: TCT201110E909 Page 60 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com /11N20SISO/L CH Report No.: TCT201110E909 Page 61 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11N20SISO_MCH_Graphs Pref/11N20SIS O/MCH Report No.: TCT201110E909 Page 62 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11N20SIS O/MCH Report No.: TCT201110E909 Page 63 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11N20SISO_HCH_Graphs Pref/11N20SIS O/HCH Report No.: TCT201110E909 Page 64 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11N20SIS O/HCH Report No.: TCT201110E909 Page 65 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11N40SISO_LCH_Graphs Pref/11N40SIS O/LCH

Report No.: TCT201110E909 Page 66 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11N40SIS O/LCH Report No.: TCT201110E909 Page 67 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11N40SISO_MCH_Graphs Pref/11N40SIS O/MCH Report No.: TCT201110E909 Page 68 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11N40SIS O/MCH Report No.: TCT201110E909 Page 69 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11N40SISO_HCH_Graphs Pref/11N40SIS O/HCH Report No.: TCT201110E909 Page 70 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Puw/11N40SIS O/HCH Report No.: TCT201110E909 Page 71 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Report No.: TCT201110E909 Page 72 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Power Spectral Density Result Table Mode Channel Meas.Level [dBm] Verdict 11B LCH -23.590 PASS 11B MCH -23.362 PASS 11B HCH -23.416 PASS 11G LCH -26.068 PASS 11G MCH -25.978 PASS 11G HCH -26.175 PASS 11N20SISO LCH -24.946 PASS 11N20SISO MCH -25.827 PASS 11N20SISO HCH -25.964 PASS 11N40SISO LCH -30.586 PASS 11N40SISO MCH -29.801 PASS 11N40SISO HCH -30.001 PASS Test Graph Graphs 11B/LCH Report No.: TCT201110E909 Page 73 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11B/MCH 11B/HCH 11G/LCH Report No.: TCT201110E909 Page 74 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11G/MCH 11G/HCH 11N20SISO/LCH Report No.: TCT201110E909 Page 75 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11N20SISO/MCH 11N20SISO/HCH 11N40SISO/LCH Report No.: TCT201110E909 Page 76 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 11N40SISO/MCH 11N40SISO/HCH Report No.: TCT201110E909 Page 77 of 77 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Appendix B: Photographs of Test Setup Refer to the test report No. TCT201110E902 Appendix C: Photographs of EUT Refer to the test report No. TCT201110E902 *****END OF REPORT*****

RF exposure evaluation §2.1093 Radiofrequency radiation exposure evaluation: Portable Devices. According to§15.247(i) and§1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the commission’s guidance. The 1-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  When the minimum test separation distance is < 5 mm, a distance of 5 mm according is applied to determine SAR test exclusion.  The result is rounded to one decimal place for comparison  For BDR+EDR: Channel Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR CH 78 2.480 3.18 2.5±1 3.5 2.24 5 0.71 3.0  For BLE: Channel Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR CH 78 2.480 2.79 2±1 3 2.00 5 0.67 3.0  For WIFI: Channel Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR CH 06 2.437 7.23 6.5±1 7.5 5.62 5 1.75 3.0 Result: Base on the calculation value, No SAR measurement is required.

Appendix A: Photographs of Test Setup Product: TABLET PC Model: F104BvII_PRO Radiated Emission Conducted Emission
