2AJFX-DZ2502Dash Cam

DZ2502C(Z系列说明书) 70401000408 1.2 20260616 修改人：徐小云 归档人：徐小云 何译文 公差：±0.5mm 尺寸：115*135mm 工艺：骑马钉 设计条件需满足： 1： 物料上不可有刀锋、非常规折叠、脏污、起翘、卷边、划痕、粉状灰尘等缺陷: 2： 丝印上不可出现叠影、模糊、不清晰、工艺偏位、易晕染； 3： 印刷颜色上不可出现≥5%的色差，材料颜色不可出现≥3%的色差； 4： 包装方式需以叠装（每10pcs单装）来料，外层需以牛皮纸外保护; 5： 所有物料要求符合ROHS要求； 英语版区 封面封底封面 瑞典语版区 荷兰语版区 希腊语版区 匈牙利语版区波兰语版区 德语版区法语版区 西班牙语版区意大利语版区 日语版区阿拉伯语版区 土耳其语版区葡萄牙版区 丹麦语版区 捷克版区 洋红：间距标注 红色：切割刀模 黄色：压线刀模 绿色：字体标注 蓝色：尺寸标注 135mm 115mm CONTENTS 1.User Manual1-3 2.Brugervejledning 4-6 3.Gebruikershandleiding 7-9 4.Uživatelská příručka 10-12 5.Användarhandbok 13-15 6.Εγχειρίδιο χρήστη 16-18 7.Felhasználói kézikönyv 19-21 8.Instrukcja obsługi 22-24 9.Benutzerhandbuch 25-27 10.Manuel d’utilisation 28-30 11.Manual de usuario 31-33 12.Manuale utente 34-36 13. 37-39 14. دلیل المستخدم40-42 15.Kullanıcı Kılavuzu 43-45 16.Manual do usuário 46-48 User Manual Z60 Master | Z90 | Z90T | Z90 Max Z Series Watch Setup Video Read Online Manual 1 1 Specifications Product Name: Dash Cam Model: DZ2502A, DZ2502A-01, DZ2502A-02, DZ2502A-03, DZ2502A-04, DZ2502A-05, DZ2502A-06, DZ2502B, DZ2502B-01, DZ2502B-02, DZ2502B-03, DZ2502B-04, DZ2502B-05, DZ2502B-06, DZ2502C, DZ2502C-01, DZ2502C-02, DZ2502C-03, DZ2502C-04, DZ2502C-05 Input: 5V 2A Resolution: 4K 3840*2160 Dimensions: 83mm x 68mm x 46mm Memory Card: Supports Micro-SD cards up to 512GB; DDPAI cards or U3 and above recommended 2 Package Contents Dash Cam USB Charger Electrostatic Sticker 3M AdhesiveCar Wire Trim ToolUser Guide Power Cable Rear Camera & Rear Camera Extension Cable(Optional) Interior Camera(Optional) & 1-to-2 Adapter Cable (Optional) Notes: • If the interior camera and 4G cloud box are purchased, please ensure you use the provided car charger (5V/3.5A). • If you select the 4G package, the default power cable will be the hardwire kit, and the USB charger and power cable are not included. • Some models do not include the optional accessories shown above. Please refer to the actual product received. 3 Product Overview Note: The actual appearance of the lens may vary depending on the model. 4 Button Description DisplayFunction Buttons Indicator Lens Adhesive Base (removable) Rear Camera / Interior Port Power Port (Type-C) MIC Micro-SD Card Slot Return Right/Down Left/Up Confirm Reset: Press and hold for 6 seconds 2 5 Installation Install the Dash Cam Step 1: Clean your windshield and attach the electrostatic sticker to the recommended area. Step 2: Insert the Micro-SD card into the card slot. Step 3: Peel off the lens protective film, tear off the 3M adhesive protective film, and stick the dash cam to the electrostatic sticker on the windshield. Step 4: Route the power cord to the cigarette lighter and connect to the power. Step 5: Start the vehicle, and adjust the camera angle based on the preview screen. Install the Rear Camera (2-Channel) 1.Connect the rear camera to the dash cam via the rear camera extension cable. 2.Please refer to the figure below for the specific installation position of the rear camera. Install the Interior Camera (3-Channel) Step 1: Please use the 1-to-2 adapter cable to connect the rear camera, interior camera, and dash cam. Refer to the wiring diagram for specific connection details. I-CAM I-CAM D-CAM D-CAM D-CAM D-CA M Interior Camera Dash Cam Digital Camera 3 Step 2: Mount the interior camera to the windshield in the recommended position shown below. For more installation details, please scan the QR code below. 6 Indicator Guide IndicatorSystem Status OffNormal Recording/Parking Monitoring (Sleep mode) Breathing RedParking Monitoring (Time-lapse video) 7 App Instruction Install DDPAI App Download DDPAI app from Google Play Store (Android) or App Store (iOS). Connect Device to Your Smartphone Step 1: Power on the Dash Cam. Turn on the Bluetooth of your mobile phone. Step 2: Launch the DDPAI App, tap “Device”> “+ Add a device”. Step 3: Select the current device name (DDPXXXXXX). Step 4: Press the confirm button of the device to authorize. ATTENTION Installation of this product requires professional automotive electrical knowledge. We strongly recommend having the device installed by a qualified professional. DDPAI assumes no liability for any damages, losses, or injuries resulting from improper installation, setup, or maintenance performed by the customer or any third-party service provider. 4 1 Specifikationer Produktnavn: Bilkamera Model: DZ2502A, DZ2502A-01, DZ2502A-02, DZ2502A-03, DZ2502A-04, DZ2502A-05, DZ2502A-06, DZ2502B, DZ2502B-01, DZ2502B-02, DZ2502B-03, DZ2502B-04, DZ2502B-05, DZ2502B-06, DZ2502C, DZ2502C-01, DZ2502C-02, DZ2502C-03, DZ2502C-04, DZ2502C-05 Indgang: 5V 2A Opløsning: 4K 3840*2160 Dimensioner: 83mm x 68mm x 46mm Hukommelseskort: Understøtter Micro-SD-kort op til 512GB; DDPAI-kort eller U3 og derover anbefales 2 Pakkens indhold Bilkamera USB-opladerElektrostatisk klistermærke 3M klæbemiddel Værktøj til ledningsføring Brugervejledning Power Cable Bakkamera & Forlængerkabel til bakkamera (valgfrit) Indvendigt kamera (valgfrit) & 1-til-2 adapterkabel (valgfrit) Bemærkninger: • Hvis det indvendige kamera og 4G cloud box tilkøbes, skal du sørge for at bruge den medfølgende biloplader (5V/3,5A). • Hvis du vælger 4G-pakken, vil standardstrømkablet være et "hardwire kit", og USB-opladeren samt strømkablet medfølger ikke. • Nogle modeller inkluderer ikke det valgfrie tilbehør vist ovenfor. Se venligst det modtagne produkt. 3 Produktoversigt Bemærk: Objektivets faktiske udseende kan variere afhængigt af modellen. 4 Knapbeskrivelse DisplayFunktionsknapper Indikator Linse Klæbebase (aftagelig) Port til bakkamera / indvendigt kamera Strømport (Type-C) Mikrofon Micro-SD-kortlæser Tilbage Højre/Ned Venstre/Op Bekræft Nulstilling (Reset): Tryk og hold nede i 6 sekunder 5 5 Installation Installer bilkameraet Trin 1: Rengør forruden og sæt det elektrostatiske klistermærke på det anbefalede område. Trin 2: Indsæt Micro-SD-kortet i kortlæseren. Trin 3: Fjern beskyttelsesfilmen fra linsen, træk 3M-klæbemidlets beskyttelsesfilm af, og klæb kameraet f…

Text truncated - open the document above for the full version.

DDPAI Technology Co., Ltd. Covered Equipment Certification Attestation Letter 7/27/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AJFX-DZ2502 DDPAI Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. DDPAI Technology Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. DDPAI Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). <Signature>: Name: Sean Yu Title: Certification Engineer Company: DDPAI Technology Co., Ltd. Date: 7/27/2026

DDPAI Technology Co., Ltd. * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 7/27/2026 TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTN.: Reviewing Engineer FCC ID: 2AJFX-DZ2502 FRN of applicant: 0025803503 Per section 2.911(d)(7) of the FCC rules, [DDPAI Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is designated to the following U.S. agent* for service of process: Company Name: Herland International Trading Inc FCC Registration Number (FRN): 0036324101 Physical U.S. Company Address: 1370 Valley Vista Dr Ste 200 Diamond Bar, CA 91765 Contact Person: Jianfeng Gao Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed: Printed name: Sean Yu Title: Certification Engineer Company Name: DDPAI Technology Co., Ltd. Date: 7/27/2026 Agent Signed (if different from Applicant): Signed: Printed name: Jianfeng Gao Title: Manager Company Name: Herland International Trading Inc Date: 7/27/2026

DDPAI Technology Co., Ltd. 2026-07-25 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen DL Testing Technology Co., Ltd.（101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China）to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with DDPAI Technology Co., Ltd.（28F, Building 8A, International Innovation Valley, Nanshan District, Shenzhen, Guangdong Province） <Signature>: Name: Sean Yu Title: Certification Engineer Company: DDPAI Technology Co., Ltd.

DDPAI Technology Co., Ltd. 2026-07-25 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature>: Name: Sean Yu Title: Certification Engineer Company: DDPAI Technology Co., Ltd.

DDPAI Technology Co., Ltd. 2026-07-25 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AJFX-DZ2502 Product Name: Dash Cam Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...)  Schematics  Block diagram  Operation description  SOFTWARE SECURITY DESCRIPTION  BOM These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>: Name: Sean Yu Title: Certification Engineer Company: DDPAI Technology Co., Ltd.

DDPAI Technology Co., Ltd. FCC ID: 2AJFX-DZ2502 Product Similarity Declaration Applicant: DDPAI Technology Co., Ltd. Address: 28F, Building 8A, International Innovation Valley, Nanshan District, Shenzhen, Guangdong Province Manufacturer: DDPAI Technology Co., Ltd. Address: 28F, Building 8A, International Innovation Valley, Nanshan District, Shenzhen, Guangdong Province Product Name: Dash Cam Trade Mark: DDPAI Model Number: DZ2502A, DZ2502A-01, DZ2502A-02, DZ2502A-03, DZ2502A-04, DZ2502A-05, DZ2502A-06, DZ2502A-07, DZ2502B, DZ2502B-01, DZ2502B-02, DZ2502B-03, DZ2502B-04, DZ2502B-05, DZ2502C, DZ2502C-01, DZ2502C-02, DZ2502C-03, DZ2502C-04, DZ2502C-05 We (DDPAI Technology Co., Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), All models are the same as the samples except for the model name, appearance color. <Signature>: Name: Sean Yu Title: Certification Engineer Company: DDPAI Technology Co., Ltd.

1/1 DDPAI Technology Co., Ltd. FCC Software Configuration Control Declaration Date: 2026-07-25 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Attn: OET Dept. Company Name: DDPAI Technology Co., Ltd. FCC ID: 2AJFX-DZ2502 Product Name: Dash Cam Regarding FCC Country Code Selection guidelines identified in KDB 594280 D01 v02r01. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. <Signature>: Name: Sean Yu Title: Certification Engineer Company: DDPAI Technology Co., Ltd.

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(External Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

Size: 20*15mm Model.: DZ2502A FCC ID: 2AJFX-DZ2502 Label location

Shenzhen DL Testing Technology Co., Ltd. EUT PHOTO(Internal Photos) Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. ANT Shenzhen DL Testing Technology Co., Ltd. ※※※※※ END OF REPORT ※※※※※

FCC ID: 2AJFX-DZ2502 RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in KDB 447498 D01 V06 and 1.1307(b) and 2.1091 Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. EIRP=E Meas +20log(d Meas )-104.7 EIRP is the equivalent isotropically radiated power, in dBm E Meas is the field strength of the emission at the measurement distance, in dBμV/m d Meas is the measurement distance, in m Test Result of RF Exposure Evaluation For BT Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result -0.13 0.97 0.0001 1.0 PASS Remark: antenna gain=-2.73dBi For WiFi 5G Output power to antenna (dBm) Output power to antenna (mW) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 12.14 16.37 0.0053 1.0 PASS Remark: antenna gain=2.15dBi For Simultaneous transmitting, 1): The sum of the ratios of the spatially averaged results to the applicable frequency dependent MPE limits =0.0001/1 + 0.0053/1 = 0.0054< 1 Since the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in the device is ≤ 1.0, the EUT is considered to satisfy MPE compliance for simultaneous transmission operations.

PartsAcknowledgment NameofPart：antenna Specificationof Parts： Accessory,Antenna,DR2008,DualbandWIFI antenna2.4G&5G&BT,built-in,21.93* 21.3mm,linelength85mm,third-generation IPEX,,FPC;SF2489A-1L23B-085-A,built-in Stareatthe materialnumbe： 10883000165 Modelof application： DR2008-2.9-inchscreenrecorder NameofSupplier： ShenzhenSuoWardCommunication TechnologyCo.,Ltd. TypeofSupplier：Manufacturer、Agent、Trader; Manufacturer's materialnumber： SF2489A-1L23B-085-A Recognition number： CRS0004344 Keepaneyeonthe dateofissue： DDPaiTechnologyCO.,LTD.Tel:86-755-26401213 Address:Guangdong,China.12thFloor,YihuaFintechBuilding,SoftwareIndustryBase,NanshanDistrict,Shenzhen; Website:www.ddpai.com DDPaivisionequipmentCo.,LTD Address:Building6,No.139,XinhuangRoad,XindaiTown,PinghuCity,Jiaxing,Zhejiang SupplierAddress:6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135,QianjinSecondRoad,Bao'an District,Shenzhen Contactinformationofsupplier:ChenHeng/13717086260 Supplierapprovalcolumn Todevelop：LTTaudit：Approvedbythe： *Thefollowingisthecheckcolumnofthetagtag Materialtosendsamplecheckcolumn Materialconfirmationandapproval column ProcurementEngineerPurchasingSupervisor Researchand DevelopmentEngineer Researchand DevelopmentSupervisor SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135Qianjin2ndRoad,Bao'an District,Shenzhen Phone:0755-29985185Fax:0755-27487028 Two Serial number CertificationnumberMaterialtypeDateofissueRemarks 1SHAEC24025471005 Tinnedcopper wire 2024-11-25 Oneyear 2SHAEC24027284565 halogen 2024-12-06 Oneyear 3SHAEC24027480902 Adhesive 2024-12-06 Oneyear 4SHAEC24029171725 FEPsheath 2024-12-26 Oneyear 5SHAEC24027284563 FEPinsulation 2024-12-05 Oneyear 6SZXEC24002306404 Tinwire 2024-07-24 Oneyear 7SZXEC24002306408 Tin 2024-07-24 Oneyear 8ETR24600712 Printingink 2024-06-14 Oneyear 9A2240123200102001E Substrate 2024-03-20 Oneyear 10CANEC24028865417 EVAfoam 2025-01-03 Oneyear 11A2240439752101001 Conductive cloth 2024-07-29 Oneyear 12SZXEC24002471802 Goldplating 2024-08-08 Oneyear SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135Qianjin2ndRoad,Bao'an District,Shenzhen Phone:0755-29985185Fax:0755-27487028 Three contents 一:Devicesupport&testableantennatype ............................ 1 二:Overview ..................................................................................... 2 三:Matchcircuitdiagram&machineimage&antennaimage . 3 四:AntennaStandingWaveRatio&AntennaEfficiency(VSWR) ........................................................................................................... 4 五:Activedata ............................................................................... 5 六:3Dpattern ................................................................................. 6 七:structuraldrawings .............................................................. 7 SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135Qianjin2ndRoad,Bao'an District,Shenzhen Phone:0755-29985185Fax:0755-27487028 Four 一:Devicesupport&testableantennatype SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135Qianjin2ndRoad,Bao'an District,Shenzhen Phone:0755-29985185Fax:0755-27487028 Five 二:Overview (1)Antennaperformance 1.ThisapprovalsheetsupportsforMIDproject.FPCantennasincludeinthisproject.Thisreport isfortheperformanceofWIFI&BTantenna. 2.Antennashapesize：MeettherequirementofMID 3.Antennaband：2.4GHz~5GHz 4.Antennamaterial：AntennamaterialmeettherequirementofMID 5.Adhesiveperformance：AdhesiveperformancemeettherequirementofMID 6.Antennaperformancemeetthespecbelow： Description2.4GHz~5GHzUnits VSWR≤2.0 AverageAntennaGain≥-4.5dB FeedImpedance50ohms OperatingTemperature-40to+85degC Polarization/AzimuthLinear/Omni-directional (2)MechanicalInformation MechanicalDimension CableLength085mm/BLACK DescriptionWIFI&BTantenna MaterialFPC CoaxialCable50Ω/O.D.0.81mm Environmental OperationTemperature-40to+85degC StorageTemperature-40to+85degC SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6th Floor,BuildingB, HexiHangchengIndustrialZone,No. 135 Qianjin2nd Road,Bao'an District,Shenzhen Phone:0755-29985185Fax:0755-27487028 Six 三:Matchcircuitdiagram&machineimage&antennaimage (1)matchingcircuit (2) Machineimages&antennaimages NA RF NA NA NA NA NA SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6th Floor,BuildingB, HexiHangchengIndustrialZone,No. 135 Qianjin2nd Road,Bao'an District,Shenzhen Phone:0755-29985185Fax:0755-27487028 Seven 四 : Antenna St an dingWaveRatio&A ntennaEfficiency (VSWR) SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135Qianjin2ndRoad,Bao'an District,Shenzhen Phone:0755-29985185Fax:0755-27487028 Eight SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135Qianjin2ndRoad,Bao'an District,Shenzhen Phone:0755-29985185Fax:0755-27487028 Nine 五:Activedata SWARDShenzhenSuoWardCommunicationTechnologyCo.,Ltd. 6thFloor,BuildingB,HexiHangchengIndustrialZone,No.135Qianjin2ndRoad,Bao'an District,Shenzhen Phone:0755-29985185Fax:0755-27487028 Ten 六:3Dpattern 七:structuraldrawings

Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260127052R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 1 of 31 FCC Part 15C Test Report FCC ID: 2AJFX-DZ2502 Applicant: DDPAI Technology Co., Ltd. Address: 28F, Building 8A, International Innovation Valley, Nanshan District, Shenzhen, Guangdong Province Manufacturer: DDPAI Technology Co., Ltd. Address: 28F, Building 8A, International Innovation Valley, Nanshan District, Shenzhen, Guangdong Province Product Name: Dash Cam Trade Mark: DDPAI Model Number: DZ2502A, DZ2502A-01, DZ2502A-02, DZ2502A-03, DZ2502A-04, DZ2502A-05, DZ2502A-06, DZ2502A-07, DZ2502B, DZ2502B-01, DZ2502B-02, DZ2502B-03, DZ2502B-04, DZ2502B-05, DZ2502C, DZ2502C-01, DZ2502C-02, DZ2502C-03, DZ2502C-04, DZ2502C-05 Date of Receipt: May. 04, 2026 Test Date: May. 04, 2026 – May. 21, 2026 Date of Report: May. 21, 2026 Prepared By: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China Applicable Standards: FCC PART 15 C 15.247 ANSI C63.10:2020 Test Result: Pass Report Number: DLE-260127052R Prepared (Test Engineer): Alisa Song Reviewer (Supervisor): Jack Bu Approved (Manager): Jade Yang This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Shenzhen DL Testing Technology Co., Ltd. Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260127052R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 2 of 31 Table of Contents Page 1. . SUMMARY OF TEST RESULTS 4 1.1. MEASUREMENT UNCERTAINTY 4 2. . GENERAL INFORMATION 5 2.1. GENERAL DESCRIPTION OF EUT 5 2.2. DESCRIPTION OF TEST MODES 6 2.3. BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 6 2.4. DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 7 2.5. TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 7 2.6. EQUIPMENTS LIST FOR ALL TEST ITEMS 8 3. . EMC EMISSION TEST 9 3.1. CONDUCTED EMISSION MEASUREMENT 9 3.1.1. POWER LINE CONDUCTED EMISSION LIMITS 9 3.1.2. TEST PROCEDURE 9 3.1.3. DEVIATION FROM TEST STANDARD 9 3.1.4. TEST SETUP 10 3.1.5. EUT OPERATING CONDITIONS 10 3.1.6. TEST RESULTS 10 3.2. RADIATED EMISSION MEASUREMENT 11 3.2.1. RADIATED EMISSION LIMITS 11 3.2.2. TEST PROCEDURE 12 3.2.3. DEVIATION FROM TEST STANDARD 12 3.2.4. TEST SETUP 12 3.2.5. EUT OPERATING CONDITIONS 13 3.2.6. TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 14 3.2.7. TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 15 3.2.8. TEST RESULTS (1GHZ~25GHZ) 17 3.3 RADIATED BAND EMISSION MEASUREMENT 18 3.3.1 TEST REQUIREMENT: 18 3.3.2 TEST PROCEDURE 18 3.3.3 DEVIATION FROM TEST STANDARD 18 3.3.4 TEST SETUP 19 3.3.5 EUT OPERATING CONDITIONS 19 3.4 CONDUCTED BAND EDGE EMISSION&CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 21 3.4.1 APPLICABLE STANDARD 21 3.4.2 TEST PROCEDURE 21 3.4.3 DEVIATION FROM STANDARD 21 3.4.4 TEST SETUP 21 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260127052R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 3 of 31 Table of Contents Page 3.4.5 EUT OPERATION CONDITIONS 21 3.4.6 TEST RESULTS 21 4. . PEAK OUTPUT POWER 24 4.1. APPLIED PROCEDURES / LIMIT 24 4.1.1. TEST PROCEDURE 24 4.1.2. DEVIATION FROM STANDARD 24 4.1.3. TEST SETUP 24 4.1.4. EUT OPERATION CONDITIONS 24 4.1.5. TEST RESULTS 25 5. . POWER SPECTRAL DENSITY TEST 27 5.1. APPLIED PROCEDURES / LIMIT 27 5.1.1. TEST PROCEDURE 27 5.1.2. DEVIATION FROM STANDARD 27 5.1.3. TEST SETUP 27 5.1.4. EUT OPERATION CONDITIONS 27 5.1.5. TEST RESULTS 27 6. . 6DB BANDWIDTH TEST 29 6.1. APPLIED PROCEDURES / LIMIT 29 6.1.1. TEST PROCEDURE 29 6.1.2. DEVIATION FROM STANDARD 29 6.1.3. TEST SETUP 29 6.1.4. EUT OPERATION CONDITIONS 29 6.1.5. TEST RESULTS 29 7. . ANTENNA REQUIREMENT 31 7.1. STANDARD REQUIREMENT 31 7.2. EUT ANTENNA 31 8. . TEST SEUUP PHOTO 31 9. . EUT PHOTO 31 Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260127052R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 4 of 31 1.. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 15.205, 15.209, 15.247(d) Radiated Spurious Emission PASS 15.209, 15.205 Band Edge Emission PASS 15.247(b) Peak Output Power PASS 15.247(a)(2) 6dB Bandwidth PASS 15.247(e) Power Spectral Density PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Test lab: Shenzhen DL Testing Technology Co., Ltd. Address: 101-201, Comprehensive Building, Tongzhou Electronics Longgang Factory Area, No.1 Baolong Fifth Road, Baolong Community, Baolong Street, Longgang District, Shenzhen, China FCC Test Firm Registration Number: 854456 Designation Number: CN1307 IC Registered No.: 27485 CAB ID.: CN0118 1.1. MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±2.56dB 2 RF power,conducted ±0.42dB 3 Spurious emissions,conducted ±2.76dB 4 All emissions,radiated(<1G) ±3.65dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% 8 6dB Bandwidth ±0.2MHz 9 Power Spectral Density ±0.3dBm Shenzhen DL Testing Technology Co., Ltd. Report No.: DLE-260127052R Test Report Tel: 400-688-3552 Web:www.dl-cert.com Email: [email protected] Page 5 of 31 2.. GENERAL INFORMATION 2.1. GENERAL DESCRIPTION OF EUT Product Name: Dash Cam Trade Mark: DDPAI Model Number: DZ2502A, DZ2502A-01, DZ2502A-02, DZ2502A-03, DZ2502A-04, DZ2502A-05, DZ2502A-06, DZ2502A-07, DZ2502B, DZ2502B-01, DZ2502B-02, DZ2502B-03, DZ2502B-04, DZ2502B-05, DZ2502C, DZ2502C-01, DZ2502C-02, DZ2502C-03, DZ2502C-04, DZ2502C-05 Tes…

Text truncated - open the document above for the full version.

Shenzhen DL Testing Technology Co., Ltd. EUT TEST PHOTO Radiated Measurement Photos ※※※※※ END OF REPORT ※※※※※
