2AIZN-X688BMobile Phone

Infinix X688B User Manual (H) 1 E E x x p p l l o o s s i i o o n n d d i i a a g g r r a a m m s s p p e e c c i i f f i i c c a a t t i i o o n n 1 FL(CTP+LCM 2 fornt housing Assembly 3 PCBA Main 4 Front Camera 5 Back Camera 6 Back Camera 7 REC Deco part 8 F CAM Cop foil 9 LT sensor diffuse film 10 M1.4xL3.5 SCREW 11 REC con fb 12 LT sensor Seal rubber 13 Fornt CAM rubber 14 M1.4xL2.5 SCREW 15 SPK 16 UP frame asm 17 Bat cover asm 18 MAIN seal mylar 19 Rear CAM Lens 20 Fingerchip spacer 21 Shield Imp foam 22 Bat con rubber 23 LCM FPC con rubber 24 FP con imp steel asm 25 trope fill foam 26 R trope foam B 27 FPC Side key 28 PCBA SUB 29 Moto 30 Battery 31 USB Seal rubber 32 Audio Jack Seal rubber 33 SUB PCB BTB Rubber 34 coaxial cable 35 SPK frame asm 36 3in1 card holder 37 R CAM Con foams 38 Audio cavity seal mylar 39 Shield Seal Cop foil 40 FP Con Foams 41 FP support foam 42 2 Know your phone 1. Front camera 2. Volume + key 3. Volume - key 4. Power key ① 3 SIM/SD card installation 1. Power off mobile. 2. Refer to the following picture for SIM / SD card installation. 4 Charging the phone You can charge your device using a charger or by connecting it to the computer using a USB cable (comes with the phone). 1. Please remind the front and back of the plug. 2. Use only INFINIX charger and cables. Other chargers or cables may damage the device. This will invalidate your phone warranty. 5 FCC Statement 1.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2.Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver.` Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. SAR Information Statement Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to 6 radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output. Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is 1.403W/Kg and when worn on the body, as described in this user guide, is 0.773W/Kg(Body-worn measurements differ among phone models, depending upon available accessories and FCC requirements). The maximum scaled SAR in hotspot mode is 0.773W/Kg. While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RFexposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/ oet/fccid after searching on FCC ID: 2AIZN-X688B Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Asso-ciation (CTIA) web-site at http://www.wow-com.com. * In the 7 United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a sub-stantial margin of safety to give additional protection for the public and to account for any variations in measurements. Body-worn Operation This device was tested for typical body-worn operations. To comply with RF exposure requir…

Text truncated - open the document above for the full version.
