2AJEM-MC004Wireless Solar Driveway Alarm

eMACROS was founded in 2012, the brainchild of a group of friends who previously designed Motorola products. Fast forward a few years and we are now the industry leader in home intercom and security products. Our vision is to create a global world leader in home intercom solutions and products. We design and engineer intelligent residential home solution and intercom systems. Our company philosophy is to direct our efforts based on our client's wishes. We want you to have the best possible experience with our products. We also offer superior customer service to address damaged or defective products. If you have any questions, please contact us at: [email protected], we will assist you as quickly as possible. www.emacros.com Vehicle Alert Installation: The best mounting position for detecting vehicles is about 4 feet (1.2m)high. Between 0-30 feet (0-9m ) from the road and The PIR sensor detects the movements with heat sources. Please adjust the sensor eye with horizontal angle to the engine of the car. Note : The sensors operate best in the -4F to 140F degree range. The sensors will not work properly out of this temperature range. PIR Motion Sensor Installation a. Mount the waterproof PIR Motion Sensor vertically on a solid surface 3-5 feet (1-1.5m) above the ground (rotate sensor to access screw holes). The sensor should be able to swivel as needed. Position the sensor to avoid direct sunlight shining on the sensor eye while simultaneously keeping the solar cell facing upward. Troubleshooting • The PIR Motion Sensor operates, but the base station does not respond. Check the sensor switch settings (Assembly & Setting) and make sure the sensor and base in the valid 1/2 mile range. • PIR Motion Sensor is detecting motion only part of the time. Set the PIR Sensor Switch to High sensitivity setting. To detect vehicles, The PIR sensor detects the movements with heat sources. Please adjust the sensor eye with horizontal angle to the engine of the car. Swivel the sensor to obtain the best line of sight to a vehicle. • The system is giving false alarms. Check for moving tree branches or insects in the sensor window and remove as necessary. Check the Sensor Switches on the PIR Motion Sensor (Assembly & Setting). Ensure that sunlight is not shining directly onto the sensor eye. • The system is not getting expected transmission range. Ensure that the PIR Motion Sensors are vertically aligned, not attached to the far side of a tree, and away from metal objects. Ensure that the Base Station has the clearest possible line of site to the sensors. The fewer objects between the devices, the longer the range. Limited 24 months Warranty EXCEPT AS PROVIDED HEREIN, SELLER MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES CONTAINED HEREIN, EXCEPT AS PROVIDED HEREIN, SELLER SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO ANY DAMAGES RESULTING FROM INCONVENIENCE, 231 910118 Operation & Features 1.Base Station On/Off To turn the Base Station on or off, hold down the Power button until you hear the on/off tone. The red power light will illuminate on #3 when the Base Station is on. Volume The Base Station is equipped with adjustable Volume +/- controls. The lowest volume setting mutes the volume. Volume adjustments will be heard on subsequent alarm activations, not Overview The Wireless Motion Alert has a range of up to 1/2 mile (800 meters). It uses a Passive Infrared (PIR) Motion Sensor to detect movement of people and vehicles while allowing small animals to pass through undetected. The Base Station is powered by an AC adapter, it can also run on 4AA batteries as backup in case of power outage for 2 weeks. What's in the box LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES,EVEN IF SELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. In the event of a product defect during the warranty period, contact the Seller to obtain an RBM#, and then return the product, along with the sales receipt as proof of purchase date, to Seller. The Seller will, at its option either correct the defect by product repair without charge for parts and labor; replace the product with one of the same or similar design or refund the purchase price. All replaced parts and products and refunded products become the property of the Seller. New or reconditioned parts and products may be used in the performance of warranty service. Repaired or replaced parts and products are warranted for the remainder of the original warranty period. You will be charged for repairs on products no longer covered by warranty. For all returns, please write down the RBM# and return date on the outside of the package. This will speed up the process of handling your return and issuing a refund or providing you with a replacement. Refunds are not issued for products no longer covered by warranty. The warranty will not cover replacements in cases where damage or failure is caused by, or attributable to: (a) acts of God, abuse, accident, misuse, improper abnormal usage, failure to follow instructions, improper installation or maintenance, alteration, lightning or other instance of excess voltage or current, (b) any repairs other than those provided by the Seller, (c) consumables such as fuses or batteries, (d) cosmetic damage, (e) transportation, shipping or insurance costs, (f) or costs of product removal, installation, set-up, service adjustment or reinstallation. Our goal is for you to have the best possible experience with Hosmart. We appreciate receiving comments on any aspect of your experience with Hosmart or our p…

Text truncated - open the document above for the full version.

< Shenzhen Macross Industrial Co., Ltd. > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD21046 Date:2020-03-17 Subject; Request for Long Term Confidentiality FCC ID: 2AJEM-MC004 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: William King Title: Manager

Shenzhen Macross Industrial Co., Ltd. Letter of Authorization Company: Shenzhen Macross Industrial Co., Ltd. Address: 3rd floor,#5 Building,Jianghao Technology Park #430 Jihua Rd.Bantian St.Longgang District Shenzhen, Guangdong,China Product Name: Wireless Solar Driveway Alarm Model Number(s): Receiver: MC-004A Transmitter: MC-004B Product Description: Wireless Solar Driveway Alarm We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-03-17 Name: William King Title: Manager Company: Shenzhen Macross Industrial Co., Ltd.

Test model number: MC-004B

POWER: DC 5V (AC Adaptor) FCC ID: 2AJEM-MC004 Manufacturer: Shenzhen Macross Industrial Co.,Ltd. 外 20 POWER: DC 5V (AC Adaptor) DC 6V 4AA (Backup Battery) Manufacturer: Shenzhen Macross Industrial Co.,Ltd. 内 [email protected] POWER: DC 5V (AC Adaptor) DC 6V 4AA (Backup Battery) Manufacturer: Shenzhen Macross Industrial Co.,Ltd. POWER: DC 5V (AC Adaptor) FCC ID: 2AJEM-MC004 Manufacturer: Shenzhen Macross Industrial Co.,Ltd. 内 外 20

Test model number: MC-004B

Global United Technology Services Co., Ltd. Report No.: GTS202001000057F01 Authorized Signature: Robinson Lo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 23 Cover Page TEST REPORT Applicant: Shenzhen Macross Industrial Co., Ltd. Address of Applicant: 3rd floor,#5 Building,Jianghao Technology Park #430 Jihua Rd.Bantian St.Longgang District Shenzhen, Guangdong,China Manufacturer/Factory: Shenzhen Macross Industrial Co., Ltd. Address of Manufacturer/Factory: 3rd floor,#5 Building,Jianghao Technology Park #430 Jihua Rd.Bantian St.Longgang District Shenzhen, Guangdong,China Equipment Under Test (EUT) Product Name: Wireless Solar Driveway Alarm Model No.: Receiver: MC-004A Transmitter: MC-004B Trade Mark: eMACROS FCC ID: 2AJEM-MC004 Applicable standards: FCC CFR Title 47 Part 15 Subpart C Section 15.231 Date of sample receipt: January 13, 2020 Date of Test: January 14, 2020-March 12, 2020 Date of report issued: March 13, 2020 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTS202001000057F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 23 2 Version Version No. Date Description 00 March 13, 2020 Original Prepared By: Date: March 13, 2020 Project Engineer Check By: Date: March 13, 2020 Reviewer Report No.: GTS202001000057F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 23 3 Contents Page 1 COVER PAGE ...........................................................................................................................................1 2 VERSION ...................................................................................................................................................2 3 CONTENTS ...............................................................................................................................................3 4 TEST SUMMARY ......................................................................................................................................4 4.1 MEASUREMENT UNCERTAINTY .............................................................................................................4 5 GENERAL INFORMATION .......................................................................................................................5 5.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 5.2 TEST MODE .........................................................................................................................................6 5.3 TEST FACILITY ....................................................................................................................................6 5.4 TEST LOCATION ..................................................................................................................................6 5.5 DESCRIPTION OF SUPPORT UNITS ........................................................................................................6 5.6 DEVIATION FROM STANDARDS ..............................................................................................................6 5.7 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................6 5.8 OTHER INFORMATION REQUESTED BY THE CUSTOMER ..........................................................................6 6 TEST INSTRUMENTS LIST ......................................................................................................................7 7 TEST RESULTS AND MEASUREMENT DATA .......................................................................................9 7.1 ANTENNA REQUIREMENT ......................................................................................................................9 7.2 CONDUCTED EMISSIONS ....................................................................................................................10 7.3 RADIATED EMISSION METHOD ............................................................................................................13 7.3.1 Field Strength of The Fundamental Signal ..................................................................................15 7.3.2 Spurious emissions .....................................................................................................................16 7.4 20DB OCCUPY BANDWIDTH ...............................................................................................................20 7.5 DWELL TIME ......................................................................................................................................21 7.6 SILENT PERIOD ..................................................................................................................................22 8 TEST SETUP PHOTO .............................................................................................................................23 9 EUT CONSTRUCTIONAL DETAILS .......................................................................................................23 Report No.: GTS202001000057F01 Global United Technology Services Co., Ltd. No. 123- 128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Gu…

Text truncated - open the document above for the full version.

Test model number: MC-004B Conducted Emission
