FCCID:2AIP7PBT9518

LabelLocationOnEUT Label ProductName:Bluetoothspeaker ModelNo.:PBT9518 FCCID:2AIP7PBT9518 ThisdevicecomplieswithPart15oftheFCCRules. Operationissubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived, includinginterferencethatmaycauseundesired operation.

FCCID:2AIP7PBT9518 BTANT

version01 ShenZhenSuperGlobalElectronicsCo.,Ltd DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.: PBT9518,PBT650,PBT9514,PBT9533,SBT2017,BSSK2017,PBT9530,PBT9522, PBT9523,BSSK9037,PBT9538,AR1060,PBT7095,PBT9543,PBT3095,AR1065, PBT9543,PBT3095,PBT7095,PBT3090,PBT9545,AR1068,PBT7538,BSSK9528,BSSK9062 FCCID:2AIP7PBT9518 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsfor internal antennatype(s) describedbelow: ModelNo.ofantenna:N/A Typeofantenna:PCBAntenna Gainoftheantenna:-0.58dBi Frequencyrange:2402-2480MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Sincerely, JamesLai Manager CompanyName:ShenZhenSuperGlobalElectronicsCo.,Ltd CompanyAddress:2FBuilding4BaiHuaYuanRoad11#,GuangMingNewDistrictShenzhen China518107

RFEXPOSUREEVALUATION FCCID:2AIP7PBT9518 AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeused toevaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF) Radiationasspecifiedin§1.1307(b): RoutineSARevaluationreferstothatspecificallyrequiredby§2.1093,using measurementsorcomputersimulation.WhenroutineSARevaluationisnot required,portabletransmitterswithoutputpowergreaterthantheapplicable lowthresholdrequireSARevaluationtoqualifyforTCBapproval. Channel (MHz) Maximum output power (dBm) Tuneup tolerance (dBm) MaxTuneUp Power(dBm) Distance (mm) Calculation results Limit Operating Mode 2402 -1.236-1.236 ±1 -0.236 5 0.294 3 BDR 2441 -1.143-1.143 ±1-0.143 5 0.302 3 2480 1.3281.328 ±12.32850.5383 2402 -2.013-2.013 ±1 -1.013 5 0.245 3 EDR2441 -2.158-2.158 ±1-1.158 5 0.239 3 2480 0.1170.117 ±11.11750.4073 TestResults:PASS.
