2AJ8T-JT116K-H03Digital photo Frame

1 User Manual Digital Photo Frame Cautions Precautions and maintenance  For indoor use only  To avoid risk of fire or electric shock, do not expose the unit to moisture or condensation.  To avoid overheating, do not block the ventilation holes on the back of the Digital Photo Frame.  Keep the Digital Photo Frame out of direct sunlight.  Always use the eject buttons on the memory storage card slots to remove the storage cards.  Do not dismantle the Digital Photo Frame. There is a risk of electric shock and there are no user-serviceable parts inside. Dismantling the Digital Photo Frame will void your warranty. Cleaning the LCD Screen  Treat the screen carefully. Because the screen of the Digital Photo Frame is made of glass and it would easily be broken or scratched.  If fingerprints or dust accumulate on the LCD screen, we recommend using a soft, non-abrasive cloth such as a camera lens cloth to clean the LCD screen.  Moisten the cleaning cloth with the cleaning solution and apply the cloth to the screen. Introduction: WARNING: Please power off the unit before inserting or removing a card or USB device. Failure to do so may cause damage to the card/USB and the unit. To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. 2  Thank you for your purchase of the Digital Photo Frame. It is designed to allow quick and easy view of photos taken from your digital camera, mobile phone, or from a memory storage card.  Please read this User Manual carefully to learn the correct way to use the Digital Photo Frame. Features: 1. 11.6 inch IPS screen and touch panel. 2. Built-in clock, calendar, weather, alarm,music,video,video call,WIFI. 3. Support viewing pictures in thumbnail mode. 4. Adjustable slide show speed and above 11 kinds of transition slide show. 5. Copy files to Memory and delete files in the USB driver & Memory &Card. 6. OSD Language: English, French, German, Italian,Spanish,Russian,Japanese,Chinese. 7. Sharing photos, videos from Facebook, Twitter, Cloud Photo APP. 8. Support picture slideshow with background music. 9. With Cabinet Lock Hole & the photo frame can hung on the Wall. 10. Built-in stereo speaker and earphone jack. Packaging Check List: 1. digital photo frame 2. AC/DC adapter 3. Bracket 4. User manual 1 piece 1 piece 1 piece 1 piece 3 Contents 1. Product Diagram ........................................................................................................ 4 1.1 Back side of the frame ......................................................................................4 1.2 Side Panel ......................................................................................................... 4 2. Getting Started ........................................................................................................... 4 3. Facebook，Twitter，Cloud Photo APP Operating Instruction ................................ 5 3.1 Connect Wi-Fi ................................................................................................... 5 3.2 Link to Face Book, Twitter, Cloud Frame APP................................................... 6 4.General Operating Instruction .................................................................................... 10 4.1 Pictures. .............................................................................................................10 4.2 Music ................................................................................................................. 11 4.3 Videos .............................................................................................................. 12 4.4 Clock ................................................................................................................. 12 4.5 Calendar ........................................................................................................... 13 4.6 Alarm ................................................................................................................ 13 4.7 Weather .......................................................................................................... 14 4.8 Video call .......................................................................................................... 14 5.Settings. .................................................................................................................. 14 5.1 Device info. ....................................................................................................... 14 5.2User Management .................................................................................................15 5.3 PC control ........................................................................................................ 15 5.4 Wi-Fi Setting ................................................................................................... 15 5.5 Album Setting .................................................................................................. 15 5.6 System Settings ................................................................................................16 5.7 About.............................................................................................................. 16 6.Suspended Ball ........................................................................................................... 18 7. Technical Specifications............................................................................................ 18 8.Trouble shooting Guide ............................................................................................. 19 9.Contact Us ...................................................................................................................20 4 1. Product Diagram 1.1 Bottom of the frame 1.2 Side Panel 2. Getting Started 2.1 Put the digital photo frame with installing bracket on a flat position steadily, then plug one end of the AC adapter into a standard 110-240V AC electrical ou…

Text truncated - open the document above for the full version.

Report No.: TB-FCC174444 Page: 3 of 9 FCC ID: 2AJ8T-JT116K-H03 TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT Report No.: TB-FCC174444 Page: 4 of 9 FCC ID: 2AJ8T-JT116K-H03 TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT Report No.: TB-FCC174444 Page: 5 of 9 FCC ID: 2AJ8T-JT116K-H03 TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

Report No.: TB-FCC174444 Page: 1 of 9 FCC ID: 2AJ8T-JT116K-H03 TB-RF-074-1.0 Appendix IFCC ID Label Size：30x40cm FCCID: 2AJ8T-JT116K-H03 Model: JT116K-H03(JT116M-H03 AFT11F) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Report No.: TB-FCC174444 Page: 2 of 9 FCC ID: 2AJ8T-JT116K-H03 TB-RF-074-1.0 Appendix II ID Label Location ID LOCATION

Report No.: TB-FCC174444 Page: 6 of 9 FCC ID: 2AJ8T-JT116K-H03 TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Internal of EUT 2.4G WiFi Ant. Report No.: TB-FCC174444 Page: 7 of 9 FCC ID: 2AJ8T-JT116K-H03 TB-RF-074-1.0 Photo 9 Appearance of PCB Photo 10 Appearance of PCB

version01 Sh en Zhen JoyHong Technology CO., Ltd Declaration concerning Antenna Specification It is hereby declared that the product Model No.: JT116K-H03(JT116M-H03AFT11F),JT065X-XXX,JT070X-XXX,JT071X-XXX,JT080X- XXX,JT081X-XXX,JT090X-XXX,JT097X-XXX,JT100X-XXX,JT101X-XXX,JT102X-XXX,JT104X- XXX,JT110X-XXX,JT114X-XXX,JT116X-XXX,JT120X-XXX,JT121X-XXX,JT130X-XXX,JT133X-XXX, JT140X-XXX,JT141X-XXX,JT142X-XXX,JT150X-XXX,JT154X-XXX,JT156X-XXX,JT170X-XXX, JT171X-XXX,JT172X-XXX,JT173X-XXX,JT185X-XXX,JT190X-XXX,JT192X-XXX,JT215X-XXX, JT11GX-XXX, JD065X-XXX,JD070X-XXX,JD071X-XXX,JD080X-XXX,JD081X-XXX,JD090X- XXX,JD097X-XXX,JD100X-XXX,JD101X-XXX,JD102X-XXX,JD104X-XXX,JD110X-XXX,JD114X- XXX,JD116X-XXX,JD120X-XXX,JD121X-XXX,JD130X-XXX,JD133X-XXX,JD140X-XXX,JD141X- XXX,JD142X-XXX,JD150X-XXX,JD154X-XXX,JD156X-XXX,JD170X-XXX,JD171X-XXX,JD172X- XXX,JD173X-XXX,JD185X-XXX,JD190X-XXX,JD192X-XXX,JD215X-XXX,JD11GX-XXX (X stanT for 0～9 or A～Z) FCC ID: 2AJ8T-JT116K-H03 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for Internal antenna type(s) described below: Model No. of antenna: N/A T ype of antenna: 1. 2dBi PIFA Antenna Gain of the antenna: 1.2dBi Frequency range: 2412-2462 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Co mpany name : Sh en Zhen JoyHong Technology CO., Ltd Ad dress: 4th Floor, Building 1, Zhongtai Road NO. 18, Loucun Second Industrial Park, Xinhu Street, Gua ngming, Shenzhen, China. Ci ty: ShenZhen ZIP / Postal code: Countr y: Ch ina Pl ace: Lisong Pan / Sales manag er Date: 2020-08-20 Si gnature:

Report No.: TB-MPE173819 Page: 1 of 4 TB-RF-075-1.0 Maximum Permissible Exposure Evaluation FCC ID: 2AJ8T-JT116K-H03 1. Client Information Applicant : Shen Zhen JoyHong Technology CO., Ltd Address : 4th Floor, Building 1, Zhongtai Road NO. 18, Loucun Second Industrial Park, Xinhu Street, Guangming, Shenzhen, China. Manufacturer : Shen Zhen JoyHong Technology CO., Ltd Address : 4th Floor, Building 1, Zhongtai Road NO. 18, Loucun Second Industrial Park, Xinhu Street, Guangming, Shenzhen, China. 2. General Description of EUT EUT Name : Digital photo Frame Models No. : JT065X-XXX,JT070X-XXX,JT071X-XXX,JT080X-XXX,JT081X-XXX, JT090X-XXX,JT097X-XXX,JT100X-XXX,JT101X-XXX,JT102X-XXX, JT104X-XXX,JT110X-XXX,JT114X-XXX,JT116X-XXX,JT120X-XXX, JT121X-XXX,JT130X-XXX,JT133X-XXX,JT140X-XXX,JT141X-XXX, JT142X-XXX,JT150X-XXX,JT154X-XXX,JT156X-XXX,JT170X-XXX, JT171X-XXX,JT172X-XXX,JT173X-XXX,JT185X-XXX,JT190X-XXX, JT192X-XXX,JT215X-XXX,JT11GX-XXX, JD065X-XXX,JD070X-XXX,JD071X-XXX,JD080X-XXX,JD081X-XXX, JD090X-XXX,JD097X-XXX,JD100X-XXX,JD101X-XXX,JD102X-XXX, JD104X-XXX,JD110X-XXX,JD114X-XXX,JD116X-XXX,JD120X-XXX, JD121X-XXX,JD130X-XXX,JD133X-XXX,JD140X-XXX,JD141X-XXX, JD142X-XXX,JD150X-XXX,JD154X-XXX,JD156X-XXX,JD170X-XXX, JD171X-XXX,JD172X-XXX,JD173X-XXX,JD185X-XXX,JD190X-XXX, JD192X-XXX,JD215X-XXX,JD11GX-XXX(X stanT for 0～9 or A～Z) Model Different : All of these models are in the same PCB, layout and circuitry, the only difference is model name. Brand Name : ---- Product Description : Operation Frequency: 802.11b/g/n(HT20): 2412MHz~2462MHz 802.11n(HT40): 2422MHz~2452MHz Number of Channel: 802.11b/g/n(HT20):11 channels 802.11n(HT40):7 channels E.I.R.P: 802.11b: 2.76dBm 802.11g: 3.14 dBm 802.11n (HT20): 7.90 dBm 802.11n (HT40): 7.86 dBm Antenna Gain: 1.2dBi PIFA Antenna Power Rating : (Adapter:JHD-AP015U-050250BA) Input: AC 100-240V, 50/60Hz, 0.45A Output：DC 5V 2.5A Software Version : 8.1.0 Report No.: TB-MPE173819 Page: 2 of 4 TB-RF-075-1.0 Hardware Version : RF102 Connecting I/O Port(S) : Please refer to the User's Manual Remark : the MPE report used the EUT(TBBJ-20200720-04-2 # ). Report No.: TB-MPE173819 Page: 3 of 4 TB-RF-075-1.0 MPE Calculations for WIFI 1. Antenna Gain: PIFA Antenna:1.2dBi. 2. EUT Operation Condition: Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 3. Exposure Evaluation: Equation from page 18 of OET Bulletin 65, Edition 97-01 S=(PG)/4πR 2 Where S: power density P: power input to the antenna G: power gain of the antenna in the direction of interest relative to an isotropic radiator. R: distance to the center of radiation of the antenna 4. Test Result: Worst Maximum MPE Result Mode N TX Freq. (MHz) Conducted Power(max) (dBm) Turn-up Power (dB) Max tune up power (dBm) [P] ANT Gain (dBi) [G] Distance (cm) [R] Power Density (mW/ cm 2 ) [S] 802.11b 1 2412 2.76 2±1 3 1.2 20 0.0005 2437 2.35 2±1 3 1.2 20 0.0005 2462 2.71 2±1 3 1.2 20 0.0005 802.11g 1 2412 3.14 3±1 4 1.2 20 0.0006 2437 2.30 2±1 3 1.2 20 0.0005 2462 2.93 2±1 3 1.2 20 0.0005 802.11n(HT20) 1 2412 7.59 7±1 8 1.2 20 0.0016 2437 7.08 7±1 8 1.2 20 0.0016 2462 7.90 7±1 8 1.2 20 0.0016 802.11n(HT40) 1 2422 7.86 7±1 8 1.2 20 0.0016 2437 7.45 7±1 8 1.2 20 0.0016 2452 7.52 7±1 8 1.2 20 0.0016 Note: (1) N TX = Number of Transmit Antennas (2) RF Output power specifies that Maximum Conducted Peak Output Power. Report No.: TB-MPE173819 Page: 4 of 4 TB-RF-075-1.0 5. Conclusion: As specified in Table 1B of 47 CFR 1.1310- Limits for Maximum Permissible Exposure (MPE), Limits for General Population/ Uncontrolled Exposure Frequency Range (MHz) Power density (mW/ cm 2 ) 300-1,500 F/1500 1,500-100,000 1.0 For 2.4WIFI:2412~2462 MHz 2422~2452 MHz MPE limit S: 1mW/ cm 2 The MPE is calculated as 0.0016 mW / cm 2 < limit 1mW / cm 2 . So, RF exposure limit warning or SAR test are not required. The EUT will only be used with a separation of 20cm or greater between the antenna and nearby persons and can therefore be considered a mobile transmitter per 47 CFR2.1091 (b). The RF Exposure Information page from the manual is included here for reference. Note For a more detailed features description, please refer to the RF Test Report. 6. Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. -----END OF REPORT-----

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC174444 Page: 1 of 80 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 FCC Radio Test Report FCC ID: 2AJ8T-JT116K-H03 Original Grant Report No. : TB-FCC174444 Applicant : Shen Zhen JoyHong Technology CO., Ltd Equipment Under Test (EUT) EUT Name : Digital photo Frame Model No. : JT116K-H03(JT116M-H03 AFT11F) Series Model No. : See page 4 Appendix Brand Name : ---- Sample ID : TBBJ-20200720-04-1#& TBBJ-20200720-04-2# Receipt Date : 2020-07-27 Test Date : 2020-07-28 to 2020-08-12 Issue Date : 2020-08-13 Standards : FCC Part 15, Subpart C 15.247 Test Method : ANSI C63.10: 2013 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, The EUT technically complies with the FCC and IC requirements Test/Witness Engineer : Jack Deng Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC174444 Page: 2 of 80 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 APPENDIX .............................................................................................................................................. 4 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 6 1.5 Description of Test Mode .................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 8 1.8 Test Facility ........................................................................................................................... 9 2. TEST SUMMARY ..................................................................................................................... 10 3. TEST SOFTWARE ................................................................................................................... 10 4. TEST EQUIPMENT .................................................................................................................. 11 5. CONDUCTED EMISSION TEST ........................................................................................... 12 5.1 Test Standard and Limit .................................................................................................... 12 5.2 Test Setup ........................................................................................................................... 12 5.3 Test Procedure ................................................................................................................... 13 5.4 Deviation From Test Standard ......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data ............................................................................................................................. 13 6. RADIATED EMISSION TEST ................................................................................................ 14 6.1 Test Standard and Limit .................................................................................................... 14 6.2 Test Setup ........................................................................................................................... 15 6.3 Test Procedure ................................................................................................................... 16 6.4 Deviation From Test Standard ......................................................................................... 17 6.5 EUT Operating Condition ................................................................................................. 17 6.6 Test Data ............................................................................................................................. 17 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 18 7.1 Test Standard and Limit .................................................................................................... 18 7.2 Test Setup ........................................................................................................................... 18 7.3 Test Procedure ................................................................................................................... 19 7.4 Deviation From Test Standard ......................................................................................... 19 7.5 EUT Operating Condition ................................................................................................. 19 7.6 Test Data .........................................................................................................................…

Text truncated - open the document above for the full version.

Report No.: TB-FCC174444 Page: 8 of 9 FCC ID: 2AJ8T-JT116K-H03 TB-RF-074-1.0 Appendix V EUT Test Photographs 15C Test Setup Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Below 1 GHz) Report No.: TB-FCC174444 Page: 9 of 9 FCC ID: 2AJ8T-JT116K-H03 TB-RF-074-1.0 Photo of Setup for Conducted Emission -----END OF REPORT-----
