2AIQ4-SPKPL-GTWY-ESpektrum+ Gateway with Ethernet Port

American Lighting Inc.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Dec 08, 2022
Application Purpose: Original Equipment
Date of Application: Dec 08, 2022
Equipment Note: Spektrum+ Gateway with Ethernet Port
Frequency Range: 2412.00000000 - 2462.00000000
Company: American Lighting Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Page 1 of 1 SPKPL-GTWY-E INSTALLATION INSTRUCTIONS 120VSpektrum+ Gateway with Ethernet Port 11775 E. 45th Ave. Denver, CO 80239 Ph: 1-800-880-1180 Fax: 303-695-7633©2022 American Lighting, Inc. REV2248 www.AmericanLighting.com SAFETY INFORMATION • Read all instructions before beginning; Save these instructions for future use. • To reduce the risk of fire, electric shock, or injury to persons, pay close attention to this manual and stay within its guidelines when using this product. • If you are unsure about your wiring, consult a qualified electrician or local electrical inspector, and check your local electrical code. • There are no serviceable parts inside this gateway. Do not attempt to dismantle, open or service this gateway in any way. • The optimal operating temperature of this product is -10°C (14°F) to 55°C (131°F). • Thie gateway requires a 2.4Ghz WiFi or Ethernet signal to operate. • This gateway is not intended for use with a standard wall plate dimmer switch. Use only with Spektrum+ Smart Lighting App • This gateway is rated for dry/indoor locations only. Keep away from all water and moisture. These products may represent a possible shock or fire hazard if improperly installed or attached in any way. Products should be installed in accordance with these instructions, current electrical codes, and/or the current National Electric Code (NEC). The electrical rating of this product is 5V DC and utilizes a 120V AC power adapter. The installer must determine whether power supply is appro- priate before installation. Ensure power supply is turned off at the fuse box or circuit breaker prior to attempting installation or servicing of the gateway. WARNING WARNING INSTALLATION INSTRUCTIONS: This fixture requires a 120VDC power source. 1. Place gateway within 18” of power receptacle. 2. Plug mini USB power adapter into Gateway. See Figure 1. 3. Plug power adapter into receptacle. The blue power indicator light on the Gateway will light when powered. See Figure 2. 4. Use the Ethernet port if connecting to Ethernet router. 5. Pair device to Spektrum+ Smart Lighting app on your mobile phone or tablet. For pairing instructions please refer to the Spektrum+ Smart Lighting app guide or quick start guide. Resetting the fixture 1. To reset the gateway, press and hold the Reset Button for 5 seconds until the WIFI indicator light flashes. Indicator light status Red Light: WiFi Status 1. Long light indicates connected. 2.Blinking indicates pending connection. Blue light: 1. 2. Long off indicates activated. 3. Long light indicates inactive. Blinking indicates that the sub-device is allowed to access the network. FIGURE 1 FIGURE 2 Reset Button Ethernet Port WiFi Indicator MESH Inidicator FCC Caution: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCCs RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna. FCC ID: 2AIQ4-SPKPL-GTWY-E

Cover Letter(s)

Sincerely, Name/Title： Jennifer Barry/Product manager Company: American Lighting Inc. Address: 11775 E. 45th Ave Denver Colorado United States Phone: 800-880-1180 Fax: 303-695-7633 E-Mail: [email protected]

External Photos

Page1of4FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity ExternalPhotosoftheEUT Fig.1 Fig.2 Page2of4FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.3 Fig.4 Page3of4FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.5 Fig.6 Page4of4FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.7 Fig.8

ID Label/Location Info

Page1of1FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity LABELANDLOCATION (Size:L39.5mmx39.5mm)

Internal Photos

Page1of6FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity InternalPhotosoftheEUT Fig.1 Fig.2 2.4GWIFIAntenna0 2.4GWIFIAntenna1 Page2of6FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.3 Fig.4 Page3of6FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.5 Fig.6 Page4of6FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.7 Fig.8 ZigbeeANT Page5of6FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.9 Fig.10 Page6of6FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Fig.11

RF Exposure Info

Page1of7FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity MaximumPermissibleExposureReport 1.ProductInformation EUT:Spektrum+GatewaywithEthernetPort TestModel:SPKPL-GTWY-E PowerSupply: Input:5V1A ForACAdapterInput:100-240V~,50/60Hz,0.3AMax AdapterOutput:5V1000mA HardwareVersion:/ SoftwareVersion:/ WIFI(2.4GBand): FrequencyRange: 2412MHz~2462MHz ChannelNumber:11Channelsfor20MHzbandwidth(2412~2462MHz) 7Channelsfor40MHzbandwidth(2422~2452MHz) ChannelSpacing: 5MHz ModulationType:IEEE802.11b:DSSS(CCK,DQPSK,DBPSK) IEEE802.11g:OFDM(64QAM,16QAM,QPSK,BPSK) IEEE802.11n:OFDM(64QAM,16QAM,QPSK,BPSK) AntennaDescription:Antenna0:PFCAntenna,1.75dBi(Max.) Antenna1:PFCAntenna,1.75dBi(Max.) Zigbee FrequencyRange:2405MHz-2480MHz ChannelSpacing:5MHz ChannelNumber:16Channels ModulationType:O-QPSK AntennaDescription:PCBAntenna,1.11dBi(Max.) Extremetemp.Tolerance:-10°Cto+55°C Extremevol.Limits:4.5VDCto5.5VDC(nominal:5VDC) Exposurecategory : Generalpopulation/uncontrolledenvironment EUTType:ProductionUnit DeviceType:MobileDevice Page2of7FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 2.EvaluationMethod SystemsoperatingundertheprovisionsofFCC47CFRsectionshallbeoperatedinamannerthatensures thatthepublicisnotexposedtoradiofrequencyenergylevelinexcessoftheCommission’sguidelines. Inaccordancewith47CFRFCCPart2SubpartJ,section2.1091thisdevicehasbeendefinedasmobile devicewherebyadistanceof0.2mnormallycanbemaintainedbetweentheuserandthedevice,andbelow RFPermissibleExposurelimitshallcomplywith. InaccordancewithKDB447498D01forSimultaneoustransmissionMPEtestexclusionapplieswhenthe sumoftheMPEratiosforallsimultaneoustransmittingantennasincorporatedinahostdevice,basedonthe calculated/estimated,numericallymodelledormeasuredfieldstrengthsorpowerdensity,is≤1.0.TheMPE ratioofeachantennaisdeterminedattheminimumtestseparationdistancerequiredbytheoperating configurationsandexposureconditionsofthehostdevice,accordingtotheratiooffieldstrengthsorpower densitytoMPElimit,atthetestfrequency.Eitherthemaximumpeakorspatiallyaveragedresultsfrom measurementsornumericalsimulationsmaybeusedtodeterminetheMPEratios.Spatialaveragingdoes notapplywhenMPEisestimatedusingsimplecalculationsbasedonfar-fieldplane-waveequivalent conditions.Theantennainstallationandoperatingrequirementsforthehostdevicemustmeettheminimum testseparationdistancesrequiredbyallantennas,inbothstandaloneandsimultaneoustransmission operations,tosatisfycompliance. 3.Limit 3.1ReferEvaluationMethod ANSIC95.1–2019:IEEEStandardforSafetyLevelswithRespecttoHumanExposuretoElectric,Magnetic, andElectromagneticFields,0Hzto300GHz FCCKDBpublication447498D01General1RFExposureGuidancev06:MobileandPortableDevicesRF ExposureProceduresandEquipmentAuthorizationPolicies. FCCCFR47part11.1310:Radiofrequencyradiationexposurelimits. FCCCFR47part22.1091:Radiofrequencyradiationexposureevaluation:mobiledevices. Page3of7FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 3.2Limit LimitsforMaximumPermissibleExposure(MPE)/ControlledExposure Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm²) AveragingTime (minute) LimitsforOccupational/ControlledExposure 0.3–3.0 3.0–30 30–300 300–1500 1500–100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100)* (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 LimitsforMaximumPermissibleExposure(MPE)/UncontrolledExposure Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) PowerDensity (mW/cm²) AveragingTime (minute) LimitsforOccupational/UncontrolledExposure 0.3–3.0 3.0–30 30–300 300–1500 1500–100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100)* (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequencyinMHz *=Plane-waveequivalentpowerdensity 4.MPECalculationMethod PredicationofMPElimitatagivendistance Equationfrompage18ofOETBulletin65,Edition97-01 S=PG/4πR² Where:S=powerdensity P=powerinputtoantenna G=powergainoftheantennainthedirectionofinterestrelativetoanisotropicradiator R=distancetothecenterofradiationoftheantenna 5.AntennaInformation EUTcanonlyuseantennascertificatedasfollowsprovidedbymanufacturer; Antennatypeand antennanumber OperatefrequencybandMaximumantennagain Notes PFCAntenna2400MHz-2500MHz2.4GWIFI:1.75dBiAntenna0 PFCAntenna2400MHz-2500MHz2.4GWIFI:1.75dBiAntenna1 PCBAntenna2400MHz-2500MHzZigbee:1.11dBiAntenna2 Page4of7FCCID:2AIQ4-SPKPL-GTWY-E ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6.ConductedPower [2.4GWIFI] ModeChannel Frequency (MHz) Ant0 MaxConducted Power(dBm) Ant1 MaxConducted Power(dBm) 11B 1241214.7515.32 6243715.0915.12 11246214.8414.86 11G 1241213.2714.02 6243713.2213.38 11246212.9413.49 11N20SISO 1241213.2012.99 6243712.9512.84 11246213.8913.62 11N40SISO 3242211.8511.13 6243711.6611.03 9245211.4711.74 <Zigbee> ModeChannelFrequency(MHz)PeakConductedOutputPower(dBm) O-QPSK 02405-3.32 72440-3.53 152480-3.87 7.ManufacturingTolerance [2.4GWIFIAnt0] 11B(Peak) ChannelChannel1Channel6Channel11 Target(dBm)14.015.014.0 Tolerance±(dB)1.01.01.0 11G(Peak) ChannelChannel1Channel6Channel11 Target(dBm)13.013.012.0 Tolerance±(dB)1.01.01.0 11N20(Peak) ChannelChannel1Channel6Channel11 Target(dBm)13.012.013.0 Tolerance±(dB)1.01.01.…

Text truncated - open the document above for the full version.

Test Report

东莞地址：东莞市塘厦镇林村社区新太阳工业城79栋杭州地址：杭州市滨江区秋溢路500号乐通科技园3栋106室电话：0769-81777126 传真：0769-81777125 网址：www.ubuant.com 承认书 SPECIFICATIONFORAPPROVAL 产品名称 PRODUC 客户名称 CUSTOMER NAME: American Lighting Inc. TNAME: P/N 客户料号 2.4G FPCANT MODEL : 优比电子料号 UBP/N:UB01C55F3D2401AREV:A MANUFACTURER SIGNATURE CUSTOMER SIGNATURE CHECKEDBY: APPROVEDBY: DATE:2021/11/02 SPKPL-GTWY-E 东莞地址：东莞市塘厦镇林村社区新太阳工业城79栋杭州地址：杭州市滨江区秋溢路500号乐通科技园3栋106室电话：0769-81777126 传真：0769-81777125 网址：www.ubuant.com 1 ．规格表 : 产品主要技术参数主要技术指标 Maintechnicalspecifications 频率范围（MHZ） 2400~2500 FrequencyRange (MHZ) 2400~2500 特性阻抗(Ω) 50Impedance(Ω)50 增益(dBi) PeakGain(dBi1.75) 输出电压驻波 1.75 比 ≤1.92 VSWR ≤1.92 极化方式线极化PolarizationLine 连接方式同轴线 + 端子 ConnectorTypeRFCable+Terminal 物理性能PhysicalProperties 天线本体材料 FPCAntennaBaseFPC 工作温度 -20 °C ~+70 °C OperatingTemp-20 °C ~+70 °C 保存温度 -20°C~+70°CStorageTemp-20°C~+70°C 东莞地址：东莞市塘厦镇林村社区新太阳工业城79栋杭州地址：杭州市滨江区秋溢路500号乐通科技园3栋106室电话：0769-81777126 传真：0769-81777125 网址：www.ubuant.com 2.成品图：东莞地址：东莞市塘厦镇林村社区新太阳工业城79栋杭州地址：杭州市滨江区秋溢路500号乐通科技园3栋106室电话：0769-81777126 传真：0769-81777125 网址：www.ubuant.com 3.测试报告 3.1：网络分析仪测试报告Test Report 3.2：暗室2D、3DRaditationPattern Frequency/MH 3.2.1 效率及增益Gain zEfficiency/dBEfficiency/%Gain/dB 2400-2.0362.661.22 2410-1.9863.391.57 2420-2.0562.371.65 2430-2.0162.951.75 2440-1.9663.681.05 2450-2.0262.811.11 2460-1.8365.611.2 2470-1.5969.341.36 2480-1.4571.611.42 2490-1.4771.291.32 2500-1.8665.161.27 东莞地址：东莞市塘厦镇林村社区新太阳工业城79栋杭州地址：杭州市滨江区秋溢路500号乐通科技园3栋106室电话：0769-81777126 传真：0769-81777125 网址：www.ubuant.com 3.2.22D/3D场型图 Phi02D图 Phi902D图 Theta902D图东莞地址：东莞市塘厦镇林村社区新太阳工业城79栋杭州地址：杭州市滨江区秋溢路500号乐通科技园3栋106室电话：0769-81777126 传真：0769-81777125 网址：www.ubuant.com ANT3DRadiationwithMaxGain 2400MHz 2450MHz 2500MHz

Test Report

Page 1 Manufacturer: Tuya Model: Antenna Type ZS3 :PCB Writed: Long Wang Date:2020.10.11 Versions:A Hangzhou Tuya Information Technology Co.,Ltd Page 2 Test Setup Antenna Size Hangzhou Tuya Information Technology Co.,Ltd Page 3 2D Pattern Hangzhou Tuya Information Technology Co.,Ltd Phi 0 Phi 90 Theta 90 Page 4 Hangzhou Tuya Information Technology Co.,Ltd 3D Radiation Pattern 2400MHz 2450MHz 2500MHz Page 5 Frequency（MHz）Efficiency(%)Gain (dBi) 2400 49.430.82 2410 49.430.78 2420 48.420.78 2430 48.190.67 2440 49.320.91 2450 521.11 2460 49.550.99 2470 45.190.66 2480 41.110.2 2490 38.990.2 2500 40.830.49 Efficiency & Gain Hangzhou Tuya Information Technology Co.,Ltd

Test Report

Page1of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity AppendixA RFTestDatafor2.4GWIFI(ConductedMeasurement) ProductName:Spektrum+GatewaywithEthernetPort TestModel:SPKPL-GTWY-E EnvironmentalConditions Temperature: 23.8  C RelativeHumidity:52.1% ATMPressure:100.0kPa TestEngineer:NickPeng Supervisedby:LiHuan Page2of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.16dBBandwidth ConditionModeFrequency(MHz)Antenna6dBBandwidth(MHz)Limit6dBBandwidth(MHz)Verdict NVNTb2412Ant09.558>=0.5Pass NVNTb2437Ant09.631>=0.5Pass NVNTb2462Ant07.943>=0.5Pass NVNTg2412Ant016.432>=0.5Pass NVNTg2437Ant016.383>=0.5Pass NVNTg2462Ant016.441>=0.5Pass NVNTn202412Ant016.597>=0.5Pass NVNTn202437Ant017.07>=0.5Pass NVNTn202462Ant015.745>=0.5Pass NVNTn402422Ant035.386>=0.5Pass NVNTn402437Ant035.226>=0.5Pass NVNTn402452Ant035.453>=0.5Pass Page3of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs 6dBBandwidthNVNTb2412MHzAnt0 6dBBandwidthNVNTb2437MHzAnt0 Page4of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6dBBandwidthNVNTb2462MHzAnt0 6dBBandwidthNVNTg2412MHzAnt0 Page5of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6dBBandwidthNVNTg2437MHzAnt0 6dBBandwidthNVNTg2462MHzAnt0 Page6of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6dBBandwidthNVNTn202412MHzAnt0 6dBBandwidthNVNTn202437MHzAnt0 Page7of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6dBBandwidthNVNTn202462MHzAnt0 6dBBandwidthNVNTn402422MHzAnt0 Page8of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6dBBandwidthNVNTn402437MHzAnt0 6dBBandwidthNVNTn402452MHzAnt0 Page9of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity ConditionModeFrequency(MHz)Antenna6dBBandwidth(MHz)Limit6dBBandwidth(MHz)Verdict NVNTb2412Ant19.625>=0.5Pass NVNTb2437Ant19.559>=0.5Pass NVNTb2462Ant110.047>=0.5Pass NVNTg2412Ant116.399>=0.5Pass NVNTg2437Ant116.352>=0.5Pass NVNTg2462Ant116.361>=0.5Pass NVNTn202412Ant117.548>=0.5Pass NVNTn202437Ant116.873>=0.5Pass NVNTn202462Ant116.818>=0.5Pass NVNTn402422Ant135.7>=0.5Pass NVNTn402437Ant135.886>=0.5Pass NVNTn402452Ant135.254>=0.5Pass Page10of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs 6dBBandwidthNVNTb2412MHzAnt1 6dBBandwidthNVNTb2437MHzAnt1 Page11of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6dBBandwidthNVNTb2462MHzAnt1 6dBBandwidthNVNTg2412MHzAnt1 Page12of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6dBBandwidthNVNTg2437MHzAnt1 6dBBandwidthNVNTg2462MHzAnt1 Page13of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity 6dBBandwidthNVNTn202412MHzAnt1 6dBBandwidthNVNTn202437MHzAnt1 Page14of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabia…

Text truncated - open the document above for the full version.

Test Report

Page48of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity A.5ConductedRFSpuriousEmission ConditionModeFrequency(MHz)AntennaMaxValue(dBc)Limit(dBc)Verdict NVNTb2412Ant0-50.43-20Pass NVNTb2437Ant0-49-20Pass NVNTb2462Ant0-49.05-20Pass NVNTg2412Ant0-46.62-20Pass NVNTg2437Ant0-44.71-20Pass NVNTg2462Ant0-43.01-20Pass NVNTn202412Ant0-46.26-20Pass NVNTn202437Ant0-44.58-20Pass NVNTn202462Ant0-43.69-20Pass NVNTn402422Ant0-38.49-20Pass NVNTn402437Ant0-38.05-20Pass NVNTn402452Ant0-38.52-20Pass Page49of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs Tx.SpuriousNVNTb2412MHzAnt0Ref Tx.SpuriousNVNTb2412MHzAnt0Emission Page50of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTb2437MHzAnt0Ref Tx.SpuriousNVNTb2437MHzAnt0Emission Page51of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTb2462MHzAnt0Ref Tx.SpuriousNVNTb2462MHzAnt0Emission Page52of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTg2412MHzAnt0Ref Tx.SpuriousNVNTg2412MHzAnt0Emission Page53of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTg2437MHzAnt0Ref Tx.SpuriousNVNTg2437MHzAnt0Emission Page54of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTg2462MHzAnt0Ref Tx.SpuriousNVNTg2462MHzAnt0Emission Page55of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTn202412MHzAnt0Ref Tx.SpuriousNVNTn202412MHzAnt0Emission Page56of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTn202437MHzAnt0Ref Tx.SpuriousNVNTn202437MHzAnt0Emission Page57of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTn202462MHzAnt0Ref Tx.SpuriousNVNTn202462MHzAnt0Emission Page58of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTn402422MHzAnt0Ref Tx.SpuriousNVNTn402422MHzAnt0Emission Page59of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTn402437MHzAnt0Ref Tx.SpuriousNVNTn402437MHzAnt0Emission Page60of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity Tx.SpuriousNVNTn402452MHzAnt0Ref Tx.SpuriousNVNTn402452MHzAnt0Emission Page61of97FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EA ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity ConditionModeFrequency(MHz)AntennaMaxValue(dBc)Limit(dBc)Verdict NVNTb2412Ant1-49.71-20Pass NVNTb2437Ant1-50.44-20Pass NVNTb2462Ant1-48.89-20Pass NVNTg2412Ant1-45.58-20Pass NVNTg2437Ant1-44.27-20Pass NVNTg2462Ant1-43.46-20Pass NVNTn202412Ant1-43.99-20Pass NVNTn202437Ant1-45.69-20Pass NVNTn202462Ant1-45.23-20Pass NVNTn402…

Text truncated - open the document above for the full version.

Test Report

Page 1 of 23 FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EB ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity AppendixB RFTestDataforZigbee(ConductedMeasurement) ProductName:Spektrum+GatewaywithEthernetPortSmartHub TestModel:SPKPL-GTWY-E EnvironmentalConditions Temperature: 23.8  C RelativeHumidity:52.2% ATMPressure:100.0kPa TestEngineer:NickPeng Supervisedby:LiHuan Page 2 of 23 FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EB ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity B.1DTSBandwidth TestResult TestModeAntennaFrequency[MHz] DTSBW[MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict ZIGBAnt1 24051.6302404.1202405.7500.5PASS 24401.6302439.1102440.7400.5PASS 24801.6302479.1202480.7500.5PASS Page 3 of 23 FCCID:2AIQ4-SPKPL-GTWY-EReportNo.:LCSA103122145EB ShenzhenLCSComplianceTestingLaboratoryLtd. Add:101,201BldgA&301BldgC,JujiIndustrialParkYabianxueziwei,ShajingStreet,BaoanDistrict,Shenzhen, 518000,China Tel:+(86)0755-82591330|E-mail:[email protected]|Web:www.lcs-cert.com Scancodetocheckauthenticity TestGraphs ZIGB_Ant1_2405 ZIGB_Ant1_2440 ZIGB_Ant1_2480 Page 4 of 23 FCCID:2AIQ4-SPKPL-GTWY-ERepor…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jennifer Barry(Product manager)

[email protected]800-880-1180Fax: 303-695-7633

Test Firm

Shenzhen LCS Compliance Testing Laboratory Ltd.Gavin Liang

[email protected]0755-82591330Fax: 0755-82591132

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.41 GHz - 2.46 GHz	47.50 mW

Confidentiality

Long Term

Grant Notes

Output Power listed is peak conducted. This device supports 2*2 MIMO and supports 802.11b, 802.11g and 802.11n with a 20 MHz and 40 MHz bandwidth mode. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
