2AJ6BBHTV16D001TactSuit X16

Wearable Haptic Vest User Manual & Warranty www.bhaptics.com © 2023 bHaptics Inc. All rights Reserved. X40X16 Before Getting Started Be sure to read the user manual before using the product to ensure safe and proper use of the product. • Please read carefully the bHaptics Limited Warranty before using the product. • Do not use the product for any purpose other than the intended purpose. • Do not attempt to modify, disassemble or repair the product. • Do not drop the product or subject the product to other forms of strong impacts. • Users with sensitive skin should avoid wearing the product directly on the skin. • Do not excessively pull on the side straps while wearing the product, as it may irritate your body. • This product is not waterproof. Store the product in a dry place free from humidity and moisture. • The main body of the product contains electronic components and must not be washed in water under any circumstances. Should the product need to be cleaned, gently wipe it with a soft cloth. The mesh lining may be removed, and machine washed with neutral detergent. (Do not use strong chemicals or strong detergents.) • The latest user manual for the device and related software can be found at https://www. bhaptics.com/support/downloads. Table of Contents 01 Overview General Information 4 What’s in the Box 5 Part Names 6 LED Indicator 8 02 Getting Started Product Charging 9 Power On / Off 10 Product Fitting 11 Enjoy 12 03 How to Play PC VR 14 Standalone VR 18 PC Game 20 Music / Movie 20 Console 21 04 bHaptics Software bHaptics Player (PC) 23 bHaptics Player (Mobile) 26 bHaptics Studio 29 bHaptics Designer 31 05 Appendix Product Specifications 32 Support 34 Health & Safety Warnings 36 Cautions 42 Limited Customer Warranty 50 4 Overview Introducing the TactSuit X40, a wireless haptic vest that packs 40 individually controllable vibro- tactile motors. Stay immersed in your content with positional haptic feedback delivered to every corner of your body. TactSuit is compatible with a wide range of platforms, including PC, VR, Mobile, and console. TactSuit X16 is designed to be a strong, yet lightweight haptic vest that you can wear for hours. The short and breathable design makes long sit-down gaming sessions much more enjoyable. TactSuit X16 packs the same vibro-tactile motors used in the TactSuit X40, giving you the same powerful haptic feedback. General Information Overview 01 Overview 5 Basic Components TactSuit X40 or TactSuit X16 Mesh Lining* *Mesh Lining is attached to the device. Bluetooth DongleUSB Type C Charging CableUser Manual & Warranty Additional Components (purchased separately) Additional Components can be purchased from bHaptics online shop. Y JackAudio CableAdditional Mesh Lining What’s in the Box bhaptics.com/shop 6 Overview Part Names Hanger Loop Shoulder Snap Buttons Haptic Motor * 40 Mesh Lining Detachable Logo Zipper Main Controller Audio Port Power Button & LED Indicator Audio Cable Holder Side Straps * 4 Elastic Loop Strap Adjuster Charging Port This product uses 3.63V, 9,800mAh, and 35.574Wh battery and charges to 5V (maximum 2A). [FR] Ce produit utilise une batterie de 3,63V, 9800mAh et 35,574Wh et se charge à 5V (maximum 2A). Overview 7 Part Names Hanger Loop Shoulder Snap Buttons Haptic Motor * 16 Mesh Lining Detachable Logo Zipper Main Controller Audio Port Power Button & LED Indicator Charging Port Audio Cable Holder Side Straps * 4 Elastic Loop Strap Adjuster This product uses 3.63V, 4,900mAh, and 17.787Wh battery and charges to 5V (maximum 2A). [FR] Ce produit utilise une batterie de 3,63V, 4900mAh et 35,574Wh et se charge à 5V (maximum 2A). 8 Overview Blue Purple Mint Red/Green Yellow BluetoothWiredButton LockBattery StatusDevice Management LED StateIndication Yellow ActivatedPower On Blue BlinkingBluetooth Pairing Blue SolidBluetooth Paired Purple SolidAudio Cable In Purple & Blue BlinkingAudio Cable In & Bluetooth Pairing Purple & Blue SolidAudio Cable In & Bluetooth Paired Mint SolidPower Button Lock Red SolidLow Battery or Charging Green SolidFully Charged Yellow RotatingUpdating Firmware LED Indicator Getting Started 9 Getting Started 02 Product Charging TactSuit is shipped in Sleep Mode for safety during transportation. Before using your TactSuit for the first time, plug it into a charger to bring it out of sleep mode and fully charge the device. You can use 2A charging cable included in the package to charge the device. It takes about 5 hours, TactSuit X40, and 2.5 hours, TactSuit X16, to fully charge the device using 2A charging current. LED Indication for each battery status Green Solid Fully ChargedChargingLow Battery 0~33%34~66%67~99% Red SolidRed Solid Be sure to use an authorized AC adapter and included charging cable to charge the product. Use of an unauthorized device or accessory may result in personnel injury, may cause damage of the product or your property, and may void your warranty. [FR] Assurez-vous d'utiliser un adaptateur secteur agréé et le câble de charge inclus pour charger le produit. L'utilisation d'un appareil ou d'un accessoire non autorisé peut entraîner des blessures corporelles, endommager le produit ou votre propriété et annuler votre garantie. If the product is left unattended for a long time while the battery is discharged, the LED may not light even if the charging cable is connected. In this case, the light turns on again after charging for more than 1 hour. [FR] Si le produit est laissé sans surveillance pendant une longue période alors que la batterie est déchargée, la LED peut ne pas s'allumer même si le câble de charge est connecté. Dans ce cas, le voyant se rallume après une charge supérieure à 1 heure. 10 Getting Started Power On / Off Power on PushLights will turn on in 3 stages Ready to be Paired when Blinking Blue If the Power does not turn on, check if it is released from the sleep mode and sufficiently charged. [FR] Si l'alimentation ne s'allume pas, vérifiez s'il est sorti du mode veille et suffisamment c…

Text truncated - open the document above for the full version.

Attestation Statement Letter I Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: __________________ Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC Application for FCC ID: _______________________________ ________________________ certifies that the equipment for which authorization is sought is not “covered” equipment prohibited for receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Applicant’s Signature: Applicant’s Name:

Attestation Statement Letter II Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: __________________ Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC Application for FCC ID: _______________________________ _________________________ certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Applicant’s Signature: Applicant’s Name:

Date: 04/17/2018 VCB_F-01: Operating Procedures Form – FCC Confidentiality v03 Page 1 of 1 bHaptics Inc. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AJ6BBHTV16D001 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Type of Confidentiality Requested Exhibit Type ☐Short Term ☒Permanent Block Diagrams ☒Short Term External Photos ☒Short Term ☐Permanent* Internal Photos ☐Short Term ☒Permanent Operation Description ☐Short Term ☒Permanent Parts List/BOM ☐ Short Term ☒Permanent Schematics ☒Short Term Test Setup Photos ☒Short Term ☐Permanent* User manual *Requires further justification before permanent confidentiality will be allowed. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below for an initial period of 180 days. Sincerely, Client’s signature: Client’s name & title : Kiuk Gwak / CEO Contact information / address: 82-31-427-6034 / 82 -42-867-2468/ Bldg 3 Unit 503 , 70, Yuseong-daero 1689beon-gil,Yuseong-gu, Daejeon, Republic of Korea

Date: 04/17/2018 VCB_F-01: Operating Procedures Form – FCC Authorization v02 Page 1 of 1 Date: 2023-06-30 SUBJECT: FCC Application for (FCC ID: 2AJ6BBHTV16D001) To Whom It May Concern: We, the undersigned, hereby authorize David Zhang in Vista Laboratories, Inc. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Vista Laboratories, Inc. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, (Must be signed by the person that is listed on the FCC Website) Client’s signature: Client’s name & title: Kiuk Gwak/ CEO Contact information / address: 82-42-867-2468/ Bldg 3 Unit 503 , 70, Yuseong- daero 1689beon-gil,Yuseong-gu, Daejeon, Republic of Korea bHaptics Inc. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046

FCC ID: 2AJ6BBHTV16D001 Page 1 of 4 Upper Lower FCC ID: 2AJ6BBHTV16D001 Page 2 of 4 Side 1 Side 2 FCC ID: 2AJ6BBHTV16D001 Page 3 of 4 Side 3 Side 4 FCC ID: 2AJ6BBHTV16D001 Page 4 of 4 Side 5 Ant

FCC ID : 2AJ6BBHTV16D001 Copyright Ⓒ 2023, KRL Co., Ltd. SA MPLE LABEL & LOCATION bHaptics Inc. M/N: BHTV16D001 FCC ID : 2AJ6BBHTV16D001

FCC ID: 2AJ6BBHTV16D001 Page 1 of 2 Main Board Front Main Board Rear FCC ID: 2AJ6BBHTV16D001 Page 2 of 2 Sub Board Front Sub Board Rear

KES Co., Ltd. 3701, 40, Simin-daero 365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14057, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Report No.: KES-RF-23T0096 Page ( 1 ) of ( 39 ) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The results shown in this test report refer only to the sample(s) tested unless otherwise stated. The authenticity of the test report, contact [email protected] KES-QP16-F01(00-23-01-01) TEST REPORT Part 15.247 & RSS-247 (Issue 2) Equipment under test TactSuit X16 Model name BHTV16D001 FCC ID 2AJ6BBHTV16D001 IC 24747-BHTV16D001 Applicant bHaptics Inc. Manufacturer bHaptics Inc. Date of test(s) 2023.06.29 ~ 2023.06.30 Date of issue 2023.06.30 Issued to bHaptics Inc. Bldg 3 Unit 503, 70, Yuseong-daero 1689boen-gil, Yuseong-gu, Daejeon, South Korea Tel: +82-42-867-2468 / Fax : +82-42-867-2467 Issued by KES Co., Ltd. 3701, 40, Simin-daero 365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14057, Korea 473-21, Gayeo-ro, Yeoju-si, Gyeonggi-do, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 Test and report completed by : Report approval by : Bong-Seok, Kim Test engineer Yeong-Jun, Cho Technical manager This test report is not related to KS Q ISO/IEC 17025 and KOLAS KES Co., Ltd. 3701, 40, Simin-daero 365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14057, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Report No.: KES-RF-23T0096 Page ( 2 ) of ( 39 ) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The results shown in this test report refer only to the sample(s) tested unless otherwise stated. The authenticity of the test report, contact [email protected] KES-QP16-F01(00-23-01-01) Revision history Revision Date of issue Test report No. Description - 2023.06.30 KES-RF-23T0096 Initial KES Co., Ltd. 3701, 40, Simin-daero 365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14057, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Report No.: KES-RF-23T0096 Page ( 3 ) of ( 39 ) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The results shown in this test report refer only to the sample(s) tested unless otherwise stated. The authenticity of the test report, contact [email protected] KES-QP16-F01(00-23-01-01) TABLE OF CONTENTS 1. General information ................................................................................................................................................... 4 1.1. EUT description ........................................................................................................................................ 4 1.2. Test configuration ...................................................................................................................................... 4 1.3. Information about derivative model .......................................................................................................... 5 1.4. Accessory information............................................................................................................................... 5 1.5. Sample calculation .................................................................................................................................... 5 1.6. Measurement Uncertainty ......................................................................................................................... 5 1.7. Frequency/channel operations ................................................................................................................... 6 2. Summary of tests ........................................................................................................................................................ 7 3. Test results .................................................................................................................................................................. 8 3.1. 99% Occupied Bandwidth ......................................................................................................................... 8 3.2. 6 ㏈ bandwidth ...................................................................................................................................... 10 3.3. Output power ........................................................................................................................................... 12 3.4. Power spectral density ............................................................................................................................. 14 3.5. Radiated restricted band and emissions ................................................................................................... 16 3.6. Conducted spurious emissions & band edge ........................................................................................... 31 3.7. AC conducted emissions ......................................................................................................................... 35 Appendix A. Measurement equipment ......................................................................................................................... 38 Appendix B. Test setup photos ..................................................................................................................................... 39 KES Co., Ltd. 3701, 40, Simin-daero 365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14057, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Report No.: KES-RF-23T0096 Page ( 4 ) of ( 39 ) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The results shown in this test report refer only to the sample(s) tested unless otherwise stated. The authenticity of the test report, contact [email protected] KES-QP16-F01(00-23-01-01) 1. General information Applicant: bHaptics Inc. Applicant address: Bldg 3 Unit 503, 70, Yuseong-daero 1689boen-gil, Yuseong-gu, Daejeon, South …

Text truncated - open the document above for the full version.

AEC-Q200 Qualification Available 2.4GHz Chip Antenna, SMD Detail Specification: Page 1 of 5 ±± ±± ±± ±± ±± https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 1.1 2019 Johanson Technology, Inc. All Rights Reserved 18 months max. Frequency (GHz) 2.4 - 2.5 Reel Quantity (pcs/reel) 1000 Operating Temperature -40 to +85°C High Frequency Ceramic Solutions Part Number 6/9/2020 Let us help you with the antenna design, optimization, and tuning! 2450AT43B100 General Specifications P/N 2450AT43B100 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. e.g. 2450AT43B100(E or S)100% Tin Packing Style Evaluation Board 2450AT43B100-EB1SMA Bulk (loose) T&R Suffix = E or S Suffix = E P/N Suffix Mechanical Dimensions In L 0.2760.0087.000.2 W 0.0790.0082.000.2 L1 0.1022.600.20.008 W1 0.0200.0080.500.2 T 0.0792.00+0.1 / -0.2+0.004 / -0.008 a 0.0200.0120.500.3 Terminal Configuration Function FEED 1 FEED 2 GND No. 1 2 3 mm e.g. 2450AT43B100E e.g. 2450AT43B100SSuffix = S Part Number Explanation Return Loss (dB) 9.5 min. Peak Gain (dBi) 1.3 typ. Average Gain (dBi) -0.5 typ. Impedance (Ω) Input Power (W) Recommended Storage Conditions and Period for unused T&R Product +5 to +35°C Humidity 45 - 75% RH 50 2 max. (CW) Bottom Top View Side View L W L1W1 Bottom View a T     2.4GHz Chip Antenna, SMDP/N 2450AT43B100 Detail Specification: Page 2 of 5 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 1.1 2019 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" 6/9/2020 Mounting Considerations 1: Evaluation Board Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. Would you like the layout file? Contact our engineers at: https://www.johansontechnology.com/ask-a-question 0.83 2.81 1.6 1.6 1 0.8 1.83 0.8 1 2 22 10 4.87 * 1.8nH 2.7nH ) ) 4.87 40 20 Ground No Ground 10 Antenna Units in mm *50ΩGCPW transmission line recommended Note 1: Pins 2, 3 & 4, although "NC", must be soldered to their corresponding PCB pads for proper electrical operation 2.4GHz Chip Antenna, SMDP/N 2450AT43B100 Detail Specification: Page 3 of 5 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 1.1 2019 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" 6/9/2020 Mounting Considerations 1: Electrical Performance @25°C Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. Measured Return Loss Have antenna tuning issues? Please contact us if you have any questions regarding the implementation of this antenn a in your PCB's layout. We'll be happy to guide you to maximize the antenna's performance Contact our applications engineers at: https://www.johansontechnology.com/ask-a-question 2.4GHz Chip Antenna, SMDP/N 2450AT43B100 Detail Specification: Page 4 of 5 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 1.1 2019 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" 6/9/2020 Mounting Considerations 1: Antenna Performance Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. Typical 2D radiation patterns @ 2.45GHz YZ‐plane XZ‐plane XY‐plane θ φ +Z (θ= 0°) θ +Z +Z +X -Z +Y (θ= 90°) -Y -Z +Z (θ= 0°) +X (θ= 90°) -X -Z -Z +Y -Y +X -X +Y -Y -X +X (φ= 0°) -X +Y (φ= 90°) -Y Vertical Horizontal Vertical Horizontal Vertical Horizontal 2.4GHz Chip Antenna, SMDP/N 2450AT43B100 Detail Specification: Page 5 of 5 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 1.1 2019 Johanson Technology, Inc. All Rights Reserved Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. https://www.johansontechnology.com/antennas Soldering Information https://www.johansontechnology.com/ipcsoldering-profile MSL Info https://www.johansontechnology.com/msl-rating https://www.johansontechnology.com/rohs-compliance Packaging Information https://www.johansontechnology.com/tape-reel-packaging For layout review contact our applications team at: https://www.johansontechnology.com/ask-a-question RoHS Compliance "High Frequency Ceramic Solutions" Antenna tuning, optimization, and validation services: https://www.johansontechnology.com/ipc-antenna-services For more antennas and to download measured S-parameters, go to: 6/9/2020 Need help designing the antenna in? Use our antenna design services! https://www.johansontechnology.com/ipc-antenna-services We provide 2 free layout reviews and if you need us to tune and characterize the antenna on your product (inside anechoic chamber) we can do that too. Small lab fee may apply for the latter.

KES Co., Ltd. 3701, 40, Simin-daero 365beon-gil, Dongan-gu, Anyang-si, Gyeonggi-do, 14057, Korea Tel: +82-31-425-6200 / Fax: +82-31-424-0450 www.kes.co.kr Report No.: KES-RF-23T0096 Page ( 39 ) of ( 39 ) This report shall not be reproduced except in full, without the written approval of KES Co., Ltd. The results shown in this test report refer only to the sample(s) tested unless otherwise stated. The authenticity of the test report, contact [email protected] KES-QP16-F01(00-23-01-01) Appendix B. Test setup photos Radiated test AC Conducted test N/A The end of test report.
