2AIV6-T740A4G LTE Terminal

01 For CE Manufacturer Information: Inrico Technologies Co.,Ltd. A1703, Shenzhen National Engineering Laboratory Building, No. 20 Gaoxin South 7th Road, Shenzhen, China Transmitter Frequency: EGSM 900: 880-915MHz DCS 1800: 1710-1785MHz WCDMA 2100(Band 1): 1920-1980MHz WCDMA 900(Band 8): 880-915MHz LTE Band 1: 1920-1980MHz LTE Band 3: 1710-1785MHz LTE Band 7: 2500-2570MHz LTE Band 8: 880-915MHz LTE Band 20: 832-862MHz LTE Band 28: 703-748MHz LTE Band 38: 2570-2620MHz LTE Band 40: 2300-2400MHz LTE Band 41: 2496-2690MHz BT: 2402-2480MHz BLE: 2402-2480MHz 2.4G Wi-Fi: 2412-2472MHz 5G Wi-Fi: 5150-5250MHz, 5250-5350MHz, 5470-5725MHz, 5725-5850MHz NFC: 13.56MHz Receiver Frequency: EGSM 900: 925-960MHz DCS 1800: 1805-1880MHz WCDMA 2100(Band 1): 2110-2170MHz WCDMA 900(Band 8): 925-960MHz LTE Band 1: 2110-2170MHz LTE Band 3: 1805-1880MHz LTE Band 7: 2620-2690MHz LTE Band 8: 925-960MHz LTE Band 20: 791-821MHz LTE Band 28: 758-803MHz LTE Band 38: 2570-2620MHz LTE Band 40: 2300-2400MHz LTE Band 41: 2496-2690MHz BT: 2402-2480MHz BLE: 2402-2480MHz 2.4G Wi-Fi: 2412-2472MHz 5G Wi-Fi: 5150-5250MHz, 5250-5350MHz, 5470-5725MHz, 5725-5850MHz GPS L1 C/A, BDS B1I, GLONASS G1, SBAS L1: 1559-1610 MHz NFC: 13.56MHz 02 RF-Output Power: EGSM 900: 31.85dBm(GMSK), 27.4dBm(8PSK) DCS1800: 28.43dBm(GMSK), 24.96dBm(8PSK) WCDMA 2100(Band 1): 21.43 dBm WCDMA 900(Band 8): 22.01 dBm LTE Band 1: 23.49dBm LTE Band 3: 23.41dBm LTE Band 7: 23.2dBm LTE Band 8: 23.51dBm LTE Band 20: 24dBm LTE Band 28: 23.61dBm LTE Band 38: 23.27dBm LTE Band 40: 23.61dBm LTE Band 41: 24.41dBm BT: 7.18 dBm BLE: 7.52 dBm 2.4G Wi-Fi: 16.50 dBm 5G Wi-Fi: 5150-5250MHz: 11.74dBm 5250-5350MHz: 10.77dBm 5470-5725MHz: 11.39dBm 5725-5850MHz: 10.57dBm NFC: 15.34dBuA/m @ 3m 03 For FCC&ISED Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with Innovation, Science, and Economic Development Canad licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d' Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil nedoit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. To control your exposure and ensure compliance with the occupational/controlled environment exposure limits always adhere to the following procedures. Guidelines: • Do not remove the RF Exposure Label from the device. • User awareness instructions should accompany device when transferred to other users. • Do not use this device if the operational requirements described herein are not met. Operating Instructions: • Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the Push-To-Talk (PTT) button. To receive calls, release the PTT button. Transmitting 50 % of the time, or less, is important because this radio generates measurable RF energy exposure only when transmitting (in terms of measuring for standards compliance). 04 • Hold the radio in a vertical position in front of face with the microphone (and the other parts of the radio, including the antenna) at least one inch (2.5 cm) away from the nose. Keeping the radio at the proper distance is important because RF exposures decrease with distance from the antenna. Antenna should be kept away from eyes. • When worn on the body, always place the radio in approved clip, holder, holster, case, or body harness for this product. Use of non-approved accessories may result in exposure levels, which exceed the occupational/controlled environment RF exposure limits. • Use only manufacturer’s name approved supplied or replacement antennas, batteries, and accessories. Use of non-manufacturer-name approved antennas, batteries, and accessories may exceed the FCC and IC RF exposure guidelines. • For a list approved accessories please consult your local dealer for information. Pour contrôler votre exposition et garantir le respect des limites d'exposition en milieu professionnel / contrôlé, respectez toujours les procédures suivantes. Des lignes directrices: • Ne retirez pas l'étiquette d'exposition RF de l'appareil. • Les instructions de sensibilisation de l'utilisateur doivent accompagner l'a…

Text truncated - open the document above for the full version.

www.inricosolutions.com Please read this instruction book carefully before using and keep this with care. T740A USER GUIDE 4G LTE Terminal Please read the following content carefully. It is very important for radio users to gain general knowledge and risks. ● Do not use the device or charging the battery in any hazardous areas such as gas, dust, steam, etc. ● Please turn off the device while refueling or parking at the gas station. ● Do not disassemble your radio. ● Avoid prolonged time in the sun or placing it near heating appliance. ● Avoid excessive exposure to the extreme dusty, damp and splashing place, or leave it on unstable surface. ● Reparation by professional technicians, do not disassemble by yourself. Notes Before Using Inrico reserves the right to modify product design and specifications. Inrico assumes no responsibility in the event of printing errors. All specifications are subject to change without notice. Disclaimer Unpacking and Device Checking................................ Accessories................................................................... Handling Precautions.................................................. Battery Care................................................................. Fully Charge Battery Before Initial Use.................... Properly Store Batteries........................................... Features of Lithium Battery ..................................... Clean and Maintenance............................................ Product Overview........................................................ Accessories Installation.............................................. Insert SIM Card ......................................................... Attaching the Battery................................................ Attaching Headset..................................................... Install Hand Strip....................................................... Basic Functions............................................................ Power On/Off............................................................. User Log-in................................................................. Initiate a Call.............................................................. Program..................................................................... Status Indicators.......................................................... Simple Troubleshooting.............................................. Specification................................................................ Contents 01 01 02 03 03 03 03 04 05 07 07 07 08 08 09 09 09 09 09 09 10 11 01 Unpacking and Device Checking Please unpack and take out the device and all accessories carefully, and ensure all lists have been gotten before discarding the cardboard box. If any items are lost or damaged in transit, please contact with our distributors. PoC Radio Lithium Battery Power Adaptor USB Charging Cable Belt Clip Antenna Desktop Charger Hand Strip QR Code Manual 1 1 1 1 1 1 1 1 1 ItemsNumber Accessories 02 Handling Precautions ● Do not overcharge the battery Please stop charging if it can’t be fully charged within required time. The battery probably overheats, smokes, bursts or suddenly be on fire due to abnormal charging process. When fully charged or not charged, please disconnect the charger and unplug it from the power outlet. ● Do not discard battery in a microwave or high pressure container. The battery probably overheats, smokes, bursts or suddenly be on fire. ● Do not expose damaged battery near any fire. If the battery is broken, leaking or has an abnormal odor, please remove it from flammable areas immediately. The fluid in the battery is flammable, which may cause smoke and fire. ● Do not use abnormal battery If the battery is with odd smelly, discolored, deformed, etc., please stop charging or disassemble from the device immediately. ● Please use authorized power adaptor To comply with warranty terms and avoid damages, charge the battery using a specified charger for best performance. 02 03 Battery Care Fully Charge Battery Before Initial Use ● Do preserve battery life by switching off a device and removing the batteries when it's not being used, and is not expected to be used for extended periods of time. ● Do practice proper battery storage by keeping batteries in a cool, dry place at normal room temperature. Properly Store Batteries ● Remove the battery from the device. ● Charge and discharge the battery to 40%-65% if it will not be used for 10 days or more. This can greatly extend the battery life. ● The battery should drop below 65% when it is idle for more than 10 days to prevent it from swelling. ● Store the battery in cool and dry environment that’s less than 25°C. Features of Lithium Battery ● Battery capacity will reduce after multiple charging cycles. ● The battery capacity drops gradually even without being used. ● Longer charging time is required in shady place. ● Charging and storing Lithium battery in warm condition will short its lifespan. Please do not leave them inside the vehicle or near the heater. ● If the battery working time has reduced significantly, please replace the battery immediately in avoidance of fluid leakage. 03 Clean and Maintenance ● Before cleaning and maintaining the device: please stop running, turn off the device, and disconnect all connections with other equipment. ● When you do not use the radio, please cover the accessories connector. ● When cleaning the dust, please use soft brush and neutral detergent (no strong corrosive chemicals) to wipe it. ● Please keep the equipment and accessories dry. ● Please do not use the microwave oven or hair dryer or other heating devices to dry them. 04 05 05 Product Overview F2 PTT SOS Return OK Up Down Knob1 Knob2 F3 Action PTT Push to talk Function Remark Short press Long press Long press Short press Long press Long press F2 Short press F3 Knob1 Knob2 SOS R-rotation L-rotation R-rotation L-rotation Enter private call mode En…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp.(Shenzhen) Report No.: 2501T17664E-SAA TR-EM-SA005 Page 1 of 2 Version 3.0 APPENDIX B EUT TEST POSITION PHOTOS Liquid depth ≥ 15cm Phantom: SAM-Twin V8.0 P1aP2a; Type: QD 000 P41 AA ; Serial: 1962 Bay Area Compliance Laboratories Corp.(Shenzhen) Report No.: 2501T17664E-SAA TR-EM-SA005 Page 2 of 2 Version 3.0 Face Up Setup Photo (25 mm) Body Back Setup Photo (0 mm)

Bay Area Compliance Laboratories Corp. (Shenzhen) EXHIBIT No.: 2501T17664E-RF-TSPC Page 1 / 4 TEST SETUP PHOTOGRAPHS Conducted Emissions - Front View Conducted Emissions - Side View Bay Area Compliance Laboratories Corp. (Shenzhen) EXHIBIT No.: 2501T17664E-RF-TSPC Page 2 / 4 Radiated Emissions View (Below 30MHz) Radiated Emissions View (Below 1 GHz) Bay Area Compliance Laboratories Corp. (Shenzhen) EXHIBIT No.: 2501T17664E-RF-TSPC Page 3 / 4 Radiated Emissions View (1-18 GHz) Radiated Emissions View (18-25 GHz) Bay Area Compliance Laboratories Corp. (Shenzhen) EXHIBIT No.: 2501T17664E-RF-TSPC Page 4 / 4 RF Conducted View *****END *****

Shenzhen Jinhong Wireless Technology Co., Ltd. Customers： Zhongruike Technology Co., Ltd. Project name：P2A RF eng ineer：JiangYa Report edition：2025-5-26 3rd Floor, Building B, Weiyehuaxin 18 Industrial Park, Xixiang Sub-district, Bao'an District, Shenzhen City Antenna gain Band Mode Frequency Antenna Max Gain GSM Band Band-5 GSM 850 824-894 -1.44 dBi Band-8 GSM 900 880-960 -0.98 Band-3 DCS 1800 1710-1880 0.23 Band-2 PCS 1900 1850-1990 0.22 WCDMA Band Band-1 2100 1920-2170 -0.64 dBi Band-2 1900 1850-1990 0.22 Band-4 1700 1710-2155 0.18 Band-5 850 824-894 -1.44 Band-8 900 880-960 -0.98 LTE Band Ban d-1 2100 FDD 1920-2170 -0.64 dBi Band-2 1900 FDD 1850-1990 0.22 Band-3 1800 FDD 1710-1880 0.23 Band-4 1700 FDD 1710-2155 0.18 Band-5 800 FDD 824-894 -1.44 Band-7 2600 FDD 2500-2690 2.04 Band-8 900 FDD 880-960 -0.98 Band-12 700 FDD 699-746 -3.45 Band-13 700 FDD 746-787 -3.18 Band-14 700 FDD 758-798 -3.08 Band-17 700 FDD 704-746 -3.45 Band-20 800 FDD 832-821 -2.21 Band-26 800 FDD 814-894 -1.44 Band-28 700 FDD 703-803 -2.26 Band-66 1700 FDD 1710-2200 0.24 Band-38 2570 TDD 2570-2620 2.13 Band-39 1880 TDD 1880-1920 0.24 Band-40 2300 TDD 2300-2400 0.37 Band-41 2500 TDD 2496-2690 2.13 Wi-Fi 802. 11b/g/n 2.4GHz 2400-2483.5 0.58 dBi 802. 11a/n/ac 5GHz 5150-5850 0.27 dBi BT&BLE Bluetooth 2400-2483.5 0.58 dBi GNSS GPS L1 C/A, BDS B1I, GLONASS G1, SBAS L1 1559-1610 / / NFC 13.56 / / Lobe diagram(Red represents X, green represents Y, and dark blue represents Z) Main Antenna Aux Antenna BT/BLE/Wi-Fi Device Test scenario Antenna size diagram Antenna size diagram Antenna size diagram Antenna size diagram Antenna size diagram Size:18*18*6.5mm

Note: The information marked # is provided by the applicant, the laboratory is not responsible for its authenticity and this information can affect the validity of the result in the test report. Customer model name, addresses, names, trademarks etc. are included. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP or any agency of the U.S. Government. This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “▼”. Bay Area Compliance Laboratories Corp. (Shenzhen) 5F(B-West) , 6F, 7F, the 3rd Phase of Wan Li Industrial Building D, Shihua Rd, FuTian Free Trade Zone, Shenzhen, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn TR-EM-RF012 Page 1 of 103 Version 4.1 TEST REPORT Applicant Name:Inrico Technologies Co.,Ltd Address:A1703, Shenzhen National Engineering Laboratory Building, No. 20 Gaoxin South 7th Road, Shenzhen, China Report Number:2501T17664E-RFC FCC ID:2AIV6-T740A IC:26136-T740A Test Standard (s) FCC PART 15.247; RSS-GEN ISSUE 5, FEBRUARY 2021 AMENDMENT 2; RSS-247 ISSUE 3, AUGUST 2023 Sample Description Product Type:4G LTE Terminal Model No.:T740A Multiple Model(s) No.:N/A Trade Mark:Inrico Date Received:2025-05-21 Issue Date:2025-09-25 Test Result:Pass ▲ ▲ In the configuration tested, the EUT complied with the standards above. Prepared and Checked By:Approved By: Jim ChengNancy Wang RF EngineerRF Supervisor Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: 2501T17664E-RFC TR-EM-RF012 Page 2 of 103 Version 4.1 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ..........................................................................................................................3 GENERAL INFORMATION ........................................................................................................................................4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)......................................................................................4 OBJECTIVE ....................................................................................................................................................................4 TEST METHODOLOGY....................................................................................................................................................4 MEASUREMENT UNCERTAINTY .....................................................................................................................................5 TEST FACILITY ..............................................................................................................................................................5 SYSTEM TEST CONFIGURATION ...........................................................................................................................6 SUMMARY OF TEST RESULTS ................................................................................................................................9 TEST EQUIPMENT LIST ..........................................................................................................................................10 REQUIREMENTS AND TEST PROCEDURES ......................................................................................................12 AC LINE CONDUCTED EMISSIONS...............................................................................................................................12 SPURIOUS EMISSIONS ..................................................................................................................................................15 99% OCCUPIED BANDWIDTH & 6 DB EMISSION BANDWIDTH ....................................................................................19 MAXIMUM CONDUCTED OUTPUT POWER ...................................................................................................................22 POWER SPECTRAL DENSITY ........................................................................................................................................23 100 KHZ BANDWIDTH OF FREQUENCY BAND EDGE....................................................................................................24 CONDUCTED SPURIOUS EMISSION...............................................................................................................................25 DUTY CYCLE ...............................................................................................................................................................26 ANTENNA REQUIREMENT .....................................................................................................................................27 TEST DATA AND RESULTS .....................................................................................................................................29 AC LINE CONDUCTED EMISSIONS...............................................................................................................................29 SPURIOUS EMISSIONS ..................................................................................................................................................32 6DB EMISSION BANDWIDTH........................................................................................................................................79 99% OCCUPIED BANDWIDTH ......................................................................................................................................83 MAXIMUM CONDUCTED OUTPUT POWER ..................................................................................................…
