2AIZN-X683Mobile Phone

INFINIX MOBILITY LIMITED

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Jul 20, 2020
Application Purpose: Original Equipment
Date of Application: Jul 20, 2020
Equipment Note: Mobile Phone
Frequency Range: 2545.00000000 - 2645.00000000
Company: INFINIX MOBILITY LIMITED
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Infinix X683 User Manual (H) 1 E E x x p p l l o o s s i i o o n n d d i i a a g g r r a a m m s s p p e e c c i i f f i i c c a a t t i i o o n n 1 FL(CTP+LCM) 6.78HD+h 2 REC Deco partasm X682 Black 3 F hsg asm X682 Black 4 F CAM frame asm 5 PCBA MB 6 CAM AF 16M S5K3P9SX 7 Distance Sensor rubber 8 Shield Seal Cop foil X682 PA 9 Waterproof label paper 3mm RoHS 10 CAM FF 8M 11 R CAM Con foams microspur 12 REC con foam 13 TOP seal mylar 14 machine screw M1.4* L3.5*D2.5*H0.5 black 15 card holder asm X682 16 F CAM Con Sealrubber 17 UP frame X682 18 R CAM rubber X682 2M 2 microspur Black 19 R CAM rubber X682 2M Grey 20 R CAM lens X682 21 MAIN CAM radiating Cop foil 22 F CAM con fb 23 REC_1206W_H20 9.4*3.5*0.75 black 24 FPC REC X682 25 Shield graphite film 26 Bat cover asm 27 CAM_FF_2M_OV2685 28 CAM_FF_2M_GC02M1B 29 CAM_FF_8W 30 Shield Seal Cop foil X682 BB 31 FPC Side key 32 V ignette R CAM Con Sealrubber 33 FM(SW9008) 34 R CAM Con foams 8W 35 BAT con imp steelAds 36 BAT con imp steel asm 37 R CAM rubber X682 8W Black 38 FP support PC slice 39 FP support PC slice 40 LCM FPCcon rubber 41 Shield Seal Cop foil X682 RF 42 Speaker 43 PCBA SUB 44 Vibrate 45 Fragile label paper 2.5mm general 46 coaxial cable 47 mc screw M1.4*L2.5* D2.5*H0.5 silver glue 48 SPK frame asm 49 Battery 50 MAIN FPC con rubber 3 Know your phone 1. Front camera 2. Volume + key 3. Volume - key 4. Power key ① 4 SIM/SD card installation 1. Power off mobile. 2. Refer to the following picture for SIM / SD card installation. 5 Charging the phone You can charge your device using a charger or by connecting it to the computer using a USB cable (comes with the phone). 1. Please remind the front and back of the plug. 2. Use only INFINIX charger and cables. Other chargers or cables may damage the device. This will invalidate your phone warranty. 6 FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that 7 interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. SAR Information Statement Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy 8 for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it 9 does not exceed the limit established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is1.003W/Kgand when worn on the body, as described in this user guide, is0.582W/Kg(Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). The maximum scaled SAR in hotspot mode is 0.582W/Kg. While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RFexposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/ oet/fccid after searching on 10 FCC ID:2AIZN-X683 Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Asso-ciation (CTIA) web-site at http://…

Text truncated - open the document above for the full version.

Cover Letter(s)

INFINIX MOBILITY LIMITED DATE :2020-07-07 Equipment Autorisation Division Federal Communications Commission 7345 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AIZN-X683 Product Name: Mobile Phone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics Block diagram Operation description and Tune up BOM These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 2020-07-07 By: Yiting Luo Signature Printed Title: manager On behalf of : INFINIX MOBILITY LIMITED Telephone: +86 0755-61803856

Cover Letter(s)

INFINIX MOBILITY LIMITED Date: 2020-07- 07 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, Dated this 2020-07-07 By: Yiting Luo Signature Printed Title: manager On behalf of : INFINIX MOBILITY LIMITED Telephone: +86 0755-61803856

Cover Letter(s)

INFINIX MOBILITY LIMITED DATE:2020-07-07 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appoint Shenzhen Zhongjian Nanfang Testing Co.,Ltd.; 1st Floor, Block No.B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China；Bruce.Zhang, to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko Canada Inc, still resides with INFINIX MOBILITY LIMITED/ ROOM 604 6/F SOUTH TOWER WORLD FINANCE CTR HARBOUR CITY 17 CANTON ROAD TST KL Hong Kong Dated this 2020-07-07 By: Yiting Luo Signature Printed Title: manager On behalf of : INFINIX MOBILITY LIMITED Telephone: +86 0755-61803856

Cover Letter(s)

INFINIX MOBILITY LIMITED DATE :2020-07-07 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AIZN-X683 Product Name: Mobile Phone Request for Short-Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission rules, and in accordance with the FCC Public notice dated June 15, 2004 (DA 04-1705), we hereby request short-term confidentiality for the following items prior to marketing the device.:  Test Setup Photos  External Photos  Internal Photos  User Manual The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. <Signature> Name Yiting Luo Title manager Company INFINIX MOBILITY LIMITED

External Photos

ID Label/Location Info

36*30MM label location label location

Internal Photos

Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 54 of 63 Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 55 of 63 Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 56 of 63 Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 57 of 63 Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 58 of 63 Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 59 of 63 Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 60 of 63 Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 61 of 63 Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 62 of 63 Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 63 of 63 ------End of report------

RF Exposure Info

Shenzhen Zhongjian Nanfang Testing Co.,Ltd. Report No: CCISE200605501 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1 Cover Page FCC SAR REPORT Applicant: INFINIX MOBILITY LIMITED Address of Applicant: ROOM 604 6/F SOUTH TOWER WORLD FINANCE CTR HARBOUR CITY 17 CANTON ROAD TST KL Hong Kong Equipment Under Test (EUT) Product Name: Mobile Phone Model No.: X683 Trade mark Infinix FCC ID: 2AIZN-X683 Applicable standards: FCC 47 CFR Part 2.1093 Date of Test: 03 Jul., 2020 ~ 16 Jul., 2020 Test Result: Maximum Reported1-g SAR (W/kg) Head: 1.003 Body: 0.582 Hotspot: 0.582 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 2 of 232 2 Version Version No. Date Description 00 17 Jul., 2020 Original Tested by: Date: 17 Jul., 2020 Report Clerk Reviewed by: Date: 17 Jul., 2020 Project Engineer Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 3 of 232 3 Contents 1 COVER PAGE ....................................................................................................................................................... 1 2 VERSION ............................................................................................................................................................... 2 3 CONTENTS ........................................................................................................................................................... 3 4 SAR RESULTS SUMMARY ................................................................................................................................. 5 5 GENERAL INFORMATION .................................................................................................................................. 7 5.1 CLIENT INFORMATION ..................................................................................................................................................................... 7 5.2 GENERAL DESCRIPTION OF EUT ................................................................................................................................................... 7 5.3 MAXIMUM RF OUTPUT POWER ...................................................................................................................................................... 9 5.4 ENVIRONMENT OF TEST SITE ....................................................................................................................................................... 10 5.5 TEST LOCATION ........................................................................................................................................................................... 10 6 INTRODUCTION ................................................................................................................................................. 11 6.1 INTRODUCTION ............................................................................................................................................................................. 11 6.2 SAR DEFINITION .......................................................................................................................................................................... 11 7 RF EXPOSURE LIMITS ..................................................................................................................................... 12 7.1 UNCONTROLLED ENVIRONMENT ................................................................................................................................................... 12 7.2 CONTROLLED ENVIRONMENT ....................................................................................................................................................... 12 7.3 RF EXPOSURE LIMITS .................................................................................................................................................................. 12 8 SAR MEASUREMENT SYSTEM ....................................................................................................................... 13 8.1 E-FIELD PROBE............................................................................................................................................................................ 14 8.2 DATA ACQUISITION ELECTRONICS (DAE) .................................................................................................................................... 14 8.3 ROBOT ..............................................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 151 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 152 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 153 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 154 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 155 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 156 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 157 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 158 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 159 of 232 Calibration information for Dipole Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 160 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 161 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 162 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 163 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 164 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 165 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 166 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 167 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 168 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366, E-mail:[email protected] Page 169 of 232 Report No: CCISE200605501 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006055 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an D…

Text truncated - open the document above for the full version.

Test Report

Shenzhen Zhongjian Nanfang Testing Co., Ltd. Report No: CCISE200605401 Authorized Signature: Bruce Zhang Laboratory Manager This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days only. 1. Cover Page FCC REPORT (GSM & WCDMA) Applicant: INFINIX MOBILITY LIMITED Address of Applicant: ROOM 604 6/F SOUTH TOWER WORLD FINANCE CTR HARBOUR CITY 17 CANTON ROAD TST KL Hong Kong Equipment Under Test (EUT) Product Name: Mobile Phone Model No.: X683 Trade mark: Infinix FCC ID: 2AIZN-X683 Applicable standards: FCC CFR Title 47 Part 2 FCC CFR Title 47 Part 22 Subpart H FCC CFR Title 47 Part 24 Subpart E FCC CFR Title 47 Part 27 Subpart L Date of sample receipt: 16 Jun., 2020 Date of Test: 17 Jun., to 04 Jul., 2020 Date of report issued: 09 Jul., 2020 Test Result: PASS* * In the configuration tested, the EUT complied with the standards specified above. Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 2 of 63 2. Version Version No. Date Description 00 09 Jul., 2020 Original Tested by: Date: 09 Jul., 2020 Test Engineer Reviewed by: Date: 09 Jul., 2020 Project Engineer Report No: CCISE200605401 Shenzhen Zhongjian Nanfang Testing Co., Ltd. Project No.: CCISE2006054 No.110~116, Building B, Jinyuan Business Building, Xixiang Road, Bao’an District, Shenzhen, Guangdong, China Tel: +86-755-23118282, Fax: +86-755-23116366 Page 3 of 63 3. Contents Page 1. COVER PAGE .............................................................................................................................................................. 1 2. VERSION ....................................................................................................................................................................... 2 3. CONTENTS ................................................................................................................................................................... 3 4. TEST SUMMARY ......................................................................................................................................................... 4 5. GENERAL INFORMATION ........................................................................................................................................ 5 5.1 CLIENT INFORMATION ............................................................................................................................................ 5 5.2 GENERAL DESCRIPTION OF E.U.T. ....................................................................................................................... 5 5.3 TEST MODES .......................................................................................................................................................... 7 5.4 DESCRIPTION OF SUPPORT UNITS .....................................................................................................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jerry Liu

[email protected]+86-0755-61803856Fax: 755-33979211

Test Firm

JianYan Testing Group Shenzhen Co., Ltd.Bruce Zhang

[email protected]+86 (0) 755 23118282

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
17	27	2.54 GHz - 2.65 GHz	179.90 mW	18M0W7D	0.06 ppm

Confidentiality

Long Term

Grant Notes

Output power listed is ERP for Part 22, EIRP for Part 24 and Part 27. SAR compliance for body-worn operating conditions is restricted to belt clips, holsters or similar accessories that have no metallic component in the assembly and must provide a minimum separation distance of 1 cm between the device and the body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (wireless router), and simultaneous transmission exposure conditions are 1.00 W/kg, 0.45 W/kg, 0.53 W/kg, and 1.38 W/kg, respectively. This device contains functions that are not operational in the U.S. Territories. This filing is only applicable for U.S. operations.
