2AJDZSTELLAOMEGAP3G Smart Phone

G-TOUCH LLC.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Sep 18, 2020
Application Purpose: Original Equipment
Date of Application: Sep 18, 2020
Equipment Note: 3G Smart Phone
Frequency Range: 1852.40000000 - 1907.60000000
Company: G-TOUCH LLC.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

1 User Manual Dear customer: Thank you for choosing this mobile phone. This mobile phone incorporates the latest world advanced functions, enabling simple and convenient operation，satisfying your special requirements. The mobile phone supports T-FLASH (Memory) card and Dual SIM standby. It integrates the following available functions: Messaging, MP3, MP4, Camera, FM radio, Clock, Call recording, Video recorder and Calendar, enabling you arranging your work, study and life freely; with long standby duration, as well as Browser and Calculator, your communication will be easier and smoother; powerful File manager allows you to manage the files conveniently. In addition, the chord ringtone allows you selecting music to set as ringtone; the personalized appearance also can satisfy your selection. Note: User’s Manual is just to guide the user about the functionality of the phone. Some functions may vary due to modifications and upgrades of software or due to print mistakes. 1 For your safety Notice: To use your mobile phone safely and efficiently, please read the following instruction carefully before using and abide by it. Be careful when you are driving. Please abide by the relative local laws and regulations. Use both of your hands to drive! Put the mobile phone in its seat to avoid falling down. The ballonet will charge quickly when it is in danger, please don’t put anything in its security scope, including fixed phone and handset equipment. Otherwise it may cause serious body injuries. The handset must be turned off when you are on the plane. The interference of mobile will influence the flight. It is illegal to use mobile on phone, please power it off. The handset must be turned off when you are in blowing-up area. When you are at a blowing-up area or near it, please abide by the relevant laws and power your mobile off. The handset must be turned off when you are near a danger product. Please do not use mobile when you are near gas station or chemical plant. The handset must be turned off when you are in a hospital. 2 You have to abide by the relevant regulations of hospital and turn your handset off when you are near medical equipment. Any wireless transmission device, including mobile, will interfere those equipment not fully-protected. Interference All the mobile handset may be interfered by the radio and reduce the performance of the handset. Professional service Only the professional can setup or maintain the handset. Improper installation or maintenance would bring out great danger, it also disobey regulations of maintenance guarantee. Accessory and battery Only the appointed accessory and battery can be used. It is suggested that you return the used battery to the factory or put it in the appointed recycle zone. Do not put it together with other rubbish or discard it. Reasonable use Please use the handset in reasonable way. It is prohibited to put your handset in high temperature (over 60°C), such as beside the window where there is sunshine. Please use wet or antistatic cloth to clean the handset. Do not use dry or static clothto clean it. Your handset is not waterproof, please keep it dry. Emergency call Please make sure the handset is powered on so that it can dial the emergency call. In idle mode, the handset can dial emergency numbers, such as 112, 100, 101 and 102. Press dial key to dial it, report your location and the situation briefly. Do not end the call without permission. Note: this handset, like any other one, may not support all the features because of the network coverage and wireless transmission. Some network even can not support 112. So do not rely totally on your handset about some significant calling (like medical aid). Please refer to the local operator. 2 Mobile phone appearance and key description The keys Function Home Key 1) In any application, or interface, press this button to return to the home screen interface. 2) Long press into Google search. Menu Key Press this button to the most recently used applications. 3 Back Key Press this button to return to the previous interface, or close the dialog, the options menu, notify the panel or on-screen keyboard. Power Key Long press this button to turn on the phone option menu, and then you can choose to Power off or Reboot Volume Up Press this button to increase volume. Volume Down Press this button to decrease volume. 3 Status icon Above the main screen as shown below the status bar, drag down to view unread messages, missed calls, Email notification or other information. Contents Browser............................................................................................................................... Backup and Restore............................................................................................................ Calculator............................................................................................................................ Email............................................................................................................... File Manager........................................................................................................................ Gallery................................................................................................................................. Google............................................................................................................. Clock............................................................................................................... Calendar.......................................................................................................... Camera............................................................................................................ Music............................................................................................................... Contacts.....................................................................................…
