2AIP7-V60093Tower Firework Speaker

User’s Manual Item V60093BT-NOC Light-Up Tower Speaker with Remote Control Wireless When using your Wireless Tower Speaker with Remote Control, basic safety precautions should always be followed, including the following: 1. READ ALL INSTRUCTIONS BEFORE USING YOUR SPEAKER. 2. Clean using a soft cloth or paper towel. 3. Do not allow children or the infirm to play with your speaker without adult supervision. 4. Do not expose your speaker to excessive heat, flames or fire. 5. Always press all buttons or switches carefully. Do not manhandle your speaker. 6. Do not use in extremely dry environments, as this can lead to static discharge during usage. 7. Do not expose your speaker to temperatures above 40°C. 8. Do not attempt to repair this product yourself. Contact a qualified service center if your speaker is in need of service. 9. Do not drop, puncture or expose your speaker to excessive trauma. 10. Your speaker is not intended for commercial use. 11. Do not place near objects that generate a strong magnetic field. 12. Unplug this device when not in use for long periods of time or during lightning storms. 13. In order to avoid the risk of fire or electric shock, do not expose this unit to rain or moist environments. 14. Only use product indoors. Do not expose to water or moisture. 15. Keep your speaker on a dry, cool even surface. *Please note: this product is for indoor use ONLY. Introduction Thank you for purchasing the Vivitar Wireless Light-Up Tower Speaker, item V60093BT-NOC. Your speakers are designed specifically for indoor use. Please read this manual first before using your device. Package Contents -Light-Up Tower Speaker -Remote Control -Power Adapter -User’s Manual with Warranty Information Specifications Bluetooth: V5.0 Bluetooth Range: Up to 33 feet (10 meters) Rated Voltage: DC5V Frequency Response: 50Hz-18KHz Bluetooth Transmitting Frequency: 2.40---2.48GHz S/N Ratio: ≥78dBA Remote Battery Type: One Lithium CR2025 Button Cell Battery A Look at Your Speaker Controls Speaker Controls 1 2 3 4 5 67 1. Previous Track (press and hold to decrease volume) 2. Play/Pause 3. Next Track (press and hold to increase volume) 4. Mode(Bluetooth,AUX,FM, LED) 5. DC 5V Power Input 6. Power ON/OFF 7. AUX Input Jack Remote Control 1. SWITCH: press to power ON/OFF 2. PLAY/PAUSE: press to Play or Pause media playback. 3. NEXT TRACK: press to skip to the next track. 4. PREVIOUS TRACK: press to skip to the previous track. 5. MODE: press to change input modes 6. LIGHT: press to change LED light modes. 7. VOL +: press the button to increase the volume. 8. VOL -: press the button to decrease the volume. 1 7 8 2 5 4 3 6 A Look at Your Remote Control Note: When using your remote, keep at a close distance to the IR sensor on the speaker. WARNING:Chemical Burn Hazard. Keep batteries away from children. This product contains a button/coin cell battery. If a new or used button/coin cell battery is swallowed or enters the body, it can cause severe internal burns and can lead to death in as little as 2 hours. Always completely secure the battery compartment. If the battery compartment does not close securely, stop using the product, remove the batteries, and keep it away from children. If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical attention. The cells shall be disposed of properly, including keeping them away from children; Even used cells may cause injury. Powering Your Speaker BATTERY WARNING: · Do not mix old and new batteries. · Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickle-cadmium) batteries. · Batteries are not to be inserted with the wrong polarity. · Exhausted batteries are to be removed. · The supply terminals are not to be short-circuited. Please recycle or dispose of the battery properly. Contact local recycling facilities and/or the manufacturer of your battery for further information. 1. Slide open the battery case located on the back of your remote. 2. Insert one CR2025 button cell battery with the correct polarity (+, -). 3. Slide the battery case back into place. Inserting Batteries In Your Remote Power Adapter WARNING -Make sure that the power supply of your home corresponds with the voltage of this unit. -Never handle the power cord or plug with wet hands. -Ensure that the main power switch is in the “OFF” position before connecting the Power Adapter to the power supply to avoid damage to this unit. -A damaged power cord can easily cause an electric shock or fire hazard; never use a power cord after it had been damaged. Insert the Power Adapter into the DC 5V power input, then plug the other end into a suitable power outlet. Power on the speaker system by pressing the Power button on the speaker or the remote. Once the speaker is turned on it will automatically go into Bluetooth mode. To connect a Bluetooth-enabled device follow the steps below. 1. If your speaker does not automatically go into Bluetooth mode, press the MODE button on the speaker or the remote until Bluetooth mode is turned ON. 2. Turn on Bluetooth from the device you would like to connect. Then select pairing name “V60093BT” from the Bluetooth menu to pair. Note: Keep Bluetooth device within signal range (10 meters). V60093BT To use the speaker’s AUX mode, attach a 3.5mm auxiliary cable into the AUX input jack. Attach the other end of the AUX cable into a computer, music player or other media-playing device. The speaker will automatically switch to AUX mode after following the steps above. If not, press the MODE button on the speaker or the remote to switch to AUX mode. Maintenance and Care -Before using your speakers or before charging, inspect the ports to make sure that they are clear of dust and debris. -Use a soft cloth to clean your speakers. Never use any harsh chemicals or detergents. Make sure your speakers are dry before charging. -When your speakers are not in use, they should be stored in a cool, dry place. -Connect and disconnect …

Text truncated - open the document above for the full version.

Form: RFT-AMER-TCB-OP-19o Revision: 1 Page 1 of 1 Date: 1/25/2023 [Shenzhen Super Global Electronics Co.,Ltd] Attention: Application Examiner Re: Certification designating a U.S. agent for service of process pursuant to section 2.911(d)(7) of the FCC rules To whom it may concern, This letter is to confirm both [Sakar International Inc] (“Agent”) and [Shenzhen Super Global Electronics Co.,Ltd] (“Applicant”) acknowledge consent to obligations of each party pursuant to 47 CFR part §2.911(d)(7) of the FCC rules in regard to the agent for service of process. I [Jem Qiu] HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Applicant. I further acknowledge the requirement to maintain an agent extends for no less than one year after the termination of all marketing and importation or the conclusion of and commission-related proceeding involving the equipment and agree to immediately notify the FCC and Intertek if there is any change in the status identified above. Applicant Company Name : Shenzhen Super Global Electronics Co.,Ltd Contact Name : Jem Qiu Address : 2F Building 4 BaiHuaYuan Rode 11#, GuangMing New District ShenZhen 518107 China Telephone No : 86 0755 23243162 Email : [email protected] FCC ID : 2AIP7-V60093 Applicant FRN : 0025647652 Signature: . Date: 2023.5.9 . I [Dawn Leitao] HEREBY CERTIFY THAT I am authorized to make the representations above on behalf of the Agent. I consent to the obligation to accept service of process on behalf of the applicant in regard to the FCC ID designated above. Agent Company Name : Sakar International Inc Contact Name : Dawn Leitao Address : 195 Carter Drive • Edison, NJ 08817 Telephone No : 732.248.1306 x340 Email : [email protected] Agent FRN : 0028102671 Signature: . Date: 2023.5.9 .

Form:RFT-AMER-TCB-OP-19nRevision:1Page 1 of 1 Date:1/25/2023 ShenzhenSuperGlobalElectronicsCo.,Ltd Attention:ApplicationExaminer Re:CoveredList,locatedathttps://www.fcc.gov/supplychain/coveredlistand47CFRparts§2.903and §2.911(d)(5)(ii)oftheFCCrules Applicant:ShenzhenSuperGlobalElectronicsCo.,Ltd FCCID:2AIP7-V60093 Towhomitmayconcern, ShenzhenSuperGlobalElectronicsCo.,Ltdcertifiesthattheequipmentforwhichauthorizationissoughtis not“covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuantto47CFRpart §2.903oftheFCCrulesanddoesnotoriginatedirectlyorindirectlyfromanycompanynamedonthe coveredlistlocatedinthelinkaboveoranysubsidiaryoraffiliatethereof. Applicantfurthercertifiesthat,asofthedateofthefilingoftheapplication,theApplicantisnotidentifiedon theCoveredListasanentityproducing“covered”equipmentandisnotasubsidiaryoraffiliateofanysuch entitypursuantto47CFRpart§1.50002andrequiredby47CFRpart§2.911(d)(5)(ii)oftheFCCrules. IHEREBYCERTIFYTHATIamauthorizedtomaketherepresentationsaboveonbehalfoftheApplicant andagreetoimmediatelynotifyIntertekifthereisanychangeinthestatusidentifiedabove. JamesLai Manager ShenzhenSuperGlobalElectronicsCo.,Ltd 2023.05.09

Shenzhen Super Global Electronics Co.,Ltd [2023.4.21] Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement (Shenzhen Super Global Electronics Co.,Ltd) FCC ID: 2AIP7-V60093 To Whom It May Concern: We, (Shenzhen Super Global Electronics Co.,Ltd), hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number 2AIP7-V60093 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is (2023.4.21). The Limited Agency Agreement expires on (2024.4.21), unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, [James Lai] [Manager]

Shenzhen Super Global Electronics Co.,Ltd Attention: Certification reviewer RE: Request for Confidentiality FCC ID: 2AIP7-V60093 To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] Schematics Block Diagrams Operational Description Tune-up Procedure Parts List Internal Photos (see note) Users Manual (see note) Note 1: Internal Photos may be held confidential 1) if the circuit board or internal components are not accessible to users. For example, it is acceptable if the circuit board is enclosed in epoxy. 2) Also, it is acceptable if the device is not accessible to the public, for example, a device mounted on the top of a large tower (or in a fenced enclosure) such that it is only serviceable by professional designated technicians under a Non-Disclosure Agreement (NDA). All sales for these devices must be under a NDA restricting the disclosure of the propriety information, including internal photos. Users Manual may be held confidential only when the manual contains proprietary technical information intended for professional technicians obligated under a NDA. All sales and distribution of the user’s manual must be under a NDA that restricts the disclosure of the information. In the application cover letter requesting permanent confidentiality the following additional description and the NDA exhibit is required: 1. Describe in detail how internal photos and/or users manual information are controlled to prevent them from becoming public or disclosed to unauthorized persons. 2. Describe how public access is restricted for products serviceable by professional designated technicians. 3. A statement that all sales of the non-consumer device will be under a NDA to include third party sales and that the final user of the device is subject to the NDA. 4. Provide an example of the NDA between the grantee and a purchaser. The request for confidentiality must Note 2: For scanning receiver, the schematics, block diagrams, operational description, tune-up procedure, parts list and internal photos are always held permanently confidential. Short-term Confidentiality [Complete this section if short-term confidentiality is requested] Request to withhold from public review for a period of [please enter 1 to 180] days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept short-term confidential for a period above from the date of the grant [Select one or more of items below that are not selected in the list above, as appropriate] Schematics Block diagrams Operational Description Tune-up Procedure Parts List Test Setup Photos External Photos Internal Photos Users Manual Rationale for request for confidentiality: We have invested considerable time and materials in research and development to produce the referenced product. Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Short-term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development. If you have questions or need further information, please contact the undersigned. Sincerely, _James Lai________________ Shenzhen Super Global Electronics Co.,Ltd manager 2023.4.21

The label is located at the top of the back of the product and the lower part of the DC 5V power port

INTERTEK TESTING SERVICES RF Exposure The equipment under test (EUT) is a Tower Firework Speaker with Bluetooth 5.0 EDR function operating in 2402-2480MHz. The EUT is powered by DC 5V with adapter. For more detail information pls. refer to the user manual. Antenna Type: Integral antenna Modulation Type: /4-DQPSK Antenna Gain: -0.58 dBi Bluetooth Version: 5.0 EDR (Single Mode) The nominal conducted output power specified: -8.42 dBm (±3dB) The nominal radiated output power (e.i.r.p) specified: -9 dBm (±3dB) According to the KDB 447498: The Maximum peak radiated emission for the EUT is 89.1 dBμV/m at 3m in the frequency 2402MHz The EIRP = [(FS*D) ^2 / 30] mW = -6.13dBm which is within the production variation. The Minimum peak radiated emission for the EUT is 83.5 dBμV/m at 3m in the frequency 2441MHz The EIRP = [(FS*D) ^2 / 30] mW = -11.73dBm which is within the production variation. The maximum conducted output power specified is -5.42dBm= 0.287mW The source- based time-averaging conducted output power = 0.287 * Duty factor mW (where Duty Factor≤1) = 0.287mW 1-mW Test Exemption: Since the source-based time-averaging conducted output power is well below 1-mW Test Exemption, per 447498 and §1.1307(b)(3)(i)(A), the EUT is considered to comply with SAR requirement without testing and no evaluation is required. FCC ID: 2AIP7-V60093

Shenzhen Super Global Electronics Co.,Ltd TEST REPORT SCOPE OF WORK FCC TESTING–V60093BT-NOC, V60093BT-BLK, SKU#2198088 REPORT NUMBER 230418094SZN-002 ISSUE DATE [REVISED DATE] 26 May 2023 [---------------------] PAGES 27 DOCUMENT CONTROL NUMBER FCC ID 249_C © 2017 INTERTEK Intertek Report No.: 230418094SZN-002 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen, P.R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page: 1 of 27 FCC ID 249_C Test Report Shenzhen Super Global Electronics Co.,Ltd Application For Certification FCC ID: 2AIP7-V60093 Tower Firework Speaker Model: V60093BT-NOC, V60093BT-BLK, SKU#2198088 Brand Name: Vivitar 2.4GHz Transceiver Report No.: 230418094SZN-002 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-21] Prepared and Checked by: Approved by: Tenet Cao Assistant Engineer Ryan Chen Project Engineer Date: 26 May 2023 Intertek Report No.: 230418094SZN-002 Version: 01-November-2017 Page: 2 of 27 FCC ID 249_C Test Report MEASUREMENT/TECHNICAL REPORT This report concerns (check one:) Original Grant X Class II Change Equipment Type: DXX - Part 15 Low Power Communication Device Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator − the new 47 CFR [10-1-21 Edition] provision. Report prepared by: Tenet Cao Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen, P.R. China Tel / Fax: 86-755-8614 0743/86-755-8601 6661 Intertek Report No.: 230418094SZN-002 Version: 01-November-2017 Page: 3 of 27 FCC ID 249_C Test Report Table of Contents 1.0 Summary of Test Result ................................................................................................. 4 2.0 General Description ...................................................................................................... 5 2.1 Product Description .................................................................................................... 5 2.2 Related Submittal(s) Grants ......................................................................................... 5 2.3 Test Methodology ...................................................................................................... 5 2.4 Test Facility ............................................................................................................... 5 3.0 System Test Configuration ............................................................................................. 6 3.1 Justification ............................................................................................................... 6 3.2 EUT Exercising Software .............................................................................................. 6 3.3 Special Accessories ..................................................................................................... 6 3.4 Equipment Modification .............................................................................................. 6 3.5 Measurement Uncertainty .......................................................................................... 7 3.6 Support Equipment List and Description ........................................................................ 7 4.0 Emission Results ........................................................................................................... 8 4.1 Radiated Test Results .................................................................................................. 8 4.1.1 Field Strength Calculation ......................................................................................... 8 4.1.2 Radiated Emission Configuration Photograph .............................................................. 9 4.1.3 Radiated Emissions .................................................................................................. 9 4.1.4 Transmitter Spurious Emissions ............................................................................... 12 4.2 Conducted Emission Configuration Photograph ............................................................ 16 4.2.1 Conducted Emission ............................................................................................... 16 5.0 Equipment Photographs .............................................................................................. 19 6.0 Product Labelling ........................................................................................................ 19 7.0 Technical Specifications ........................…
