2AJDL-ASC-OO-VLPlugfones SafeComm Earphones

INNATE DEVICES.LLC

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Nov 24, 2025
Application Purpose: Original Equipment
Equipment Note: Plugfones SafeComm Earphones
Frequency Range: 2402.00000000 - 2480.00000000
Company: INNATE DEVICES.LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

M200T IN-EA R BLUETOOT H HEARING PROTECTI ON Congratulations and thanks for your choosing Plugfones Plugfones Hearing Protectors designed to protect users from harmful noise. Overview Earhook Ambient microphone Eartip Music volume up Multi-function button (MFB) Music volume down Type-C charging port Movable wire clip Aware volume up Aware volume down Indicator light Power ON/OFF Operation instructions -Long press [Multi-Function Button] 2 seconds to turn on the unit. the indicator flashes blue and you will hear “ POWER ON” and “Pairing”. - Long press [Multi-Function Button] 2 seconds to turn off the unit. The indicator flashes red light 3 time and you will hear “POWER OFF”. -Automatically shuts down if there is no key operation, Bluetooth call or music playback within two hours. The indicator flashes red light 3 time and you will hear “POWER OFF” Bluetooth Mode ON Bluetooth Bluetooth FreeReign Pro - Click the MFB to enter the Bluetooth pairing mode when powered on, the indicator light blue. - The unit Bluetooth pairing name is FreeReign Pro. - You will hear" Connected” after Bluetooth connected successfully. - The unit will connect back the last device automatically. - Under connected the other devices, long press [Music volume down Button] 5 seconds to clear the Bluetooth pair list. - If no connection with a paired device. The unit will switch off after 5 mins. Bluetooth Disconnect - Bluetooth will disconnect when the distance exceeds 18 meter, and you will hear "disconnect", the indicator light blue. - The unit will enter pairing mode if it does not reconnect after 1 minute, the indicator light flashes blue quickly. Red light Blue light Ambient listening volume Aware volume upClick the Aware volume up Aware volume down: Click the Aware volume down Turn off ambient listening volume : click the aware volume down to minimum Operation is disabled in Quiet mode Disable ambient sound pickup at minimum volume. Music & phone calls operation Music volume upClick Next track : short press, double click Music volume down Click Previous track : short press, double click Play/PauseClick Answer the phoneClick Reject callPress and hold for 1 seconds End call : double click Charging Specifications Material - Use the Type-C cable to connect the charging port to the power supply - During charging: the red light remains on - Fully charged: the red light turns off Shell: ABS Eartips: PU Version Battery Sound Pickup Characteristics Speak size Storage temperature range V5.3 150mAh Omnidirectional 6mm -50°C~70°C Description Plugfones M200T is designed for protecting hearing in noisy environments. lt helps you clearly hear the ambient sounds around you and maintain good communication. The earplugs adopts an in-ear hook and neck hanging design, making it more stable to wear and not easily take off. Featured Bluetooth, it allows you freely listen to music and answer/reject calls even in a noise-canceling mode.The multi-function button design allows you to easily adjust the volume of music, switch between tracks, answer, hang up, or reject calls. Safety information Please read, understand, and follow all safety information in these instructions prior to using the product.Retain these instructions for future reference. Important user information Recommendation that the user should ensure that: 1) the earplugs are fitted, adjusted and maintained in accordance with the manufacturer's instructions; 2) the earplugs are worn at all times in noisy surroundings; 3) the earplugs are regularly inspected for serviceability; Note: if the recommendations given are not adhered to, the protection afforded by the earplugs will be severely impaired; Operating and storage temperature Operation temperature-40°C to +50°C Storage temperature-50°C to +70°C NOTE: Do not store the hearing protector behind a windshield or at temperatures above +70°C Weight of hearing protector:20±10g The product is suitable for transport in original packaging. Transport information Use a wet cloth with soap and warm water to clean EARMOR® M200T NOTE: Foam eartips are re-usable. To ensure optimal performance, we recommend replacing them every three months or whenever they become dirty. Regularly inspect the foam eartips for signs of aging, cracking, or otherdamage. The eartips can be cleaned between uses with a damp cloth and water. Over time, the eartips should be replaced. Cleaning and maintenance Removing and replacing the eartips To remove the eartips, unscrew the eartips and take them out Screw the new eartips into the headset bar Spare parts and accessories Eartips: F0300010001/F0300010002/F0300010003 1) 2) WARNING To reduce the risks associated with harmful noise or chemicals: lf instructions are not followed, bodily injury may result or protection may be severely affected; When interference increases or the sound level becomes too weak, it is time to charge; These hearing protectors help reduce exposure to hazardous noise and other loud sounds.Misuse or failure to wear hearing protectors at all times when you are exposed to noise may result in hearing loss or injury; lf there is any drainage from your ear or if you have an ear infection, consult with your physician before wearing hearing protection. Failure to do so may result in hearing loss or injury; The product may be adversely affected by certain chemical substances. Refer to the manufacturer for further information."; Regularly inspect the foam earplugs for signs of aging, cracking, or other damage; To ensure peak performance,we recommend replacing the earplugs every three months or when they become soiled; The earplugs is provided with level-dependent attenuation, safety-related audio input.Please check correct operation before use.lf distortion or failure is detected, please refer to the manufacturer's advice for maintenance. The product shall not be used if it can't be ensured that the input voltage doesn't exceed the maximum value stated in APPROVALS EN352-10:2020 table 1; The audibility…

Text truncated - open the document above for the full version.

Attestation Statements

1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: INNATE DEVICES.LLC FRN: 0025707340 Contact Name: Dan Hill Address: 2052 W 700 S Unit B Springville Utah United States 84663 Telephone No: 4352560983 Email: [email protected] Applicant: Company name: INNATE DEVICES.LLC FRN: 0025707340 Product Description: Plugfones SafeComm Earphones Grantee code: 2AJDL FCC ID: 2AJDL-ASC-OO-VL Contact Name: Dan Hill Address: 2052 W 700 S Unit B Springville Utah United States 84663 Telephone No: 4352560983 Email: [email protected] [INNATE DEVICES.LLC] certifies that, as of the date of this filing of the application with the TCB, [INNATE DEVICES.LLC] is our designated US agent for service of process for the above referenced FCC ID. [INNATE DEVICES.LLC] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [INNATE DEVICES.LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 06.24.2025 Applicant’s Name: Dan Hill US Agent’s Name: Dan Hill Title: COO Title: COO Signature Signature

Attestation Statements

Attestation Statement. Old Code: C5266091 24 New Code: 00015544 Ed.3 Change reason: FRN is added to the Applicant information section. 1/1 TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: INNATE DEVICES.LLC Grantee code: 2AJDL FCC ID: 2AJDL-ASC-OO-VL FRN: 0025707340 Contact Name: Dan Hill Address: 2052 W 700 S Unit B Springville Utah United States 84663 Telephone No: 4352560983 Fax No: 4352560983 Email: [email protected] i. [INNATE DEVICES.LLC] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [INNATE DEVICES.LLC] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. INNATE DEVICES.LLC certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 06.24.2025 Applicant’s Name: Dan Hill Title: COO Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Attestation Statements

INNATE DEVICES.LLC Code 00018768 Ed. 2 Item 1. The device is able to install software/program installation? ☐ Yes, go to Item 2. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky cybersecurity or anti-virus software. Item 2. Technical Requirements for Kaspersky Cybersecurity Software: # General Requirements (For all Devices) Yes / No or N/A Comments 1 Internet connection for activation and updates (For all Operating Systems) N/A Device Plugfones SafeComm Earphones Company name INNATE DEVICES.LLC Grantee code 2AJDL FCC ID 2AJDL-ASC-OO-VL FRN 0025707340 Contact name Dan Hill Address 2052 W 700 S Unit B Springville Utah United States 84663 Telephone number 4352560983 E-mail [email protected] Chipset/module information BES2600IUC Operating System (if applicable) N/A Storage Capacity (hard drive or other permanent memory storage, if applicable) N/A 2 # General Requirements (For Windows Devices) Yes / No or N/A Comments 1 Storage: 1500 MB free space on the hard drive N/A 2 Operating System: Microsoft Windows 8, 8.1, 10 & 11 Home / Pro / Enterprise Microsoft Windows 7 Starter / Home Basic & Premium / Professional / Ultimate SP1 or higher N/A 3 Processor: 1 GHz or higher (x86 or x64) N/A 4 Memory (RAM)1 GB (32-bit) or 2 GB (64-bit) N/A 5 Screen Resolution: Minimum resolution of 1024 x 768 N/A # General Requirements (For macOS devices) Yes / No or N/A Comments 1 Operating System macOS® 13 – 14 N/A 2 Memory (RAM)4 GB N/A 3 Storage: 3455 MB free space on the hard drive N/A # General Requirements (For Android Devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: Android™ 10 – 14 N/A 3 Screen Resolution: Minimum resolution of 320 x 480 N/A # General Requirements (for iOS devices) Yes / No or N/A Comments 1 Storage: 150 MB free space N/A 2 Operating System: iOS® 17 N/A 3 # General Requirements (For Linux system) Yes / No or N/A Comments 1 Hard drive: 1 GB of free space N/A 2 CPU: Intel Pentium 1 GHz or higher N/A 3 RAM: 1 GB N/A 4 Minimum software requirements: AlmaLinux OS 8 or later; AlterOS 7.5 or later; Astra Linux Common Edition 2.12 or later; CentOS 6.7 or later; Debian GNU/Linux 10.0 or later; EulerOS 2.0 or later; Oracle Linux 7.3 or later ; Red Hat Enterprise Linux 6.7 or later ; Rocky Linux 8.5 or later ; SUSE Linux Enterprise Server 12.5 or later; Ubuntu 12.04 or later ; Uncom OS Home / Business / Education / Enterprise 2.2 or later; ALT Linux Workstaton / Workstation K / Server / Education 8 or later; ROSA Linux Workstation / Server 12 or later ; RED OS 7.3 and later ; N/A After reviewed the technical requirements, is the device capable of supporting the installation of Kaspersky software? ☐ Yes, go to Item 3. ☒ No. In this case, the rest of the items do not apply. The device cannot support installation of Kaspersky software 4 Item 3. Connectivity Capabilities: # Physical Interface Purpose Justification 1 1 # Wireless Interface Purpose Justification 1 1 After the review of this items, the device: ☒ Cannot support installation of any cybersecurity or anti-virus software on the covered list. ☐ Potentially can operate with any cybersecurity or anti-virus software on the covered list – additional third- party proof is provided to demonstrate compliance with requirements as of 2.911(d)5(i),(ii) – “Proof of Compliance with Covered List Software Requirements” of this document applies Signature: Name: Dan Hill Date: 11/13/2025 1 The justification field is used to justify why the software cannot be received through that interface. Check the annex for more indications.

Attestation Statements

TCB CALL página 1 File FCC ID: 2AJDL-ASC-OO-VL Please upload an exhibit that explains how does the TCB verify the new agent information: 1- Is the address of the agent a valid physical US mailing address (not a US post office box, not a virtual mailbox, not P.O. Boxes, not a vacant lot, not a public building, etc.) ○ We have checked if the address exists in a real and potential building (Google maps) + official US register, after this verification and the evidence below we can guarantee the following: not a US post office box not a virtual mailbox not P.O. Boxes not a vacant lot not a public building(note) ► We checked the FCC FRN Search based on the information provided by the grantee. On the official register from : https://opencorporates.com/companies/us_il/LLC_12842678 In google: ► CONCLUSION by TCB: The ASOP defined and provided by grantee is VALID and confirmed. Therefore the exhibit "C5266091_X23_Ed1_US_Agent_Letter" TCB CALL página 2 included in the file is ok. 2- Is the agent physically located at that valid US address such that the agent can be legally served at that address? Yes , check above 3- Has the listed agent clearly agreed in writing to serve as the agent for the grantee at that address? Yes, it is included in the exhibit "C5266091_X23_Ed1_US_Agent_Letter" >

Cover Letter(s)

C5266091_X10_Ed.2 1/1 INNATE DEVICES.LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 6/24/2025 Subject: Request for Confidentiality FCC ID: 2AJDL-ASC-OO-VL To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. C5266091_X10_Ed.2 1/1 Sincerely, Signature: Name: Dan Hill Title: COO

Cover Letter(s)

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: INNATE DEVICES.LLC Address: 2052 W 700 S Unit B Springville Utah United States 84663 Product Name: Plugfones SafeComm Earphones Model Number: ASC-OO(VL) FCC Identifier: 2AJDL-ASC-OO-VL We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Dan Hill Date: 6/24/2025 Title: COO Signature of applicant:

External Photos

Page1of4ReportNo.:MTi250311012-0201 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] PhotographsoftheEUT(ExternalPhotos) Model:ASC-OO(VL) Page2of4ReportNo.:MTi250311012-0201 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page3of4ReportNo.:MTi250311012-0201 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page4of4ReportNo.:MTi250311012-0201 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected]

ID Label/Location Info

ASC-OO(VL) FCC ID:2AJDL-ASC-OO-VL Input voltage: 5V/120Ma

Internal Photos

Page1of5ReportNo.:MTi250311012-0201 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] PhotographsoftheEUT(InternalPhotos) Model:ASC-OO(VL) Page2of5ReportNo.:MTi250311012-0201 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page3of5ReportNo.:MTi250311012-0201 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page4of5ReportNo.:MTi250311012-0201 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected] Page5of5ReportNo.:MTi250311012-0201 Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China. Tel:0755-88850135-1439Mobile:131-4343-1439(Wechatsamenumber)Web:http://www.mtitest.cnE-mail:[email protected]

RF Exposure Info

Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE012 Ver./Rev.：A1 Page 1 of 6 RFEXPOSURE TestReport ReportNo.:MTi250311012-0201E2 DateofIssue:2025-04-09 Applicant:GUANGZHOUOPSMENTECHCO.,LTD. Product:PlugfonesSafeCommEarphones Model(s):ASC-OO(VL) FCCID:2AJDL-ASC-OO-VL ShenzhenMicrotestCo.,Ltd. TESTREPORT ReportNo.:MTi250311012-0201E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE012 Ver./Rev.：A1 Page2of6 Tableofcontents 1StandaloneSARtestexclusionconsiderations.................................................................4 2SARTestExclucsionThresholds.........................................................................................5 TESTREPORT ReportNo.:MTi250311012-0201E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE012 Ver./Rev.：A1 Page3of6 TestResultCertification ApplicantINNATEDEVICES.LLC ApplicantAddress2052W700SUnitBSpringvilleUtahUnitedStates84663 ManufacturerGUANGZHOUOPSMENTECHCO.,LTD. Manufacturer Address Room601,BuildingA,No.94LiwanRoad,LiwanDistrict,Guangzhou, GuangdongProvince,China Productdescription ProductnamePlugfonesSafeCommEarphones TrademarkPlugfones ModelnameASC-OO(VL) SeriesModel(s)N/A Standards47CFRPart2.1093 TestmethodKDB447498D01v06 TestingInformation Dateoftest2025-04-04to2025-04-07 TestResultPass Preparedby:JamesQin Reviewedby:DavidLee Approvedby:LewisLian TESTREPORT ReportNo.:MTi250311012-0201E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE012 Ver./Rev.：A1 Page4of6 1StandaloneSARtestexclusionconsiderations UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone1-g headorbodyand10-gextremitySARevaluationforgeneralpopulationexposureconditions,by measurementornumericalsimulation,isnotrequiredwhenthecorrespondingSARTest ExclusionThresholdcondition(s),listedbelow,is(are)satisfied. Thesetestexclusionconditionsarebasedonsource-basedtime-averagedmaximum conductedoutputpoweroftheRFchannelrequiringevaluation,adjustedfortune-uptolerance, andtheminimumtestseparationdistancerequiredfortheexposureconditions. Theminimumtestseparationdistancedefinedin4.1f)isdeterminedbythesmallestdistance fromtheantennaandradiatingstructuresoroutersurfaceofthedevice,accordingtothehost formfactor,exposureconditionsandplatformrequirements,toanypartofthebodyorextremity ofauserorbystander. ToqualifyforSARtestexclusion,thetestseparationdistancesappliedmustbefullyexplained andjustified,typicallyintheSARmeasurementorSARanalysisreport,bytheoperating configurationsandexposureconditionsofthetransmitterandapplicablehostplatform requirements,accordingtotherequiredpublishedRFexposureKDBprocedures. WhennootherRFexposuretestingorreportingarerequired,astatementofjustificationand compliancemustbeincludedintheequipmentapproval,inlieuoftheSARreport,toqualifyfor SARtestexclusion. Whenrequired,thedevicespecificconditionsdescribedintheotherpublishedRFexposure KDBproceduresmustbesatisfiedbeforeapplyingtheseSARtestexclusionprovisions. a)For100MHzto6GHzandtestseparationdistances≤50mm,the1-gand10-gSARtest exclusionthresholdsaredeterminedbythefollowing: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f(GHz)]≤3.0for1-gSAR,and≤7.5for10-gextremitySAR,where f (GHz) istheRFchanneltransmitfrequencyinGHz  PoweranddistanceareroundedtothenearestmWandmmbeforecalculation  Theresultisroundedtoonedecimalplaceforcomparison Thevalues3.0and7.5arereferredtoasnumericthresholdsinstepb)below Thetestexclusionsareapplicableonlywhentheminimumtestseparationdistanceis≤50mm, andfortransmissionfrequenciesbetween100MHzand6GHz.Whentheminimumtest separationdistanceis<5mm,adistanceof5mmaccordingto4.1f)isappliedtodetermine SARtestexclusion. b)For100MHzto6GHzandtestseparationdistances>50mm,the1-gand10-gSARtest exclusionthresholdsaredeterminedbythefollowing(alsoillustratedinAppendixB): 1){[Powerallowedatnumericthresholdfor50mminstepa)]+[(testseparation distance–50mm)·(f(MHz)/150)]}mW,for100MHzto1500MHz 2){[Powerallowedatnumericthresholdfor50mminstepa)]+[(testseparation distance–50mm)·10]}mW,for>1500MHzand≤6GHz c)Forfrequenciesbelow100MHz,thefollowingmaybeconsideredforSARtestexclusion (alsoillustratedinAppendixC): 1)Fortestseparationdistances>50mmand<200mm,thepowerthresholdatthe correspondingtestseparationdistanceat100MHzinstepb)ismultipliedby[1+ TESTREPORT ReportNo.:MTi250311012-0201E2 Tel:0755-88850135-1439 Mobile:131-4343-1439（Wechatsamenumber） Web:http://www.mtitest.cnE-mail:[email protected] Address:101,No.7,Zone2,XinxingIndustrialPark,FuhaiAvenue,XinheCommunity,FuhaiStreet,Bao’anDistrict,Shenzhen,Guangdong,China Q/MTI-QP-12-FE012 Ver./Rev.：A1 Page5of6 log(100/f(MHz))] 2)Fortestseparationdistances≤50mm,thepowerthresholddeterminedbythe equationinc)1)for50mmand100MHzismultipliedby½ 3)SARmeasurementproceduresarenotestablishedbelow100MHz. WhenSARtestexclusioncannotbeapplied,aKDBinquiryisrequiredtodetermineSAR evaluationrequirementsforanySARtestresultsbelow100MHztobeacceptable. 2SARTestExclucsionThresholds Weuse5mmasseparationdistancetocalculated. BluetoothDSS: Transmit Frequency (GHz) Mode Measured Power (dBm) Tune-up power (dBm) Maxtune-upResult 1gSAR test exclusion threshold power(dBm)calculation 2402 GFSK 2.002±130.61853 24412.672±130.62353 24803.753±140.79113 2402 π/4-DQPSK 1.861±120.49133 24412.572±…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.
